SIMATIC HMI
HMI device
Industrial Thin Client ITC1200,
ITC1500, ITC1900, ITC2200
Operating Instructions
04/2013
A5E03474888-02
Preface
Overview
1
Safety instructions
2
Installing and connecting the
device
3
Commissioning the device
4
Assigning device parameters
5
Configuring the server
6
Operating the device
7
Device maintenance and
repair
8
Technical specifications
9
Technical Support
A
Abbreviations
B

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03474888-02
Ⓟ 03/2013 Technical data subject to change
Copyright © Siemens AG 2013.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 3
Preface
Purpose of the operating instructions
These operating instructions provide information based on the requirements defined by DIN
EN 62079 for mechanical engineering documentation. This information relates to the place of
use, transport, storage, mounting, use and maintenance.
These operating instructions are intended for the following user groups:
● Operators
The following chapters are of relevance:
– Overview (Page 9)
– Operating the device (Page 87)
● Administrator
The following chapters are of relevance:
– Overview (Page 9)
– Assigning device parameters (Page 35)
– Configuring the server (Page 81)
● Commissioning engineers
The following chapters are of relevance:
– Overview (Page 9)
– Installing and connecting the device (Page 19)
– Configuring the server (Page 81)
● Maintenance personnel
The following chapters are of relevance:
– Overview (Page 9)
– Device maintenance and repair (Page 97)
Chapter Safety instructions (Page 17) must be particularly observed by all user groups.
Basic knowledge required
General knowledge of automation technology and process communication is needed to
understand the operating instructions.
It is also assumed that those using the manual have experience in using personal computers
and knowledge of Microsoft operating systems.

Preface
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
4 Operating Instructions, 04/2013, A5E03474888-02
Scope of the operating instructions
These operating instructions apply to the following devices:
● SIMATIC ITC1200
● SIMATIC ITC1500
● SIMATIC ITC1900
● SIMATIC ITC2200
The designation "ITC (Industrial Thin Client)" encompasses all of the named devices.
Registered trademarks
The following designations marked with the symbol ® are registered trademarks of
Siemens AG:
● HMI®
● SIMATIC®
● WinCC®
Conventions
The following text notation will facilitate reading this manual:
Notation Scope
"Add screen" Terminology that appears in the user interface, for example
dialog names, tabs, buttons, menu commands
Required input, for example, limits, tag values.
Path information
"File > Edit" Operating sequences, for example, menu commands, shortcut
menu commands
<F1>, <Alt+P> Keyboard operation
Please observe notes labeled as follows:
Note
Notes contain important information concerning the product, its use or a specific section of
the documentation to which you should pay particular attention.
Illustrations in this manual
This documentation includes illustrations associated with the product. These illustrations
may differ from the factory state of the product.
Recycling and disposal
The HMI devices described in these operating instructions can be recycled due to the low
levels of pollutants. Contact a certified disposal service company for environmentally sound
recycling and disposal of your old devices.

Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 5
Table of contents
Preface ...................................................................................................................................................... 3
1 Overview.................................................................................................................................................... 9
1.1 Product description ........................................................................................................................9
1.2 Product package ..........................................................................................................................10
1.3 Layout of the devices ...................................................................................................................11
1.3.1 Interfaces .....................................................................................................................................12
1.4 Accessories..................................................................................................................................13
1.5 Typical applications......................................................................................................................13
1.6 Requirements...............................................................................................................................16
2 Safety instructions ................................................................................................................................... 17
2.1 General safety instructions ..........................................................................................................17
2.2 Security information .....................................................................................................................18
3 Installing and connecting the device ........................................................................................................ 19
3.1 Brief instructions - connecting and starting the device ................................................................19
3.2 Preparing for installation ..............................................................................................................20
3.2.1 Checking the package contents...................................................................................................20
3.2.2 Checking the operating conditions...............................................................................................21
3.2.3 Selecting a mounting position......................................................................................................21
3.2.4 Checking clearances....................................................................................................................22
3.2.5 Preparing the mounting cutout.....................................................................................................22
3.3 Mounting the device.....................................................................................................................24
3.4 Connecting the device .................................................................................................................26
3.4.1 Overview ......................................................................................................................................26
3.4.2 Connection of equipotential bonding ...........................................................................................27
3.4.3 Connecting the power supply.......................................................................................................29
3.4.4 Connecting device to the server ..................................................................................................30
3.4.5 Connecting a USB device ............................................................................................................31
3.5 Installing strain relief ....................................................................................................................31
4 Commissioning the device....................................................................................................................... 33
4.1 Switching on and testing the device ............................................................................................33
4.2 Interrupting and restoring a connection .......................................................................................34
5 Assigning device parameters................................................................................................................... 35
5.1 Possible applications ...................................................................................................................35
5.2 Opening the configuration............................................................................................................35
5.3 Configuration settings of the device.............................................................................................38

