Faceplate optiset E basic
These operating instructions describe
all functions and operating proce-
dures.
Those operations you can use is de-
pend on the individual class of service
of your telephone and on the configu-
ration of your system.
When cleaning your telephone, do
not use abrasive cleaning agents or
chemicals that attack plastic.
Your service technician can customize
the default assignment to meet your
preferences and requirements follow-
ing order placement.
1)
2)
3)
4)
6)
5)
Handset
Speaker (ringing tones/open listening)
Keys for telephone settings
Eight fixed function keys
Default assignment
– Consultation
– Redial
– Message Waiting
– Callback
– Speed Dial
– Mute
– Speaker
– Release
LEDs
Keypad
1)
2)
3)
4)
5)
6)

Contents
3
Faceplate optiset E basic .......................................................................... 2
Hicom 150 E Office and optiset E ............................................................. 5
Symbols ...................................................................................................... 5
Settings....................................................................................................... 6
Setting the Ringer Volume ...........................................................................6
Setting the Ringer Pitch ...............................................................................6
Setting the Receiving Volume ......................................................................6
Answering Calls ......................................................................................... 7
Handsfree Answer ....................................................................................... 7
Making Calls ............................................................................................... 7
Reserve Trunk .............................................................................................. 8
Function Keys............................................................................................. 8
Consultation Hold ......................................................................................... 8
Call Transfer ................................................................................................. 9
Number Redial ............................................................................................. 9
Retrieving Message ................................................................................... 10
Callback, Automatic .................................................................................... 10
Dialing Speed Dial Numbers ......................................................................11
Mute On/Off ............................................................................................... 11
Open Listening ........................................................................................... 12
Release ...................................................................................................... 12
Boss Ringing (Only if Configured) ..............................................................12

4
A
ccepting a Waiting Call .............................................................................13
A
ccount Code .............................................................................................26
A
ctivate Door Opener function ...................................................................32
A
ctuating Relays .........................................................................................29
A
ppointment Reminder ..............................................................................31
A
ssign Station Number (Not for U.S.) .........................................................27
A
ssociated Dialing ......................................................................................18
A
ssociated Service .....................................................................................17
A
utomatic call distribution (UCD) ................................................................15
Call Forwarding ...........................................................................................34
Call Pickup - Directed ..................................................................................33
Call Pickup - Group .....................................................................................33
Call Ringing Group ......................................................................................28
Call Waiting .................................................................................................13
Caller ID Suppression (for outbound external call; only if requested from carr
er) ...............................................................................................................27
Central COS Change ...................................................................................36
Conference, five-Party ................................................................................22
Do Not Disturb ............................................................................................14
DTMF Dialing (Tone Dialing) .......................................................................23
Hunt Group/Group Call ...............................................................................28
Log On CMI Unit/Ready to Log On (Not for U.S.) .......................................24
MSN Trunk Forwarding (Only in a Multi-Device Connection with Release 2.2
or Later, Not for the U.S.) ...........................................................................35
Night Answer ..............................................................................................24
Open Door ..................................................................................................32
Override ......................................................................................................18
Park Call ......................................................................................................25
Phone Test .................................................................................................20
Preventing/Allowing Call Waiting ................................................................14
Radio Paging (Not for U.S.) .........................................................................26
Release Trunk .............................................................................................23
Relocate Procedure ....................................................................................20
Reset All Services .......................................................................................19
Retrieve Line ..............................................................................................36
Room Monitoring (Baby Phone) .................................................................19
Sending a Message Text ............................................................................21
Silent Monitor (U.S. Only) ...........................................................................24
Speaker Call ................................................................................................20
Station COS Changeover (Locking/Unlocking Telephone) ..........................30
T
elephone Data Service ..............................................................................31
T
oggle (between two parties) .....................................................................23
T
race Call (only if requested from carrier, not for U.S.) ..............................21
T
runk Flash, Recall to Network ...................................................................29
Accessing Functions Via Codes............................................................... 13
Meaning of Functions.............................................................................. 37
Overview of Codes................................................................................... 41
Speed Dial Destinations.......................................................................... 44

5
Hicom 150 E Office and optiset E
You can use your telephone to access the functions of the
Hicom®150 E Office communication system (Release 2.0 and 2.2) via func-
tion keys and codes.
Symbols
Symbol Meaning
Lift the handset (off-hook).
Speak.
Replace the handset (on-hook).
Dial the station number or code.
Press the specified keys.
You hear a tone.
A long tone (positive confirmation tone) con-
firms that you have successfully activated a
function or procedure.
A short tone (negative confirmation tone) indi-
cates that the function or procedure was re-
jected.
Press the key.
Press the illuminated key.
Press the flashing key.
(
Æ
7) Reference to a page where more information
can be found.
2 4
Contents/Symbols

6
Settings
Setting the Ringer Volume
The telephone is idle
Setting the Ringer Pitch
The telephone is idle
Setting the Receiving Volume
You are conducting a call
Press one of these keys.
Enter 1.
You hear a ringing tone.
Adjust the volume.
To save the setting
press both keys simultaneously.
or
1
or
simultaneously
Press one of these keys.
Enter 2.
You hear a ringing tone.
Adjust the pitch.
To save the setting
press both keys simultaneously.
or
2
or
simultaneously
Adjust the volume.
To save the setting:
Press both keys simultaneously.
or
simult.

