Siemens S66 User manual

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_IVZ.fm
Table of Contents 1
VAR Language: am; VAR issue date: 041001
See also Index at the end of this User Guide
left page (1) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Legal notices ...............................3
Safety precautions ......................5
Antenna care ............................7
Phone operation .......................7
Electronic devices .....................8
Overview of phone
(schematic) ...............................12
Display symbols ........................14
Getting started .........................16
Insert SIM card/battery ............16
Inserting an
RS MultiMediaCard .................17
Charge battery ........................18
Switch on/off, PIN entry ............20
Entering the PIN .....................20
Emergency number (SOS) .......20
General instructions .................21
Signal strength .......................21
Digital Rights Mgmt. (DRM) .....21
Standby mode ........................21
Main menu .............................21
Standard functions ...................23
Menu speed dialling ...............24
Security .....................................25
Codes .....................................25
Text entry .................................27
My phone ..................................31
Calling .......................................32
Swap between two calls .........34
Set Default Book .......................37
Address Book ............................ 38
New Entry .............................. 38
Change entry ......................... 40
Call entry ............................... 40
Show Groups ......................... 41
SmartChip ................................ 42
New Entry .............................. 42
Call (search for an entry) ........ 43
Change entry ......................... 43
<Other Books> ....................... 44
Recent Calls .............................. 45
Camera ..................................... 46
Video mode ........................... 47
Main Inbox ............................... 49
IM ............................................. 50
Start menu ............................. 50
Sign on .................................. 51
Buddy list ............................... 51
Start chat ............................... 52
Msg. History ........................... 53
Setting ................................... 53
Text Message ........................... 54
Write/send ............................. 54
Read ...................................... 56
Setting ................................... 58
Multimedia Msg ....................... 60
Create .................................... 60
Templates .............................. 62
Send ...................................... 63
Receive .................................. 64
Table of
Contents
See also In-
dex at the end
of this User
Guide

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_IVZ.fm
2 Table of Contents
VAR Language: am; VAR issue date: 041001
See also Index at the end of this User Guide
left page (2) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Read ...................................... 65
Setting ................................... 66
E-Mail ....................................... 68
Write ..................................... 68
Receive/read .......................... 69
Setting ................................... 70
Voice message/mailbox ........... 71
CB Messages ............................ 72
Text Zoom ............................. 72
Games ...................................... 73
MEdia Mall ............................... 75
Media Player ............................ 76
MEdia Net ................................ 77
Internet ................................ 77
Bookmarks ............................. 79
My MEdia ................................. 80
RS MultiMediaCard™ .............. 81
Favorites ................................ 82
Games ................................... 82
Organizer ............................... 83
Extras .................................... 89
Record Audio ......................... 93
Settings .................................... 94
Set Ringtones ......................... 94
Set Wallpaper ......................... 94
Set Screensaver ..................... 94
Set Themes ............................ 96
Audio Settings ....................... 96
Display Settings ..................... 98
Call Settings ........................... 99
Profile Settings ..................... 100
Phone Settings .....................102
Set Date/Time ....................... 103
Connectivity .........................104
Security ................................109
Network Settings ..................111
Accessories ..........................113
Mobile Phone Manager .......... 114
Questions & Answers ............. 117
Customer Care ........................ 120
Care and maintenance ...........122
Product data ........................... 125
Accessories ............................. 126
Quality .................................... 128
U.S. FDA .................................. 129
FCC/Industry Canada Notice ... 135
Ten driving safety tips ............ 136
Intellectual property .............. 138
SAR (S66) ................................ 139
End user license agreement ...141
Menu tree ............................... 146
Index ....................................... 151

