Siemens SICAM P 7KG7750 User manual

E50417-B1076-C340-A6
Power Meter
SICAM P 7KG7750/55
Manual
Foreword, Contents
Commissioning 1
Operation 2
Measured Quantities 3
Device Parameterization 4
Parameterization via PC Software 5
Calibration 6
Maintenance, Storage, Transport 7
Technical Data 8

Siemens Aktiengesellschaft Order No.: E50417-B1076-C340-A6
Disclaimer of Liability
We have checked the contents of this document and every effort
has been made to ensure that the descriptions of both hardware
and software are as accurate as possible. However, since devia-
tions cannot be ruled outentirely, we do not accept liability for com-
plete conformity or for any errors or omissions.
The information in this manual is checked periodically, and neces-
sary corrections will be included in future editions. We are grateful
for any improvements that you care to suggest.
Subject to technical alterations.
Document Release V99.06
Edition 09.2013
Copyright
Copyright © Siemens AG 2013
This document shall not be transmitted or reproduced, nor shall its
contents be exploited or disclosed to third parties without prior writ-
ten consent from Siemens. Offenders will be liable for damages. All
rights, including rights created by patent grant or registration of a
utility model or design, are reserved.
Registered Trademarks
SIPROTEC®, DIGSI®, OSCOP®and SICAM®are registered
trademarks of SIEMENS AG.
Other designations in this manual might be trademarks whose use
by third parties for their own purposes would infringe the rights of
the owner.
Note
Please observe the instructions and warnings for your safety in the foreword.

3Power Meter, SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Foreword
Purpose of the manual
This manual describes the commissioning, operation and parameterization of the Power Meter
SICAM P 7KG7750/55.
Target audience
This manual is directed to the user of the Power Meter SICAM P.
Validity of the manual
This manual is valid for the devices SICAM P 7KG7750/55.
Additional support
For any questions concerning your system, please contact your local Siemens representative.
Hotline Our Customer Support Center provides around-the-clock service.
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: http://www.powerquality.de/pq_da/index_e.htm
Further documents
SICAM P Power Meter 7KG775x Operating Instructions
Ordering no. E50417-B1074-C339
SICAM P PROFIBUS DP Manual
Ordering no. E50417-B1076-C238
Power Meter SICAM P Modbus Manual
Ordering no. E50417-B1076-C241
Power Meter SICAM P 7KG7750/55 Communication Protocol IEC 60870-5-103 Manual
Ordering no. E50417-B1076-C375

Foreword
4Power Meter, SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Training courses
Please ask our Training Center for information on the individual courses available:
Siemens AG
Siemens Power Academy TD
Humboldtstr. 59
90459 Nuremberg
Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: http://www.siemens.com/poweracademy

Foreword
5Power Meter, SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Information for your safety
This manual does not represent a complete listing of all the safety measures required to operate
the equipment (module, device) since specific operating conditions may make further measures
necessary. However, it contains information which you have to observe in order to ensure your
personal safety and in order to avoid material damage. The information is highlighted by a warn-
ing triangle and, depending on the degree of danger, is shown as follows:
DANGER
DANGER means that death or severe injury will result if the measures specified are not taken.
•Comply with all instructions, in order to avoid death or severe injuries.
WARNING
WARNING means that death or severe injury may result if the measures specified are not taken.
•Comply with all instructions, in order to avoid death or severe injuries.
CAUTION
CAUTION means that minor or moderate injury can occur if the measures specified are not
taken.
•Comply with all instructions, in order to avoid moderate or minor injuries.
NOTICE
NOTICE means that property damage can result if the measures specified are not taken.
•Comply with all instructions, in order to avoid material damage.
Note
Important information about the product, product handling or a certain section of the documen-
tation, which must be given particular attention.

