Siemens 1FT7 Series User manual

Operating Instructions · 04/2010
1FT7 Synchronous Motors
s

1FT7 synchronous motors
_
_________________
_
_
_________________
_
_
______________
_
___
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
_
_________________
_
1FT7 synchronous motors
Operating Instructions
04/2010
610.40075.40b
Introduction 1
Safety information
2
Description
3
Preparations for use
4
Mounting
5
Connection
6
Commissioning
7
Operation
8
Servicing
9
Decommissioning and
disposal
10
Appendix
A

Legal information
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation for the specific task, in particular its warning notices and
safety instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be adhered to. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
Order number: 610.40075.40b
Ⓟ 04/2010
Copyright © Siemens AG 2010.
Technical data subject to change

1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 5
Table of contents
1 Introduction................................................................................................................................................ 7
1.1 About these operating instructions ................................................................................................7
2 Safety information...................................................................................................................................... 9
2.1 General safety information.............................................................................................................9
2.2 Safety and operating instructions.................................................................................................10
3 Description............................................................................................................................................... 13
3.1 Product description ......................................................................................................................13
3.2 Technical features........................................................................................................................14
3.3 Rating plate..................................................................................................................................16
3.4 Structure.......................................................................................................................................17
3.4.1 Regulations ..................................................................................................................................17
3.4.2 Types of construction...................................................................................................................17
3.4.3 Degree of protection ....................................................................................................................17
3.4.4 Environmental conditions.............................................................................................................18
3.4.5 Cooling.........................................................................................................................................18
3.4.6 Noise emission.............................................................................................................................22
4 Preparations for use ................................................................................................................................ 23
4.1 Shipment and packaging .............................................................................................................23
4.2 Transportation and storage..........................................................................................................23
4.2.1 Transporting.................................................................................................................................23
4.2.2 Storing..........................................................................................................................................24
5 Mounting.................................................................................................................................................. 25
5.1 Installing.......................................................................................................................................25
5.2 Fitting output elements.................................................................................................................26
5.3 Vibration response .......................................................................................................................27
6 Connection .............................................................................................................................................. 29
6.1 Mechanical connection of water cooling system..........................................................................29
6.2 Electrical connection ....................................................................................................................29
6.2.1 Safety guidelines..........................................................................................................................29
6.2.2 Circuit diagram.............................................................................................................................30
6.2.3 Motor connection .........................................................................................................................31
6.2.4 Rotating the connectors ...............................................................................................................34
6.2.5 Motors with DRIVE-CLiQ interface ..............................................................................................35
6.2.6 Motors without DRIVE-CLiQ interface .........................................................................................36
6.2.7 Connecting the temperature sensor ............................................................................................36
6.2.8 Connecting a forced-ventilation 1FT7 motor................................................................................37
6.2.9 Connecting to a converter............................................................................................................38

Table of contents
1FT7 synchronous motors
6 Operating Instructions, 04/2010, 610.40075.40b
7 Commissioning ........................................................................................................................................ 39
7.1 Measures prior to commissioning ............................................................................................... 39
7.2 Switching on................................................................................................................................ 42
8 Operation................................................................................................................................................. 43
8.1 Safety guidelines during operation.............................................................................................. 43
8.2 Faults........................................................................................................................................... 44
8.3 Stoppages ................................................................................................................................... 46
9 Servicing.................................................................................................................................................. 47
9.1 Inspection and maintenance ....................................................................................................... 47
9.1.1 Safety information ....................................................................................................................... 47
9.1.2 Maintenance intervals ................................................................................................................. 48
9.1.3 Bearing replacement intervals..................................................................................................... 49
9.2 Corrective maintenance .............................................................................................................. 50
9.2.1 Safety guidelines......................................................................................................................... 50
9.2.2 Removing/Installing the encoder................................................................................................. 51
10 Decommissioning and disposal ............................................................................................................... 53
10.1 Decommissioning........................................................................................................................ 53
10.1.1 Preparing for disassembly........................................................................................................... 53
10.1.2 Dismantling the motor ................................................................................................................. 53
10.2 Disposal....................................................................................................................................... 54
A Appendix.................................................................................................................................................. 55
A.1 Order number Configuration Manual ..........................................................................................55
A.2 Siemens Service Center ............................................................................................................. 55
A.3 Declaration of conformity ............................................................................................................ 57
Index........................................................................................................................................................ 59

