Quick Startup Guide for
SIMOVERT MASTERDRIVES
6SE70 VC
Vector Control
Section 1: Parameterization of Base Drive
Section 2: Parameterization of Rectifier
Section 3: Simovis Trace Setup Method
Section 4: When Should a Drive be re-Tuned

Page 2 Version 1.0 March 1, 2000
We reserve the right to modify functions, technical data, standards, drawings
and parameters.
We have checked the contents of this document to ensure that they coincide
with the described hardware and software. However, deviations cannot be
completely ruled-out, so we cannot guarantee complete conformance.
However, the information in this document is regularly checked and the
necessary corrections will be included in subsequent editions. We are thankful
for any recommendations or suggestions.
e-mail: mailto:[email protected]

Version 1.0 March 1, 2000 Page 3
Note:
This Quick Startup Guide is not an autonomous document, but is intended to direct users to
the section in the Operating Instructions which are important for start-up. Thus, these brief
instructions can only be completely valid when used in conjunction with the Operating
Instructions. It is especially important to observe the warning and information regarding
potential hazards in the Operating Instructions.
Warning:
•Electrical equipment has parts an components which are at hazardous voltage levels.
•If the warning information in the detailed Operating Instructions is not observed, this
can result in severe bodily injury or material damage.
•Only appropriately qualified personnel may work with this equipment.
•These personnel must be knowledgeable with all of the warning information and
service/maintenance measures of the Operating Instruction.
Perfect and safe operation of this equipment assumes professional transport, storage, erection
and installation as well as careful operating control and service.
NOTE:
These instructions do not purport to cover all details or variations in equipment, nor to
provide for every possible contingency to be met in connection with installation,
operation or maintenance. Should further information be desired or should particular
problems arise which are not covered sufficiently for the purchaser’s purposes, please
contact your local Siemens office.
Further, the contents of these instructions shall neither become a part of nor modify
any prior or existing agreement, commitment or relationship. The sales contract
contains the entire obligation of Siemens Energy & Automation. The warranty
contained in the contract between the parties is the sole warranty of Siemens Energy &
Automation. Any statements contained herein do not create new warranties nor
modify the existing warranty.

Page 4 Version 1.0 March 1, 2000

Version 1.0 March 1, 2000 Page 5
Section 1:
Parameterization of Base Unit
SIMOVERT MASTERDRIVES
6SE70 VC
Vector Control
1.1 Power Section Defintion
1.2 Factory Reset
1.3 Basic Start-up
1.3.1 Volts/Hz without encoder feedback
1.3.2 Volts/Hz with encoder feedback
1.3.3 Vector Control without encoder feedback
1.3.4 Vector Control with encoder feedback
1.4 Drive Control Word
1.5 Communication Board Configuration
Note: Refer to Operating Instruction Manual for power and control connections.

Page 6 Version 1.0 March 1, 2000

Version 1.0 March 1, 2000 Page 7
1.1 Power Section Definition
Note: Power Section is pre-defined at the factory. Power Section
Definition is required if a new board CUVC board is put into the drive or
boards are switched between units with different ratings. Drive should
be defaulted and re-parameterized after Power Section Definition.
P060 = 8
P070 = ?
P060 = 1
Select “Power Section Definition”
Menu
Input Code for unit (PWE)
(Refer to Compendium section
6.3 or use the bookmark “PWE
Listing” or check the following
table)
Return to Parameter Menu

Page 8 Version 1.0 March 1, 2000
Unit List
P070: Parameter Value (PWE)
P072: Rated Output Current in Amps In[A]
Frequency Converter
AC-AC type
3 AC 200V to 230V PWE Order Number In[A]*1
14 6SE7021-1CA60 10.6
21 6SE7021-3CA60 13.3
27 6SE7021-8CB60 17.7
32 6SE7022-3CB60 22.9
39 6SE7023-2CB60 32.2
48 6SE7024-4CC60 44.2
54 6SE7025-4CD60 54.0
64 6SE7027-0CD60 69.0
70 6SE7028-1CD60 81.0
13 6SE7031-0CE60 100.0
29 6SE7031-3CE60 131.0
41 6SE7031-6CE60 162.0
87 6SE7032-0CE60 202.0
Frequency Inverter
DC-AC type
DC 270V to 310V PWE Order Number In[A]*1
15 6SE7021-1R60 10.6
22 6SE7021-3RA60 13.3
28 6SE7021-8RB60 17.7
33 6SE7022-3RB60 22.9
40 6SE7023-2RB60 32.2
49 6SE7024-4RC60 44.2
55 6SE7025-4RD60 54.0
65 6SE7027-0RD60 69.0
71 6SE7028-1RD60 81.0
20 6SE7031-0RE60 100.0
34 6SE7031-3RE60 131.0
86 6SE7031-6RE60 162.0
92 6SE7032-0RE60 202.0

