Siemens 9410 Series User manual

9410 series
User manual
7EN05-0336-03
11/2017
www.usa.siemens.com/pds

9410 series
Safety information
Important information
Read these instructions carefully and look at the equipment to become familiar with the
device before trying to install, operate, service or maintain it. The following special
messages may appear throughout this bulletin or on the equipment to warn of potential
hazards or to call attention to information that clarifies or simplifies a procedure.
The addition of either symbol to a “Danger” or “Warning” safety label indicates that an
electrical hazard exists which will result in personal injury if the instructions are not
followed.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury or
death.
DANGER
DANGER indicates a haz ardous situation which, if not avoided, will result in death
or serious injury.
WARNING
WARNING indicates a ha zardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
CAUTION indicates a haz ardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE
NOTICE is used to addre ss practices not related to physical injury.
Please note
Electrical equipment should be installed, operated, serviced and maintained only by
qualified personnel. No responsibility is assumed by Siemens Industry for any
consequences arising out of the use of this material. A qualified person is one who has
skills and knowledge related to the construction, installation, and operation of electrical
equipment and has received safety training to recognize and avoid the hazards
involved.
2 7EN05-0336-03

9410 series
Notices
FCC
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that the interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The user is cautioned that any changes or modifications not expressly approved by
Siemens Industry could void the user’s authority to operate the equipment.
This digital apparatus complies with CAN ICES-3 (B) /NMB-3(B).
About this manual
This manual discusses features of the 9410 series power meter and provides
installation and configuration instructions.
Throughout the manual, the term “meter” refers to all models of the 9410. All
differences between the models, such as a feature specific to one model, are indicated
with the appropriate model number or description.
This manual assumes you have an understanding of power metering and are familiar
with the equipment and power system in which your meter is installed.
This manual does not provide configuration information for advanced features where
an expert user would perform advanced configuration. It also does not include
instructions on how to incorporate meter data or perform meter configuration using
energy management systems or software, other than ION Setup.
ION Setup is a free configuration tool available for download from
www.usa.siemens.com/pds. It is recommended that you always upgrade to the latest
version of ION Setup to help properly configure the features available on your meter.
Please contact your local Siemens Industry representative to learn what additional
training opportunities are available regarding the 9410 meter.
Make sure you are using the most up-to-date version of your meter’s firmware in order
to access the latest features.
The most up-to-date documentation about your meter is available for download from
www.usa.siemens.com/pds.
7EN05-0336-03 3

9410 series
Related documents
Document Number
9410DC / 9410D24VDC installation sheet NVE23944
9410TC and 9410T24VDC installation sheet NVE23945
ION Reference 70005-0290
ION device template reference —
4 7EN05-0336-03

9410 series
Table of Contents
Safety precautions.......................................................................................... 11
Meter overview................................................................................................12
9410 overview ...............................................................................................12
Your meter in an energy management system ..................................................12
Measured parameters ....................................................................................13
Localization ...................................................................................................15
Data display and analysis tools .......................................................................15
Supported protocols .......................................................................................16
ION Setup device configuration tool.................................................................16
Meter types....................................................................................................16
Mounting adaptors .........................................................................................17
Terminal covers..............................................................................................17
Replacement hardware...................................................................................17
Basic setup ......................................................................................................18
Default values for commissioning ....................................................................18
Meter setup ...................................................................................................18
Minimum configuration requirements for basic metering ....................................19
Hardware reference .......................................................................................20
Supplemental information ...............................................................................20
Meter base ....................................................................................................20
Remote meter display (RMD) ..........................................................................21
Mounting adaptors .........................................................................................22
Terminal covers..............................................................................................22
Replacement hardware...................................................................................22
LED locations ................................................................................................22
Energy pulsing LED behavior ..........................................................................23
Revenue lock LED behavior............................................................................23
Remote display connection LED behavior ........................................................23
Panel-mount meter and remote display mounting and wiring
recommendations ..........................................................................................24
Power system wiring ......................................................................................24
RS-485 wiring ................................................................................................24
Ethernet communications connections.............................................................25
Option modules overview................................................................................25
Maximum number of option modules ...............................................................25
Meter display...................................................................................................27
Display overview............................................................................................27
Display menu.................................................................................................30
Setup menu ...................................................................................................34
Using the onscreen keyboard ....................................................................37
Remote display troubleshooting icons..............................................................39
Creating custom displays using ION Setup.......................................................40
Security ............................................................................................................42
Security overview...........................................................................................42
7EN05-0336-03 5