Table of contents
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
6 Operating Instructions, 04/2013, A5E03474888-02
5.3.1 Access and structure................................................................................................................... 38
5.3.2 Device data ................................................................................................................................. 40
5.3.3 System settings........................................................................................................................... 41
5.3.4 Network settings.......................................................................................................................... 46
5.3.5 Connections ................................................................................................................................ 50
5.3.5.1 Basics.......................................................................................................................................... 50
5.3.5.2 Setting up client-server connections ........................................................................................... 53
5.3.5.3 Connection settings..................................................................................................................... 54
5.3.5.4 Setting up startup connection...................................................................................................... 56
5.3.5.5 PROFINET basic functions ......................................................................................................... 57
5.3.6 Password settings....................................................................................................................... 58
5.3.7 Desktop settings.......................................................................................................................... 61
5.3.8 Application settings ..................................................................................................................... 64
5.4 Remote configuration of several devices ....................................................................................66
5.4.1 Introduction ................................................................................................................................. 66
5.4.2 Installation ................................................................................................................................... 67
5.4.3 Start............................................................................................................................................. 68
5.4.4 Operation..................................................................................................................................... 69
5.4.4.1 Overview of remote operation..................................................................................................... 69
5.4.4.2 Perform action............................................................................................................................. 74
5.4.4.3 Status .......................................................................................................................................... 75
5.4.4.4 Assigning the IP address ............................................................................................................ 76
5.4.5 Backing up remote configuration ................................................................................................ 77
5.4.6 Assigning a key ........................................................................................................................... 78
5.4.7 Basic settings .............................................................................................................................. 79
6 Configuring the server ............................................................................................................................. 81
6.1 RDP............................................................................................................................................. 81
6.1.1 RDP overview ............................................................................................................................. 81
6.1.2 Administration on the server ....................................................................................................... 82
6.2 VNC............................................................................................................................................. 83
6.3 Sm@rtServer .............................................................................................................................. 84
6.4 SINUMERIK ................................................................................................................................ 85
7 Operating the device................................................................................................................................ 87
7.1 Overview ..................................................................................................................................... 87
7.2 Front operator controls................................................................................................................ 88
7.3 Operating the taskbar.................................................................................................................. 89
7.3.1 Structure and functions of the taskbar ........................................................................................ 89
7.3.2 Starting a connection .................................................................................................................. 91
7.3.3 Changing from one connection to another..................................................................................92
7.3.4 Terminating a connection............................................................................................................ 93
7.4 Operating the on-screen keyboard ............................................................................................. 94
7.5 Operating a USB memory device ............................................................................................... 95

