Siemens SINAMICS S120 User manual

Cabinet Modules liquid cooled

SINAMICS
S120
Cabinet Modules liquid cooled
Equipment Manual
04/2020
A5E37067587A
Preface
Fundamental safety
instructions
1
System overview
2
Mechanical installation
3
Electrical installation
4
Commissioning the cooling
circuit
5
Cabinet Modules
6
Maintenance and servicing
7
Diagnostics
8
Options
9

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E37067587A
Ⓟ
04/2020 Subject to change
Copyright © Siemens AG 2015 - 2020.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 3
Preface
SINAMICS documentation
The SINAMICS documentation is organized in the following categories:
●General documentation / catalogs
●Manufacturer/service documentation
●Electronic documentation
This documentation is part of the manufacturer/service documentation for SINAMICS. All of
the documents are available individually.
Please contact your local Siemens office for further information about other available
SINAMICS publications.
For the sake of simplicity, this documentation does not contain comprehensive detailed
information about all types of the product and cannot cover every conceivable case of
installation, operation, or maintenance.
The contents of this documentation are not part of an earlier or existing agreement, a
promise, or a legal agreement, nor do they change this. The Purchase Agreement contains
the complete and exclusive obligations of Siemens, including the warranty provisions. These
contractual warranty provisions are neither extended nor curbed as a result of the
statements made in this documentation.
Target group
This documentation is intended for machine manufacturers, commissioning engineers, and
service personnel who use the SINAMICS drive system.
Objective
This manual describes the hardware components and design of the liquid-cooled SINAMICS
S120 Cabinet Modules. It provides information about installation, electrical connection, and
cabinet design.

Preface
Cabinet Modules liquid cooled
4Equipment Manual, 04/2020, A5E37067587A
Technical support
If you have any questions, please contact our hotline:
Time zone Europe and Africa
Phone
[phone]
Fax
[phone]
Internet
https://support.industry.siemens.com/sc/ww/en/sc/4868
Time zone Americas
Phone
[phone]
Fax
[phone]
E-mail
[e-mail]
Time zone Asia/Pacific
Phone
[phone]
Fax
[phone]
E-mail
[e-mail]
Note
Country
-specific tele
phone numbers for technical support can be found on the Internet at the
following address:
https://www.automation.siemens.com/aspa_app
Siemens Support for on the move
With the "Siemens Industry Online Support" App, you can access more than 300,000
documents for Siemens Industry products – any time and from anywhere. The App supports
you in the following areas:
●Resolving problems when executing a project
●Troubleshooting when faults develop
●Expanding a system or planning a new system
Further, you have access to the Technical Forum and other articles that our experts have
drawn-up:
●FAQs
●Application examples
●Manuals
●Certificates
●Product announcements and much more
The App "Siemens Industry Online Support" is available for Apple iOS and Android.

Preface
Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 5
Data matrix code data on the rating plate
The data matrix code on the rating plate contains the specific device data. This code can be
read-in with any Smartphone and technical information for the appropriate device can be
displayed via the "Industry Online Support" Mobile App.
Spare parts
Spare parts are available on the Internet at: Spare parts
(https://support.industry.siemens.com/sc/de/en/sc/2110)
The spare parts available for the ordered drive can be found in the spare parts list.
These are provided on the customer DVD.
Test certificates
Test certificates for functional safety functions ("Safety Integrated") can be found at:
https://support.industry.siemens.com/cs
An up-to-date list of currently certified components is also available on request from your
local Siemens office. If you have any questions relating to certifications that have not yet
been completed, please ask your Siemens contact.
Internet addresses
Up-to-date information about our products can be found on the Internet at the following
address:
http://www.siemens.com
Information about SINAMICS S120 Cabinet Modules can be found on the Internet at the
following address:
http://www.siemens.com/sinamics-s120-cabinet-modules
Certification
The following certifications can be found on the Internet under the link SINAMICS S120
Cabinet Modules certificates (https://support.industry.siemens.com/cs/de/en/ps/13233/cert):
The following certifications are included in the documentation:
●EC declaration of conformity with reference to the low voltage directive:
●EC declaration of conformity with reference to the EMC directive:
●EC declaration of conformity with reference to the machinery directive (safety)
●Manufacturers declaration in reference to Safety Integrated