9410 series
Security features on your device......................................................................42
Network port control..................................................................................42
Enable/disable communication ports..........................................................42
Revenue and billing security features ......................................................... 43
Event logging ...........................................................................................43
Syslog .....................................................................................................43
Advanced security through the meter’s display ...........................................43
NERC CIP .....................................................................................................43
Security recommendations and best practices..................................................44
Password best practices ...........................................................................44
Standard and advanced security features ........................................................45
Security configuration process ........................................................................45
Communications protocol lockout overview ......................................................46
Password setup .............................................................................................47
Advanced security username and password through the display........................47
Changing your meter’s display password using the display................................47
Configuring standard security using ION Setup.................................................48
Configuring users and passwords using ION Setup (advanced security
only)..............................................................................................................49
Loading an existing security configuration file (.scf) using ION Setup..................50
Communications.............................................................................................51
Communications overview ..............................................................................51
ION ...............................................................................................................70
Modbus .........................................................................................................71
Your meter as a Modbus slave...................................................................73
Your meter as a Modbus master ................................................................74
Ethernet gateway ...........................................................................................79
FTP...............................................................................................................83
IEC 61850 .....................................................................................................90
DNP..............................................................................................................92
Time and timekeeping....................................................................................94
Time overview................................................................................................94
Internal clock temperature compensation .........................................................94
Internal clock temperature compensation parameters..................................94
Time synchronization overview........................................................................94
Supported time synchronization sources..........................................................95
GPS time quality flag ......................................................................................95
Configuring time information using your meter’s display ....................................96
Configuring time and time synchronization using ION Setup ..............................97
Maintenance....................................................................................................99
Firmware and templates .................................................................................99
Device-specific information ...........................................................................105
Troubleshooting ...........................................................................................106
Technical assistance...............................................................................106
Meter webpages ...........................................................................................107
Webpage interface .......................................................................................107
Default meter webpages...............................................................................108
6 7EN05-0336-03

9410 series
Accessing the meter’s webpages for data viewing and meter
configuration................................................................................................109
Viewing files using your meter’s webpages .................................................... 110
Creating custom webpages for your meter ..................................................... 110
Sample data viewing webpage...................................................................... 111
Logging .......................................................................................................... 119
Logging overview ......................................................................................... 119
Data logging overview .................................................................................. 119
Event log overview .......................................................................................120
User triggered event log entries ............................................................... 120
Assigning a designated reader for event log notification............................. 120
Syslog overview .....................................................................................121
Waveform recording overview .......................................................................122
Default logging framework ............................................................................124
Advanced log setup and memory optimization................................................ 129
Viewing log configuration and memory usage information .......................... 129
Log depth configuration...........................................................................130
Log interval configuration ........................................................................130
Log mode configuration...........................................................................130
Log buffer configuration ..........................................................................131
Changing log interval and depth settings using ION Setup ......................... 133
Data log memory calculations.................................................................. 134
Waveform record memory calculations..................................................... 134
Inputs / outputs .............................................................................................135
I/O Overview................................................................................................135
Input/output ION modules .............................................................................135
Input/output ION modules, ports and labels .................................................... 135
I/O option modules .......................................................................................136
Option I/O modules configuration............................................................. 137
Analog inputs...............................................................................................138
Analog outputs.............................................................................................140
Digital inputs................................................................................................141
IRIG-B time synchronization .................................................................... 141
WAGES monitoring ................................................................................143
Input metering........................................................................................144
Digital outputs..............................................................................................146
Energy pulsing.............................................................................................148
Alarms and alerts..........................................................................................150
Alarms overview...........................................................................................150
Alarm types .................................................................................................150
Relative setpoint ..........................................................................................152
Alarm event priorities....................................................................................152
Alarm indicators ...........................................................................................153
Default alarms .............................................................................................154
Alarm information.........................................................................................154
Viewing and acknowledging alarms using the meter’s display .......................... 155
Alarm configuration ......................................................................................155
7EN05-0336-03 7