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_LegalNotices.fm
3Legal notices
VAR Language: am; VAR issue date: 041001
left page (3) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Legal notices
The mobile phone described in this guide is approved for use on the GSM and
GPRS networks operating on the GSM 850, 1800 (DCS/PCN) and 1900 (PCS)
bands. It is approved for use in the country where it was originally sold and
may be approved for use in other countries.
© 2004 Siemens Information and Communication Mobile, LLC.
All rights reserved.
Siemens and the S66 model phone are
trademarks or registered trademarks of Sie-
mens AG and/or its affiliates in the United
States and/or other countries.
T9® is a registered trademark of America
Online, Inc. in the United States. Java and all
Java-based trademarks and logos are trade-
marks or registered trademarks of Sun
Microsystems, Inc. in the U.S and other
countries. The names of actual companies
and products mentioned herein may be the
trademarks of their respective owners.
Disclaimer
The information contained in the User Guide
is written for the S66 phone. Siemens
reserves the right to make changes and
improvements to the products and any of the
features of the products described in this
document without prior notice. The contents
of the user guide are provided "AS IS".
Except as required by applicable law, no
warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and fit-
ness for a particular purpose, are made in
relation to the accuracy, reliability or con-
tents of this document. Siemens reserves
the right to revise the user guide or withdraw
it at any time without prior notice. Under no
circumstances shall Siemens be responsible
for any loss of data or income or any special,
incidental, consequential or indirect dam-
ages howsoever caused.
Export Information
The mobile phone may be subject to export
regulation of the United States and other
countries. Diversion contrary to law is pro-
hibited. You must comply with all applicable
export laws, restrictions and regulations of
the United States foreign agencies or
authorities, and may not export, or transfer
for the purpose of re-export, the mobile
phone or any part of the phone in violation of
any applicable restrictions, laws or regula-
tions, or without all necessary approvals.
Network Services
A number of features included in this guide
are called Network Services. They are spe-
cial services provided by wireless service
providers. In order to use any of these Net-
work Services, you must subscribe to these
service(s) from your service provider and
obtain instructions for their use. Some of
these Network Services may not be avail-
able when roaming on a network other than
your home network.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_LegalNotices.fm
Legal notices4
VAR Language: am; VAR issue date: 041001
left page (4) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Standby and
Talk Time Information
The mobile phone incorporates features that
are new to the mobile phone world. These
may include color displays and lighting,
graphic games, music reproduction and
browsing the Internet. The way you use the
display and the features will affect the perfor-
mance of the battery and how long it lasts
between charge cycles. The quoted standby
times and talk times show the minimum and
maximum performance that can be expected
from the battery under normal network con-
ditions and with the default settings as set by
the factory. However, playing games (partic-
ularly with the backlight continuously
switched on) and listening to music will
shorten the time available for standby and to
make and receive telephone calls. Operation
times also vary depending on network condi-
tions, SIM settings, charging and battery
condition, how you use your phone and
other factors.
Memory
The mobile phone contains an internal mem-
ory device that stores the software required
to operate the mobile phone, communicate
with the GSM/GPRS network and provide
the user interface. Some features in the
internal memory run additional devices and
some additional games and utilities. The
amount of memory available in the mobile
phone is finite and may be insufficient to
store large numbers of applications and files.
Third party web sites
The phone contains links to the web pages
of third parties. A link to a non-Siemens site
does not imply that Siemens endorses the
site or the products or services referenced
on such third party site. Siemens shall have
no liability for the contents of such web
pages and does not make representations
about or endorse such web pages or their
contents as its own, as Siemens does not
control the information on such web pages
and is not responsible for the contents and
information given thereon. When linking to a
third-party site, you do so at your own risk
and should review and determine if you
agree to that site's terms and conditions of
use (legal policy, privacy policy, etc.) before
using such site.
Warning!
Remember to back up your data and to do
so frequently. Always back up all data and
programs before sending the mobile phone
in for repair.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
5Safety precautions
VAR Language: am; VAR issue date: 041001
left page (5) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal
requirements and local restric-
tions when using the phone.
For example in aeroplanes,
petrol stations, hospitals or
while driving.
Mobile phones can interfere
with the functioning of medical
devices such as hearing aids or
pacemakers. Keep at least
20 cm/9 inches between phone
and pacemaker. When using
the mobile phone hold it to the
ear which is further away from
the pacemaker. For more infor-
mation consult your doctor.
The ringtone (p. 94), info tones
(p. 97) and handsfree talking
are reproduced through the
loudspeaker. Do not hold the
phone to your ear when it rings
or when you have switched on
the handsfree function (p. 34).
Otherwise you risk serious
permanent damage to your
hearing.
Do not use an optical magnifier
to look at the activated infrared
interface [Class 1 LED product
(classification as per
IEC 60825-1)].
Only use original Siemens bat-
teries (100 % mercury-free) and
charging devices. Otherwise
you risk serious damage to
health and property. The battery
could explode, for instance.
The SIM card may be removed.
Caution! Small parts like this
could be swallowed by young
children.
The mains voltage specified on
the power supply unit (V) must
not be exceeded. Otherwise
the charging device may be
destroyed.
Do not open the phone. Only
the battery (100% mercury-
free) or SIM card may be re-
placed. You must not open the
battery under any circumstanc-
es. Any other changes to this
device are strictly prohibited, as
they will invalidate the type ap-
proval required for operation of
the unit.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
Safety precautions6
VAR Language: am; VAR issue date: 041001
left page (6) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Bluetooth®
Your phone has a Blutooth interface. This al-
lows you to wirelessly connect your phone to
a headset, a car handsfree kit or other Blue-
tooth-enabled equipment.
So that this results in a secure connection
between the equipment and so that, for ex-
ample, third parties cannot access your
phone via radio, you should observe the fol-
lowing points:
• The first connection between two pieces of
equipment, so-called "pairing", should be
done in a trustworthy environment.
• Both pieces of equipment must identify
themselves with a password/PIN. To en-
sure adequate security, you should (un-
less a PIN has been specified) choose a
combination of numbers that is hard to
guess and that contains 16 digits if possi-
ble.
• You should only switch to automatic con-
nection ("connection without confirma-
tion") in exceptional circumstances.
Important
Please dispose of unwanted
batteries and phones as permit-
ted by the laws in your country.
The phone may cause interfer-
ence in the vicinity of TV sets,
radios and PCs.
Use only Siemens original ac-
cessories. This will avoid poten-
tial risks to health or property
and ensure compliance with all
relevant regulations.
Improper use will invalidate the guarantee!
These safety instructions also apply to
Siemens original accessories.
Product attributes are subject to changes in
technology, design and availability.
Siemens reserves the right to modify prod-
ucts without prior notice.
Official emergency telephone numbers
vary by location, are subject to change and
are not guaranteed, as listed, to be correct.
Emergency calls may not be possible on all
wireless phone networks or when certain
network services and/or phone features
are in use. You should determine the rele-
vant emergency number(s) and any restric-
tions in your location by checking with the
local law enforcement agency or service
provider. Siemens assumes no liability for
inaccuracies in the information provided
and reserves the right to make changes
without notice. Remember that this phone,
like any other wireless phone, cannot guar-
antee connection in all conditions. Do not
rely solely on your wireless phone for
emergency communications.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
7Safety precautions
VAR Language: am; VAR issue date: 041001
left page (7) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
• In order to minimise any security risks,
connections should be made only with
trustworthy equipment, in general.
• Where possible, you should limit the "visi-
bility" of your phone. You can make it
much more difficult for unknown equip-
ment to try to establish a connection with
your phone. To do this, in the Bluetooth
menu set the option Visib.to Others from
Always Visible to the value Not Visible
p. 106.
• In a Bluetooth connection, your phone’s
name is transmitted. In the delivery state
this is the "Bluetooth ID". When switching
Bluetooth on for the first time, or later in the
Bluetooth menu, you can change this
name (My BT Name, p. 106).
• If Bluetooth is not needed, this function
should be switched off.
Before using Bluetooth accessories or mo-
bile phones within a vehicle, check the vehi-
cle instruction manual for any restrictions on
using such products.
Antenna care
Use only the supplied or an approved
replacement antenna. Unauthorized
antennas, modifications, or attach-
ments could damage the phone and
may violate FCC regulations.
Phone operation
Normal position
Hold the phone as you would any
other telephone with the antenna
pointed up and over your shoulder.
Tips on efficient operation
For your phone to operate most
efficiently:
• Extend your antenna fully
(if applicable).
• Do not touch the antenna unnec-
essarily when the phone is in use.
Contact with the antenna affects
call quality and may cause the
phone to operate at a higher pow-
er level than otherwise needed.
The Wireless Clip-on Headset HS-3W is
compliant with and adopts the Bluetooth
Specification 1.1. However, interoperability
between the Wireless Clip-on Headset
HS-3W and other Bluetooth-enabled prod-
ucts is not guaranteed because it depends
on compatibility. For more information on
the compatibility between the Wireless
Clip-on Headset HS-3W with other
Bluetooth-enabled products, please check
with your dealer.
Important
Read this information before using
your wireless handheld phone.
As this mobile phone is equipped
with a fixed (non-retractable) an-
tenna, some paragraphs in the text
below may not be applicable.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
Safety precautions8
VAR Language: am; VAR issue date: 041001
left page (8) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Driving
Laws pertaining to the use of mobile
phones while driving vary signifi-
cantly from state to state and some-
times even from locality to locality
within states. For example, some ar-
eas may allow persons to use their
mobile phones only if they employ a
hands-free device, and some areas
may prohibit the use of cell phones
entirely. Accordingly, Siemens rec-
ommends that persons check the
laws for the areas in which they drive
or will be driving. For areas where
the use of mobile phones while driv-
ing is permitted, Siemens encourag-
es persons to use their phones re-
sponsibly and to employ hands-free
devices. Also, if using your phone
while driving, please:
• Give full attention to driving –
driving safely is your first
responsibility;
• Use hands-free operation, if
available;
• Pull off the road and park before
making or answering a call, if
driving conditions so require.
For vehicles equipped with
air bags
An air bag inflates with great force.
DO NOT place objects, including ei-
ther installed or portable wireless
equipment, in the area over the air
bag or in the air bag deployment ar-
ea. If in-vehicle wireless equipment
is improperly installed and the air
bag inflates, serious injury could re-
sult.
Electronic devices
Most modern electronic equipment
is shielded from radio frequency (RF)
signals. However, certain electronic
equipment may not be shielded
against the RF signals from your
wireless phone.
Pacemakers
The Health Industry Manufacturers'
Association recommends that a min-
imum separation of six inches (6")
be maintained between a handheld
wireless phone and a pacemaker to
avoid potential interference with the
pacemaker. These recommenda-
tions are consistent with the inde-
pendent research by and recommen-
dations of Wireless Technology
Research.
Persons with pacemakers
• should ALWAYS keep the phone
more than six inches from their
pacemaker when the phone is
turned ON;
• should not carry the phone in a
breast pocket;
• should use the ear opposite the
pacemaker to minimize the poten-
tial for interference;