Preface
Cabinet Modules liquid cooled
6Equipment Manual, 04/2020, A5E37067587A
Standards that are not relevant
China Compulsory Certification
SINAMICS S120 Cabinet Modules do not fall in the area of validity of the China Compulsory
Certification (CCC).
Web sites of third-party companies
This document includes hyperlinks to web sites of third-party companies Siemens accepts
no responsibility for the content of these web sites, nor does it use these web sites and their
content for its own use, as Siemens cannot check these web sites and is also not
responsible for the content and information provided on them. The user uses these web sites
at his own risk.
Compliance with the General Data Protection Regulation
Siemens respects the principles of data privacy, in particular the data minimization rules
(privacy by design).
For this product, this means:
The product does not process or store any person-related data, only technical function data
(e.g. time stamps). If the user links this data with other data (e.g. shift plans) or if he/she
stores person-related data on the same data medium (e.g. hard disk), thus personalizing this
data, he/she must ensure compliance with the applicable data protection stipulations.

Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 7
Table of contents
Preface ...................................................................................................................................................... 3
1 Fundamental safety instructions .............................................................................................................. 15
1.1 General safety instructions .....................................................................................................15
1.2 Handling electrostatic sensitive devices (ESD) ......................................................................20
1.3 Industrial security....................................................................................................................21
1.4 Residual risks of power drive systems....................................................................................22
2 System overview...................................................................................................................................... 23
2.1 Overview .................................................................................................................................23
2.2 Field of application..................................................................................................................25
2.3 Benefits ...................................................................................................................................26
2.4 Line Connection Modules .......................................................................................................27
2.4.1 General information ................................................................................................................27
2.4.2 Basic Line Connection Modules .............................................................................................27
2.4.3 Active Line Connection Modules ............................................................................................28
2.5 Motor Modules ........................................................................................................................29
2.6 Auxiliary Power Supply Modules ............................................................................................29
2.7 Heat Exchanger Modules .......................................................................................................30
2.8 Overview of options ................................................................................................................31
2.9 System structure.....................................................................................................................34
2.10 System data ............................................................................................................................35
2.11 Derating data ..........................................................................................................................38
2.11.1 Derating factors as a function of coolant temperature............................................................38
2.11.2 Derating factors as a function of the ambient temperature.....................................................40
2.11.3 Derating factors as a function of installation altitude ..............................................................41
2.11.4 Current de-rating depending on the pulse frequency .............................................................43
3 Mechanical installation............................................................................................................................. 45
3.1 Important notes.......................................................................................................................45
3.2 Mechanical installation: Checklist...........................................................................................47
3.3 Installing..................................................................................................................................48
3.3.1 Important safety precautions ..................................................................................................48
3.3.2 Preparation .............................................................................................................................49
3.3.2.1 On-site requirements ..............................................................................................................49
3.3.2.2 Requirements on the levelness of the floor ............................................................................51
3.3.2.3 Shipping and handling indicators............................................................................................52
3.3.2.4 Unpacking the cabinets ..........................................................................................................54
3.3.2.5 Tools required.........................................................................................................................54