9410 series
Alerting........................................................................................................159
Setpoint learning overview............................................................................160
Learning installation mode and learning duration ............................................ 160
Resets ............................................................................................................164
Meter resets ................................................................................................164
Option module reset .....................................................................................164
Available resets ...........................................................................................164
Measurements ..............................................................................................168
Power and power factor................................................................................168
Power demand.............................................................................................170
WAGES monitoring ......................................................................................171
Incremental energy ......................................................................................172
Conditional energy .......................................................................................173
Trending and forecasting overview ................................................................ 174
Power quality.................................................................................................176
Power quality overview.................................................................................176
Sag/swell overview.......................................................................................176
Harmonics overview.....................................................................................176
Voltage crest factor.......................................................................................177
Crest factor current.......................................................................................177
K-factor .......................................................................................................177
Harmonic content calculations.......................................................................178
TDD calculations..........................................................................................178
thd and TDD ................................................................................................178
Phasors.......................................................................................................178
Disturbance direction detection overview ....................................................... 179
COMTRADE................................................................................................180
COMTRADE implementation overview..................................................... 180
Waveforms on your meter’s webpages .......................................................... 181
Verifying accuracy ........................................................................................184
Overview of meter accuracy..........................................................................184
Accuracy test requirements...........................................................................184
Energy pulsing.............................................................................................185
Verifying accuracy test meter settings ............................................................ 185
Verifying accuracy test..................................................................................186
Calculate the number of required pulses ........................................................ 187
Percentage error calculation for accuracy verification testing ........................... 188
Typical sources of test errors.........................................................................188
Accuracy verification test points .................................................................... 188
Revenue metering ........................................................................................190
Revenue metering overview..........................................................................190
Components of revenue metering.................................................................. 190
Revenue firmware security features............................................................... 190
Protected features and settings ..................................................................... 190
Revenue meter pre-installation procedure...................................................... 190
Revenue locking ..........................................................................................191
Revenue lock switch.....................................................................................191
8 7EN05-0336-03

9410 series
Revenue locking your meter..........................................................................192
PT/CT correction .......................................................................................... 192
Time of use..................................................................................................193
Specifications overview ...............................................................................194
Mechanical characteristics............................................................................194
Electrical characteristics ...............................................................................194
Environmental characteristics ....................................................................... 196
LEDs...........................................................................................................197
EMC (electromagnetic compatibility).............................................................. 197
Safety .........................................................................................................198
Ethernet communications .............................................................................198
RS-485 communications...............................................................................198
Real-time clock ............................................................................................198
MID.............................................................................................................198
Remote display ............................................................................................199
Option modules............................................................................................199
Other...........................................................................................................199
7EN05-0336-03 9

Safety precautions 9410 series
Safety precautions
Installation, wiring, testing and service must be performed in accordance with all local
and national electrical codes.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Failure to follow these instructions will result in death or serious injury.
• Apply appropriate personal protective equipment (PPE) and follow safe electrical
work practices. See NFPA 70E in the USA, CSA Z462 or applicable local
standards.
• Turn off all power supplying this device and the equipment in which it is installed
before working on the device or equipment.
• Always use a properly rated voltage sensing device to confirm that all power is
off.
• Treat communications and I/O wiring connected to multiple devices as hazardous
live until determined otherwise.
• Do not exceed the device’s ratings for maximum limits.
• Never short the secondary of a potential/voltage transformer (PT/VT).
• Never open circuit a current transformer (CT).
• Always use grounded external CTs for current inputs.
• Do not use the data from the meter to confirm power is off.
• Replace all devices, doors and covers before turning on power to this equipment.
NOTE: See IEC 60950-1:2005, Annex W for more information on communications
and I/O wiring connected to multiple devices.
WARNING
UNINTENDED OPERATION
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
Do not use this device for critical control or protection applications where human or
equipment safety relies on the operation of the control circuit.
WARNING
POTENTIAL COMPROMISE OF SYSTEM AVAILABILITY, INTEGRITY, AND
CONFIDENTIALITY
Failure to follow these instructions can result in death, serious injury, or
equipment damage.
• Change default passwords to help prevent unauthorized access to device
settings and information.
• Disable unused ports/services and default accounts, where possible, to minimize
pathways for malicious attacks.
• Place networked devices behind multiple layers of cyber defenses (such as
firewalls, network segmentation, and network intrusion detection and protection).
• Use cybersecurity best practices (for example: least privilege, separation of
duties) to help prevent unauthorized exposure, loss, modification of data and
logs, interruption of services, or unintended operation.
7EN05-0336-03 11

