Siemens 1FK7 Series User manual

Operating instructions · 03/2011
Synchronous motors 1FK7
s
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

 
Synchronous Motors 1FK7
_
_________________
_
_
_________________
_
_
____________
_
_____
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
Synchronous Motors 1FK7
Operating Instructions
03/2011
610.40700.40c
Introduction
1
Safety instructions
2
Description
3
Preparing for use
4
Installation
5
Connecting
6
Commissioning
7
Operation
8
Maintenance
9
Decommissioning and
disposal
10
Appendix
A
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
Order number: 610.40700.40c
Ⓟ 03/2011
Copyright © Siemens AG 2011.
Technical data subject to change
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 3
Table of contents
1 Introduction................................................................................................................................................ 5
1.1 About these operating instructions ................................................................................................5
2 Safety instructions ..................................................................................................................................... 7
2.1 General safety notes......................................................................................................................7
2.2 Safety and application instructions ................................................................................................8
3 Description............................................................................................................................................... 11
3.1 Product description ......................................................................................................................11
3.2 Technical features........................................................................................................................12
3.3 Rating plate (type plate)...............................................................................................................14
3.4 Design ..........................................................................................................................................15
3.4.1 Standards and regulations...........................................................................................................15
3.4.2 Types of construction...................................................................................................................15
3.4.3 Degree of protection ....................................................................................................................15
3.4.4 Ambient conditions.......................................................................................................................16
3.4.5 Cooling.........................................................................................................................................16
3.4.6 Noise emission.............................................................................................................................17
4 Preparing for use ..................................................................................................................................... 19
4.1 Shipping and packaging...............................................................................................................19
4.2 Transport and storage..................................................................................................................19
4.2.1 Transport......................................................................................................................................19
4.2.2 Storage.........................................................................................................................................21
5 Installation ............................................................................................................................................... 23
5.1 Installation....................................................................................................................................23
5.2 Attaching transmission elements .................................................................................................25
5.3 Vibration response .......................................................................................................................26
6 Connecting .............................................................................................................................................. 27
6.1 Electrical connection ....................................................................................................................27
6.1.1 Safety instructions........................................................................................................................27
6.1.2 Circuit diagram.............................................................................................................................28
6.1.3 Motor connection .........................................................................................................................28
6.1.4 Rotating the connector for 1FK7xxx5 and 1FK7xxx-7 .................................................................32
6.1.5 Rotating the connector for 1FK7xxx-2, 1FK7xxx-3, 1FK7xxx-4...................................................33
6.1.6 Motors with DRIVE-CLiQ interface ..............................................................................................35
6.1.7 Motors without DRIVE-CLiQ interface .........................................................................................36
6.1.8 Connecting to a converter............................................................................................................36
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Table of contents
Synchronous Motors 1FK7
4 Operating Instructions, 03/2011, 610.40700.40c
7 Commissioning ........................................................................................................................................ 37
7.1 Measures prior to commissioning ............................................................................................... 37
7.2 Switching on................................................................................................................................ 39
8 Operation................................................................................................................................................. 41
8.1 Safety guidelines in operation..................................................................................................... 41
8.2 Faults........................................................................................................................................... 42
8.3 Non-operational periods.............................................................................................................. 44
9 Maintenance ............................................................................................................................................ 45
9.1 Inspection and maintenance ....................................................................................................... 45
9.1.1 Safety instructions....................................................................................................................... 45
9.1.2 Maintenance intervals ................................................................................................................. 46
9.1.3 Bearing change interval .............................................................................................................. 47
9.2 Repair.......................................................................................................................................... 48
9.2.1 Safety instructions....................................................................................................................... 48
9.2.2 Removing/Installing the encoder................................................................................................. 49
10 Decommissioning and disposal ............................................................................................................... 51
10.1 Decommissioning........................................................................................................................ 51
10.1.1 Preparing for removal.................................................................................................................. 51
10.1.2 Dismantling the motor ................................................................................................................. 51
10.2 Disposal....................................................................................................................................... 52
A Appendix.................................................................................................................................................. 53
A.1 Order number Configuration Manual ..........................................................................................53
A.2 Declaration of conformity ............................................................................................................ 54
Index........................................................................................................................................................ 55
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 5
Introduction 1
1.1 About these operating instructions
These operating instructions describe the motor and explain how to handle the motor from
the delivery up to disposal.