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
9Safety precautions
VAR Language: am; VAR issue date: 041001
left page (9) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
• should turn the phone OFF imme-
diately if there is any reason to
suspect that interference is taking
place.
Hearing aids
Some digital wireless phones may
interfere with some hearing aids. In
the event of such interference, you
may want to consult your service
provider or your hearing aid manu-
facturer to discuss alternatives.
Other medical devices
If you use any other personal medi-
cal devices, consult the manufactur-
ers of your devices to determine if
they are adequately shielded from
external RF energy. Your physician
may be able to assist you in obtain-
ing this information.
Turn your phone OFF in health care
facilities when any regulations post-
ed in these areas instruct you to do
so. Hospitals or health care facilities
may be using equipment that could
be sensitive to external RF energy.
Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles.
Check with the manufacturer or its
representative regarding your vehi-
cle. You should also consult the
manufacturer of any equipment that
has been added to your vehicle.
Posted facilities
Turn your phone OFF in any facility
where posted notices so require.
Airplanes
FCC and Airline Regulations prohibit
using your phone while in the air.
Turn your phone OFF when request-
ed by the airline.
Check and comply with the policy of
your airline regarding the use of your
phone while the airplane is on the
ground.
Blasting areas
To avoid interfering with blasting op-
erations, turn your phone OFF when
in a “blasting area” or in areas post-
ed: “Turn off two-way radio.” Obey
all signs and instructions.
Potentially explosive
atmospheres
Turn your phone OFF when in any
area with a potentially explosive
atmosphere and obey all signs and
instructions. Sparks in such areas
could cause an explosion or fire
resulting in bodily injury or even
death.
Areas with a potentially explosive at-
mosphere are often but not always
clearly marked. They include: fueling
areas such as gasoline stations; be-
low deck on boats; fuel or chemical
transfer or storage facilities; vehicles
using liquefied petroleum gas (such

