Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 3
Preface
Scope of validity
These compact operating instructions apply to the following devices which are based on the
following standard devices:
INOX device
Basic device
TP700 Comfort INOX, article number 6AV2144-8GC10-0AA0
TP700 Comfort V1
TP900 Comfort INOX, article number 6AV2144-8JC10-0AA0
TP900 Comfort V1
TP1200 Comfort INOX, article number 6AV2144-8MC10-0AA0
TP1200 Comfort V1
TP1200 Comfort INOX LF, article number 6AV2144-8MC10-0AC0
TP1200 Comfort V1
TP1500 Comfort INOX, article number 6AV2144-8QC10-0AA0
TP1500 Comfort V1
TP1500 Comfort INOX, article number 6AV2144-8QC10-0AA1
TP1500 Comfort V2
TP1500 Comfort INOX, article number 6AV2144-8QC10-0AA2
TP1500 Comfort V2
TP1900 Comfort INOX, article number 6AV2144-8UC10-0AA0
TP1900 Comfort V1
TP1900 Comfort INOX, article number 6AV2144-8UC10-0AA1
TP1900 Comfort V2
ITC1900 INOX, article number 6AV6646-8AC10-0AA0
ITC1900
These compact operating instructions describe the technical differences between the INOX
devices and the corresponding basic devices.
The notes in these compact operating instructions take precedence over statements in the
basic operating instructions, the release notes and online help.
Comfort Panels operating instructions
(http://support.automation.siemens.com/WW/view/en/49313233)
Industrial Thin Clients operating instructions
(http://support.automation.siemens.com/WW/view/en/61187980)
Unless otherwise described in this document, all of the statements made in the general
operating manual concerning the basic device are valid for the corresponding INOX device.
This means the statements on hardware, operating system, software, configuration,
maintenance, and servicing.
Note
This document belongs to the device and will also be required for repeat commissioning.
Keep all supplied and supplementary documentation for the entire service life of the device.
Pass on all of these documents to a future owner of the device.

Preface
Comfort Panels INOX, ITC INOX
4Compact Operating Instructions, 08/2022, A5E33472156-AP
Style conventions
Style Convention
Scope
"Add screen"
•Terms that occur in the user interface, for example, dialog name, tab,
button, menu command
•Necessary entries, for example, limit value, tag value
•
Path specification
"File > Edit"
Operating sequences, for example, menu item, shortcut menu command
<F1>, <Alt+P>
Designation of a key on a keyboard
You should also observe notes that are marked as follows:
Note
A note contains important information about the product described in the document and its
handling, or a specific section of the document to which you should pay particular attention.
Naming conventions
Term
Applies to
System
•System
•Machining center
•One or more machines
INOX device, HMI device
Comfort INOX device
•TP700 Comfort INOX
•TP900 Comfort INOX
•TP1200 Comfort INOX
•TP1200 Comfort INOX LF
•TP1500 Comfort INOX 1
•TP1500 Comfort INOX 2
•TP1900 Comfort INOX 1
•
TP1900 Comfort INOX
2
ITC INOX device
•ITC1900 INOX
1Based on the corresponding Comfort V1 device.
2Based on the corresponding Comfort V2 device.
Unless otherwise specified, "TP1500 Comfort INOX" and "TP1900 Comfort INOX" apply to the
entire basis V1 and V2.
Figures
This document contains illustrations of the described devices. The figures can deviate from
the particularities of the delivered device.

Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 5
Table of contents
Preface ................................................................................................................................................... 3
1 Overview................................................................................................................................................ 7
1.1 Product overview................................................................................................................. 7
1.2 Scope of delivery ................................................................................................................. 8
1.3 Layout of the devices ........................................................................................................... 8
1.4 Interfaces ............................................................................................................................ 9
1.5 Accessories........................................................................................................................ 10
2 Safety instructions............................................................................................................................... 11
2.1 General safety instructions................................................................................................. 11
2.2 Notes on use ..................................................................................................................... 12
2.3 Supplemental notes........................................................................................................... 12
3 Installing and connecting the device .................................................................................................. 13
3.1 Mounting instructions........................................................................................................ 13
3.2 Preparing for installation.................................................................................................... 13
3.2.1 Check the scope of delivery................................................................................................ 13
3.2.2 Checking the operating conditions..................................................................................... 13
3.2.3 Selecting a mounting position............................................................................................ 14
3.2.4 Checking clearances .......................................................................................................... 16
3.3 Inserting the mounting seal ............................................................................................... 17
3.4 Positions of the mounting clips for TP1900 Comfort INOX and ITC1900 INOX ..................... 19
3.5 Mounting the device.......................................................................................................... 19
3.6 Connecting the device ....................................................................................................... 21
3.7 Securing cables for use in hazardous areas ......................................................................... 22
4 Cleaning the device ............................................................................................................................. 23
4.1 Cleaning product ............................................................................................................... 23
4.2 Clean screen for Touch HMI devices ................................................................................... 23
4.3 Chemical Resistance .......................................................................................................... 24
4.4 Handling of stainless steel surfaces .................................................................................... 24
5 Technical specifications....................................................................................................................... 26
5.1 Software license agreements ............................................................................................. 26
5.2 Certificates and approvals .................................................................................................. 26
5.3 Electromagnetic compatibility............................................................................................ 32