Before you start to handle the motor, you must read these operating instructions. to ensure
safe, problem-free operation and to maximize the service life.
These operating instructions are valid in conjunction with the relevant SIEMENS
Configuration Manual.
Siemens continually strives to improve the quality of information provided in these operating
instructions. If you find any mistakes or would like to offer suggestions about how this
document could be improved, please contact the Siemens Service Center.
Always follow the safety instructions and notices in these operating instructions. The warning
notice system is explained on the rear of the inside front.
Text format features
In addition to the safety-related notices and instructions that you must carefully observe, you
will find the text in these operating instructions is formatted in the following way:
1. Handling instructions are always shown as a numbered list. Always perform the handling
steps in the sequence given.
● Lists are formatted as bulleted lists.
– Lists at the second level are hyphenated.
Note
A Note is an important item of information about the product, handling of the product
or the relevant section of the document. Notes provide you with help or further
suggestions/ideas.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Introduction
1.1 About these operating instructions
Synchronous Motors 1FK7
6 Operating Instructions, 03/2011, 610.40700.40c
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 7
Safety instructions 2
2.1 General safety notes
Safety and commissioning information for converter-fed low-voltage three-phase motors
DANGER
All activities associated with transporting, connecting, commissioning, and maintaining the
motors must be carried out by properly trained, responsible personnel (observe DIN EN
50110-1; IEC 60364).
Failure to follow proper procedures may result in injury or material damage.
Special versions and design versions may differ with respect to certain technical aspects. If
in doubt, you are strongly advised to contact the manufacturer, specifying the type
designation and serial number (see rating plate), or arrange for any maintenance work to be
carried out by the SIEMENS Service Center.
Systems and machines with converter-fed low-voltage three-phase motors must fulfill the
protective requirements of the EMC Directive.
The machine manufacturer is responsible for ensuring that installation is carried out properly.
The signal and power cables to the motor must be shielded.
The information provided by the converter manufacturer regarding EMC-compliant
installation must be observed.
Intended use
These motors are designed for use in industrial or commercial systems. They comply with
the EN 60034-1 standards and the relevant associated sections.
WARNING
It is forbidden to install them in hazardous areas unless they are explicitly designed for this.
If more stringent requirements are necessary in special cases (e.g. shock-hazard protection
in non-commercial applications where children are likely to be present), the customer must
implement the relevant measures to ensure that these requirements are fulfilled.
Any alternative data specified on the rating plate must be taken into account. The conditions
at the installation location must comply with the rating plate specifications.
The motors are designed for use in sheltered areas under normal climatic conditions, such
as those found in production environments.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Safety instructions
2.2 Safety and application instructions
Synchronous Motors 1FK7
8 Operating Instructions, 03/2011, 610.40700.40c
2.2 Safety and application instructions
The safe use of electrical machines
WARNING
Rotating or live parts
Rotating or live parts are dangerous.
Fatal or severe injuries and substantial material damage can occur if the necessary covers
are removed or if the machines are not handled, operated, or maintained properly.
Covers must only be removed and the motor operated in accordance with the relevant
regulations. The motor must be maintained on a regular basis.
Qualified personnel
These operating instructions only contain the information necessary for ensuring that the
motor is operated by properly trained personnel in accordance with its intended purpose.
Those responsible for plant safety must ensure the following:
● The basic planning work for the plant or system and all work relating to transportation,
assembly, installation, commissioning, maintenance and repairs is carried out by qualified
personnel and checked by responsible, suitably skilled personnel.
● The operating instructions and the motor documentation are available at all times.
● The technical data and specifications relating to installation, connection, ambient and
operating conditions are taken into account at all times.
● The system-specific installation and safety regulations are observed.
● Personal protective equipment is used.
● Unqualified persons must not work on or in the vicinity of these motors at any time.
● If the motors are used outside industrial areas, the installation site must be protected
against unauthorized access by means of suitable protective measures (e.g. safety
fences and warning signs).