Table of contents
Cabinet Modules liquid cooled
8Equipment Manual, 04/2020, A5E37067587A
3.3.3 Lifting the cabinet units off the transport pallet and installing them....................................... 55
3.3.4 Disassembling the crane transport assembly........................................................................ 56
3.3.5 Mechanical connection of the cabinet units........................................................................... 58
3.3.5.1 Connecting the cooling circuit collecting pipes ...................................................................... 58
3.3.5.2 Connecting the cabinet units.................................................................................................. 61
3.3.5.3 Connection to the foundation................................................................................................. 65
4 Electrical installation ................................................................................................................................ 67
4.1 Safety information .................................................................................................................. 67
4.2 Electrical installation: Checklist.............................................................................................. 68
4.3 EMC-compliant design........................................................................................................... 73
4.4 Connecting shielded three-phase cables............................................................................... 74
4.5 Connections ........................................................................................................................... 74
4.5.1 Cable lugs .............................................................................................................................. 74
4.5.2 Connection overview.............................................................................................................. 76
4.5.3 PE busbar .............................................................................................................................. 77
4.5.3.1 General information ............................................................................................................... 77
4.5.3.2 Connection for side-by-side installation of cabinet units........................................................ 77
4.5.3.3 Connection according to the system-side grounding concept............................................... 79
4.5.3.4 Connecting external cables to the PE busbar........................................................................ 79
4.5.4 DC busbar.............................................................................................................................. 80
4.5.4.1 General information ............................................................................................................... 80
4.5.4.2 Removing the heat exchanger for degree of protection IP55................................................ 81
4.5.4.3 Connection for side-by-side installation of cabinet units........................................................ 83
4.5.4.4 Connecting cabinet units with different numbers of DC busbars........................................... 86
4.5.5 Auxiliary power supply system............................................................................................... 87
4.5.5.1 General information ............................................................................................................... 87
4.5.5.2 Connection overview.............................................................................................................. 90
4.5.5.3 Connection for side-by-side installation of cabinet units........................................................ 90
4.5.5.4 Connecting to the infeed........................................................................................................ 91
4.5.6 Connecting the motor cables ................................................................................................. 91
4.5.7 Line supply connections......................................................................................................... 94
4.5.8 Connecting Cabinet Modules to non-grounded line supplies (IT systems) ........................... 95
4.5.9 Signal connections................................................................................................................. 98
4.5.10 Other connections.................................................................................................................. 98
4.5.11 Cable routing.......................................................................................................................... 99
4.5.11.1 General information ............................................................................................................... 99
4.5.11.2 Cable routing for Basic Line Connection Modules............................................................... 100
4.5.11.3 Cable routing for Active Line Connection Modules.............................................................. 105
4.5.11.4 Cable routing for Motor Modules.......................................................................................... 110
4.5.11.5 Cable routing for Auxiliary Power Supply Modules.............................................................. 116
5 Commissioning the cooling circuit.......................................................................................................... 119
5.1 Checklist for commissioning the cooling circuit with Heat Exchanger Module.................... 119
5.2 Coolant for the raw water circuit on the plant side............................................................... 120
5.2.1 Coolant properties................................................................................................................ 120
5.3 Coolant for the internal deionized water circuit.................................................................... 122
5.3.1 Coolant properties................................................................................................................ 122
5.3.2 Antifreeze, biocides, inhibitors ............................................................................................. 124