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
Safety precautions10
VAR Language: am; VAR issue date: 041001
left page (10) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
as propane or butane); areas where
the air contains chemicals or parti-
cles, such as grain, dust or metal
powders; and any other area where
you would normally be advised to
turn off your vehicle engine.
Emergency calls (SOS)
Your wireless phone can be used
to make emergency calls. You can
make an emergency call from the
main display screen. Enter the local
emergency number such as 911 and
then press the Akey
This phone, like any wireless phone,
operates using radio signals, wire-
less and landline networks, and user-
programmed functions. Because of
this, connections in all conditions
cannot be guaranteed. Therefore,
you should never rely solely on any
wireless phone for essential commu-
nications (for example, medical
emergencies). Remember – to make
or receive any calls, the phone must
be switched on and be used in a ser-
vice area that has adequate signal
strength. Emergency calls might not
be possible on all wireless phone
networks or when certain network
services or phone features are in use.
Check with local service providers re-
garding their network features.
Always make certain that your
phone is properly charged before
attempting any emergency calls. If
you allow your battery to discharge,
you will be unable to receive or make
calls, including emergency calls. You
must then wait a few minutes after
the charging begins to place any
emergency calls.
When making an emergency call,
remember to give all of the neces-
sary information as accurately as
possible. Remember that your wire-
less phone might be the only means
of communication at the scene of an
accident, therefore you should not
terminate the call until given permis-
sion to do so.
Batteries and Chargers
Only use original Siemens batteries
(100% mercury-free) and charging
devices. Use of non-Siemens batter-
ies and/or charging devices may
cause explosion resulting in serious
injury and/or property damage. Use
original Siemens accessories in order
to avoid possible injury and property
damage and to ensure compliance
with applicable laws and regula-
tions. Improper use invalidates the
warranty.
Battery safety precautions
To reduce the risk of fire, injury or
electric shock, and to properly dis-
pose of batteries, please read and
understand the following instruc-
tions. CONTAINS LITHIUM-ION OR