Note
Siemens Service Center
For any service work you may require, you are advised to contact your nearest Siemens
Service Center to request their services and support for maintenance activities.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Safety instructions
2.2 Safety and application instructions
Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 9
Observing the five safety rules
For your personal safety and to prevent material damage when working on the machine,
always observe the safety instructions and the following five safety rules. Apply the five
safety rules in the order stated before starting work at the machine.
1. Isolate the equipment from the power supply
You must also make sure that the auxiliary circuits are also disconnected.
2. Protect against reconnection.
3. Make sure that the equipment is de-energized and in a no-voltage condition.
4. Ground and short-circuit
5. Cover or enclose adjacent components that are still live.
After the work has been completed, undo the previous measures in the reverse order.
Thermal hazard
CAUTION
The surface temperature of the motors can exceed 100 °C.
Do not touch hot surfaces!
Temperature-sensitive components (electric cables, electronic components) must not be
placed on hot surfaces. If the motors overheat, this can destroy the windings/bearings and
permanent magnets may become demagnetized.
Only operate the motors in conjunction with effective temperature monitoring!
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Safety instructions
2.2 Safety and application instructions
Synchronous Motors 1FK7
10 Operating Instructions, 03/2011, 610.40700.40c
Notes about electromagnetic fields
WARNING
Electromagnetic fields
Electromagnetic fields are generated by the operation of electrical power equipment – such
as transformers, converters or motors.
Electromagnetic fields can destroy electronic devices, which could cause them to
malfunction. For example, the operation of heart pacemakers can be impaired, potentially
leading to personal injury or even death. It is therefore forbidden for persons with heart
pacemakers to enter these areas.
The company operating the plant is responsible for taking appropriate measures (labels
and hazard warnings) to adequately protect operating personnel and others against any
possible risk.
● Observe the relevant local and domestic health and safety regulations. In Germany,
"electromagnetic fields" are subject to regulations BGV B11 and BGR B11 stipulated by
the German statutory industrial accident insurance institution.
● Display adequate hazard warning notices.
● Place barriers around hazardous areas.
● Take measures, e.g. using shields, to reduce electromagnetic fields at their source.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 11
Description 3
3.1 Product description
Overview
1FK7 motors are compact permanent-magnet synchronous motors. The available options,
gear units and encoders, together with the expanded product range, mean that the 1FK7
motors can be optimally adapted to any application. They therefore also satisfy the
permanently increasing demands of state-of-the-art machine generations.
1FK7 motors can be combined with the SINAMICS S120 drive system to create a high-
performance system with a high degree of functionality. The integrated encoder systems for
speed and position control can be selected depending on the application.
The motors are designed for operation without external ventilation as the heat is dissipated
through the motor surface. 1FK7 motors have a high overload capability.
Benefits
1FK7 Compact motors offer:
● Space-saving installation thanks to extremely high power density
● Can be universally used for many applications
● Wide range of motors
1FK7 High Inertia motors offer:
● Rugged closed-loop control properties for high or variable load moments of inertia
● Low optimization and commissioning overhead to compensate disturbances
Applications
● Machine tools
● Robots and handling systems
● Wood, glass, ceramics and stone working
● Packaging, plastics and textile machines
● Auxiliary axes
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.2 Technical features
Synchronous Motors 1FK7
12 Operating Instructions, 03/2011, 610.40700.40c
3.2 Technical features
Table 3- 1 Technical features
Type of motor Permanent-magnet synchronous motor
Magnet material Rare-earth magnetic material
Cooling Natural cooling
Insulation of the stator winding according to EN
60034-1 (IEC 60034-1)
Temperature class 155 (F) for a winding temperature of
ΔT = 100 K at an ambient temperature of +40° C
Installation altitude (in accordance with EN 60034–1