Table of contents
Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 9
5.4 Filling the internal deionized water circuit.............................................................................126
5.4.1 Venting the cooling circuit.....................................................................................................127
5.4.1.1 Venting the components .......................................................................................................127
5.4.1.2 Venting the heat exchanger..................................................................................................128
5.4.1.3 Venting the heatsinks of the SINAMICS power units ...........................................................131
5.4.1.4 Checking the system standstill pressure ..............................................................................133
5.4.1.5 Completing venting ...............................................................................................................133
5.5 Plant-specific settings ...........................................................................................................134
5.6 Anti-condensation measures ................................................................................................134
5.7 Draining the cooling circuit....................................................................................................135
6 Cabinet Modules.................................................................................................................................... 137
6.1 Basic Line Connection Modules ...........................................................................................137
6.1.1 Description ............................................................................................................................137
6.1.1.1 Fuse switch disconnector (input current ≤800 A) ................................................................142
6.1.1.2 Circuit breaker (input current > 800 A) .................................................................................143
6.1.2 Interface description..............................................................................................................145
6.1.2.1 General information ..............................................................................................................145
6.1.2.2 Control Interface Module ......................................................................................................145
6.1.2.3 X41 EP terminal / temperature sensor connection...............................................................146
6.1.2.4 DRIVE-CLiQ interfaces X400, X401, X402 ..........................................................................147
6.1.2.5 Terminal block -X40 external 230 V AC auxiliary infeed ......................................................147
6.1.3 Options..................................................................................................................................148
6.1.4 Technical data.......................................................................................................................150
6.2 Active Line Connection Modules ..........................................................................................154
6.2.1 Description ............................................................................................................................154
6.2.1.1 Fused switch disconnector (input current ≤700 A) ..............................................................161
6.2.1.2 Circuit breaker (input current > 700 A) .................................................................................162
6.2.2 Interface description..............................................................................................................163
6.2.2.1 General information ..............................................................................................................163
6.2.2.2 Control Interface Module ......................................................................................................164
6.2.2.3 X41 EP terminal / temperature sensor connection...............................................................164
6.2.2.4 DRIVE-CLiQ interfaces X400, X401, X402 ..........................................................................166
6.2.2.5 Terminal block -X40 external 230 V AC auxiliary infeed ......................................................166
6.2.3 Options..................................................................................................................................166
6.2.4 Technical data.......................................................................................................................169
6.3 Motor Modules ......................................................................................................................175
6.3.1 Description ............................................................................................................................175
6.3.2 Interface description..............................................................................................................183
6.3.2.1 General information ..............................................................................................................183
6.3.2.2 Control Interface Module ......................................................................................................183
6.3.2.3 X41 EP terminal / temperature sensor connection...............................................................184
6.3.2.4 X46 Brake control and monitoring ........................................................................................185
6.3.2.5 DRIVE-CLiQ interfaces X400, X401, X402 ..........................................................................186
6.3.3 Options..................................................................................................................................186
6.3.4 Technical data.......................................................................................................................188
6.3.5 Overload capability ...............................................................................................................202
6.4 Heat Exchanger Modules .....................................................................................................204
6.4.1 Description ............................................................................................................................204

Table of contents
Cabinet Modules liquid cooled
10 Equipment Manual, 04/2020, A5E37067587A
6.4.2 Electrical interfaces.............................................................................................................. 209
6.4.2.1 General information ............................................................................................................. 209
6.4.2.2 Overview of the electrical interfaces .................................................................................... 210
6.4.2.3 X1 - power supply ................................................................................................................ 211
6.4.2.4 X6 - external 24 V DC power supply.................................................................................... 211
6.4.3 Interfaces in the cooling circuit............................................................................................. 213
6.4.3.1 Flow diagram of the cooling circuit....................................................................................... 213
6.4.3.2 Layout of the components.................................................................................................... 214
6.4.4 Coolant connections ............................................................................................................ 216
6.4.4.1 Overview of connections...................................................................................................... 216
6.4.4.2 Connection of the converter-side deionized water circuit .................................................... 217
6.4.4.3 Connection of the plant-side raw water circuit..................................................................... 218
6.4.5 Options................................................................................................................................. 219
6.4.6 Technical data...................................................................................................................... 220
6.5 Auxiliary Power Supply Modules.......................................................................................... 224
6.5.1 Description ........................................................................................................................... 224
6.5.2 Fuse switch disconnector (-Q1) ........................................................................................... 229
6.5.3 Transformer (-T2) for generating the auxiliary voltage 230 V AC........................................ 229
6.5.4 Auxiliary power supply system............................................................................................. 230
6.5.5 Customer interfaces for supplying power to an additional auxiliary power supply
system.................................................................................................................................. 230
6.5.6 Options................................................................................................................................. 232
6.5.7 Technical data...................................................................................................................... 233
7 Maintenance and servicing .................................................................................................................... 235
7.1 Chapter content.................................................................................................................... 235
7.2 Cleaning the cabinet ............................................................................................................ 236
7.3 Servicing the cabinet............................................................................................................ 236
7.4 Maintaining the cooling circuit.............................................................................................. 238
7.4.1 General information ............................................................................................................. 238
7.4.2 Maintenance of the coolant.................................................................................................. 239
7.4.3 Maintaining the filter (seated at an inclination) .................................................................... 239
7.4.4 Maintenance of the cooling hoses ....................................................................................... 241
7.4.5 Maintenance of the pumps................................................................................................... 241
7.4.6 Maintaining the fan of the internal heat exchanger.............................................................. 242
7.4.7 Maintenance intervals .......................................................................................................... 242
7.4.8 Replacing the fan of the internal heat exchanger ................................................................ 242
7.5 Replacing components ........................................................................................................ 245
7.5.1 General information ............................................................................................................. 245
7.5.2 Safety information ................................................................................................................ 246
7.5.3 Messages after replacement of DRIVE-CLiQ components ................................................. 246
7.5.4 Mounting equipment for power units.................................................................................... 247
7.5.5 Replacing the filter mats ...................................................................................................... 248
7.5.6 Replacing power units.......................................................................................................... 249
7.5.7 Replacing the power unit ..................................................................................................... 251
7.5.8 Replacing the Control Interface Module .............................................................................. 254
7.5.8.1 Replacing the Control Interface Module, Motor Module, frame size FXL............................ 254
7.5.8.2 Replacing the Control Interface Module, Active Line Module and Motor Module, frame
size GXL............................................................................................................................... 257