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_SecurityInfo.fm
11Safety precautions
VAR Language: am; VAR issue date: 041001
left page (11) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
NICKEL-METAL HYDRIDE BATTERY.
BATTERY MUST BE RECYCLED OR DIS-
POSED OF PROPERLY. DO NOT DIS-
POSE IN MUNICIPAL WASTE.
1. Only use the batteries specified
for use with this mobile phone.
2. Do not use batteries of different
sizes or from different manufac-
turers in this mobile phone.
3. Do not dispose of the battery in a
fire; it may explode. Dispose of
used batteries and phones in
accordance with applicable laws
and safety regulations. Do not
expose battery to water. Check
with local codes for special dis-
posal instructions.
4. Do not open or mutilate the bat-
tery. Doing so may cause damage
to the eyes or skin.
5. Exercise care in handling the bat-
tery in order not to short the bat-
tery with conducting materials
such as rings, bracelets, and keys.
The battery or conducting mate-
rial may overheat and cause burns
or fire.
6. Charge the battery provided with,
or identified for use with, this
product only in accordance with
the instructions and limitations
specified in the User's Guide. Do
not attempt to charge the battery
by any means other than those
specified in the User's Guide.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Overview.fm
Overview of phone (schematic)12
VAR Language: am; VAR issue date: 041001
left page (12) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
Overview of phone (schematic)
1ACall key
Dial displayed/highlighted phone num-
bers/names, take calls. Show last
phone numbers dialled in standby
mode.
2BOn/Off/End key.
• Switched off: press and hold to switch
on.
• During a conversation or in an appli-
cation: press briefly to end.
• In menus: press briefly to go back a
level.
Press and hold to go back to standby
mode.
• In standby mode: press and hold to
switch off phone.
3Joystick
CPress the joystick down vertical-
ly to start an application or func-
tion.
In standby mode:
COpen Cingular homepage.
GOpen text message editor.
HOpen SmartChip/Addressbook.
EOpen IM.
DOpen My MEdia.
In lists, messages and menus:
IScroll up and down.
DBack a level.
EHas the same function as the
right soft key.
During a call:
ISet volume.
ECall options.
4Soft keys
The current functions of this key are
shown in the bottom line of the display
as §Text§/symbol (e.g. ?).
5@Camera access
Z£X
Cingular
05/07/04 03:35
Menu ?Options
P
M