and IEC 60034–1)
≤ 1000 m above sea level, otherwise power derating
Type of construction in accordance with EN 60034-7
(IEC 60034-7)
IM B5 (IM V1, IM V3)
Degree of protection in accordance with EN 60034-5
(IEC 60034-5)1)
IP64; optional IP65 or IP65 + IP67 at the shaft gland
Temperature monitoring KTY 84 temperature sensor in the stator winding
Paint finish Anthracite (RAL 7016)
Drive shaft end acc. to DIN 748-3
(IEC 60072-1)
Plain shaft, optional shaft with fitted key and keyway (half-key
balancing)
Radial eccentricity, concentricity and axial eccentricity
acc. to DIN 42955 (IEC 60072–1) 2)
Tolerance N (normal)
Vibration severity grade according to EN 60034-14
(IEC 60034-14)
Grade A is maintained up to rated speed
Sound pressure level LpA (1 m) in accordance with
DIN EN ISO 1680, max. tolerance + 3 dB(A)
1FK701 to 1FK704: 55 dB(A)
1FK706: 65 dB(A)
1FK708 to 1FK710: 70 dB(A)
Built-in encoder systems for motors without DRIVE-
CLiQ interface
IC2048S/R3) incremental encoder, sin/cos 1 Vpp, 2048 S/R 3)
with C and D tracks, for SH 20 to SH 100
AM2048P/R 3) absolute encoder 2048 P/R 3), 4096 revolutions
multiturn, with EnDat interface for SH 36 to SH 100
AM512P/R 3) absolute encoder 512 P/R 3), 4096 revolutions
multiturn, with EnDat interface for SH 28
AM16P/R 3) absolute encoder 16 P/R 3), 4096 revolutions
multiturn, with EnDat interface for SH 20 and SH 28
Resolver multi-pole (number of poles corresponds to number of
pole pairs of the motor), for SH 20 and SH 28
2-pole resolver for SH 20 and SH 28
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.2 Technical features
Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 13
Integrated encoder systems for motors with DRIVE-
CLiQ interface
AS24DQI absolute encoder single-turn 24 bit , for SH 36 to
SH 100
AM24DQI absolute encoder 24 bit + 12 bit multiturn, for SH 36
to SH 100
AS20DQI absolute encoder single-turn 20 bit, for SH 36 to
SH 100
AM20DQI absolute encoder 20 bit + 12 bit multiturn, for SH 36
to SH 100
IC22DQ incremental encoder 22 bit + commutation position, 11
bit, for SH 20 to SH 100
AM22DQI absolute encoder 22 bit + 12 bit multiturn, for SH 36
to SH 100
AM20DQ absolute encoder 20 bit + 12 bit multiturn, for SH 28
AM15DQ absolute encoder 15 bit + 12 bit multiturn, for SH 28
R15DQ resolver 15 bit, for SH 28
R14DQ resolver 14 bit, for SH 28
Connecting Connectors for signals and power, can be rotated
Holding brake Optional mounted holding brake (free of backlash, 24 V)
Second rating plate Enclosed separately
1) 1FK701 only available in degree of protection IP54 with paint finish, planetary gearbox not possible
2) Radial eccentricity of the shaft extension, concentricity of centering edge and axial eccentricity of the mounting flange to
the axis of the shaft extension.
3) P/R = Pulses/Revolution
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.3 Rating plate (type plate)
Synchronous Motors 1FK7
14 Operating Instructions, 03/2011, 610.40700.40c
3.3 Rating plate (type plate)
The rating plate (type plate) contains the technical data relevant for the motor.
%UDNH(%'%.9:
PNJ
a0RW ).$)&%
1R<)31
0
(QFRGHU$0'4,
7K&O))
51
,
,
8
Q
Q
,3
(1
0DGHLQ*HUPDQ\







  






&
1P
0

1
,1
PD[
1

1
1P
$
$
9
PLQ
PLQ
86
6LHPHQV$*,QGXVWULHVWU'%DG1HXVWDGW



Figure 3-1 Schematic layout of rating plate
Table 3- 2 Description of the rating plate data
Position Description / technical data
1 Motor type: Synchronous motors
2 ID no., serial number
3 Static torque M0 [Nm]
4 Rated torque MN [Nm]
5 Designation of the encoder type
6 Holding brake data: Typical, voltage, power consumption
7 Standard for all rotating electrical machines
8 Production address
9 Stall current I0 [A]
10 Rated current IN [A]
11 Induced voltage at rated speed UIN [V]
12 Temperature class
13 Motor version
14 Standards and specifications
15 2D code
16 Degree of protection
17 Motor weight m [kg]
18 Rated speed nN [rpm]
19 Maximum speed nmax [rpm]
20 SIEMENS motor type/order number
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.4 Design
Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 15
3.4 Design
3.4.1 Standards and regulations
The motors comply with the following regulations according to IEC / EN 60034:
Table 3- 3 Regulations that have been applied
Feature Standard
Ratings and operating performance IEC/EN 60034-1
Degree of protection 1) IEC/EN 60034-5
Type of construction (1) IEC/EN 60034-7
Terminal markings IEC/EN 60034-8
Noise emission IEC/EN 60034-9
Temperature monitoring IEC/EN 60034-11
Vibration severity levels IEC/EN 60034-14
(1) The degree of protection and type of construction of the motor are stamped on its rating plate.