Table of contents
Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 11
7.5.8.3 Replacing the Control Interface Module, Active Line Module and Motor Module, frame
size HXL................................................................................................................................260
7.5.8.4 Replacing the Control Interface Module, Active Line Module and Motor Module, frame
size JXL ................................................................................................................................262
7.5.8.5 Replacing the Control Interface Module, Motor Module, frame size JXL 6SL3325-
1TG41-6AP3.........................................................................................................................265
7.5.8.6 Replacing the Control Interface Module, Basic Line Module, frame size FBL .....................270
7.5.8.7 Replacing the Control Interface Module, Basic Line Module, frame size GBL.....................272
7.5.9 Replacing the Control Unit....................................................................................................274
7.5.10 Replacing the fans ................................................................................................................276
7.5.10.1 Replacing the electronic fan, Motor Module, frame size FXL...............................................276
7.5.10.2 Replacing the electronic fan, Active Line Module, and Motor Module, frame size GXL.......279
7.5.10.3 Replacing the electronic fan, Active Line Module, and Motor Module, frame size HXL.......282
7.5.10.4 Replacing the electronic fan, Active Line Module, and Motor Module, frame size JXL........285
7.5.10.5 Replacing the electronic fan, Basic Line Module, frame size FBL .......................................288
7.5.10.6 Replacing the electronic fan, Basic Line Module, frame size GBL.......................................291
7.5.10.7 Replacing the electronic fan of the Control Interface Module...............................................294
7.5.11 Replacing the fuses ..............................................................................................................296
7.5.11.1 General information ..............................................................................................................296
7.5.11.2 Replacing the fuses for the auxiliary power supply ..............................................................296
7.5.11.3 Replacing fuses (F71 to F73) ...............................................................................................296
7.5.11.4 Replacing cylindrical fuses ...................................................................................................297
7.5.11.5 Replacement of LV HRC fuses with blade contacts.............................................................298
7.5.12 Replacing the backup battery for the cabinet operator panel...............................................301
7.6 Forming the DC link capacitors.............................................................................................303
7.7 Environmental compatibility ..................................................................................................306
8 Diagnostics............................................................................................................................................ 307
8.1 Chapter content ....................................................................................................................307
8.2 LEDs on the CU320-2 DP Control Unit.................................................................................308
8.3 LEDs on the CU320-2 PN Control Unit.................................................................................311
8.4 LEDs on the CBE20 Communication Board.........................................................................313
8.5 LEDs on the Control Interface Module in the Basic Line Module.........................................315
8.6 LEDs on the Control Interface Module in the Active Line Module........................................316
8.7 LEDs on the Control Interface Module in the Motor Module ................................................317
8.8 LEDs on the Voltage Sensing Module (VSM) in the Active Interface Module......................318
8.9 LEDs on the SMC10 Sensor Module....................................................................................319
8.10 LEDs on the SMC20 Sensor Module....................................................................................319
8.11 LEDs on the SMC30 Sensor Module....................................................................................320
8.12 LEDs on the TM31 Terminal Module....................................................................................321
8.13 LEDs on the TM54F Terminal Module..................................................................................321
8.14 LEDs on the TM150 Terminal Module..................................................................................323
8.15 LEDs on the SITOP power supply unit .................................................................................323

