Siemens SIMATIC RTLS PCB OEM PULSE User manual

10/2018
C79000-G8976-C552-01
SIMATIC RTLS
Localization systems
SIMATIC RTLS PCB OEM PULSE
(6GT2700-8AF03)
Manual

SIMATIC RTLS PCB OEM PULSE
2Manual, 10/2018, C79000-G8976-C552-01
Legal notices
Concept of the warning notices
This manual contains notices which you need to observe to ensure your own personal safety, as well as to avoid
damage to equipment. Notices relating to your personal safety are highlighted by a warning triangle; notices
relating to property damage only do not have a warning triangle. Warnings in descending order according to the
degree of danger are shown as follows.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury can result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that damage to property can result if proper precautions are not taken.
If more than one degree of danger is present, the notice representing the highest degree of danger will be used. A
notice warning of injury to persons with a warning triangle may also include a warning relating to property
damage.
Qualified personnel
The product/system to which this documentation applies may only be handled by
qualified personnel
for the
intended purpose taking into account the documentation relating to the intended purpose and, in particular, the
safety and warning notices it contains. Due to training and experience, qualified personnel is capable of
recognizing risks and avoiding possible dangers when handling these products/systems.
Proper use of Agilion products
Note the following:
WARNING
Agilion products may only be used for the applications indicated in the catalog and in the relevant technical
documentation. If third-party products and components are used, these must be recommended or approved by
Agilion. These products can only function correctly and safely if they are transported, stored, set up, mounted,
installed, commissioned, operated and maintained properly. The permitted environmental and ambient
conditions must be adhered to. Notices in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining designations in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of liability
We have checked this document for agreement with the hardware and software described. Since deviations
cannot be precluded entirely, we cannot guarantee full agreement. However, the data in this manual is reviewed
regularly and any necessary corrections included in subsequent editions.

SIMATIC RTLS PCB OEM PULSE
Manual, 10/2018, C79000-G8976-C552-01 3
Agilion GmbH
Blankenauer Str. 74
09113 Chemnitz
Germany
Tel.: +49 - (0)371 - 45 00 48-0
Fax.: +49 - (0)371 - 45 00 48-11
www.agilion.de
servic[email protected]
Management:
Andreas Werner
Johannes Waldhör
Sven Sieber
HR B 21249 Chemnitz
VAT ID no.: DE236591552

SIMATIC RTLS PCB OEM PULSE
4Manual, 10/2018, C79000-G8976-C552-01
Table of contents
English
1
Dimensions, connections and LEDs .........................................................................................................5
1.1 Dimensions................................................................................................................................................5
1.2 Displays .....................................................................................................................................................6
1.3 Solder contact P4 ......................................................................................................................................6
1.4 P1 connector .............................................................................................................................................7
1.5 P2 connector .............................................................................................................................................7
2
Technical specifications ...........................................................................................................................8
2.1 Connections and supply voltage ...............................................................................................................8
2.2 Wireless.....................................................................................................................................................8
2.3 Environment ..............................................................................................................................................8
3
Approvals ................................................................................................................................................9
3.1 EU declaration of conformity .....................................................................................................................9
3.2 RoHS .........................................................................................................................................................9
3.3 RED .........................................................................................................................................................10
3.3.1 Protection of health and safety ...............................................................................................................10
3.4 Recycling and disposal............................................................................................................................11

SIMATIC RTLS PCB OEM PULSE
Manual, 10/2018, C79000-G8976-C552-01
5
1Dimensions, connections and LEDs
1.1 Dimensions
The antenna is connected to the PCB via a 5 cm long U.FL cable. The contacts used are P3 on
the PCB and P1 on the antenna.
PCB
Drill holes

SIMATIC RTLS PCB OEM PULSE
6Manual, 10/2018, C79000-G8976-C552-01
Antenna
1.2 Displays
Display (LED)
Description
Short flash Indicates radio activity
Off Transponder is not in operation
1.3 Solder contact P4
Pin
Description/function
1 Grounding
2 Rx - Input on the transponder, 3.3 V
3 Tx - Output on transponder, 3.3 V
4 Supply voltage, 3.3 V

SIMATIC RTLS PCB OEM PULSE
Manual, 10/2018, C79000-G8976-C552-01
7
1.4 P1 connector
The individual pins are connected to the solder contacts (P4).
Type: JST SM04B-SRSS-TB
Pin
Description/function
1 Rx - Input on the transponder, 3.3 V
2 Tx - Output on transponder, 3.3 V
3 Grounding
4 Supply voltage, VCC, 3.3 V ±100 mV
1.5 P2 connector
Internal interface for production and manufacturing test, do not use.