The three-phase motors comply with the relevant sections of EN 60034 and EN 60204-1.
Three-phase motors comply with the Low-Voltage Directive 2006/95/EC. Motors which have
"UR" stamped on their rating plates comply with UL regulations.
Low-voltage motors are components designed for installation in machines in accordance
with the Machinery Directive. They must not be commissioned until it has been verified that
the end product complies with this directive (also take into account EN 60204-1).
Note
Make sure that your end product is in compliance with all of the applicable laws! The
applicable domestic, local, and system-specific regulations and requirements must be taken
into account.
3.4.2 Types of construction
The motor has type construction IM B5 (IM V1, IM V3).
3.4.3 Degree of protection
1FK7 motors are available with IP64 or IP65 degree of protection. The degree of protection
of the motor is specified on the rating plate.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.4 Design
Synchronous Motors 1FK7
16 Operating Instructions, 03/2011, 610.40700.40c
3.4.4 Ambient conditions
The following temperature ranges apply to naturally-cooled motors.
● Permissible temperature range in operation: T = -15 °C to +40 °C
● Permissible temperature range during storage: T = -20 °C to +70 °C
For deviating conditions (ambient temperature > 40°C or installation altitude > 1000 m
above sea level) the permissible torque/power must be determined from the following table.
Ambient temperatures and installation altitudes are rounded off to 5°C and 500 m
respectively.
Table 3- 4 Power derating as a function of the installation altitude and ambient temperature
Ambient temperature in °C
Installation altitude above
sea level [m] < 30 30 - 40 45 50 55
1000 1.07 1.00 0.96 0.92 0.87
1500 1.04 0.97 0.93 0.89 0.84
2000 1.00 0.94 0.90 0.86 0.82
2500 0.96 0.90 0.86 0.83 0.78
3000 0.92 0.86 0.82 0.79 0.75
3500 0.88 0.82 0.79 0.75 0.71
4000 0.82 0.77 0.74 0.71 0.67
NOTICE
What has to be observed when installing the motors
1FK7 motors are not suitable for operation
in salt-laden or corrosive atmospheres
outdoors
3.4.5 Cooling
Natural cooling
The rated data only applies when the ambient temperature does not exceed 40 °C (104 °F)
as a result of the installation conditions.
To ensure sufficient cooling, a minimum clearance of 100 mm from adjacent components
must be observed at three lateral surfaces.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.4 Design
Synchronous Motors 1FK7
Operating Instructions, 03/2011, 610.40700.40c 17
3.4.6 Noise emission
When operated in the speed range 0 to rated speed, 1FK7 motors can reach the following
measuring-surface sound pressure level Lp(A):
Table 3- 5 Sound pressure level
Shaft height Measuring-surface sound pressure level Lp(A)
1FK701 to 1FK704 55 dB(A) + 3 dB tolerance
1FK706 65 dB(A) + 3 dB tolerance
1FK708 to 1FK710 70 dB(A) + 3 dB tolerance
The motors are certified for a wide range of installation and operating conditions. These
conditions such as rigid or vibration-isolated foundation design influence noise emission,
sometimes significantly.
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR

Description
3.4 Design
Synchronous Motors 1FK7
18 Operating Instructions, 03/2011, 610.40700.40c
EUROSERVO SERVO MOTOR TAMİR MERKEZİ
WWW.EUROSERVO.COM.TR