Table of contents
Cabinet Modules liquid cooled
12 Equipment Manual, 04/2020, A5E37067587A
9 Options .................................................................................................................................................. 325
9.1 Safety information ................................................................................................................ 325
9.2 C95, supply voltage for the Heat Exchanger Module 440 - 480 V / 60 Hz .......................... 325
9.3 C97, supply voltage for the Heat Exchanger Module 500 - 690 V / 60 Hz .......................... 326
9.4 G20, CBC10 Communication Board.................................................................................... 326
9.5 G33, CBE20 Communication Board .................................................................................... 330
9.6 G51 to G54, temperature sensor module TM150................................................................ 333
9.6.1 General information ............................................................................................................. 333
9.6.2 Interfaces ............................................................................................................................. 334
9.6.3 Connection example ............................................................................................................ 338
9.7 G60, Terminal Module TM31 ............................................................................................... 340
9.7.1 General information ............................................................................................................. 340
9.8 G61, additional TM31 Terminal Module............................................................................... 350
9.9 G62, TB30 Terminal Board.................................................................................................. 351
9.10 K01 to K05, safety license for 1 to 5 axes ........................................................................... 357
9.11 K08, AOP30 advanced operator panel................................................................................ 358
9.12 K46, Sensor Module Cabinet-Mounted SMC10................................................................... 360
9.12.1 General information ............................................................................................................. 360
9.12.2 Safety information ................................................................................................................ 362
9.12.3 Interfaces ............................................................................................................................. 363
9.12.4 Connection example ............................................................................................................ 366
9.13 K48, Sensor Module Cabinet-Mounted SMC20................................................................... 367
9.13.1 General information ............................................................................................................. 367
9.13.2 Safety information ................................................................................................................ 368
9.13.3 Interfaces ............................................................................................................................. 369
9.13.4 Connection example ............................................................................................................ 373
9.14 K50, Sensor Module Cabinet-Mounted SMC30................................................................... 374
9.14.1 General information ............................................................................................................. 374
9.14.2 Safety information ................................................................................................................ 378
9.14.3 Interfaces ............................................................................................................................. 379
9.14.4 Connection example ............................................................................................................ 383
9.15 K51, VSM10 Voltage Sensing Module Cabinet-Mounted.................................................... 384
9.16 K52, Additional SMC30 Sensor Module .............................................................................. 386
9.17 K76, auxiliary voltage generating unit in the Line Connection Module................................ 387
9.18 K82, terminal module for activating safety functions "Safe Torque Off" and "Safe Stop
1".......................................................................................................................................... 389
9.19 K87, Terminal Module TM54F ............................................................................................. 390
9.20 K88, Safe Brake Adapter SBA 230 V AC ............................................................................ 392
9.21 K90, Control Unit CU320-2 DP ............................................................................................ 394
9.21.1 General information ............................................................................................................. 394
9.21.2 Connection overview............................................................................................................ 395
9.21.3 Connection example ............................................................................................................ 397