1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 7
Introduction 1
1.1 About these operating instructions
These operating instructions describe the motor and explain how to handle the motor from
the delivery to the disposal stage.
Before you start using the motor, you must read these operating instructions to ensure safe,
problem-free operation and to maximize the service life.
These operating instructions complement the relevant SIEMENS configuration manual.
Siemens strives continually to improve the quality of information provided in these operating
instructions. If you find any mistakes or would like to offer suggestions about how this
document could be improved, please contact the Siemens Service Center.
Always follow the safety instructions and notices in these operating instructions. The warning
notice system is explained on the rear of the inside front.
Text format features
In addition to the safety-related notices and instructions which you must read, you will find
the text in these operating instructions is formatted in the following way:
1. Handling instructions are always formatted as a numbered list. Always perform the steps
in the order given.
● Lists are formatted as bulletted lists.
– Lists on the second level are hyphenated.
Note
A Note is an important item of information about the product, handling of the product
or the relevant section of the document. Notes provide you with help or further
suggestions/ideas.

Introduction
1.1 About these operating instructions
1FT7 synchronous motors
8 Operating Instructions, 04/2010, 610.40075.40b

1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 9
Safety information 2
2.1 General safety information
Safety and commissioning information for converter-fed low-voltage three-phase motors
DANGER
All activities associated with transporting, connecting, commissioning, and maintaining the
motors must be carried out by properly trained, responsible personnel (DIN EN 50110-1;
note IEC 60364).
Failure to follow proper procedures may result in injury or material damage.
Special versions and construction variants may differ with respect to certain technical
aspects. If in doubt, you are strongly advised to contact the manufacturer, specifying the type
designation and serial number (see rating plate), or arrange for any maintenance work to be
carried out by the SIEMENS Service Center.
Systems and machines with converter-fed low-voltage three-phase motors must fulfill the
protective requirements of the EMC Directive.
The machine manufacturer is responsible for ensuring that installation is carried out properly.
The signal and power cables to the motor must be shielded.
The information provided by the converter manufacturer regarding EMC-compliant
installation must be observed.
Proper usage
These motors are designed for use in industrial or commercial systems. They comply with
the EN 60034-1 standards and the relevant associated sections.
WARNING
It is forbidden to install them in hazardous areas unless they are explicitly designed for this.
If more stringent requirements are necessary in special cases (e.g. shock-hazard protection
in non-commercial applications where children are likely to be present), the customer must
implement the relevant measures to ensure that these requirements are fulfilled.
Any alternative requirements specified on the rating plate must be taken into account. The
on-site conditions must comply with the rating plate specifications.
The motors are designed for use in sheltered areas under normal climatic conditions, such
as those found in production halls.

Safety information
2.2 Safety and operating instructions
1FT7 synchronous motors
10 Operating Instructions, 04/2010, 610.40075.40b
2.2 Safety and operating instructions
The safe use of electrical machines
WARNING
Rotating or live parts
Rotating or live parts are dangerous.
Fatal or severe injuries and substantial material damage can occur if the required covers
are removed or if the machines are not handled, operated, or maintained properly.
Covers must only be removed and the motor operated in accordance with the relevant
regulations. The motor must be maintained on a regular basis.
Qualified personnel
These operating instructions only contain the information necessary for ensuring that the
motor is operated by properly trained personnel in accordance with its intended purpose.
Those responsible for plant safety must ensure the following:
● The basic planning work for the system and all work relating to transportation, assembly,
installation, commissioning, maintenance and repairs is carried out by qualified personnel
and checked by responsible, suitably skilled personnel.
● The operating instructions and the motor documentation are available at all times.
● The technical data and specifications relating to installation, connection, ambient and
operating conditions are taken into account at all times.
● The system-specific installation and safety regulations are observed.
● Personal protective equipment is used.
● Unqualified persons must not work on or in the vicinity of these motors at any time.
● If the motors are used outside industrial areas, the installation site must be protected
against unauthorized access by means of suitable protection facilities (e.g. safety fences
and warning signs).
Note
Siemens Service Center
You are advised to contact your nearest Siemens Service Center to request their services
and support for maintenance activities.