Table of contents
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 7
8 Device maintenance and repair ............................................................................................................... 97
8.1 Cleaning the device front .............................................................................................................97
8.2 Disabling the touch screen...........................................................................................................98
8.3 Calibrating the touch screen ........................................................................................................98
8.4 Spare parts and repairs ...............................................................................................................99
9 Technical specifications......................................................................................................................... 101
9.1 Certificates and approvals .........................................................................................................101
9.2 Directives and declarations........................................................................................................103
9.2.1 Electromagnetic compatibility ....................................................................................................103
9.2.2 ESD guideline ............................................................................................................................104
9.3 Dimensional drawings................................................................................................................106
9.3.1 Dimensional drawings of ITC1200.............................................................................................106
9.3.2 Dimensional drawings of ITC1500.............................................................................................107
9.3.3 Dimensional drawings of ITC1900.............................................................................................108
9.3.4 Dimensional drawings of ITC2200.............................................................................................109
9.4 Technical specifications .............................................................................................................110
9.4.1 General technical specifications ................................................................................................110
9.4.2 Performance data ......................................................................................................................112
9.4.3 Ambient conditions.....................................................................................................................112
9.4.3.1 Transport and storage conditions ..............................................................................................112
9.4.3.2 Operating conditions ..................................................................................................................113
9.4.3.3 Information on insulation tests, protection class and degree of protection................................116
9.5 Description of the ports ..............................................................................................................117
9.5.1 Power supply..............................................................................................................................117
9.5.2 USB............................................................................................................................................117
9.5.3 PROFINET (LAN) 10/100/1000 Mb ...........................................................................................118
A Technical Support.................................................................................................................................. 119
A.1 Service and support...................................................................................................................119
B Abbreviations......................................................................................................................................... 121
Glossary ................................................................................................................................................ 123
Index...................................................................................................................................................... 127

Table of contents
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
8 Operating Instructions, 04/2013, A5E03474888-02

Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 9
Overview 1
1.1 Product description
SIMATIC ITC - the high-performance local thin client solution
Industrial Thin Clients are low-cost HMI terminals that provide local HMI functionality in
plants spread over large areas. In this way, Industrial Thin Clients contribute to an improved
overview, operability, and productivity of plants. In addition, the Industrial Thin Clients also
reduce the total cost of ownership (TCO) by virtue of their extremely easy commissioning,
efficient Ethernet networking, reduced software costs, and minimal service costs.
The Industrial Thin Client always communicates with a host, such as an HMI device,
industrial PC, or server, via the following connection types:
● Web browser functionality
● SIMATIC WinCC Sm@rtServer
● Standard RDP (Remote Desktop Protocol) from Microsoft
● VNC (Virtual Network Computing)
● SINUMERIK connection
The Industrial Thin Client itself requires no installation and no licenses to operate. For
remote configuration, we offer the Management Software Remote Configuration Center at
(as of RCC V2.0). You can also bridge greater distances via Ethernet.
You can do the following from the Industrial Thin Client:
● Display and run web-based content from a web server available on the network (e.g., S7
controller, Intranet/Internet) via the integrated web browser.
● Run WinCC projects on other HMI devices or industrial PCs via Sm@rtServer.
● Run HMI applications (e.g., WinCC), Office applications (e.g., Excel), or SAP directly at
the machine via RDP.
● Operate a PC remotely with VNC (similar to RDP)
● Use the SINUMERIK connection to make the Industrial Thin Client a SINUMERIK Thin
Client Unit (TCU).
Hardware equipment
The device is available with 12", 15", 19", or 22" LCD TFT widescreen display with 16 million
colors. You operate the device via the touch screen or a keyboard/mouse connected to the
two USB ports.
In terms of the mounting cutout (width and height) and design, the Industrial Thin Client built-
in units are compatible with the SIMATIC HMI Comfort Panels of the same size.

Overview
1.2 Product package
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
10 Operating Instructions, 04/2013, A5E03474888-02
Easy commissioning
The Industrial Thin Client merely requires an IP address. For fast on-site commissioning and
diagnostics, the SIMATIC ITC is equipped with a Setup Wizard optimized for touch operation.
Alternatively, the Remote Configuration Center (RCC V2.0 or higher) management software
enables easy, efficient remote configuration and diagnostics of one or more devices. Local
software installation on the device is not necessary. The display and user interface of the
application are provided by the host.
High robustness
As a remote operator terminal without any rotating media (hard drive or fan), you can
operate the Industrial Thin Client on machines having stringent requirements for mechanical
robustness.
1.2 Product package
The following components are included in the scope of delivery of the device:
Designation Figure Quantity
HMI device 1
Installation instructions
(Quick Installation
Guide)
1
Remote Configuration
Center (RCC).
On CD 1
Aluminum mounting clamps 12 ITC1200 Mounting clamps with
threaded pin
Steel mounting clamps 12 ITC1500
ITC1900
ITC2200
Mains terminal 1