Table of contents
Comfort Panels INOX, ITC INOX
6Compact Operating Instructions, 08/2022, A5E33472156-AP
5.4 Dimension drawings .......................................................................................................... 34
5.4.1 Dimension drawing TP700 Comfort INOX........................................................................... 34
5.4.2 Dimension drawing TP900 Comfort INOX........................................................................... 35
5.4.3 Dimension drawing TP1200 Comfort INOX......................................................................... 36
5.4.4 Dimension drawing TP1200 Comfort INOX LF..................................................................... 37
5.4.5 Dimension drawing TP1500 Comfort INOX......................................................................... 38
5.4.6 Dimension drawing TP1500 Comfort INOX based on V2 ..................................................... 39
5.4.7 Dimension drawing TP1900 Comfort INOX, ITC1900 INOX ................................................. 40
5.4.8 Dimension drawing TP1900 Comfort INOX based on V2 ..................................................... 41
5.5 Technical specifications ..................................................................................................... 41
5.6 Classification of environmental conditions ......................................................................... 43
5.6.1 Overview........................................................................................................................... 43
5.6.2 Classification for storage.................................................................................................... 43
5.6.3 Classification for shipping .................................................................................................. 44
5.6.4 Classification for stationary and weather-protected use ...................................................... 45
5.6.5 Climate diagram ................................................................................................................ 48
A Technical Support................................................................................................................................ 49
A.1 Service and support ........................................................................................................... 49
B List of abbreviations ............................................................................................................................ 50

Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 7
Overview
1
1.1 Product overview
INOX devices with touch screen and stainless steel front are designed for use in the food and
beverage industry, including in splash zones of food production, the pharmaceutical industry,
fine chemicals and in other hygiene areas for machine-level operator control and monitoring.
For this reason, the devices with stainless steel front have been developed in compliance with
DIN EN 1672-2 "Food processing machinery – Safety and Hygiene Requirements".
•The external dimensions of the front and mounting cutout are the same as for the
standard product
•Optimized rack design with slight projections to the cabinet and for allowing liquids to run
off
•Simpler cleaning thanks to resistant and rugged stainless steel front with smooth surface
and minimal grooves and gaps
•IP66K degree of protection 1on the front for increased tightness and ruggedness
•Stainless steel surface polished with grain size 240
•Decorative foil tested against chemicals
•Display splash protection
•Food-grade mounting gasket, exchangeable
•Rear clamping frame for even application pressure of the mounting gasket
1For use in hazardous areas of Zones 2 and 22: on the front at least IP65, see section
"Technical specifications (Page 41)".

Overview
1.2 Scope of delivery
Comfort Panels INOX, ITC INOX
8Compact Operating Instructions, 08/2022, A5E33472156-AP
1.2 Scope of delivery
Depending on the order, the scope of delivery includes:
•1 × device
•1 × accessory pack with the following contents:
–1 mounting gasket
–1 clamping frame
–1 power supply terminal
–1 strain relief plate (only for TP700 Comfort INOX)
–Mounting clips: depending on the display size generally:
Display size
Number of mounting clips
7" devices
10
9" devices
13
12" devices
12
15" devices
20
19" devices
18
•1 × "Comfort Panels INOX, ITC INOX" product information
1.3 Layout of the devices
The figures in this chapter show the layout of the INOX devices using the TP700 Comfort
INOX as an example.
Front view and side view
①
Cutout for mounting clip
②
Stainless steel front
③
Display with touch screen
④
Mounting gasket

