1 About this document
Goal and purpose
This document contains information required to mount the radio gateway
FDCW241.
Prerequisites:
● The installation location of the radio gateway has been established.
● Mounting should be performed by a specialist in compliance with safety
regulations.
You will find more information on the radio gatewayFDCW241 in document
A6V10227639.
Intended use
The radio gateway FDCW241 must only be used on a FDnet/C-NET detector line
in a fire detection system FS20/FS720.
● Specialist electrical engineering knowledge is required for installation.
● Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.
Applicable documents
Document ID Title
A6V10227631 Planning Radio fire detection system SWING
A6V10227639 Technical manual Radio gateway FDCW241
A6V10271323 Data sheet SWING Neural radio fire detector FDCW241,
FDOOT271, FDM273, FDM275, FDM275(F)
About this document 1
A6V10227641_h_en_-- 5 | 20

2 Mounting/Installation
2.1 Mounting
AB
C
2
1
3
4
5
5
Figure 1: Installing the radio gateway
1 Housing cover
2 Screw
3 Lock
4 Strain relief fastenings
5 Cable entries
wYou have the radio gateway, battery pack, fixing screws, and cable tie to hand.
wYou have the device location plan to hand.
wThe connection cable has a conductor cross-section of 0.2…1.5mm².
wThe lines to the installation location are installed.
wTwo fixing screws (Ømax.4.3mm) are to hand.
1. Determine the installation location:
– The housing must be positioned in accordance with the planning
specifications (make sure there is a wide radio range and that the housing
can be accessed easily).
– Make sure there is enough space for you to open the housing cover easily.
– The housing may be installed in any appropriate position.
2. Open the housing:
– Remove the screw(2)(A).
– Using a screwdriver to press the lock(3) into the housing(B) and unlock
the housing cover(1).
– Lift the housing cover(1) and remove it.
3. Remove the adhesive label bearing the serial number from the back box and
use it to mark the installation location on the device location plan.
4. In the back box, break out the plastic for the cable entry (5):
– Openings in the supporting surface for recess-mounted cables
– Openings in the narrow side for surface-mounted cables
5. Insert the cables into the back box.
6. Mount the back box, without the battery pack, on a flat surface using two
screws (Ømax.4.3mm) at the mounting points (see
'Master gauge for recesses [➙18]' chapter). One screw at the mounting point
is sufficient for fixing in housing FDCH221.
Mounting/Installation
Mounting
2
6 | 20 A6V10227641_h_en_--

7. Fasten the cable using a cable tie as strain relief (4).
8. Label the battery pack with the date.
9. Insert the battery pack and check the position of the battery cable. Do not
connect the battery pack until you are ready to commission the radio cell.
aThe radio gateway is installed.
Mounting/Installation
Mounting 2
A6V10227641_h_en_-- 7 | 20

2.2 Mounting in housing FDCH221
The radio gateway can be installed in a separate housing FDCH221. The housing
protects the radio gateway from dirt and dust.
Ø max. 4.8 mm
1 2 3 4 5
Figure 2: Installing housing FDCH221
1 Cable entry 4 Screws for securing the housing
2 Cables 5 Screws for housing cover
3 Screw for radio gateway
Proceed as follows to install the radio gateway in housing FDCH221:
1. Break out the required cable entries(1) on the housing.
2. Install the housing with screws(4) on a level surface.
3. Insert the cables(2). If necessary, fix the cables using M20x1.5 cable glands
or use a different cable entry.
4. Remove the housing cover from the radio gateway and dispose of it in an
environmentally-friendly manner.
5. Install the radio gateway in the housing using the fixing screw(3) provided.
6. Connect the radio gateway.
7. Close the housing using the screws(5) provided.
aThe radio gateway is now installed in housingFDCH221. The radio gateway
indicators can be viewed through the window of the housing.
Mounting/Installation
Mounting in housing FDCH221
2
8 | 20 A6V10227641_h_en_--

2.3 Connecting the radio gateway
● Specialist electrical engineering knowledge is required for installation.
● Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.
Once all the radio devices of a radio cell have been logged on to the radio
gateway(B) in battery mode (A), the radio gateway can be connected to the FDnet/
C-NET detector line(C).
AFC20xx
FC72x
SWING
FDCW241
BFC20xx
FC72x
SWING
FDCW241
CFC20xx
FC72x
SWING
FDCW241
Figure 3: Connecting the radio cell to the detector line
++ __ +_
++ __
+-+- +-
1111
Figure 4: Connections on radio gateway FDCW241
1 detector line terminal strip
The radio gateway 'FDCW241' automatically assigns the additional, virtual address
'FDCL221v' as a line separator. When you assign the connections, you determine
the order in which the devices are read in at the control panel.
Mounting/Installation
Connecting the radio gateway 2
A6V10227641_h_en_-- 9 | 20