Table of contents
Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 13
9.21.4 X100 - X103 DRIVE-CLiQ interface......................................................................................398
9.21.5 X126 PROFIBUS ..................................................................................................................399
9.21.6 PROFIBUS address switch...................................................................................................400
9.21.7 X127 LAN (Ethernet).............................................................................................................401
9.21.8 X140 serial interface (RS232)...............................................................................................402
9.21.9 Measuring sockets T0, T1, T2 ..............................................................................................403
9.21.10 Memory card.........................................................................................................................404
9.21.10.1 Using the memory card.........................................................................................................404
9.21.10.2 Data functions.......................................................................................................................406
9.21.10.3 Saving the memory card parameter settings........................................................................406
9.21.10.4 Slot for the memory card ......................................................................................................407
9.22 K94, Performance extension for CU320-2............................................................................408
9.23 K95, Control Unit CU320-2 PN .............................................................................................409
9.23.1 General information ..............................................................................................................409
9.23.2 Connection overview.............................................................................................................410
9.23.3 Connection example .............................................................................................................412
9.23.4 X100 - X103 DRIVE-CLiQ interface......................................................................................413
9.23.5 X127 LAN (Ethernet).............................................................................................................414
9.23.6 X140 serial interface (RS232)...............................................................................................415
9.23.7 X150 P1/P2 PROFINET connection.....................................................................................416
9.23.8 Measuring sockets T0, T1, T2 ..............................................................................................417
9.23.9 Memory card.........................................................................................................................418
9.23.9.1 Using the memory card.........................................................................................................418
9.23.9.2 Data functions.......................................................................................................................420
9.23.9.3 Saving the memory card parameter settings........................................................................420
9.23.9.4 Slot for the memory card ......................................................................................................421
9.24 dv/dt filter compact plus Voltage Peak Limiter......................................................................422
9.25 Motor reactor.........................................................................................................................426
9.26 dV/dt filter plus Voltage Peak Limiter....................................................................................427
9.27 L13, main contactor for Basic Line Connection Modules < 800 A........................................430
9.28 L21, surge suppression ........................................................................................................430
9.29 L22, supplied as standard without line reactor .....................................................................432
9.30 L25, circuit breaker in withdrawable unit design...................................................................432
9.31 L40, line filter monitoring.......................................................................................................433
9.32 L41, current transformer upstream of main switch ...............................................................434
9.33 L45, EMERGENCY OFF pushbutton installed in the cabinet door ......................................436
9.34 L50, cabinet lighting with service socket...............................................................................437
9.35 L55, cabinet anti-condensation heating................................................................................438
9.36 L87, insulation monitoring.....................................................................................................439
9.37 M06, base 100 mm high, RAL 9005 .....................................................................................442
9.38 M07, cable-marshalling compartment 200 mm high, RAL 7035 ..........................................443
9.39 M23/M43/M55, IP23/IP43/IP55 degree of protection ...........................................................444
9.40 M26/M27, side panels mounted on right and left..................................................................445

Table of contents
Cabinet Modules liquid cooled
14 Equipment Manual, 04/2020, A5E37067587A
9.41 M70, EMC shield bus........................................................................................................... 446
9.41.1 General information ............................................................................................................. 446
9.41.2 Connecting the cables to the EMC shield bus..................................................................... 446
9.42 M72, quick-release couplings water hoses.......................................................................... 447
9.43 M80 to M87, DC busbar system .......................................................................................... 447
9.44 M88, DC busbar system for line-side Cabinet Modules....................................................... 449
9.45 M90, crane transport assembly (top-mounted).................................................................... 449
9.46 N52, DC link fuses ............................................................................................................... 450
9.47 P10, measuring instrument for line values (installed in the cabinet doors) ......................... 451
9.48 P11, measuring instrument for line values with PROFIBUS connection (installed in the
cabinet door) ........................................................................................................................ 452
9.49 W01, Heat Exchanger Module, partially redundant with 2 pumps....................................... 453
9.50 W10, insulation of the pipes in the raw water circuit and heat exchanger........................... 453
9.51 W20, raw water connection from the bottom ....................................................................... 454
9.52 W34, Heat Exchanger Module prepared for installation on the left in the cabinet lineup.... 454
9.53 W36, Heat Exchanger Module prepared for installation on the right in the cabinet
lineup.................................................................................................................................... 455
9.54 W43, release valve in the deionized water circuit................................................................ 455
9.55 W49, leakage sensor in the Heat Exchanger Module, at the bottom in the cabinet floor.... 456
9.56 W62, sensors in the raw water circuit on the plant/system side.......................................... 456
9.57 Y11, factory assembly into transport units........................................................................... 457
Index...................................................................................................................................................... 459

Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 15
Fundamental safety instructions
1
1.1 General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or serious injury.
•Only work on electrical equipment if you are appropriately qualified.
•Always observe the country-specific safety rules for all work.
Generally, the following steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check that every auxiliary circuit is de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems or
water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness by following the
above steps in the reverse order.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.