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Overview.fm
13Overview of phone (schematic)
VAR Language: am; VAR issue date: 041001
left page (13) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:22)
1Integrated antenna
Do not obstruct the phone above the
battery cover unnecessarily. This re-
duces the signal quality.
2Loudspeaker
3kl Plus-minus key
• During a call: volume high – low.
• In menus, lists, Internet sites: scroll up
and down.
In standby mode:
Press and hold:
kSound recording (press and hold).
lActivate camera.
Press briefly in standby mode.
kPlay back last sound recording.
lQuery before activating camera.
In camera mode:
ktakes a picture.
4Display
5Infrared interface (IrDA)
6Input keys
6*Ringtone
• Press and hold in standby mode:
Switch all audible signals on/off
(except alarm).
• Press and hold on incoming call:
Switch off ringtone for this call only.
7#Key lock
Press and hold in standby mode:
Switch key lock on/off.
8Connection socket
For charger, headset, flash etc.
9Slot for RS MultiMediaCard
:Car kit holder
!Connection for external antenna
"Camera lens
Z£X
Cingular
05/07/04 03:35
Menu ?Options
P
M

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Displaysymbols.fm
Display symbols14
VAR Language: am; VAR issue date: 041001
left page (14) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:27)
Display symbols
Display symbols (selection)
ZSignal strength
YCharging
WBattery charge level, e.g. 50 %
LAddress Book
PRecent Calls
MMessaging
@Camera
TSettings
ÇAll calls are diverted
ýMEdia Mall
OMEdia Net
ÿInstant Messaging
¿Ringer off
¾Short ring (beep) only
¼Ringer only if the caller is stored
in the SmartChip.
¹Alarm set
ÄKeypad locked
ÅAuto answer feature on
T9Abc Text input with T9.
£Activated and available
¢Registered
¤Temporarily interrupted
±Browser offline
²Browser online
³Browser via GPRS online
´Browser no network
¯IrDA activated
®IrDA transmission
¨Bluetooth activated
ªBluetooth transmission
Events (selection)
ãSMS memory full
äMMS memory full
åPhone memory full
ÆNo network access
ÂMissed call
ÊDelete assistant
Message symbols (selection)
pUnread
qRead
rDraft
sDelivered
tMMS not sent
wMMS received
xMMS read
yMMS with DRM contents (p. 21)

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Displaysymbols.fm
15Display symbols
VAR Language: am; VAR issue date: 041001
left page (15) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:27)
zE-mail forwarded
{E-mail with attachment
ÀVoice mail received
Camera symbols
ÈSwitch to photo mode
ÉSwitch to video mode
ÙBrightness
ÚZoom factor
ÛWhite balance
×Flash connected
Joystick symbols
îCamera
ñDelete
ðMake call/accept call
íMenu
ïZoom
ìOK
?Browser

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Startup.fm
Getting started16
VAR Language: am; VAR issue date: 041001
left page (16) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:28)
Getting started
The phone is packaged in dismantled
form and must be re-assembled prior
to using for the first time.
Your phone's
display is sup-
plied with a
protective film.
Remove this film
slowly before as-
sembling the
phone.
In rare cases,
static discharge
may cause dis-
coloration at the edges of the dis-
play. However, this will disappear
within approx. 10 minutes.
Insert SIM card/battery
The service provider supplies you with
a SIM card on which all the important
data for your line is stored. If the SIM
card has been delivered in credit-card
size, snap the smaller segment out
and remove any rough edges.
• Press the grooved area 1, then
push the battery cover towards
the front in the direction indicated
by the arrow 2.
• Place the SIM card flat in front of
the slot with the contact surface
facing downwards. Then push
the SIM card in using gentle pres-
sure 3(ensure that the cham-
fered corner is in the correct
position).
• Insert the battery sideways into
the phone 4, then press it down-
wards 5until it clicks into
position.
1
2
3