9410 series Meter overview
Meter overview
9410 overview
The 9410 series power and energy meters help meet the needs of your energy
monitoring and cost management applications.
All 9410 meters comply with international metering accuracy standards. You can
customize your meter by loading specialized frameworks, and adding option modules
and incorporating mounting accessories into the physical installation.
Meter features
True RMS metering to the 63rd harmonic
Active (kW), reactive (kVAR) and apparent (kVA) power
600 V direct connection on voltage inputs
Minimum/maximum readings of metered data
Power quality readings (THD)
Downloadable firmware and template
Configuration through integrated or remote display
Modbus master, Ethernet gateway protocols supported
Web interface
Sag/Swell capture for voltage and currents
Time synchronization to 1 ms accuracy
Dual port Ethernet (two physical ports, one Ethernet IP address)
Water Air Gas Electricity Steam (WAGES) support
Time of use support
Trending and forecasting
Alarms (active and historic) display viewing and acknowledgment
Multiple languages supported
Advanced security
Variety of industry-standard communications protocols supported
Your meter in an energy management system
As a key piece in your energy management system, the meter provides highly
accurate measurements and calculations for a wide variety of power system values,
performs analysis on collected data, alerts you of potential issues and integrates with a
variety of display and analysis software.
12 7EN05-0336-03

Meter overview 9410 series
Simple
configuration
Highly accurate
metering
Trending and
forecasting
Alarming and
alerting
Time of use
Cost allocation/tenant billing
Powerful
customization
Inputs / outputs
Power quality
monitoring
Energy
efficiency
Asset and network
management
Understa
nd
Measure
Act
Easy access
to information
Configurable
security
Perform basic setup using the color LCD display , the meter
webpages or ION Setup
Customize meter functionality using the power of ION
Access highly accurate measurements and calculations for a
wide variety of power system values
Use the onboard or extendible I/O for non-critical control,
WAGES and input metering, energy pulsing and system
monitoring (for example, breaker status)
Receive notifications of predefined meter and system events
or create custom alarms
Configure meter to help protect against unauthorized
configuration of your meter and access to your meter ’s data
Data and event
logging
Easily access information after basic configuration using:
• a variety of industry-standard protocols
• various energy management and system control software
• the meter ’s internal webpages (standard or customized to
suite your needs)
• the optional remote display (DIN models)
Use the meter as a gateway to access information from
downstream devices
T
rack the trends for power system values over time to
understand energy usage patterns, optimize network capacity
and forecast future usage
Improve energy ef ficiency and track compliance to green
standards
Help prolong asset life with proactive network management
Time of use and perform cost allocation/tenant billing
Log data in a number of onboard default logs, or customize
your meter to log other parameters, and access that
information using software or webpages
http://meteripaddress
Energy
manageme nt
software
Monitor compliance to a variety of power quality standards
using the meter ’s highly accurate metering
Use the meter ’s setpoint learning feature to learn your power
system’ s normal operating values
Locate disturbances using disturbance direction detection
Measured parameters
Energy
Your meter provides bi-directional 4-quadrant energy metering.
Your meter provides active, reactive and apparent energy values.
• kWh, kVARh, kVAh delivered and received
• kWh, kVARh, kVAh net (delivered - received)
• kWh, kVARh, kVAh total (delivered + received)
• Volt-squared-hours and amp-squared-hours
Energy parameters can be logged automatically on a programmed schedule.
All energy values represent the total for all three phases.
7EN05-0336-03 13

9410 series Meter overview
Demand
Your meter supports several demand calculation methods, including block, rolling
block, synchronized and predicted demand.
It can measure demand on any instantaneous value and record peak (maximum) and
minimum demand with time and date information.
• kW, kVAR, kVA demand
• kW, kVAR, kVA peak demand
• Amps, Volts demand
Instantaneous
Your meter provides one second and half-cycle measurements, per phase and totals
for many values.
• Voltage and current
• Apparent power (kVA), active power (kW) and reactive power (kVAR)
• Power factor and frequency
• Voltage and current unbalance
Harmonics
Your meter provides harmonic distortion metering, recording and real-time values for
all voltage and current inputs.
• Individual harmonics (including magnitude and phase angle) up to the 63rd
harmonic
• Total even harmonic distortion (TEHD) and total odd harmonic distortion (TOHD)
• Total harmonic distortion (THD) or total demand distortion (TDD)
• K-factor, Crest factor
Min/max recording
Your meter records new minimum and maximum data every recording interval for a
variety of values.
• Voltage and current
• kW, kVAR and kVA
• Power factor
• Frequency
• Voltage unbalance
• Plus any measured value
Power quality
Your meter measures and records voltage and current sags and swells.
Your meter also has many power quality related features.
• Disturbance direction detection: this allows the meter to analyze disturbance (sag/
swell) information to help determine the direction of the disturbance relative to the
meter.
• Setpoint learning: this allows the meter to learn the power quality characteristics of
your system, to help identify what constitutes a sag or a swell.
14 7EN05-0336-03