SIMATIC RTLS PCB OEM PULSE
8Manual, 10/2018, C79000-G8976-C552-01
2Technical specifications
2.1 Connections and supply voltage
Connections and supply voltage
Voltage 3.3 V DC (±100 mV)
Energy intake Max. 0.3 A
2.2 Wireless
Wireless PULSE (localization)
Wireless process IEEE 802.15.4-2011 UWB
Transmission speed 850 Kbps
Frequency range The following frequency bands are supported:
•4000 MHz
•6500 MHz
Bandwidth 500 MHz
Transmit power 0.037 mW
Antenna Connected via antenna cable
Range Inside maximum 90 m (typical 60 m),
Outside maximum 1000 m (typical 500 m)
2.3 Environment
Environment
PCB dimensions 44 x 24 x 7.5 mm
Antenna dimensions 38 x 20 x 3 mm
Weight Approx. 10 g
Temperature range 0 to +50 ℃
Method of securing PCB: 3 screws, Ø 1.7 mm
Antenna: provided by customer

SIMATIC RTLS PCB OEM PULSE
Manual, 10/2018, C79000-G8976-C552-01
9
3Approvals
3.1 EU declaration of conformity
The EU declaration of conformity is available to all responsible authorities at:
Agilion GmbH
Blankenauer Str. 74
09113 Chemnitz
Germany
You can find the current EU Declaration of Conformity for these products on the Internet at
Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/14970/cert)
The products described in this document meet the requirements
of the following EU directives:
•RoHS directive 2011/65/EU
Directive of the European Parliament and of the Council of 8 June 2011 on the restriction of
the use of certain hazardous substances in electrical and electronic equipment, official
journal of the EU L174, 1 July 2011, pages 88-110
•Radio Equipment Directive 2014/53/EU (RED)
Directive of the European Parliament and of the Council of 16 April 2014 on the
harmonization of the laws of the member states relating to placing radio equipment on the
market; official journal of the EU L153, 22 May 2014, pages 62–106
3.2 RoHS
RoHS directive (restriction of the use of certain hazardous substances)
The products described in these operating instructions meet the requirements of the EU
directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical
and electronic equipment.
Applied standard:
•EN 50581
Technical documentation for the assessment of electrical and electronic products with
respect to restriction of hazardous substances

SIMATIC RTLS PCB OEM PULSE
10 Manual, 10/2018, C79000-G8976-C552-01
3.3 RED
3.3.1 Protection of health and safety
The products described in this document meet the requirements of the applied standards:
Article 3 (1) a) Protection of health and safety
•EN 62368-1
Equipment for audio, video, information and communication technology – Part 1: Safety
requirements
•EN 62311
Assessment of electronic and electrical equipment related to human exposure restrictions in
electromagnetic fields (0 Hz – 300 GHz)
The products described in these operating instructions meet the requirements
of
art. 3 (1) b)
EMC
harmonized standards:
•ETSI EN 301 489-1
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 1: Common technical requirements
•ETSI EN 301 489-17
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 17:
Specific conditions for broadband data transmission systems
•ETSI EN 301 489-33
Electromagnetic compatibility and radio spectrum matters (ERM) - Electromagnetic
compatibility for radio equipment and services - Part 33: Specific conditions for Ultra-
WideBand (UWB) devices
•EN 55011
Industrial, scientific and medical (ISM) radio-frequency equipment – Electromagnetic
disturbance characteristics – Limits and methods of measurement
•EN 55032 Class A, Class B
Electromagnetic compatibility of multimedia equipment – Emission requirements
•EN 55035
Electromagnetic compatibility of multimedia equipment - Immunity requirements
•EN 61000-6-1
Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for residential,
commercial and light-industrial environments
•EN 61000-6-2
Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial
environments

SIMATIC RTLS PCB OEM PULSE
Manual, 10/2018, C79000-G8976-C552-01
11
•EN 61000-6-3
Electromagnetic compatibility (EMC) - Part 6-3: Generic standards - Emission standard for
residential, commercial and light-industrial environments
•EN 61000-6-4
Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard for
industrial environments
Art. 3 (2) Efficient use of the radio spectrum
•ETSI EN 300 328
Wideband transmission systems – Data transmission equipment operating in the 2.4 GHz
ISM band and using wideband modulation techniques – Harmonized EN covering the
essential requirements of article 3.2 of the EU Directive 2014/53/EU
•ETSI EN 302 065-2
Short Range Devices (SRD) using Ultra Wide Band technology (UWB) - Harmonized EN
covering the essential requirements of article 3.2 of the EU directive 2014/53/EU, Part 2:
Requirements for ultra-wideband location monitoring
Note
The specified approvals are only valid if the corresponding symbol i
s printed on the device.
3.4 Recycling and disposal
The products are low in harmful substances, can be recycled and meet the requirements of the
Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
Do not dispose of the products at public disposal sites.
For environmentally compliant recycling and disposal of your electronic waste, please contact a
company certified for the disposal of electronic waste or your Siemens representative.
Note the different national regulations.