Overview
1.3 Layout of the devices
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 11
1.3 Layout of the devices
Front view and side view



① Touch screen
② Recesses for mounting clamps
③ Mounting seal
Bottom view



① "Factory settings" key
② Interfaces
③ Recesses for mounting clamps

Overview
1.3 Layout of the devices
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
12 Operating Instructions, 04/2013, A5E03474888-02
Rear view





① Rating plate
② Cover
③ Interface designation
④ Ground connection
⑤ Fixing elements for strain relief
1.3.1 Interfaces
The following figure shows the interfaces on the device.
  
① Power supply connector
② LAN interface (PROFINET/Ethernet)
③ "Factory settings" key
④ USB ports

Overview
1.4 Accessories
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 13
1.4 Accessories
Accessories are not included in the scope of delivery of the HMI device, but can be ordered
on the Internet at Industry Mall (http://mall.automation.siemens.com).
This section provides information on the scope of accessories available at the time these
operating instructions were written.
Protective films
Designation Order No.
Protective film set for ITC1200 6AV2124-6MJ00-0AX0
Protective film set for ITC1500 6AV2124-6QJ00-0AX0
Protective film set for ITC1900 6AV2124-6UJ00-0AX0
Protective film set for ITC2200 6AV2124-6XJ00-0AX0
Service packages
Designation Order No.
Set of 20 aluminum mounting clamps for ITC1200 6AV6671-8XK00-0AX0
Set of 20 steel mounting clamps for ITC1500, ITC1900, and ITC2200 6AV6671-8XK00-0AX3
Set of 10 mains terminals 6AV6671-8XA00-0AX0
1.5 Typical applications
Industrial Thin Clients can be used as operator terminals in different scenarios. With the
Industrial Thin Client, for example, you can access an HMI device and hence control a work
process. You can also use the Industrial Thin Client to run Office applications on a server, for
example, on a PC and modern web applications.
Typical applications are presented in the following.
Access to a Sm@rtServer
The Industrial Thin Client accesses an HMI device or industrial PC as a Sm@rtServer client
using the SIMATIC WinCC Sm@rtServer option. You are operating and monitoring a WinCC
project (TIA portal). You operate and monitor a WinCC flexible project with the SIMATIC
WinCC Sm@rtAccess option in the same way.
The following figure shows one possible configuration.
&RPIRUW3DQHO ,QGXVWULDO7KLQ&OLHQW
352),1(7(WKHUQHW
$XWRPDWLRQV\VWHP

Overview
1.5 Typical applications
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
14 Operating Instructions, 04/2013, A5E03474888-02
Access to a server via "RDP".
The Industrial Thin Client uses RDP (Remote Desktop Protocol) to access a server, such as
an industrial PC or a PC. The following applications are also possible.
● WinCC/Web Navigator
The Industrial Thin Client uses an Internet browser on the server to access the WinCC
Web Navigator as a Web Navigator client. In this case, the operating system Windows
Server 2003 or 2008 must be installed on the server. For more information, refer to the
documentation for the WinCC/Web Navigator option.
● The Industrial Thin Client accesses an Office application (e.g., MS Excel) or SAP
application on the server. In contrast to the Windows Server operating systems, you can
only operate one screen with Windows XP and Windows 7. The other monitor is always
blocked.
● The Industrial Thin Client accesses an Office application running in Windows Server 2003,
(e.g., MS Excel) or SAP application on the server.
The following figure shows one possible configuration with the Windows Server operating
system on an Industrial PC or a PC.
,QGXVWULDO
7KLQ&OLHQW
352),1(7(WKHUQHW
,QGXVWULDO
7KLQ&OLHQW
,QGXVWULDO
7KLQ&OLHQW
,QGXVWULDO
7KLQ&OLHQW
,QGXVWULDO
7KLQ&OLHQWQ
$XWRPDWLRQV\VWHP
,QGXVWULDO3&V
Access to a server via "VNC"
You use VNC in a similar way as RDP to remotely monitor and run a PC and to monitor its
screen outputs. In contrast to RDP, all clients display the same server screen.
Access to SINUMERIK
The Industrial Thin Client accesses the SINUMERIK system network through the
SINUMERIK connection. The system network configures the Industrial Thin Client to be a
SINUMERIK Thin Client Unit (TCU). You use the TCU for operator control and monitoring of
a SINUMERIK PCU or SINUMERIK NCU.