Meter overview 9410 series
• COMTRADE: this allows the meter to save waveform data in COMmon format for
TRAnsient Data Exchange (COMTRADE) on its internal FTP server.
Your meter includes the following power quality compliance:
• EN50160: Your meter measures and presents statistics for determining EN50160
compliance.
• IEC 61000-4-30: Your meter complies with the IEC 61000-4-30 power quality
standard.
• IEC 62586: Your meter complies with the IEC 62586 power quality standard.
Localization
The meter can be customized to use different regional settings.
Localization settings determine:
• The language used for the display and webpages
• Time, date and digit formats
• Displayed phase labels (123/ABC)
• IEEE (Institute of Electrical and Electronics Engineers) or IEC (International
Electrotechnical Commission) conventions for power, power factor and energy
You can configure your meter’s localization settings through the display or using ION
Setup.
Data display and analysis tools
Display
Use the meter’s display for local monitoring and standalone applications.
The color LCD display lets you view real-time values, events and alarms, and perform
basic device configuration. Connect a remote display to a meter without an integrated
display to view meter data and perform basic meter configuration.
Active and historical alarms
The meter’s display shows an alarm icon and the alarm LED flashes if your meter
detects an active alarm condition.
Depending on the priority of the alarm, your meter’s display also flashes. You can view
and acknowledge active alarms and historic alarms and events through the display
and software webpages. An active alarm becomes a historic alarm when the alarm
condition no longer exists.
Meter internal web server feature
Your meter’s internal web server provides quick and easy access to real-time energy
and basic power quality information without special software using an on-board web
server combined with an Ethernet port.
The built-in web pages display selected energy and power quality information through
the web-enabled device; these pages also support basic meter configuration.
7EN05-0336-03 15

9410 series Meter overview
Email messaging feature
You can configure your meter to automatically email information, whether notification
of a high-priority event or a regularly scheduled send of logged data, to an external
email address.
Specify the type of event that triggers an email alert, such as a power quality
disturbances or interval for logged data. Email messages from your meter are received
like any other email message.
Supported protocols
Your meter’s fundamental protocol and architecture is ION.
You can integrate the meter into various industry-standard networks. Data that the
meter measures can be made available to other devices using Modbus, DNP 3.0 and
SNMP as well as the MV-90 translation system. You can configure the meter to import
data from other devices on these networks. Your meter supports the IEC 61850
protocol and COMTRADE waveform data format.
Your meter also supports IPv6, DPWS and RSTP Ethernet protocols.
Related Topics
• Protocols, ports and connections
ION Setup device configuration tool
ION Setup is a free configuration tool for your meter that allows you to remotely
configure your meter’s features over Ethernet or serial communications.
• Use the setup screens to guide you through the process of configuring your meter.
• Use the real-time data screens to verify your meter’s configuration.
• Use the data screens to view your meter’s recorded data.
• Use the charting function to view your meter’s recorded waveforms.
You can download ION Setup from www.usa.siemens.com/pds.
See the online ION Setup help, available from www.usa.siemens.com/pds, for
instructions on connecting to your meter.
Meter types
The 9410 series is available in two physical form factors, and has several accessories.
Model Commercial reference Description
9410DC US2:9410DC Panel-mounted meter with integrated display
9410D24VDC US2:9410D24VDC Same as the 9410DC, except with low-voltage DC
control power
9410TC US2:9410TC DIN rail-mounted meter without display, which can
be connected to a remote display
9410T24VDC US2:9410T24VDC Same as the 9410TC, except with low-voltage DC
control power
9410RC US2:9410RC DIN rail-mounted meter packaged with a remote
display
16 7EN05-0336-03

