Siemens PROFIBUS Technical Document

PROFIBUS bus connect
or
Equipment Manual
02/2021
A5E50543113
-AA
Introduction
1
Safety instructions
2
Device description
3
Technical specifications
4
Safety-related symbols
A

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E50543113-AA
Ⓟ
03/2021 Subject to change
Copyright © Siemens AG 2021.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 3
Table of contents
1 Introduction ........................................................................................................................................... 4
1.1 Preface ................................................................................................................................ 4
1.2 Siemens Industry Online Support ......................................................................................... 5
1.3 Industry Mall........................................................................................................................ 5
2 Safety instructions................................................................................................................................. 6
3 Device description ................................................................................................................................. 7
3.1 6ES7972-0Bx12-0XA0.......................................................................................................... 7
3.2 6ES7972-0BA30-0XA0 ....................................................................................................... 12
3.3 6ES7972-0Bx42-0XA0........................................................................................................ 14
3.4 6ES7972-0Bx52-0XA0........................................................................................................ 18
3.5 6ES7972-0Bx61-0XA0........................................................................................................ 22
3.6 6ES7972-0Bx70-0XA0........................................................................................................ 26
4 Technical specifications....................................................................................................................... 31
4.1 Introduction ...................................................................................................................... 31
4.2 Standards, approvals and safety notes................................................................................ 31
4.3 Module-specific data.......................................................................................................... 38
A Safety-related symbols ........................................................................................................................ 46
A.1 Safety-related symbols for devices without Ex protection.................................................... 46
A.2 Safety-related symbols for devices with Ex protection......................................................... 47
Index .................................................................................................................................................... 49

PROFIBUS bus connector
4Equipment Manual, 02/2021, A5E50543113-AA
Introduction
1
1.1 Preface
Purpose of the documentation
This equipment manual contains a compact description of the module-specific information
on the following devices:
Device
Article number
PROFIBUS bus connector plug with/without PG socket up to 12 Mbaud
6ES7972-0BA12-0XA0
6ES7972-0BB12-0XA0
PROFIBUS bus connector plug up to 1.5 MBaud
6ES7972-0BA30-0XA0
PROFIBUS bus connector plug with/without PG socket up to 12 Mbaud
6ES7972-0BA42-0XA0
6ES7972-0BB42-0XA0
PROFIBUS FastConnect bus connector with/without PG socket up to 12
Mbaud
6ES7972-0BA52-0XA0
6ES7972-0BB52-0XA0
PROFIBUS FastConnect bus connector with/without PG socket up to 12
Mbaud
6ES7972-0BA61-0XA0
6ES7972-0BB61-0XA0
PROFIBUS FastConnect bus connector with/without PG socket up to 12
Mbaud
6ES7972-0BA70-0XA0
6ES7972-0BB70-0XA0
The system-related functions are described in the respective system manuals. All system-
spanning functions are described in the function manuals.

Introduction
1.2 Siemens Industry Online Support
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 5
1.2 Siemens Industry Online Support
You can find current information on the following topics quickly and easily here:
•Product support
All the information and extensive know-how on your product, technical specifications,
FAQs, certificates, downloads, and manuals.
•Application examples
Tools and examples to solve your automation tasks – as well as function blocks,
performance information and videos.
•Services
Information about Industry Services, Field Services, Technical Support, spare parts and
training offers.
•Forums
For answers and solutions concerning automation technology.
•mySupport
Your personal working area in Industry Online Support for messages, support queries, and
configurable documents.
This information is provided by the Siemens Industry Online Support in the Internet
(http://www.siemens.com/automation/service&support).
1.3 Industry Mall
The Industry Mall is the catalog and order system of Siemens AG for automation and drive
solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power
(TIP).
You can find catalogs for all automation and drive products on the Internet
(https://mall.industry.siemens.com).

PROFIBUS bus connector
6Equipment Manual, 02/2021, A5E50543113-AA
Safety instructions
2
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. firewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens' products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers' exposure to
cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed visit (https://www.siemens.com/industrialsecurity).

PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 7
Device description
3
3.1 6ES7972-0Bx12-0XA0
The following provides you with product information about the PROFIBUS bus connector
with/without PG socket up to 12 MBaud 6ES7972-0Bx12-0XA0:
You can use the PROFIBUS bus connector to
•Connect stations with an electrical 9-pin D-sub interface according to IEC 61158-2 directly
to the SIMATIC NET PROFIBUS lines.
•Electrical segments or individual stations can be connected to the Optical Link Module
(OLM, OBT).
•Stations or programming devices are connected to the repeater.
More information
You can find more information about the PROFIBUS bus connector in the SIMATIC NET
PROFIBUS manual. The manual can be obtained at the nearest offices of your Siemens
representative or free of charge on the Internet at the following link
(http://support.automation.siemens.com/WW/view/en/35222591).
Maintenance
The PROFIBUS bus connector requires no maintenance. In the event of a fault, contact your
Siemens representative responsible for spare parts/repairs:
Services (https://support.industry.siemens.com/cs/ww/en/sc/2154)

Device description
3.1 6ES7972-0Bx12-0XA0
PROFIBUS bus connector
8Equipment Manual, 02/2021, A5E50543113-AA
Bus cable assembly
No.
Description
1
Cable shield
2
Bus cable (e.g. 6XV1 830-0EH10) - strip insulation, e.g. with stripping tool 6GK1905-6AA00
3 Screw terminal block on connector board for bus cable connection.
- Insert green and red wire into screw terminal block (A1, B1 or A2, B2)
(Recommendation: A = green, B = red)
4
Press cable between the two terminal blocks. Cable shield must be stripped on contact element.
5
Screw the green and red wires tightly into the screw terminal.
6
Close the enclosure cover and screw it tight.
7
PG socket (only for 6ES7972-0BB12-0XA0)
Note
If the switch is set to ON, the PROFIBUS to the other stations is disconnected at this point
(e.g. for service purposes).
Bus connection for the first and last station on the PROFIBUS
Cable must always be connected on the left (see marking A1, B1), switch position must be
"ON" for the first and last station on the PROFIBUS. (terminating resistor switched on).

Device description
3.1 6ES7972-0Bx12-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 9
Bus connection for all other stations on the PROFIBUS
Cable feed must always be connected on the left (see marking A1, B1). Cable continuation
must always be connected on the right (see label A2, B2). Switch position must be "OFF" for
all other stations on the PROFIBUS. (terminating resistor switched off).

Device description
3.1 6ES7972-0Bx12-0XA0
PROFIBUS bus connector
10 Equipment Manual, 02/2021, A5E50543113-AA
Connection

Device description
3.1 6ES7972-0Bx12-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 11
Approvals
You can find information on the approvals under Standards, approvals and safety notes
(Page 31).
Module-specific data
You can find information under Module-specific data (Page 38).

Device description
3.2 6ES7972-0BA30-0XA0
PROFIBUS bus connector
12 Equipment Manual, 02/2021, A5E50543113-AA
3.2 6ES7972-0BA30-0XA0
The following provides you with product information about the PROFIBUS bus connector
6ES7 972-0BA30-0XA0:
No.
Description
1
Cable shield
2
Bus cable, 6XV1 830-0AH10
Bus connection for the stations on the PROFIBUS where no terminating resistor is connected.
No.
Description
1
9-pin D-sub connector for connection at the station (pin 3 and 8 allocated)
2
Housing screws
3
Screws for fastening to the station
4
Insulation displacement terminals for bus cable connection
5
Strain relief
6
Guides

Device description
3.2 6ES7972-0BA30-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 13
Mounting the bus cable
1. Strip the insulation from the bus cable as shown in Fig. 1.
2. Open the casing of the bus connector by undoing the screws ➁
and removing the cover.
3. Press the bus cable into the strain relief ➄
(cable shield must be bare on the metal guide).
4. Place the wires in the guides ➅over the insulation displacement terminals ➃.
Ensure that the same wires are always connected to the same connection A or B
(always wire connection A with green wire and connection B
with red wire).
5. Press the red and green wires lightly into the insulation displacement terminals with your
thumb.
6. Screw the cover back on tightly.
Note
Connection of the bus l
ines
The bus lines are connected using an insulation displacement system (Fast Connect). The
insulation displacement terminals are designed for 3 connection cycles. If you want to
reconnect a line that has already been connected, you must first cut it off.
Approvals
You can find information on the approvals under Standards, approvals and safety notes
(Page 31).
Module-specific data
You can find information under Module-specific data (Page 38).

Device description
3.3 6ES7972-0Bx42-0XA0
PROFIBUS bus connector
14 Equipment Manual, 02/2021, A5E50543113-AA
3.3 6ES7972-0Bx42-0XA0
The following provides you with product information about the PROFIBUS bus connector
with/without PG socket up to 12 MBaud 6ES7972-0Bx42-0XA0:
You can use the PROFIBUS bus connector to
•Connect stations with an electrical 9-pin D-sub interface according to IEC 61158-2 directly
to the SIMATIC NET PROFIBUS lines.
•Electrical segments or individual stations can be connected to the Optical Link Module
(OLM, OBT).
•Stations or programming devices are connected to the repeater.
More information
You can find more information about the PROFIBUS bus connector in the SIMATIC NET
PROFIBUS manual. The manual can be obtained at the nearest offices of your Siemens
representative or free of charge on the Internet at the following link
(http://support.automation.siemens.com/WW/view/en/35222591).
Maintenance
The PROFIBUS bus connector requires no maintenance. In the event of a fault, contact your
Siemens representative responsible for spare parts/repairs:
Services (https://support.industry.siemens.com/cs/ww/en/sc/2154)