Overview
1.4 Interfaces
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 9
Bottom view
①
Ports
②
Cutout for mounting clip
1.4 Interfaces
Interfaces for the 7", 9" and 12" HMI devices
The figure below shows the interfaces for the following HMI devices:
•TP700 Comfort INOX
•TP900 Comfort INOX
•TP1200 Comfort INOX
•TP1200 Comfort INOX LF
The devices based on the corresponding Comfort Panels V1 devices.
①
X80 power supply connector
⑤
X1 PROFINET (LAN), 10/100 Mb
②
Connection for equipotential bonding (ground)
⑥
X90 Audio Line OUT
③
X2 PROFIBUS (SUB-D RS422/485)
⑦
X60 USB type Mini B
④
X61 / X62 USB type A

Overview
1.5 Accessories
Comfort Panels INOX, ITC INOX
10 Compact Operating Instructions, 08/2022, A5E33472156-AP
Interfaces for the 15" and 19" HMI devices
The figure below shows the interfaces for the following HMI devices:
•TP1500 Comfort INOX 1
•TP1500 Comfort INOX 2
•TP1900 Comfort INOX 1
•TP1900 Comfort INOX 2
1Based on the corresponding Comfort Panels V1 device.
2Based on the corresponding Comfort Panels V2 device.
①
X80 power supply connector
⑤
X1 PROFINET (LAN), 10/100 Mb
②
Connection for equipotential bonding (ground)
⑥
X61 / X62 USB type A
③
X2 PROFIBUS (SUB-D RS422/485)
⑦
X90 Audio Line OUT
④
X3 PROFINET (LAN), 10/100/1000 Mb
⑧
X60 USB type Mini B
Additional information
Use the X1 or X60 interface to connect a configuration PC. Use the X61 / X62 interfaces to
connect peripheral devices such as a printer or keyboard. Use the X90 interface to connect an
audio device.
You can fasten the USB and PROFINET connecting cables to the rear panel of the HMI device
with cable ties.
On the TP700 Comfort INOX you secure the cables with a separate strain relief plate. Install
the strain relief on the HMI device.
1.5 Accessories
Accessories can be ordered on the Internet at:
Industry Mall (https://mall.industry.siemens.com)
The following service packs with clamping frames, mounting gaskets, mounting clips and
strain relief plate are available for the INOX devices:
•TP700 INOX Service Pack, article number 6AV2185-4GA00-0AX0
•TP900 INOX Service Pack, article number 6AV2185-4JA00-0AX0
•TP1200 INOX Service Pack, article number 6AV2185-4MA00-0AX0
•TP1200 INOX LF Service Pack, article number 6AV2185-4MA01-0AX0
•TP1500 INOX Service Pack 1, article number 6AV2185-4QA00-0AX0
•TP1900 Comfort INOX Service Pack 1, ITC1900 INOX Service Pack, article number
6AV2185-4UA00-0AX0
1The Service Pack is valid for the entire basis V1 and V2 of the Comfort Panels INOX.

Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 11
Safety instructions
2
2.1 General safety instructions
Installation according to the instructions
WARNING
The device may only be used in machines which comply with the Machinery Directive
The "Machinery Directive" governs, among other things, the precautions to be taken when
commissioning and operating machines within the European Economic Area.
Failure to follow these precautions is a breach of the Machinery Directive. Such failure may
also cause personal injury and damage depending on the machine operated.
The machine in which the HMI device is to be operated must conform to Directive
2006/42/EC.
Notes on the touch screen
WARNING
Risk of explosion, personal injury or material damage in the case of a defective touch
screen
The application of excessive force to the device front can destroy the device touch screen,
for example, piercing the front membrane or breaking the touch screen carrier plate. There
is a risk of explosion, injury and food contamination with additional consequential and
health damage.
Make sure that excessive force cannot be applied to the device front.
If the device touch screen is defective, decommission the affected machine immediately and
replace the device at once. When replacing the device, please note the chapter "Installing
and connecting the device (Page 13)".
Note
Wrinkles on the touch screen
Wrinkles may form on the touch screen decorative foil under extreme climatic conditions.
This will not affect the operability of the touch screen and does not represent a deficiency in
quality.