Meter overview 9410 series
Model Commercial reference Description
9410RVDC US2:9410R24VDC Same as the 9410TC, except with low-voltage DC
control power
948DISP96 US2:948DISP96 Remote display (for DIN meter only)
948M2DO6DI US2:948M2DO6DI Digital I/O option module (2 outputs, 6 inputs)
948M2AO4AI US2:948M2AO4AI Analog I/O option module (2 outputs, 4 inputs)
9410SK US2:9410SK Voltage and current sealing kit
94PMAK 94PMAK Mounting adapter kit for remote display and DIN
meter
Mounting adaptors
There are different mounting adaptor accessories that can help when installing your
meter in existing panels and cutouts where the default mounting hardware is not
appropriate.
Mounting adaptor kits are ordered separately from the meter.
Terminal covers
The voltage and current terminal covers help prevent tampering with the meter’s
voltage and current measurement inputs.
The terminal covers enclose the terminals, the conductor fixing screws and a length of
the external conductors and their insulation. The terminal covers are secured by
tamper-resistant meter seals.
These covers are included for meter models where sealable voltage and current
covers are required to comply with revenue or regulatory standards.
The meter terminal covers must be installed by a qualified installer.
Refer to your meter's installation sheet or the instructions that came with your terminal
covers for instructions on installing the terminal covers.
Replacement hardware
You can order replacement mounting and installation hardware for your meter and
accessories.
7EN05-0336-03 17

9410 series Basic setup
Basic setup
Default values for commissioning
Use these default settings for the first time you connect to and configure your meter.
Parameter Default value
Display password (also for logging onto meter webpages) 0
Username (for logging onto meter webpages) 9410
IP address 169.254.0.10
Subnet mask 255.255.0.0
Gateway 0.0.0.0
Unit ID 1
Language English
Meter setup
You can configure your meter’s basic metering parameters using the display.
Volts mode
Parameter Values Description
Volts Mode 4W-Wye, Delta, 3W-Wye,
Single, Demo
The power system’s configuration
PhaseOrder ABC, ACB The power system’s phase order
PT/CT setup
Parameter Values Description
PT Primary 1 to 999,999.99 The potential transformer’s primary winding voltage
rating
NOTE: PTs are also referred to as a VTs or
voltage transformers.
PT Secondary 1 to 999,999.99 The potential transformer’s secondary winding
voltage rating
NOTE: PTs are also referred to as a VTs or
voltage transformers.
CT Primary 1 to 999,999.99 The current transformer’s primary winding current
rating
CT Secondary 1 to 999,999.99 The current transformer’s secondary winding
current rating
I4 Primary 1 to 999,999.99 The I4 current transformer’s primary winding
current rating
I4 Secondary 1 to 999,999.99 The I4 current transformer’s secondary winding
current rating
18 7EN05-0336-03

Basic setup 9410 series
Voltage polarity setup
Parameter Values Description
Va Polarity Normal, Inverted The polarity of the potential transformer on Va
Vb Polarity Normal, Inverted The polarity of the potential transformer on Vb
Vc Polarity Normal, Inverted The polarity of the potential transformer on Vc
Current polarity setup
Parameter Values Description
Ia Polarity Normal, Inverted The polarity of the current transformer on Ia
Ib Polarity Normal, Inverted The polarity of the current transformer on Ib
Ic Polarity Normal, Inverted The polarity of the current transformer on Ic
I4 Polarity Normal, Inverted The polarity of the current transformer on I4
Nominal values
Parameter Values Description
V Nominal 1 to 999,999 The nominal (normal) voltage of the power system
I Nominal 1 to 999,999 The nominal (normal) current of the power system
Nominal
Frequency
50, 60 The nominal (normal) frequency of the power
system
Minimum configuration requirements for basic metering
At a minimum, you must configure some parameters to help your meter perform basic
metering functions.
Setup screen Screen Minimum configuration
Meter Setup Volts Mode Volts mode
PT/CT Setup PT, CT and I4 CT primary and secondary
Nominal values V nominal, I nominal, Nominal frequency
NOTE: You must also configure all the parameters related to the meter features
you are using, for example, you must configure the DNS server address if you are
using the meter’s DNS feature.
7EN05-0336-03 19

9410 series Hardware reference
Hardware reference
Supplemental information
This document is intended to be used in conjunction with the installation sheet that
ships in the box with your meter and accessories.
See your device’s installation sheet for information related to installation.
See your product’s catalog pages at www.usa.siemens.com/pds for information about
your device, its options and accessories.
You can download updated documentation from www.usa.siemens.com/pds or contact
your local Siemens Industry representative for the latest information about your
product.
Meter base
Your meter base has two form factors, panel mount and DIN mount.
Panel meter
A Voltage inputs
B Control power
C Digital inputs (3)
D Revenue lock switch cover
E Digital output
F Gasket
G RS-485
H Ethernet (2)
I Current inputs
J Option module connector
K Display
Mounting hardware and accessories not shown.
20 7EN05-0336-03