Safety information
2.2 Safety and operating instructions
1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 11
Observing the five safety rules
For your personal safety and to prevent material damage when working on the machine,
always observe the safety instructions and the following five safety rules. Apply the five
safety rules in the order stated before starting work on the machine.
1. Disconnect the system
You must also make sure that the auxiliary circuits are disconnected too.
2. Protect against reconnection
3. Make sure that the equipment is de-energized
4. Ground and short-circuit
5. Cover or enclose adjacent components that are still live
When work has been completed, remove/cancel these measures in reverse order.
Thermal hazard
CAUTION
The surface temperature of the motors can exceed 100 °C.
Do not touch hot surfaces.
Temperature-sensitive components (electric cables and/or electronic components) must not
be placed on hot surfaces. If the motors overheat, this can destroy the windings/bearings
and the permanent magnets may become demagnetized.
Only operate the motors in conjunction with effective temperature control.

Safety information
2.2 Safety and operating instructions
1FT7 synchronous motors
12 Operating Instructions, 04/2010, 610.40075.40b
Information about electromagnetic fields
WARNING
Electromagnetic fields
Electromagnetic fields are generated by the operation of electrical power engineering
installations such as transformers, drives, or motors.
Electromagnetic fields can interfere with electronic devices, causing them to malfunction.
For example, the operation of heart pacemakers can be impaired, potentially leading to
personal harm or even death. It is therefore forbidden for persons with heart pacemakers to
enter these areas.
The plant operator is responsible for taking appropriate measures (labels and hazard
warnings) to adequately protect operating personnel and others against any possible risk.
● Observe the relevant nationally applicable health and safety regulations. In Germany,
"electromagnetic fields" are subject to regulations BGV B11 and BGR B11 stipulated by
the German statutory industrial accident insurance institution.
● Display adequate hazard warning notices.
● Place barriers around hazardous areas.
● Take measures, by using shields, for example, to reduce electromagnetic fields at their
source.

1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 13
Description 3
3.1 Product description
1FT7 synchronous motors are permanent-magnet-excited motors with compact dimensions
and a rugged construction. Their design supports easy mounting.
With full digital control for drive systems and encoder technology, they meet the most
stringent requirements in terms of dynamic response, speed setting range, radial
eccentricity, and positioning accuracy. The motors are designed for use with high-
performance machine tools and machines with high requirements as regards dynamic
response and precision (e.g. packaging and printing machines).

Description
3.2 Technical features
1FT7 synchronous motors
14 Operating Instructions, 04/2010, 610.40075.40b
3.2 Technical features
Table 3- 1 Technical features
Motor type Permanent-magnet synchronous motor
Magnet material Rare-earth magnetic material
Insulation of the stator winding according to EN 60034–1
(IEC 60034–1)
Temperature class 155 (F) for a winding
overtemperature of ΔT = 100 K at an ambient
temperature of +40 °C (naturally cooled) or a coolant
temperature of +30 °C (liquid-cooled)
Cooling Natural cooling, forced ventilation, and liquid cooling
Installation altitude according to EN 60034–1 (IEC 60034–1) ≤ 1000 m above sea level, otherwise power derating
Type of construction according to EN 60034–7 (IEC 60034–7) IM B5 (IM V1, IM V3)
Degree of protection according to EN60034–5 (IEC 60034–5) IP65
Temperature monitoring in accordance with EN 60034-11
(IEC 60034-11)
KTY 84 temperature sensor in stator winding
Paint finish Pearl dark gray (similar to RAL 9023)
Drive shaft end according to DIN 748-3 (IEC 60072-1) Smooth shaft (without keyway)
Radial eccentricity, concentricity, and axial eccentricity acc. to
DIN 42955 (IEC 60072-1)
Tolerance N (normal)
Vibration severity grade according to EN 60034–14
(IEC 60034–14)
Grade A is observed up to rated speed
Sound pressure level acc. to DIN EN ISO 1680
Tolerance + 3 dB(A)
Natural cooling:
1FT703 to 1FT706: 65 dB(A)
1FT708 to 1FT710: 70 dB(A)
Forced ventilation: 73 dB(A)
Water cooling:
1FT706: 65 dB(A)
1FT708 to 1FT710: 70 dB(A)
Built-in encoder system for motors without DRIVE-CLiQ
interface
Incremental encoder, sin/cos 1 Vpp, 2,048 S/R 1) with
C and D track (encoder IC2048S/R)
Absolute encoder, 2,048 S/R 1) singleturn, 4096
revolutions multiturn, with EnDat interface
(encoder AM2048S/R)
Built-in encoder system for motors with DRIVE-CLiQ interface Incremental encoder, 22-bit (resolution 4,194,304,
internal encoder 2,048 S/R 1)) + commutation
position, 11-bit (encoder IC22DQ)
Absolute encoder, 22-bit, singleturn (resolution
4,194,304, internal encoder 2,048 S/R 1)) + 12-bit
multiturn (traversing range: 4,096 revolutions)
(AM22DQ)