Safety instructions
2.2 Notes on use
Comfort Panels INOX, ITC INOX
12 Compact Operating Instructions, 08/2022, A5E33472156-AP
ESD
Electrostatically sensitive components include almost all electrical, electronic, optoelectronic
and electromechanical components. These components are sensitive to overvoltage for
technical reasons and their function may be impaired or destroyed by electrostatic discharge.
Observe the regulations governing the handling of ESD components.
2.2 Notes on use
Note
Avoid direct or indirect contact with food in the area of the device's decorative foil to avoid
possible cross contamination.
2.3 Supplemental notes
Configuration
A SIMATIC Comfort INOX HMI device is configured in the TIA Portal in the same way as the
corresponding basic device with its article number (MLFB), see section "Scope of validity" in
the preface.
To configure a SIMATIC Comfort INOX HMI device in WinCC (TIA Portal), select the
appropriate INOX HMI device in the TIA catalog and place it in your project.

Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 13
Installing and connecting the device
3
3.1 Mounting instructions
The technical specifications given for the device are guaranteed under these conditions:
•The device is installed by qualified personnel.
•Installation takes place according to the available documentation.
3.2 Preparing for installation
3.2.1 Check the scope of delivery
Check the scope of delivery for visible signs of damages caused during transport and for
completeness, see chapter "Scope of delivery (Page 8)".
NOTICE
Damaged parts
A damaged part can cause device malfunctions.
Do not install damaged parts.
In the case of damaged parts or incomplete delivery, contact your Siemens representative.
3.2.2 Checking the operating conditions
Note the following aspects before installing the device:
1. Familiarize yourself with the standards, approvals, EMC parameters and technical
specifications for operation of the device. This information is available in the following
chapters:
–"Certificates and approvals (Page 26)"
–"Electromagnetic compatibility (Page 32)"
2. Check the mechanical and climatic ambient conditions for operation of the device; see
Classification of environmental conditions (Page 43).
3. Follow the notes on use in the operating instructions.

Installing and connecting the device
3.2 Preparing for installation
Comfort Panels INOX, ITC INOX
14 Compact Operating Instructions, 08/2022, A5E33472156-AP
3.2.3 Selecting a mounting position
The HMI device is suitable for installation in:
•Mounting cabinets
•Control cabinets
•Switchboards
•Consoles
In the following, all of these mounting options are referred to by the general term "cabinet".
The HMI device is self-ventilated and approved for inclined mounting at angles of up to +/-35°
in stationary cabinets.
NOTICE
Damage due to overheating
An inclined installation reduces the convection by the HMI device and therefore the
maximum permitted ambient temperature for operation.
If there is sufficient convection from forced ventilation, the HMI device can also be operated
in the inclined mounting position up to the maximum permitted ambient temperature for
vertical installation. The HMI device may otherwise be damaged and its certifications and
warranty will be void.
Note
Extend
ed inclination and ambient temperature range
You can operate 7" to 15" devices with extended inclination and extended temperature range
under the following conditions:
•
The USB load does not exceed 100 mA per USB port.
•
The +24 V DC connection of the PROFIBUS interface is not used.
•
The relative atmospheric humidity behaves according to the climate diagram (Page 48) in
combination with the information on ambient temperature and relative humidity in the
technical specifications, see section "Classification for stationary and weather-protected
use (Page 45)".
The following mounting positions and temperature ranges are permitted under the specified
conditions:
•
Vertical landscape mounting with a maximum ambient temperature of +55 °C
•
Landscape mounting with an inclination of up to 35° from the vertical with a maximum
ambient temperature of 40 °C

Installing and connecting the device
3.2 Preparing for installation
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 15
Mounting position
Select one of the approved mounting positions for your HMI device. The approved mounting
positions are described in the following sections using the TP700 Comfort INOX as an
example.
Landscape mounting
All HMI devices are suitable for landscape mounting.
A maximum ambient temperature of +50 °C is permitted for vertical mounting (0° tilt angle);
a maximum of +40 °C is permitted for inclined mounting.
The ambient temperature for the 19" devices when installed vertically should not exceed
+45 °C.
Portrait mounting
The Touch HMI devices are also suitable for portrait mounting. Select the appropriate screen
format during configuration.
A maximum ambient temperature of +40 °C is permitted for vertical mounting (0° tilt angle);
a maximum of +35 °C is permitted for inclined mounting.

Installing and connecting the device
3.2 Preparing for installation
Comfort Panels INOX, ITC INOX
16 Compact Operating Instructions, 08/2022, A5E33472156-AP
3.2.4 Checking clearances
The following clearances are required around the HMI device to ensure sufficient self-
ventilation:
•At least 23 mm to the right and to the left of the mounting cutout (in the x direction) for
mounting the clamping frame during installation
•At least 50 mm above and 50 mm below the mounting cutout (in the y direction) for
ventilation
•At least 10 mm behind the rear panel of the HMI device (in the z direction)
The following figure shows the clearances during mounting of the HMI devices in horizontal
and vertical formats:
①
Clearance for installation in landscape format
②
Clearance for installation in portrait format
x
Distance from wall at least 23 cm.
y
At least 50 mm distance
z
At least 10 mm distance
Note
Ensure that the maximum ambient temperature is not exceeded when mounting the device
in a cabinet and especially in a closed enclosure.