The following topologies are possible:
Radio cell as LOOP
1
2
X1
LOOP1_2+
LOOP1_2-
3
4
LOOP1_1+
LOOP1_1-
-
+
-
+
FC20xx
FC720x
1
2
X1
LOOP1_2+
LOOP1_2-
3
4
LOOP1_1+
LOOP1_1-
-
+
-
+
++ __ +_
+-+- +-
++ __ +_
+-+- +-
FC20xx
FC720x
Figure 5: Loop connection
Radio cell as stub
Figure 6: Stub connection only
Mounting/Installation
Connecting the radio gateway
2
10 | 20 A6V10227641_h_en_--

Radio cell as sub-stub on loop
Figure 7: Sub-stub on loop connection
Wiring connections
NOTICE
Failure of the electrical connection
Damage to the screw terminals or contact problems may lead to faults in the
electrical connection. If the conductor cross-sections you want to connect to the
radio gateway are larger than 1.5mm², the screw terminals may become
damaged or contact problems may arise.
● Use the connection terminal DBZ1190-AB for cables with a conductor cross-
section of 1.5…2.5mm².
● Obtain a corresponding terminal from the customer for even larger cross-
sections. The terminal can be positioned inside the housing.
wThe radio cell is in battery mode.
wThe detector line cable has a wire diameter of 0.2…1.5mm².
wThe detector line terminal strip is not inserted.
wThe 2-pin terminal strip must not be connected.
1. Wire the detector line terminal strip in accordance with the required topology.
Do not insert the detector line terminal strip until the radio cell has been
commissioned and is about to be connected to the detector line.
2. Switch the detector line off.
3. Connect the socket strip to the radio gateway.
4. Switch the detector line on.
5. Snap the housing cover on and screw it down tight.
aThe radio cell is now set up and ready for commissioning via the control panel.
Mounting/Installation
Connecting the radio gateway 2
A6V10227641_h_en_-- 11 | 20

3 Details for ordering
3.1 Radio gateway FDCW221
● For the SWING radio fire detection system
● For fire detection installations
'Sinteso'/'Cerberus PRO'
● Power supplied by battery pack BAT3.6-10
and detector line
● Compatible with:
– FDOOT271
– FDM273
– FDM275
– FDM275(F)
● Can be configured using MCL-USB adapter
(radio) FDUZ227 with SWING tool FXS2061
● Order number: S54370-F11-A1
3.2 Connection terminal DBZ1190-AB
● Auxiliary terminal for connecting cables
● For T-branches of additional cabling, e.g., for
cable shielding, detector heating units,
sounder base, external alarm indicators, etc.
● For conductor cross-sections of 0.5…2.5mm²
● 3poles
● Order number: BPZ:4942340001
3.3 Battery pack BAT3.6-10
● For supplying radio devices and the radio
gateway with power
● Lithium batteries
– BAT3.6-10 LI-SOCl2 battery pack 3.6V,
10Ah
● Batteries with battery cable
● Connector system with protection against
polarity reversal
● Inscription field for commissioning date
● Compatible with:
– Radio gateway FDCW241
– Radio manual call point FDM273
– Radio manual call point FDM275
– Radio manual call point FDM275(F)
– Radio fire detector FDOOT271
● Order number: S54370-Z11-A1
Details for ordering
Radio gateway FDCW221
3
12 | 20 A6V10227641_h_en_--

3.4 Housing FDCH221
● To protect against dust and wetness
● Compatible with:
– Multi line separator module FDCL221-M
– Input module FDCI22x(-CN)
– Input/output module FDCIO22x(-CN)
– Output module FCA1209‑Z1
– Radio gateway FDCW241
– Zone module, external powered FDCI223,
FDCI723
– Sounder module FCA2005-A1
● Order number: S54312-F3-A1
3.5 Housing base FDCH271
● Housing base for radio gateway
● Order number: S54370-N45-A1
3.6 Housing cover FDCH272
● Housing cover for radio gateway
● Order number: S54370-N46-A1
Details for ordering
Housing FDCH221 3
A6V10227641_h_en_-- 13 | 20

3.7 MCL-USB (radio) adapter FDUZ227
● For connecting FDnet/C-NET devices to a
personal computer
● Signals can be transmitted to SWING radio
devices via radio
● Interface converter for USB on MC link
● Compatible with:
– Floor repeater terminal FT2010
– Floor repeater display FT2011
– Radio gateway FDCW221 and FDCW241
– Detector exchanger and tester FDUD292
– Intelligent detector tester FDUD293
– Line tester FDUL221
– Radio manual call point FDM27x
– Radio fire detector FDOOT271
● You will find more information in
documentA6V10347735
● Order number: S54323-F106-A1
Details for ordering
MCL-USB (radio) adapter FDUZ227
3
14 | 20 A6V10227641_h_en_--