Device description
3.3 6ES7972-0Bx42-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 15
Bus cable assembly
No.
Description
1
Cable shield
2
Bus cable (e.g. 6XV1 830-0EH10) - strip insulation, e.g. with stripping tool 6GK1905-6AA00
3 Screw terminal block on connector board for bus cable connection.
- Insert green and red wire into screw terminal block (A1, B1 or A2, B2; (recommendation: A =
green, B = red)
4
Press cable between the two terminal blocks. Cable shield must be stripped on contact element.
5
Screw the green and red wires tightly into the screw terminal.
6
Close the enclosure cover and screw it tight.
7
PG socket (only for 6ES7972-0BB42-0XA0)
Note
If the switch is set to ON, the PROFIBUS to the other stations is disconnected at this point
(e.g. for service purposes).

Device description
3.3 6ES7972-0Bx42-0XA0
PROFIBUS bus connector
16 Equipment Manual, 02/2021, A5E50543113-AA
Bus connection for the first and last station on the PROFIBUS
Cable must always be connected on the left (see marking A1, B1), switch position must be
"ON" for the first and last station on the PROFIBUS. (terminating resistor switched on).
Bus connection for all other stations on the PROFIBUS
Cable feed must always be connected on the left (see marking A1, B1). Cable continuation
must always be connected on the right (see label A2, B2). Switch position must be "OFF" for
all other stations on the PROFIBUS. (terminating resistor switched off).

Device description
3.3 6ES7972-0Bx42-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 17
Approvals
You can find information on the approvals under Standards, approvals and safety notes
(Page 31).

Device description
3.4 6ES7972-0Bx52-0XA0
PROFIBUS bus connector
18 Equipment Manual, 02/2021, A5E50543113-AA
Module-specific data
You can find information under Module-specific data (Page 38).
3.4 6ES7972-0Bx52-0XA0
The following provides you with product information about the PROFIBUS FastConnect bus
connector with/without PG socket up to 12 MBaud 6ES7972-0Bx52-0XA0:
You can use the PROFIBUS bus connector to
•Connect stations with an electrical 9-pin D-sub interface according to IEC 61158-2 directly
to the SIMATIC NET PROFIBUS lines.
•Electrical segments or individual stations can be connected to the Optical Link Module
(OLM, OBT).
•Stations or programming devices are connected to the repeater.
More information
You can find more information about the PROFIBUS bus connector in the SIMATIC NET
PROFIBUS manual. The manual can be obtained at the nearest offices of your Siemens
representative or free of charge on the Internet at the following link
(http://support.automation.siemens.com/WW/view/en/35222591).
Maintenance
The PROFIBUS bus connector requires no maintenance. In the event of a fault, contact your
Siemens representative responsible for spare parts/repairs:
Services (https://support.industry.siemens.com/cs/ww/en/sc/2154)

Device description
3.4 6ES7972-0Bx52-0XA0
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA 19
Bus cable assembly
No.
Description
1
Cable shield
2 Bus cable (e.g. 6XV1 830-0EH10)
- strip insulation, e.g. with stripping tool 6GK1905-6AA00
3 Contact cover for insulation displacement terminal
- Insert the green and red wires into the open contact cover as far as they will go.
- Close the contact cover completely (press it down as far as it will go).
4
Press cable into recess (cable shield must be bare on contact element)
5
Close the enclosure cover and screw it tight.
6
PG socket (only for 6ES7972-0BB52-0XA0)
Note
Connection of the bus lines
The bus lines are connected using an insulation displacement system (Fast Connect). The
insulation displacement terminals are designed to withstand 10 terminating cycl
es. If you
want to reconnect a line that has already been connected, you must first cut it off.
Note
If the switch is set to ON, the PROFIBUS to the other stations is disconnected at this point
(e.g. for service purposes).

Device description
3.4 6ES7972-0Bx52-0XA0
PROFIBUS bus connector
20 Equipment Manual, 02/2021, A5E50543113-AA
Bus connection for the first and last station on the PROFIBUS
Cable must always be connected on the left (see marking A1, B1), switch position must be
"ON" for the first and last station on the PROFIBUS. (terminating resistor switched on).
Bus connection for all other stations on the PROFIBUS
Cable feed must always be connected on the left (see marking A1, B1). Cable continuation
must always be connected on the right (see label A2, B2). Switch position must be "OFF" for
all other stations on the PROFIBUS. (terminating resistor switched off).