Installing and connecting the device
3.3 Inserting the mounting seal
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 17
3.3 Inserting the mounting seal
The following figures in this section are examples.
To prevent the mounting seal from being inserted in the wrong direction, it has an
asymmetric coding tap. On all mounting gaskets of the INOX devices, the coding tap is on the
bottom left in relation to the rear of the device.
Note
Use a new mounting seal for each installation, because the promised degree of protection
cannot be guaranteed otherwise.
Requirement
•Remove all packaging components and the edge protection tape prior to installation.
Procedure
1. Look for the coding tap on the mounting seal. Turn the mounting seal so that the coding tap
is on the bottom left as seen in the figure below:
①
Coding tap
②
Positioning hooks
③
Seal corner

Installing and connecting the device
3.3 Inserting the mounting seal
Comfort Panels INOX, ITC INOX
18 Compact Operating Instructions, 08/2022, A5E33472156-AP
2. Carefully place the device on the front of the device (interfaces point to you).
3. Insert the mounting seal into the stainless steel front as shown. Also note points ④- ⑥.
④
Seal corner is underneath the housing frame.
⑤
The positioning hook of the seal fully engages into the cut-out, flat without protrusion.
⑥
The coding key lies flat in the intended cut-out.
4. Check the correct fit of the mounting seal:
–The coding tap is placed at the specified location.
–All positioning hooks rest flush in their cutouts. The mounting seal is installed correctly
when it lies flat on the entire stainless steel front. This must not lead to distortions and
protrusions.
If necessary, correct the seat: To do this, press the mounting seal into the recess.
–The edge of the mounting seal is flush with the edge of the stainless steel front all
around.

Installing and connecting the device
3.4 Positions of the mounting clips for TP1900 Comfort INOX and ITC1900 INOX
Comfort Panels INOX, ITC INOX
Compact Operating Instructions, 08/2022, A5E33472156-AP 19
3.4 Positions of the mounting clips for TP1900 Comfort INOX and
ITC1900 INOX
The following section describes how you can install the device. Observe the following
mounting clip positions for the TP1900 Comfort INOX and the ITC1900 INOX:
3.5 Mounting the device
The following process describes installation for all devices based on the example of the
TP700 Comfort INOX.
Requirement
•1 clamping frame
•1 Allen key 2.5 mm
•Mounting clips: depending on the display size generally:
–7" devices: 10 mounting clips
–9" devices: 13 mounting clips
–12" devices: 12 mounting clips
–15" devices: 20 mounting clips
–19" devices: 18 mounting clips
Observe the additional product information, if any, supplied with the product.

Installing and connecting the device
3.5 Mounting the device
Comfort Panels INOX, ITC INOX
20 Compact Operating Instructions, 08/2022, A5E33472156-AP
Mounting
CAUTION
Risk of injury when device falls
An unsecured device may fall. This can result in damage to persons, machines and the
device.
Secure the device against dropping during the entire installation.
1. Insert the device with its mounting seal, clamping frame and all enclosed mounting clips
into the mounting cut-out from the front, as shown in the figure.
The tip of the setscrew must be inserted into the center hole as shown in the zoomed
section of the figure.
Material thickness tat the
mounting cutout:
•With 7, 9, and 12" devices: 1.5 mm to 6 mm
•
With 15" and 19" devices: 1.5 mm to 5 mm
2. Turn the setscrew of each mounting clip until a slight clamping force is perceptible.
After a few rotations a slight resistance will become perceptible. When the increase in force
is perceptible, tighten the setscrew of the next mounting clip. Perform this step for all
setscrews.
3. Check that the mounting seal is properly seated.
–The edge of the mounting seal must be flush and evenly flush with the stainless steel
front on all sides.
–The edge may protrude 0.1 to 0.5 mm.
4. Tighten the setscrew of the mounting clip until the fixed stop is reached and the torque
increases perceptibly. The tightening torque is then:
–With 7, 9, and 12" devices: approx. 1.0 Nm
–With 15" and 19" devices: approx. 0.5 Nm