7
Answering Calls
Your telephone rings
Handsfree Answer
You can hear an alerting tone and an an-
nouncement from a colleague (=speaker call).
You can answer the caller (=handsfree an-
swer).
Making Calls
Lift the handset.
Speak.
Lift the handset.
Speak.
Lift the handset.
Internal: Dial the station number.
External: Dial the external code and external
number.
You can also make calls without lifting
the handset. When you dial the first
digit, open listening is activated auto-
matically. When the other party an-
swers, lift the handset. If the other
party does not answer or is busy,
press the Speaker or Release key.
Settings / Answering Calls / Making Calls

8
Reserve Trunk
Function Keys
You can use the fixed function keys on your
optiset E basic to activate the following func-
tions without having to enter codes.
Consultation Hold
Initiating consultation hold (you are
conducting a call)
Ending consultation hold
Lift the handset.
Dial the external code and external number.
If configured, you can wait five seconds, until
the busy signal stops, when an external line is
busy and thus reserve this line for yourself.
Then replace the handset.
Once the line is free, your telephone will ring.
When you lift the handset, you hear the exter-
nal dial tone. Now dial the external number.
Press the Consultation key.
Dial the number of the other party (internal/
external dialing
Æ
7).
Conduct a consultation call (the first call is on
hold.
Consultation
Press the Consultation key
and continue with the first call.
or (dep. on configuration)
Press the Consultation key twice
and continue with the first call.
Consultation
Consultation

9
Call Transfer
You are engaged in a call and would like to
transfer it to another party
You are engaged in a call and would like to
announce and transfer it to a group of
users with a speaker call (Release 2.2 and
later)
Number Redial
Press the Consultation key.
Dial the telephone number of the other party
(internal/external dialing
Æ
7).
Replace the handset: either before the other
internal party answers or wait until after the
other internal/external party answers.
Consultation
Press the Consultation key.
Enter the code * 8 0.
Dial the group’s station number and an-
nounce the call..
After a member of the group answers:
replace the handset to transfer the call.
Lift the handset.
Press the Redial key.
The last external number called is redialed.
Consultation
8 0
Redial
Function Keys

10
Retrieving Message
A message text has been recorded for you
Callback, Automatic
Initiating callback (maximum of two; five
in Release 2.2 and later)
(Party is busy or is not answering):
Taking a call (your telephone rings)
Canceling (all callback requests)
Lift the handset. You hear a special dial tone
or an announcement.
Press the illuminated Message Waiting key.
A connection is made with the party who sent
the message text or to the voice mail system.
or
Enter the code #683.
A connection is made with the party who sent
the message text or to the voice mail system.
Message Waiting
6 8 3
Press the Callback key; the LED lights up.
or
Press the Consultation key.
Enter the code *58.
The system or user calls you back automati-
cally as soon as this party is available or has
used his/her telephone again.
Callback
Consultation
5 8
Lift the handset; the other party is called.
Lift the handset.
Enter the code #58.
5 8

11
Dialing Speed Dial Numbers
Storing station speed dial numbers
Mute On/Off
Deactivating the microphone during a call
(mute on)
Lift the handset.
Press the Speed Dial key.
or
Enter the code *7.
Enter a speed dial number:
*0 - *9 for station speed dial numbers.
000 - 299 or 000 - 999 for system speed dial
numbers (consult System Support).
Speed Dial
7
Lift the handset.
Enter the code *92.
Select a memory location (*0 - *9).
You can write down the assignment in the ta-
ble at the end of these operating instructions.
Dial the external code and external number
(wait five seconds).
9 2
to
0 9
Press the Mute key; the LED lights up.
or
Press the Consultation key.
Enter the code *52.
Mute
Consultation
5 2
Function Keys