Version 1.0 March 1, 2000 Page 9
Frequency Converter
AC-AC type
3 AC
380V to 460V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
3 6SE7016-1EA61 6.1
9 6SE7018-0EA61 8.0
11 6SE7021-0EA61 10.2
18 6SE7021-3EB61 13.2
25 6SE7021-8EB61 17.5
35 6SE7022-6EC61 25.5
42 6SE7023-4EC61 34.0
46 6SE7023-8ED61 37.5
52 6SE7024-7ED61 47.0
56 6SE7026-0ED61 59.0
66 6SE7027-2ED61 72.0
74 6SE7031-0EE60 92.0
82 6SE7031-2EF60 124.0
90 6SE7031-5EF60 146.0
98 6SE7031-8EF60 186.0
102 6SE7032-1EG60 210.0
108 6SE7032-6EG60 260.0
112 6SE7033-2EG60 315.0
116 6SE7033-7EG60 370.0
147 233 6SE7035-1EK60 510.0
151 237 6SE7036-0EK60 590.0
164 168 6SE7037-0EK60 690.0
*1Based on 3kHz carrier frequency setting, larger frames have maximum carrier
frequency restrictions

Page 10 Version 1.0 March 1, 2000
Frequency Inverter
DC-AC type
DC
510V to 650V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
4 6SE7016-1TA61 6.1
10 6SE7018-0TA61 8.0
12 6SE7021-0TA61 10.2
19 6SE7021-3TB61 13.2
26 6SE7021-8TB61 17.5
36 6SE7022-6TC61 25.5
43 6SE7023-4TC61 34.0
47 6SE7023-8TD61 37.5
53 6SE7024-7TD61 47.0
57 6SE7026-0TD61 59.0
67 6SE7027-2TD61 72.0
75 6SE7031-0TE60 92.0
83 6SE7031-2TF60 124.0
91 6SE7031-5TF60 146.0
99 6SE7031-8TF60 186.0
103 6SE7032-1TG60 210.0
109 6SE7032-6TG60 260.0
113 6SE7033-2TG60 315.0
117 6SE7033-7TG60 370.0
120 206 6SE7035-1TJ60 510.0
123 209 6SE7036-0TJ60 590.0
126 212 6SE7037-0TK60 690.0
127 213 6SE7038-6TJ60 860.0
134 6SE7041-1TM60 1100.0
135 221 6SE7041-1TK60 1100.0
140 226 6SE7041-3TM60 1300.0
150 236 6SE7041-6TM60 1630.0
153 239 6SE7042-1TQ60 2090.0
154 199 6SE7041-3TL60 1300.0
163 167 6SE7037-0TJ60 690.0
181 247 6SE7038-6TS60 6450.0
185 250 6SE7041-1TS60 6270.0
194 244 6SE7042-5TN60 2470.0

Version 1.0 March 1, 2000 Page 11
Frequency Converter
AC-AC type
3 AC
500V to 575V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
1 6SE7014-5FB61 4.5
5 6SE7016-2FB61 6.2
7 6SE7017-8FB61 7.8
16 6SE7021-1FB61 11.0
23 6SE7021-5FB61 15.1
30 6SE7022-2FC61 22.0
37 6SE7023-0FD61 29.0
44 6SE7023-4FD61 34.0
50 6SE7024-7FD61 46.5
60 6SE7026-1FE60 61.0
62 6SE7026-6FE60 66.0
68 6SE7028-0FF60 79.0
78 6SE7031-1FF60 108.0
84 6SE7031-3FG60 128.0
94 6SE7031-6FG60 156.0
100 6SE7032-0FG60 192.0
104 6SE7032-3FG60 225.0
136 222 6SE7033-0FK60 297.0
141 227 6SE7033-5FK60 354.0
143 229 6SE7034-5FK60 452.0
*1Based on 3kHz carrier frequency setting, larger frames have maximum carrier
frequency restrictions