4 Specifications
Unless otherwise mentioned, the following data applies:
Temperature = 25°C
Air pressure = 1000hPa (750Torr)
You will find information on approvals on the data sheet for the device.
4.1 Technical data
You will find information on approvals, CE marking, and the relevant EU directives
for this device (these devices) in the following document(s); see 'Applicable
documents' chapter:
● Document A6V10271323
Detector line Operating voltage DC12…33V
Operating current Typ.1mA (0.6…25mA)
Maximum current connection factor 16
Quiescent current connection factor 6
Address connection factor 2+n*1(n = number of radio devices)
Separator connection factor 1
Protocol FDnet/C-NET
Compatibility See 'List of compatibility'
Design ● Inherently short-circuit-proof
● Protected against polarity reversal
● Protected against overvoltage
Line separator Line voltage:
● Nominal DC32V (= Vnom)
● Minimum DC12V (= Vmin)
● Maximum DC33V (= Vmax)
Voltage at which the line separator opens:
● Minimum DC7.5V (= VSOmin)
● Maximum DC10.5V (= VSOmax)
Permanent current when switches
are closed
Max.1.5A (= ICmax)
Switching current (e.g., in the event
of a short-circuit)
Max.2A (= ISmax)
Leakage current when switches are
open
Max.1mA (= ILmax)
Serial impedance when switches are
closed
Max.0.4Ω (= ZCmax)
Specifications
Technical data 4
A6V10227641_h_en_-- 15 | 20

Radio Number of radio devices per radio
gateway as loop
Max. 30
Number of radio devices per radio
gateway as stub
Max. 30
Sending/receiving aerials Dual band aerial
Radio transmission:
● Frequency range 433.05…434.79MHz in band 44b¹
868…870MHz in band 48, 49, 50, 54, and
56b¹
● Channel grid 50kHz
● Number of channels 27 in 868MHz band
20 in 433MHz band
● Transmitting power ≤10mWERP in band 44b and 49¹
Type 10 (max. ≤25) mW ERP in band 48,
50, 54, and 56b¹
● Range: See document A6V10227631
¹ COMMISSION IMPLEMENTING DECISION (EU) 2019/1345 of 2 August 2019
amending Decision 2006/771/EC updating harmonised technical conditions in
the area of radio spectrum use for short-range devices (notified under
document C(2019) 5660)
Top band Bottom band
Channel Frequency [MHz] Channel Frequency [MHz]
12 868.325 144 433.425
14 868.375 146 433.475
16 868.425 148 433.525
18 868.475 150 433.575
20 868.525 152 433.625
22 868.575 154 433.675
26 868.675 156 433.725
30 868.775 158 433.775
32 868.825 160 433.825
34 868.875 162 433.875
36 868.925 164 433.925
38 868.975 166 433.975
40 869.025 168 434.025
42 869.075 170 434.075
44 869.125 172 434.125
46 869.175 174 434.175
56 869.425 176 434.225
58 869.475 178 434.275
60 869.525 180 434.325
62 869.575 182 434.375
64 869.625
68 869.725
Specifications
Technical data
4
16 | 20 A6V10227641_h_en_--

Top band Bottom band
Channel Frequency [MHz] Channel Frequency [MHz]
70 869.775
72 869.825
74 869.875
76 869.925
78 869.975
Battery pack BAT3.6-10 Lithium battery pack BAT3.6-10 LI-SOCl2 battery pack 3.6V,
10Ah
Service life Over 6years in normal operation
If the normal detector line power supply
fails, approx.1week
Battery voltage monitored Yes
Weight 0.093kg
Connections Detector line:
● Design Screw terminals on plug
● Conductor cross section 0.2…1.5mm²
MC link:
● Design 3.5 mm jack socket
Ambient conditions Operating temperature -10…+55°C
Storage temperature -30…+75°C
Air humidity, non-condensing ≤95% rel.
Protection category (IEC60529):
In housing FDCH221:
● IP40
● IP65
Electromagnetic compatibility:
100kHz…2.5GHz 30V/m
Mechanical data Weight without battery pack 0.154kg
Housing material Acrylonitrile-butadiene-styrene (ABS)
Color ~RAL9010,pure white
Standards European standards ● EN54-17
● EN54-18
● EN54-25
● EN300220-2
Specifications
Technical data 4
A6V10227641_h_en_-- 17 | 20

4.2 Dimensions
Radio gateway FDCW241
167
89 28
4.3 Master gauge for recesses
7
6
116.7
44.5
39.5 10
3.6
44.5
3.6 3.6
142.5
50.3
39.5
11.5
Specifications
Dimensions
4
18 | 20 A6V10227641_h_en_--

4.4 Environmental compatibility and disposal
This equipment is manufactured using materials and procedures
which comply with current environmental protection standards as
best as possible. More specifically, the following measures have
been undertaken:
● Use of reusable materials
● Use of halogen-free plastics
● Electronic parts and synthetic materials can be separated
Larger plastic parts are labeled according to ISO11469 and
ISO1043. The plastics can be separated and recycled on this
basis.
The device is considered an electronic device for disposal in
accordance with the European Guidelines and may not be disposed
of as domestic garbage.
● Dispose of the device through channels provided for this
purpose.
● Comply with all local and currently applicable laws and
regulations.
Specifications
Environmental compatibility and disposal 4
A6V10227641_h_en_-- 19 | 20

Issued by
Siemens Switzerland Ltd
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
[phone]
www.siemens.com/buildingtechnologies
© Siemens Switzerland Ltd, 2012
Technical specifications and availability subject to change without notice.
A6V10227641_h_en_--