Overview
1.5 Typical applications
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 15
Access to a web server via "Web"
The Industrial Thin Client displays applications and the content of a web server using the
integrated web browser functionality . Web-based content may be diagnostic or user-specific
web pages of an S7 controller (PROFINET), for example, or content from the
Intranet/Internet.
7&3,3,QWHUQHW
,QGXVWULDO
7KLQ&OLHQW
352),1(7(WKHUQHW
$XWRPDWLRQV\VWHP
,QGXVWULDO3&V
$XWRPDWLRQV\VWHP
,QWHUQHW

Overview
1.6 Requirements
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
16 Operating Instructions, 04/2013, A5E03474888-02
1.6 Requirements
The connection types have the following requirements:
RDP Sm@rt
Server
Sm@rt
Access
X Windows XP Professional
Windows 7 Home
X Windows 7 Professional
X Windows 7 Ultimate
X Windows Server 2003
X Windows Server 2008
X Windows Server 2008 R2
X Windows Embedded Standard 7
X Windows Embedded Standard 2009
X As of SIMATIC WinCC V11 (TIA portal) with the options:
SIMATIC WinCC Sm@rtServer for SIMATIC Panels
SIMATIC WinCC Sm@rtServer for Runtime Advanced
X SIMATIC WinCC flexible 2008 SP1 with the option:
Sm@rtAccess for SIMATIC Panel
Sm@rtAccess for WinCC flexible Runtime
VNC: TightVNC and UltraVNC are supported, for example.
SINUMERIK requirements: SINUMERIK is available as of V4.5 SP2. Information on the
supported version of SINUMERIK PCU with PCU basic software as well as SINUMERIK
NCU with CNC software is available on the Internet at
"http://support.automation.siemens.com" (see Service&Support portal under Technical
Support/for short Technical Support (http://www.siemens.de/automation/csi_en_WW)):
● SINUMERIK Hotline: same "Access channels" as SIMATIC.
● Online: by "Support Request".

Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 17
Safety instructions 2
2.1 General safety instructions
Open equipment and the Machinery Directive
WARNING
The device constitutes open equipment
The device constitutes open equipment. This means that the device may only be installed
in enclosures or cabinets which provide front access for operating the device.
Access to the enclosure or cabinet in which the device is installed should only be possible
by means of a key or tool and for trained and authorized personnel.
Electrocution risk when control cabinet is open
When you open the control cabinet, there may be a dangerous voltage at certain areas or
components.
Touching these areas or components can cause electrocution.
Always disconnect the cabinet from the mains before opening it.
The device may only be used in machines which comply with the Machinery Directive
The Machinery Directive specifies precautions to be taken when commissioning and
operating machinery within the European Economic Area.
Failure to follow these precautions is a breach of the Machinery Directive. Such failure may
also cause personal injury and damage depending on the machine operated.
The machine in which the HMI device is to be operated must conform to Directive
2006/42/EC.
Hazardous areas
When operating the HMI device in hazardous areas the following warning applies.
WARNING
Explosion Hazard
Do not disconnect while circuit is live unless area is known to be non-hazardous.
Substitution of components may impair suitability for Class I, Division 2 or Zone 2.
Risque d'Explosion
Ne pas déconnecter pendant que le circuit est sous tension, sauf si la zone est non-
dangereuse. Le remplacement de composants peut compromettre leur capacité à satisfaire
à la Classe I, Division 2 ou Zone 2.