Page 12 Version 1.0 March 1, 2000
Frequency Inverter
DC-AC type
DC
675V to 810V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
2 6SE7014-5UB61 4.5
6 6SE7016-2UB61 6.2
8 6SE7017-8UB61 7.8
17 6SE7021-1UB61 11.0
24 6SE7021-5UB61 15.1
31 6SE7022-2UC61 22.0
38 6SE7023-0UD61 29.0
45 6SE7023-4UD61 34.0
51 6SE7024-7UD61 46.5
61 6SE7026-1UE60 61.0
63 6SE7026-6UE60 66.0
69 6SE7028-0UF60 79.0
79 6SE7031-1UF60 108.0
85 6SE7031-3UG60 128.0
95 6SE7031-6UG60 156.0
101 6SE7032-0UG60 192.0
105 6SE7032-3UG60 225.0
110 200 6SE7033-0UJ60 297.0
114 202 6SE7033-5UJ60 354.0
118 204 6SE7034-5UJ60 452.0
121 207 6SE7035-7UK60 570.0
124 210 6SE7036-5UK60 650.0
128 214 6SE7038-6UK60 860.0
130 216 6SE7041-0UM60 990.0
132 218 6SE7041-1UM60 1080.0
138 224 6SE7041-2UM60 1230.0
144 230 6SE7041-4UM60
6SE7041-4UQ60 1400.0
148 234 6SE7042-1TQ60
6SE7041-6UQ60 1580.0
155 195 6SE7041-1UL60 1080.0
157 6SE7042-4ULJ60 2450.0
159 197 6SE7041-1UL60 1230.0

Version 1.0 March 1, 2000 Page 13
Frequency Inverter
DC-AC type
DC
675V to 810V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
161 6SE7043-3UR60 3270.0
165 6SE7044-1UR60 4090.0
169 6SE7044-8UR60 4900.0
173 6SE7045-7UR60 5720.0
177 6SE7046-5UR60 6540.0
179 245 6SE7036-5UR60 4940.0
182 248 6SE7038-6US60 6540.0
186 251 6SE7041-1US60 6160.0
188 253 6SE7041-2US60 5840.0
190 240 6SE7042-1UN60 2050.0
192 242 6SE7042-3UN60 2340.0
Frequency Converter
AC-AC type
3 AC
660V to 690V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
58 6SE7026-0HF60 55.0
72 6SE7028-2HF60 82.0
76 6SE7031-0HG60 97.0
80 6SE7031-2HF60 118.0
88 6SE7031-5HF60 145.0
96 6SE7031-7HG60 171.0
106 6SE7032-1HG60 208.0
137 223 6SE7033-0HK60 297.0
142 228 6SE7033-5HK60 354.0
146 232 6SE7034-5HK60 452.0
Frequency Inverter
DC-AC type
DC
890V to 930V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
59 6SE7026-0WF60 60.0
73 6SE7028-2WF60 82.0

Page 14 Version 1.0 March 1, 2000
DC
890V to 930V PWE Air Cooled PWE Water
Cooled
Order Number In[A]*1
77 6SE7031-0WG60 97.0
81 6SE7031-2WF60 118.0
89 6SE7031-5WF60 145.0
97 6SE7031-7WG60 171.0
107 6SE7032-1WG60 208.0
111 201 6SE7033-0WJ60 297.0
115 203 6SE7033-5WJ60 354.0
119 205 6SE7034-5WJ60 452.0
122 208 6SE7035-7WK60 570.0
125 211 6SE7036-5WK60 650.0
129 215 6SE7038-6WK60 860.0
131 217 6SE7041-0WM60 990.0
133 219 6SE7041-1WM60 1080.0
139 225 6SE7041-2WM60 1230.0
145 231 6SE7041-4WM60
6SE70414WQ60 1400.0
149 235 6SE7041-6WM60
6SE7041-6WM60 1580.0
152 238 6SE7034-5WK60 452.0
156 196 6SE7041-1WL60 1080.0
158 6SE7042-4WR60 2450.0
160 198 6SE7041-2WL60 1230.0
162 6SE7043-3WR60 3270.0
166 6SE7044-1WR60 4090.0
170 6SE7044-8WR60 4900.0
174 6SE7045-7WR60 5720.0
178 6SE7046-5WR60 6540.0
180 246 6SE7036-5WS60 4940.0
183 249 6SE7038-6WS60 6540.0
187 252 6SE7041-1WS60 6160.0
189 254 6SE7041-2WS60 5840.0
191 241 6SE7042-1WN60 2050.0
193 243 6SE7042-3WN60 2340.0