12
Activating the microphone (mute off)
Open Listening
While engaged in a call and using the handset,
you can activate and deactivate the speaker so
that other people in the room can temporarily
listen to the call.
Activating the speaker
Deactivating the speaker
Release
Releasing a connection or finishing a pro-
cedure
Boss Ringing (Only if Configured)
Activating
Deactivating
Press the illuminated Mute key; the LED goes
out.
or
Press the Consultation key.
Enter the code #52.
Mute
Consultation
5 2
Press the Speaker key; the LED lights up.
Speaker
Press the illuminated Speaker key; the LED
goes out.
Speaker
Press the Release key. The call is cleared or
the procedure is terminated.
Release
Press the Boss Ringing key; the LED lights
up.
Boss Ringing
Press the illuminated Boss Ringing key; the
LED goes out.
Boss Ringing

13
Accessing Functions Via Codes
You can enter codes to access the following
functions.
Call Waiting
Accepting a Waiting Call
You hear a bleep tone during a call
To return to the first call
Lift the handset.
Dial the internal station number.
If the party is busy, wait approximately five
seconds. The party is then called.
Replace the handset (the current call is dis-
connected). Your telephone rings.
Lift the handset.
or
Press the Consultation key.
The first call is on hold.
Enter the code *55, and conduct a call with
the waiting party.
Consultation
5 5
Press the Consultation key, wait two seconds
and resume the first call (the second call is
disconnected).
or (depending on
configuration)
Press the Consultation key twice
and resume the first call (the second call is
disconnected).
Consultation
Consultation
Function Keys / Accessing Functions Via Codes

14
Preventing/Allowing Call Waiting
Preventing call waiting
Allowing call waiting
Do Not Disturb
Activating
Deactivating
Lift the handset.
Enter the code #490.
9 7
Lift the handset.
Enter the code *490.
9 04
Lift the handset.
If do not disturb is already activated
you hear a special dial tone.
Enter the code *97.
9 7
Lift the handset.
Enter the code #97.
9 7

15
Automatic call distribution (UCD)
Logging on at start of duty period
Logging off at end of duty period
Logging off temporarily (unavailable)
Logging back on after temporary logoff
(available)
Lift the handset.
Enter the code *401.
Enter your personal group ID.
4 0 1
Lift the handset.
Enter the code #401.
4 0 1
Lift the handset.
Enter the code #402.
4 0 2
Lift the handset.
Enter the code *402.
4 0 2
Accessing Functions Via Codes

16
Requesting work time (wrap-up time)
Logging back on after work time
Activating UCD night answer
Deactivating UCD night answer
You have (or had) a UCD connection, before
you replace the handset:
Enter the code *403.
4 0 3
Lift the handset.
Enter the code #403.
4 0 3
Lift the handset.
Enter the code *404.
Enter the destination number.
4 0 4
Lift the handset.
Enter the code #404.
4 0 4

17
Associated Service
Activating and deactivating functions for other
telephones.
z
Do not disturb *97/#97
z
Call forwarding *11, *12, *13/#1
z
Advisory messages *69/#69
z
Reset all services #0
z
Message texts *68/#68
z
Night answer *44/#44
z
Caller ID suppression *86/#86
z
Call ringing group *81/#81
z
Hunt group/group call *85/#85
z
Relay on/off *90/#90
z
Changeover on/off (locking/unlocking tele-
phone) *66/#66
z
Activate door opener function *89/#89
Lift the handset.
Enter the code *83.
Enter the internal station number and the
code (such as *97 to activate do not disturb
or #97 to deactivate do not disturb) or enter
the procedure.
8 3
Accessing Functions Via Codes

18
Associated Dialing
Dialing aid for another telephone
Override
Internal party called is busy
Lift the handset.
Enter the code *67.
Enter the internal station number of the party
you want to dial.
Enter the number of the destination station
(external with external code, such as 0 or 9).
6 7
Press the Consultation key.
Enter the code *62.
Consultation
6 2

19
Room Monitoring (Baby Phone)
Activating the telephone to be monitored
Deactivating the telephone to be
monitored
Activating the feature (room monitoring)
Reset All Services
Canceling user-activated functions
z
Call forwarding
z
Call ringing group
z
Caller ID suppression
z
Do not disturb
z
Hunt group
z
Messages received
z
Callback requests (Release 2.2 and later)
Lift the handset.
Place the handset next to the telephone.
Enter the code *88.
8 8
Replace the handset.
Lift the handset.
Enter the internal station number of the tele-
phone in the room that is to be monitored.
Lift the handset.
Enter the code #0.
0
Accessing Functions Via Codes

20
Speaker Call
Relocate Procedure
Logging the telephone off
Logging the telephone on at the relocation
destination
Phone Test
Lift the handset.
Enter the code *80.
Dial the internal station number.
8 0
Lift the handset.
Enter the code *9419.
Pull the telephone plug out of the wall outlet.
9 1 9 4
First, plug the telephone into the wall outlet.
Lift the handset.
Enter the code #9419.
Lift the handset.
Enter the code*940.
Your telephone rings and all LEDs flash.
4 1 99
9 4 0