Description
3.2 Technical features
1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 15
Connection Connectors for signals and power, can be rotated
Options Flange 1 (compatible with 1FT6)
Drive shaft end with feather key and keyway (half-key
balancing)
Integrated holding brake
Degree of protection IP64, IP67
Sealing air connection (only in conjunction with IP67)
Vibration severity grade R
Radial eccentricity, concentricity and axial
eccentricity: Tolerance R
Planetary gearbox, built-on
1) S/R = Signals/revolution

Description
3.3 Rating plate
1FT7 synchronous motors
16 Operating Instructions, 04/2010, 610.40075.40b
3.3 Rating plate
The rating plate contains the technical data relevant to the motor. A 2nd rating plate is
enclosed with the motor when it is supplied.
PNJ
a0RW )7$.1+
1R<)8
0
(QFRGHU,&'4
%UDNH9'&BB
7K&O))
,
51
,
,
8
Q
Q
,3
(1
0DGHLQ*HUPDQ\








  







&
1P
0

1
,1
PD[
1

1
1P
$
$
9
PLQ
PLQ
Figure 3-1 Schematic layout of rating plate
Table 3- 2 Description of the rating plate data
Position Description / Technical data
1 Motor type: Synchronous motors
2 ID no., serial number
3 Stall torque M0 [Nm]
4 Rated torque MN [Nm]
5 Temperature class
6 Code, encoder type
7 Holding brake data: Typical, voltage, power consumption
8 Standards and regulations
9 Stall current I0 [A]
10 Rated current IN [A]
11 Encoder version
12 Motor version
13 Motor weight m [kg]
14 2D code
15 Degree of protection
16 Induced voltage at rated speed VIN [V]
17 Rated speed nN [rpm]
18 Maximum speed nmax [rpm]
19 SIEMENS motor type/order number

Description
3.4 Structure
1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 17
3.4 Structure
3.4.1 Regulations
The motors comply with the following regulations acc. to IEC/EN 60034:
Table 3- 3 Regulations that have been applied
Characteristic Standard
Dimensions and operating performance IEC/EN 60034-1
Degree of protection (1) IEC/EN 60034-5
Type of construction (1) IEC/EN 60034-7
Terminal markings IEC/EN 60034-8
Noise emission IEC/EN 60034-9
Temperature monitoring IEC/EN 60034-11
Vibration severity grades IEC/EN 60034-14
(1) The degree of protection and type of construction of the motor are stamped on its rating plate.
The three-phase motors comply with the relevant sections of EN 60034 and EN 60204-1.
Three-phase motors comply with Low-Voltage Directive 2006/95/EC. Motors which have
"UR" stamped on their rating plates comply with UL regulations.
Low-voltage motors are components designed for installation in machines in accordance
with the Machinery Directive. They must not be commissioned until it has been verified that
the end product complies with this directive (also take EN 60204-1 into account).
Note
Make sure that your end product is in compliance with all of the applicable legislation! The
applicable national, local, and system-specific regulations and requirements must be taken
into account.
3.4.2 Types of construction
The motor is designed as an IM B5 (IM V1, IM V3) type of construction.
3.4.3 Degree of protection
1FT7 motors can be designed to give IP64, IP65, or IP67 degree of protection. The degree
of protection of the motor is specified on the rating plate.
The fans for forced-ventilation motors are designed to give IP54 degree of protection.

