SIMATIC RTLS
Localization systems
SIMATIC RTLS4460T
Device manual

SIMATIC RTLS4460T
2Device manual, 06/2019, C79000-G8976-C522-02
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 3
Table of contents
English
1 Overview ................................................................................................................................................... 4
1.1 General........................................................................................................................................................ 4
1.2 Delivery contents ......................................................................................................................................... 4
1.3 Power supply ............................................................................................................................................... 4
2 Layout and connections ............................................................................................................................. 5
2.1 Dimensions.................................................................................................................................................. 5
2.2 Connections and displays ........................................................................................................................... 6
2.2.1 Possible states of the LEDs........................................................................................................................ 6
2.3 Pin allocation ............................................................................................................................................... 7
2.3.1 P1 - Power, Digital output - plug-in connector ............................................................................................ 7
2.3.2 Digital output ............................................................................................................................................... 8
2.3.3 Digital Input ................................................................................................................................................. 8
2.3.4 P3 - Antenna – RP-SMA connector ............................................................................................................ 8
3 Installation, initial start-up, safety ............................................................................................................... 9
3.1 General information ..................................................................................................................................... 9
3.2 Installation and operation ............................................................................................................................ 9
3.3 Connecting the cables................................................................................................................................. 9
3.3.1 Power supply .............................................................................................................................................. 9
3.4 Connecting the antenna .............................................................................................................................. 9
4 Technical data ......................................................................................................................................... 10
4.1 Connectors and power supply................................................................................................................... 10
4.2 In- and outputs........................................................................................................................................... 10
4.3 Radio ......................................................................................................................................................... 10
4.4 Environment .............................................................................................................................................. 11
5 Approvals ................................................................................................................................................ 12
5.1 EU declaration of conformity ..................................................................................................................... 12
5.2 RoHS ......................................................................................................................................................... 12
5.3 RED ........................................................................................................................................................... 13
5.3.1 Protection of health and safety ................................................................................................................. 13
5.4 Recycling and disposal.............................................................................................................................. 14

SIMATIC RTLS4460T
4Device manual, 06/2019, C79000-G8976-C522-02
1Overview
1.1 General
The transponder SIMATIC RTLS4460T represents the movable device considered for
localization within the SIMATIC Locating Manager localization network. It sends its positional
information to the localization network’s nodes (anchors and gateways) which transmit the data
to the localization server for computation and visualization. The device is suitable for installation
into vehicles and devices
1.2 Delivery contents
1 SIMATIC RTLS4460T (article number 6GT2700-6CE02)
Accessories (not included in scope of delivery)
•Connector with 16 crimp contacts (article number 6GT2790-0BB00)
•Antenna cable, 2 m (article number 6GT2791-6AH20)
•Antenna cable, 3 m (article number 6GT2791-6AH30)
1.3 Power supply
The device can be operated with 24 V voltage.

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 5
2Layout and connections
2.1 Dimensions

SIMATIC RTLS4460T
6Device manual, 06/2019, C79000-G8976-C522-02
2.2 Connections and displays
Connection
Description
P1 - Power, Digital Power supply and digital input signals
P3 - Antenna RP-SMA - Antenna screw connector
Fuse Mini blade fuse, 2 A
Display
Description
D1 - Radio LED (yellow) LED signaling the activity of the Locating Manager (sending
and receiving radio signals)
D2 - Run LED (green) LED signaling the device’s operating status
D3 - Bus LED (yellow) LED signaling activity of the bus system (CAN-bus or IBIS)
2.2.1 Possible states of the LEDs
D1 - Radio LED
D2 - Run LED
D3 - Bus LED
Description
Off Device is inactive
Flashes once
for 0.5 second
flashes once for
0.5 second
flashes once for
0.5 second
Device start up test
Carry out a start-up test in order to
test proper functionality of the LEDs
and the device. To this end, observe
all three LEDs whilst switching on the
device’s power supply. All three
LEDs flashing simultaneously once
for half a second indicates the just
operating status of both device and
LEDs.
any flashes every 3
seconds
any Device operating in “SLOW” state
any flashes
permanently
any Device operating in “FAST” state

