Siemens MindConnect Nano User manual

1. Mount MindConnect Nano
Mounting positions permitted vertical or horizontal.
Please make sure there’s enough space around the device
above: ≥ 50 mm, below: ≥ 100 mm
4. Load new fi rmware on MindConnect Nano - if necessary
If your box was already connected to MindSphere V2, you have to set
MindConnect Nano to factory settings and upgrade it to a new V3
fi rmware. For this procedure see „Getting
Connected to MindSphere“ or https://support.industry.siemens.com/cs/
ww/en/view/109745561
6. Download Confi guration to USB
1. Click on next to „Status“.
2. Click on „Download Onboarding Key“.
3. Download the confi guration fi le for the asset and copy it to the root
directory of your USB stick. Note: Use USB stick with one FAT32
formatted partition. Confi guration fi le is valid only for seven days.
7. Plug USB into MindConnect Nano
1. Power LED (PC ON/WD) of MindConnect Nano is green.
2. Insert the USB stick with confi gured asset data into the MindConnect
Nano.
3. The MindConnect Nano automatically reads the USB stick data (RUN/
STOP/L1 LED blinks orange), followed by a restart.
4. MindConnect Nano then attempts to establish connection to
MindSphere.
5. After a few seconds the RUN/STOP/L1 LED should be green and user
interface has the state Onboarded, which means it is connected
to MindSphere. (If the onboarding is not successful, see „Getting
Connected to MindSphere“).
6. Now remove USB stick from the MindConnect Nano.
5. Onboarding Process
1. Login
Access the MindSphere
Launchpad by clicking on
the link provided via E-Mail by
MindSphere.
2. Asset Manager
Open the Asset Manager and
create a new asset from type
MindConnectNano
(see „Getting Connected to
MindSphere“).
3. Enable Connection to
MindConnect Element
Enter the MindConnect Nano
InfoID. The rating plate is
located on the back panel of
the device.
4. Confi guring network settings
1. Select the asset in the „Asset“
tab.
2. Click on the asset icon e.g.
MindConnect Nano.
3. Click on next to „Status“.
4. Activate DHCP if a DHCP server
is available in your company
network or enter the respective
information for static IP
address.
5. Enter the proxy data area
„Communication Settings“ if
necessary and click „Save“.
2. Connect Power Supply
1. Connect the protective earth (see „Getting Connected to
MindSphere“)
2. Secure the cables
3. Connect the power supply
3. Connect with your Network
1. Connect the internet to the X1P1 port for MindSphere
connection (see „Getting Connected to MindSphere“)
2. Connect the Ethernet to the X2P1 port for connection to
the plant network
3. Switch on the device

siemens.com/mindsphere
MindConnect Nano
Quick Start
8. Use MindSphere
Once MindConnect Nano is onboarded, you can confi gure
your asset for data collection. After you have confi gured
asset data, MindConnect Nano starts the data acquisition.
You can now start the Fleet Manager to see your machine data.
If you have any problems with MindConnect Nano, consult the LOG
fi les in the “Files” extension of Fleet Manager. This extension provides
information that can be helpful for troubleshooting.
For additional information go to „Getting Connected to
MindSphere“.
Requirements
• PC with internet connection for MindSphere confi guration
• Browser for online user interface, supporting HTML5 (e. g. Firefox,
Google Chrome, Safari, Opera)
• Login data for MindSphere Access provided by Siemens after orde-
ring MindSphere
• Power Supply, 24 V DC
• Standard USB stick, one partition, FAT32 formatted
Further Information
• Getting Connected to MindSphere
(https://documentation.mindsphere.io/index.html#/kiosk/en)
• MindSphere – FAQs (https://www.mindsphere.io/community)
• Industry Online Support:
https://support.industry.siemens.com