Version 1.0 March 1, 2000 Page 15
1.2 Factory Reset
P053 = 6
P060 = 2
P366 = 0
P970 = 0
6: Parameter Changes permitted
via PMU and Serial Interface
(OP1 and PC)
2: Menu Select = Fixed Settings
Select Factory Setting
0: Standard
Start Parameter Reset
0: Parameter Reset
1: No Parameter Change

Page 16 Version 1.0 March 1, 2000

Version 1.0 March 1, 2000 Page 17
1.3 Basic Start-up without Motor Connected to Load
1.3.1 Volts/Hz without Encoder
P060 = 5
P071 = ?
P095 = ?
P097 = ?
P101 = 460
P102 = xxx
P104 = ? P105 = ?
P060=5
Select “Drive Settings”
P071 = Input Line Voltage
AC-AC Converter=460Volt
DC-AC Inverter = 620Volt
P095 = Select Motor Type
2: Asynchronous 1PH7 Motor
10: IEC Induction Motor
11: NEMA Induction Motor
P097 = Motor Code number for
1PH7 motor (See Appendix)
Motor Nameplate Information
P101= Motor Voltage (V)
P102 = Motor Rated Current (A)
P104 = Cos (phi) per nameplate
P105 = Rated Horsepower
P095 = 10 11
P095 = 2 10 or 11

Page 18 Version 1.0 March 1, 2000
P106 = ?
P107 = 60
P108 = xxxx
P115 = 1
P340 = 3
P383 = xxxx
P452 = 100
P106 = NEMA Motor Nameplated
efficiency (if unknown set =0.8)
P107 = Rated Motor Frequency
P108 = Nameplated Rotor RPM
P115 = 1
“Automatic Parameterization”
P340 = Carrier Frequency
Low # = Cooler Motor and Drive
High # = Lower Motor Noise
P383 = Motor Thermal Time
Constant. If constant unknown use
general guidelines;
2 Pole Motor = 480 seconds
4 Pole Motor = 600 seconds
6 Pole Motor = 720 seconds
P452 = Maximum Forward Speed in
Percentage (usually 100%)

Version 1.0 March 1, 2000 Page 19
P453 = -100
P060 = 1
P128 = xxxx
P462 = xxxx
P464 = xxxx
P443i2= 11
P453 = Maximum Reverse Speed in
Percentage (usually -100%)
P060 = Return to Parameter Menu
P128 = Maximum Motor Current
Options: P128 = P102
P128=1.1*P102
P128=1.5*P102
P462 = Acceleration Time in seconds
P464 = Deceleration Time in seconds
P443i2(Index2) = 11
Configures drive for analog input
(0-10Vdc) to be active at
terminals X101 pin#15 and
pin#16
If 4-20mA is required closed
CUVC board mounted jumper
S3, position 1 and 2.
Start/Stop Control is located on
the PMU (operator control panel
mounted directly on the drive)
Speed Setpoint is controlled with
the Up / Down arrows.

Page 20 Version 1.0 March 1, 2000
Connect External Wiring as connection diagram.
Step 1: Dry set of contacts between terminals X101, pin#1 and pin#5 for
Local/Remote Mode Selection. Jumper if not required.
Step 2: Dry set of contacts between terminals X101, pin#1 and pin#8 for
Coast to Stop Selection. Jumper if not required.
Step 3: Dry set of contacts between terminals X101, pin#1 and pin#9 for
Source of Main Start/Stop Selection.
Step 4: Dry set of contacts between terminals X101, pin#1 and pin#7 for
Source of Fault Reset. Leave open if not required. “P” button on PMU
will be fault reset location if pin#7 is not used.
Step 5: Dry set of contacts between terminals X101, pin#1 and pin#6 for
Fixed Speed or Preset Speed Selection. Leave open if not required.
Internal Connections
Custome
r
Connection Points