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 7
2.3 Pin allocation
2.3.1 P1 - Power, Digital output - plug-in connector
16-pin plug-in connector WR-MPC4
0.33 mm² by 1.31 mm²
Pin
Description
Pin
Description
1 n.c. 9 n.c.
2 Digital input 7 10 Digital input 8*
3 Digital input 5 11 Digital input 6
4 Digital input 3 12 Digital input 4
5 Digital input 1 13 Digital input 2
6 CAN-high 14 CAN-low
7 Digital output 1 15 Digital output 2
8 24 V DC (e.g. Terminal 30) 16 GND (e.g. Terminal 31)
* switchable input impedance
16 9
18

SIMATIC RTLS4460T
8Device manual, 06/2019, C79000-G8976-C522-02
2.3.2 Digital output
Both of the device digital outputs can drive ohmic, capacitive and inductive loads. The current
will be limited automatically at this.
In case of inductive loads (e.g. relays) consider the following: Inductivities up to 32 H can be
turned off without flyback diode DV. Higher inductivities require the insertion a flyback diode DV.
When using flyback diode DV, an additional polarity protection diode DPhas to be inserted.
2.3.3 Digital Input
The device has 8 digital inputs, 1 to 8. Each ranges from 0 to 24 V with an impedance of
4.7 kOhm.
Input 8 differs in order that the impedance resistor can be switched off. In that case the input
impedance is 110 kOhm.
2.3.4 P3 - Antenna – RP-SMA connector
Pin
Description
1 Antenna
Shield GND, Shield
High-side
Sw i t ch
8
High-side
Sw i t ch
+ 24 V
GND GND
7
15
16
WI RELESS
TAG DRI VE
In
Inductive
Load < 32 H
D
V
…..
High-side
Sw i t ch
8
High-side
Sw i t ch
+ 24 V
GND GND
7
15
16
WI RELESS
TAG DRI VE
In
Inductive
Load
DV
DP
…..

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 9
3Installation, initial start-up, safety
3.1 General information
•The devices can only be used in combination with the Locating Manager.
•Buildup, installation as well as the use of the tools and clients of the localization system are
described in the corresponding guides and manuals.
3.2 Installation and operation
•Carefully read all items listed in section 3 (Installation, initial start-up, safety) before installing
the devices in order to safeguard correct installation and operation.
•The device is destined for installation into a vehicle.
•The installation has to be carried out by appropriately qualified and trained personnel and
according to the installation guide.
•Follow the references concerning the surrounding conditions when installing and operating the
devices.
•The device has to be protected against moisture.
•The ambient temperature must not exceed 70 °C. Avoid installing devices at locations exposed
to direct sunlight.
•The installation of the devices has to be carried out according to the applicable provisions for
the installation of electrical systems and utilities.
3.3 Connecting the cables
Make sure that any wiring has been carried out correctly before the start-up of the device.
3.3.1 Power supply
•When connecting the power supply to the power connector, all LEDs flash for an instant. The
power LED is on, if power is supplied (cf. states of the LEDs 2.2.1).
•Check whether the nominal voltage of the power supply is in accordance with the values stated
in section “Technical data” (cf. 4).
3.4 Connecting the antenna
•The antenna has to be connected to the RP-SMA screw connector (P2).
•The device must not be operated without antenna. The device has to be switched off or voltage-
free before replacing the antenna.
•The antennas of all wireless devices should be aligned similarly.