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Startup.fm
17Getting started
VAR Language: am; VAR issue date: 041001
left page (17) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:28)
• To remove the battery, pull it out
with the retaining tab on the side.
• Place the cover in position and
push it towards the front 6until
it latches into place.
Inserting an
RS MultiMediaCard
When delivered, the RS MultiMedia-
Card is not yet in the phone.
• To insert the RS MultiMediaCard,
fold the cover out and down 1.
• Open the cover completely, then
insert the RS MultiMediaCard with
the contact surface facing down-
wards 2. Gently push the card
right in until it clicks into place.
Additional information
Please switch off your phone before re-
moving the battery!
The phone supports 1.8 V and 3 V SIM
cards. Please contact your service provider
if you have an older card.
SIM card problems ..........................p. 117
4
5
4
5
6
1
2

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Startup.fm
Getting started18
VAR Language: am; VAR issue date: 041001
left page (18) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:28)
• If necessary, use the battery
cover 3.
• Finally, close the cover again.
•Before removing the RS MultiMedia-
Card, carry out the Eject Card func-
tion in the My MEdia options menu.
This prevents any possible data
loss.
• To remove the RS MultiMedia-
Card, open the cover and press the
card briefly (if necessary, use the
battery cover). The card will pop
out a little and you can remove it.
Finally, close the cover again.
Charge battery
Charging procedure
The battery is not fully charged
when delivered. Plug charger cable
into the bottom of the phone, plug
power supply unit into a mains pow-
er socket and charge for at least
two hours.
YDisplay during charging.
Charging time
An empty battery is fully charged af-
ter about 2 hours. Charging is only
possible within a temperature range
of +5 °C to 45 °C (41 °F to 110 °F). If
the temperature rises/falls 5 °C
(41 °F) above/below this, the charge
symbol flashes a warning. The mains
voltage specified on the power sup-
ply unit must not be exceeded.
3

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Startup.fm
19Getting started
VAR Language: am; VAR issue date: 041001
left page (19) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:28)
Operating times
The operating time depends upon
the respective conditions of use. Ex-
treme temperatures considerably re-
duce the phone’s standby time.
Avoid placing the phone in the sun
or on a heater.
Talktime: 100 to 300 minutes
Standby time: 60 to 250 hours
Charge icon not visible
If the battery has been discharged
fully, the charge icon is not immedi-
ately visible when the power supply
is plugged in. It will appear after up
to two hours. In this case the battery
is fully charged after 3 to 4 hours.
Only use the plug-in power supply unit
supplied!
Display while in service
Charge level display during opera-
tion (empty – full):
VWX
A beep sounds when the battery is
nearly empty. The charge level of the
battery is only displayed correctly af-
ter an uninterrupted charging/dis-
charging cycle. You should therefore
not remove the battery unnecessarily and
where possible not finish the charging
procedure early.
Additional information
The power supply unit heats up when used
for long periods. This is normal and not
dangerous.
If the battery is removed for longer than
30 seconds, the clock must be reset.

©
Siemens AG 2003, W:\ICM_MP_CCQ_S_UM\04FL00594 R66_USA_Ersterstellg\Work\S66_Cingular_us\S66_Cingular\S66_Startup.fm
Switch on/off, PIN entry20
VAR Language: am; VAR issue date: 041001
left page (20) of S66 Cingular am, A31008-H7410-A40-1-4A19 (06.10.2004, 19:28)
Switch on/off, PIN entry
Switching phone on/off
BPress and hold the On/Off/
End key.
Entering the PIN
The SIM card can be protected with a
4to8-digitPIN.
JEnter the PIN using the
number keys. The charac-
ters **** appear to en-
sure nobody can read
your PIN on the display.
Correct with ].
CConfirm by pressing the
joystick. Logging on to
the network will take a
few seconds.
Emergency number
(SOS)
Only to be used in real emergencies!
By pressing the §SOS§ soft key you can
make an emergency call on any net-
work without a SIM card and without
entering a PIN (not available in all
countries).
Switching on your phone
for the first time
Copy SIM addresses
The first time the SIM card is insert-
ed, the entries on it can be copied to
the Addressbook. Please do not inter-
rupt this procedure. During this time
do not accept incoming calls. Follow in-
structions in the display.
You can also copy data from the
SIM card at a later time (p. 43).
Additional information
Change PIN.......................................p. 25
Clear SIM card barring ......................p. 26