Safety instructions
2.2 Security information
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
18 Operating Instructions, 04/2013, A5E03474888-02
High frequency radiation
NOTICE
Unwanted operating states
High-frequency radiation, for example from cellular phones, interferes with device functions
and can cause device malfunction.
This causes injury and damages the system.
Avoid high-frequency radiation:
Remove the sources of radiation from the vicinity of the device.
Switch off radiating devices.
Reduce the radio output of radiating devices.
Observe the information on electromagnetic compatibility (Page 113).
2.2 Security information
Siemens offers IT security mechanisms for its portfolio of automation and drive products in
order to support safe operation of the plant/machine. We recommend that you stay informed
about the IT security developments for your products. For information on this topic, refer to:
Industry Online Support (http://www.siemens.de/automation/csi_en_WW): You can register
for a product-specific newsletter here.
For the safe operation of a plant/machine, however, it is also necessary to integrate the
automation components into an overall IT security concept for the entire plant/machine,
which corresponds to the state-of-the-art IT technology. You can find information on this
under: Industrial Security (http://www.siemens.com/industrialsecurity).
Products used from other manufacturers should also be taken into account here.
Remote maintenance is not recommended for production and should be disabled before
production is started.
The remote maintenance settings are disabled by default. If you enable them for
maintenance purposes, disable the remote maintenance settings once again for production
in the start menu "Configuration > System", "Remote maintenance" (see configuration
settings, section "System settings").
If you use Remote configuration in production, we recommend using your own, private key
for security reasons (see section "Remote configuration of several devices", "Key
assignment").
If you are using a private key, the remote configuration service is only guaranteed from a PC
with installed private key file. Assign a password for logging on to the PC.
The Remote configuration service (SSH) is enabled by default. If you do not need remote
configuration, disable remote configuration in the system settings of the device during
production (see section "Remote configuration of several devices", "Securing remote
configuration").

Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
Operating Instructions, 04/2013, A5E03474888-02 19
Installing and connecting the device 3
3.1 Brief instructions - connecting and starting the device
Procedure
Step See also
Place the device in the mounting cutout, and fasten the
HMI device with the mounting clamps.
Mounting the device (Page 24)
Connect the equipotential bonding. Connection of equipotential bonding
(Page 27)
Connect the power supply. Connecting the power supply (Page 29)
Connect PROFINET/Ethernet. Connecting device to the server (Page 30)
Optional: Connect an external USB device. Connecting a USB device (Page 31)
Switch on the power supply. Switching on and testing the device
(Page 33)
Start the Setup wizard and follow the instructions on
the screen.
You can also open the configuration settings from the
taskbar in the "Configuration" Start menu.
Structure and functions of the taskbar
(Page 89)
Select the network
connection.
Network settings (Page 46)
Enter the IP addresses
and further access
parameters of the required
server.
Setting up client-server connections
(Page 53)
Create a new
administrator password.
Password settings (Page 58)
Close the dialog with
"Save" or "Exit".
Start the required client-server connection. Structure and functions of the taskbar
(Page 89)

Installing and connecting the device
3.2 Preparing for installation
Industrial Thin Client ITC1200, ITC1500, ITC1900, ITC2200
20 Operating Instructions, 04/2013, A5E03474888-02
3.2 Preparing for installation
Select the mounting location of the HMI device
Points to observe when selecting the mounting location:
● Position the HMI device so that it is not subjected to direct sunlight.
● Position the HMI device such that it is ergonomically accessible for the operator.
Choose a suitable mounting height.
● Ensure that the air vents of the HMI device are not covered as a result of the mounting.
● Note the permissible mounting positions.
3.2.1 Checking the package contents
Check the package content for visible signs of transport damage and for completeness.
Note
If a part is damaged
A damaged part will cause the HMI device to malfunction.
Do not install parts damaged during shipment. In the case of damaged parts, contact your
Siemens representative.
The following is included in the scope of delivery of the device:
● The device itself
● Accessory kit with mounting clamps and mains terminal
● CD with RCC remote configuration software and the source codes for the open source
software
● Additional documents as required
The documentation belongs to the device and is required for subsequent commissioning.
Retain all enclosed documentation for the entire service life of the HMI device. You must
pass on the enclosed documentation to any subsequent owner or user of the HMI device.
Make sure that every supplement to the documentation that you receive is stored together
with the operating instructions.