Description
3.4 Structure
1FT7 synchronous motors
18 Operating Instructions, 04/2010, 610.40075.40b
3.4.4 Environmental conditions
The following temperature ranges apply for natural-cooled and forced-ventilation motors.
● Permissible temperature range during operation: T = -15 °C to +40 °C
● Permissible temperature range during storage: T = -20 °C to +70 °C
For deviating conditions (ambient temperature > 40 °C or installation altitude > 1,000 m
above sea level) the permissible torque/power must be derived from the table below.
Ambient temperatures and installation altitudes are rounded-off to 5 °C or 500 m
respectively.
Table 3- 4 Power derating as a function of the installation altitude and ambient temperature
Ambient temperature in °C Installation altitude above
sea level [m] < 30 30 - 40 45 50 55
1,000 1.07 1.00 0.96 0.92 0.87
1,500 1.04 0.97 0.93 0.89 0.84
2,000 1.00 0.94 0.90 0.86 0.82
2,500 0.96 0.90 0.86 0.83 0.78
3,000 0.92 0.86 0.82 0.79 0.75
3,500 0.88 0.82 0.79 0.75 0.71
4,000 0.82 0.77 0.74 0.71 0.67
3.4.5 Cooling
Natural cooling
The rated data only applies when the ambient temperature does not exceed 40 °C (104 °F)
as a result of the installation conditions.
To ensure sufficient cooling, a minimum clearance of 100 mm from adjacent components
must be observed on three sides.

Description
3.4 Structure
1FT7 synchronous motors
Operating Instructions, 04/2010, 610.40075.40b 19
Forced ventilation
This cooling method is implemented by means of a separate ventilation module equipped
with a ventilator that operates independently of the motor. The fan is available with degree of
protection IP54.
NOTICE
Steps must be taken to ensure that the motor is always operated in conjunction with the
separately driven fan.
The motors must be arranged in such a way that the cooling air can flow in and out without
obstruction and that the minimum clearance s between the inlet/outlet air openings and
adjacent components is maintained (see "Minimum clearance" diagram below).
V
s A minimum clearance of 30 mm applies for AH 63 and AH 80.
A minimum clearance of 50 mm applies for AH 100.
Figure 3-2 Minimum clearance s
Steps must be taken to ensure that hot outlet air cannot be drawn back into the system. The
direction of air flow is from the non-drive end (NDE) to the drive end (DE). The fan may only
be operated with normal ambient air, as air containing chemical or conductive impurities
could cause the fan to fail prematurely. Deposits from contaminated air could result in poor
heat transfer at the motor or could cause the cooling-air duct to become clogged, leading to
an overheated motor.
WARNING
Danger of being drawn into the machine
There is a danger of being drawn into the machine (by means of hair, ties, loose items, etc.)
at the air inlet. Suitable protective measures must be taken to guard against this: wear a
hairnet, take off ties, keep clear of the intake area, etc.

Description
3.4 Structure
1FT7 synchronous motors
20 Operating Instructions, 04/2010, 610.40075.40b
Water cooling
The motor can only be operated in a closed cooling-water circuit with a cooling unit. The
motor is connected to the cooling circuit by means of two female threads at the rear of the
motor. The inlet and outlet connections can be freely selected.
Table 3- 5 Technical data relating to water cooling
Cooling water connection G1/4"
1FT706x 3 l/min
1FT708x 4 l/min
Cooling water flow
1FT710x 5 l/min
Max. pressure at inlet Max. 6 bar
1FT706x < 0.3 bar for minimum cooling water flow
1FT708x < 0.3 bar for minimum cooling water flow
Pressure drop between inlet and outlet
1FT710x < 0.25 bar for minimum cooling water flow
Minimum cooling water inlet temperature Tcooling > Tambient - 5 K
Maximum cooling water inlet temperature, without
derating
≤ 30 °C, higher values will cause derating
Only water with an appropriate quantity of additives to protect against corrosion and
minimize the growth of algae can be used as a coolant. Other coolants (e.g. cooling-
lubricating medium, water-oil mixtures with 10% oil and higher) may result in derating.
If there is a risk of frost, preventive measures must be taken during operation, storage, and
transportation (anti-freeze, emptying the cooling circuit and blowing it out with air, etc.). Use
and concentration of the anti-freeze according to information provided by the manufacturer.
Different anti-freeze agents should not be mixed.
A filter (100 µm) must be installed in the inlet pipe to protect the motor against
contamination. Pipes and valves can be made out of brass, stainless steel, or plastic.
However, if different materials are used in close proximity to one another, then the insulation
rating must be taken into account, which is why zinc must not be used in cooling circuits.
If a restrictor is needed to limit the flow of coolant, it is best to install it downstream of the
motor. It must not be installed directly in front of the inlet because the effects of cavitation
may damage the motor.
The values specified for the cooling water correspond to the requirements for a closed
cooling circuit. Not all of the specified concentrations will occur in the cooling water at the
same time.