SIMATIC RTLS4460T
10 Device manual, 06/2019, C79000-G8976-C522-02
4Technical data
4.1 Connectors and power supply
Connectors and power supply
Voltage 24 V DC
Power consumption Max. 1.6 W /0.06 A
Power connector (P1) 16-pin plug-in connector WR-MPC4, 0.33 mm² by 1.31mm²
Antenna connector RP-SMA connector
Fuse Mini blade fuse, 2 A
4.2 In- and outputs
In- and outputs
Input voltage 0 … 24 V DC
Input impedance 4.7 kOhm, Input 8 selectable 4.7 kOhm or 110 kOhm
Output High-side-switch -> Connect to input voltage
Output current Max. 250 mA, short-circuit proof
Output voltage 0 V or supply voltage
Load Any; inductive loads up to 32 H do not require a flyback
diode. Use of a polarity protection diode is imperative when
using a flyback diode.
4.3 Radio
Radio
Wireless technology IEEE 802.15.4a nanoLOC - Chirp Spread Spectrum (CSS)
Data rates 1 MBit/s
Operating frequency 2.45 GHz ISM-Band
Chirp bandwidth 80 MHz
Output power Max. 100 mW, adjustable
Range at 1 Mbit Indoor: max. 90m
Outdoor: max. 1000 m (typically 500 m)

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 11
4.4 Environment
Environment and dimensions
Case Plastic housing
IP-protection IP 20
Dimension 138 x 62 x 31 mm
Weight 125 g
Mounting 4 mounting holes for M4 countersunk head screw
Temperature range -40 … + 70 °C

SIMATIC RTLS4460T
12 Device manual, 06/2019, C79000-G8976-C522-02
5Approvals
5.1 EU declaration of conformity
You can find the current EU declaration of conformity for these products on the Internet pages
under Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/14970/cert)
The products described in this document meet the requirements of the following EC directives:
•RoHS directive 2011/65/EU
Directive of the European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical and electronic
equipment, official journal of the EU L174, 01/07/2011, pages 88-110
•Radio equipment directive 2014/53/EU (RED, Radio Equipment Directive)
Directive of the European Parliament and of the Council of 16 April 2014 on the
harmonization of the laws of the Member States relating to the making available on the
market of radio equipment; official journal of the EU L153, 22/05/2014, pages 62-106
5.2 RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The products described in these operating instructions meet the requirements of the EU
directive 2011/65/EU for the restriction of the use of certain hazardous substances in electrical
and electronic equipment.
Applied standard:
•EN 50581
Technical documentation for the assessment of electrical and electronic products with
respect to the restriction of hazardous substances

SIMATIC RTLS4460T
Device manual, 06/2019, C79000-G8976-C522-02 13
5.3 RED
5.3.1 Protection of health and safety
The products described in this document meet the requirements of the applied standards:
Article 3 (1) a) protection of health and safety
•EN 62368-1
Information technology equipment - Safety - Part 1: General requirements
•EN 62311
Assessment of electronic and electrical equipment related to human exposure restrictions for
electromagnetic fields (0 Hz – 300 GHz)
The products described in these operating instructions meet the requirements of EU directive
2014/30/EU "Electromagnetic Compatibility" according to the designated standards for the
following areas of application.
Art. 3 (1) b) EMC:
•ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1: Common technical requirements
•ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17:
Specific conditions for Broadband Data Transmission Systems
•EN 55011
Industrial, scientific and medical equipment - Radio-frequency disturbance characteristics -
Limits and methods of measurement
•EN 55032 Class A, Class B
Electromagnetic compatibility of multimedia equipment - Emission requirements
•EN 55035
Electromagnetic compatibility of multimedia equipment - Immunity requirements
•EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity standard for
residential, commercial and light-industrial environments
•EN 61000-6-2
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity standard for
industrial environments
•EN 61000-6-3
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission standard for
residential, commercial and light-industrial environments

SIMATIC RTLS4460T
14 Device manual, 06/2019, C79000-G8976-C522-02
•EN 61000-6-4
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard for
industrial environments
Art. 3 (2) Efficient use of the radio spectrum
•ETSI EN 300 328
Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM
band and using wide band modulation techniques; Harmonised Standard covering the
essential requirements of article 3.2 of Directive 2014/53/EU
Note
The specified approvals apply only when the corresponding mark is printed on the
device.
5.4 Recycling and disposal
The products are low in harmful substances, can be recycled and meet the requirements of the
Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
Do not dispose of the products at public disposal sites.
For environmentally compliant recycling and disposal of your electronic waste, please contact a
company certified for the disposal of electronic waste or your Siemens representative.
Note the different national regulations.