Fundamental safety instructions
1.1 General safety instructions
Cabinet Modules liquid cooled
16 Equipment Manual, 04/2020, A5E37067587A
WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shield
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•Connect cable shields and unused conductors of power cables (e.g. brake conductors)
at least on one side to the grounded housing potential.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is in operation can result in arcing that may
cause serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.

Fundamental safety instructions
1.1 General safety instructions
Cabinet Modules liquid cooled
Equipment Manual, 04/2020, A5E37067587A 17
NOTICE
Property damage due to loose power connections
Insufficient tightening torques or vibration can result in loose power connections. This can
result in damage due to fire, device defects, or malfunctions.
•Tighten all power connections to the prescribed torque.
•Check all power connections at regular intervals, particularly after equipment has been
transported.
WARNING
Spread of fire from built-in devices
In the event of fire outbreak, the enclosures of built-in devices cannot prevent the escape of
fire and smoke. This can result in serious personal injury or property damage.
•Install built-in units in a suitable metal cabinet in such a way that personnel are
protected against fire and smoke, or take other appropriate measures to protect
personnel.
•Ensure that smoke can only escape via controlled and monitored paths.
WARNING
Active implant malfunctions due to electromagnetic fields
Converters generate electromagnetic fields (EMF) during operation. People with active
implants in the immediate vicinity of this equipment are at particular risk.
•As the operator of an EMF-emitting installation, assess the individual risks of persons
with active implants. The following clearances are usually adequate:
–No clearance to closed control cabinets and shielded MOTION-CONNECT supply
cables
–Forearm length (approx. 35 cm clearance) to distributed drive systems and open
control cabinets
WARNING
Unexpected movement of machines caused by radio devices or mobile phones
When radio devices or mobile phones with a transmission power > 1 W are used in the
immediate vicinity of components, they may cause the equipment to malfunction.
Malfunctions may impair the functional safety of machines and can therefore put people in
danger or lead to property damage.
•If you come closer than around 2 m to such components, switch off any radio devices or
mobile phones.
•Use the "SIEMENS Industry Online Support App" only on equipment that has already
been switched off.

Fundamental safety instructions
1.1 General safety instructions
Cabinet Modules liquid cooled
18 Equipment Manual, 04/2020, A5E37067587A
WARNING
Motor fire in the event of insulation overload
There is a greater load on the motor insulation as a result of a ground fault in an IT system.
If the insulation fails, it is possible that death or severe injury can occur as a result of smoke
and fire.
•Use a monitoring device that signals an insulation fault.
•Correct the fault as quickly as possible so the motor insulation is not stressed.
WARNING
Fire due to inadequate ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause severe injury or even death. This can also result in
increased failures and shorter service lives for devices/systems.
•Ensure compliance with the specified minimum clearance as ventilation clearance for
the respective component.
WARNING
Unrecognized dangers due to missing or illegible warning labels
Dangers might not be recognized if warning labels are missing or illegible. Unrecognized
dangers may cause accidents resulting in serious injury or death.
•Check that the warning labels are complete based on the documentation.
•Attach any missing warning labels to the components, where necessary in the national
language.
•Replace illegible warning labels.
NOTICE
Device damage caused by incorrect voltage/insulation tests
Incorrect voltage/insulation tests can damage the device.
•Before carrying out a voltage/insulation check of the system/machine, disconnect the
devices as all converters and motors have been subject to a high voltage test by the
manufacturer, and therefore it is not necessary to perform an additional test within the
system/machine.
CAUTION
Injuries at places that are difficult to access
There is risk of injury when working at locations that are difficult to access. For example,
sharp edges and splinters can cause injuries to the head and skin.
•Use suitable personal protective equipment, for example gloves.