Foreword
6Power Meter, SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Statemant of Conformity
Qualified personnel
Commissioning and operation of the equipment (module, device) described in this manual must
be performed by qualified personnel only. As used in the safety notes contained in this manual,
qualified personnel are those persons who are authorized to commission, release, ground, and
tag devices, systems and electrical circuits in accordance with the safety standards.
Use as prescribed
The equipment (device, module) must not be used for any other purposes than those described
in the Catalogue and the Technical Description. If it is used together with third party devices and
components, these must be recommended or approved by Siemens.
Correct and safe operation of the product requires adequate transportation, storage, installation,
and mounting as well as appropriate use and maintenance.
During operation of electrical equipment, it is unavoidable that certain parts of this equipment will
carry dangerous voltages. Severe injury or damage to property can occur if the appropriate
measures are not taken:
•Before making any connections at all, ground the equipment at the PE terminal.
•Hazardous voltages can be present on all switching components connected to the power
supply.
•Even after the supply voltage has been disconnected, hazardous voltages can still be
present in the equipment (capacitor storage).
•Equipment with current transformer circuits must not be operated while open.
•The limit values indicated in the manual must not be exceeded; that also applies to testing
and commissioning.
This product complies with the directive of the Council of the European Communities
on the approximation of the laws of the Member States relating to electromagnetic
compatibility (EMC Council Directive 2004/108/EC) and concerning electrical
equipment for use within specified voltage limits (Low-voltage Directive 2006/95/EC).
This conformity has been established by means of tests conducted by Siemens AG
according to the Council Directive in agreement with the generic standards EN 61000-
6-2 and EN 61000-6-4 for the EMC directives, and with the standard EN 61010-1 for
the low-voltage directive.
The device has been designed and produced for industrial use.
The product conforms to the standards IEC 60688, EN 60688 or DIN EN 60688.

Contents
7Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Contents
1 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Application and Mode of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.2 Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Ordering Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.3.1 SICAM P 7KG7750 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.3.2 SICAM P 7KG7755 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.3.3 Parameterization Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.4.1 Device Variant SICAM P 7KG7750 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.4.2 Device Variant SICAM P 7KG7755 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.5 Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.6 Interface and Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.6.1 Terminal Assignment SICAM P 7KG7750/55 . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.6.2 Terminal Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1.6.3 Assignment of the Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1.6.4 Connection Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.6.4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.6.4.2 Single-phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.6.4.3 Three-phase, Three-wire, Balanced. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1.6.4.4 Three-phase, Three-wire, Unbalanced ( 2 I, Aron Circuit). . . . . . . . . . . . . . 27
1.6.4.5 Three-phase, Four-wire, Balanced. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
1.6.4.6 Three-phase, Four-wire, Unbalanced (Low-voltage System). . . . . . . . . . . . 28
1.6.4.7 Three-phase, Four-wire, Unbalanced (High-voltage System) . . . . . . . . . . . 29
1.6.5 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
1.6.6 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1.6.7 Electrical Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2.1 Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.2 Screen Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.2.1 Screen Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.2.1.1 3 Measured Values - Digital. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2.2.1.2 6 Measured Values - Digital. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2.2.1.3 U, I and cos f (Phasors) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2.2.1.4 3 Min-Max Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.2.2 Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3 Measured Quantities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.1 Measured Quantities - Depend on the Connection Type . . . . . . . . . . . . . . . . . . . . 40

Contents
8Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
3.2 Formulas and Calculation of Derived Quantities . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.2.1 Calculation of Derived Quantities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.2.2 Remarks to the Measuring Quantities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3.3 Connection Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3.3.1 Four-wire Three-phase Current with Any Load. . . . . . . . . . . . . . . . . . . . . . . . . . 49
3.3.2 Single-phase AC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3.3.3 Four-wire Three-phase Current with Symmetrical Load . . . . . . . . . . . . . . . . . . . 49
3.3.4 Three-wire Three-phase Current with Symmetrical Load . . . . . . . . . . . . . . . . . . 49
3.3.5 Three-wire Three-phase Current with Any Load. . . . . . . . . . . . . . . . . . . . . . . . . 50
3.4 View of Measured Quantities and Error Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4 Device Parameterization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
4.1 Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.1.1 Button Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.1.2 Windows Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.1.3 Notes on Parameterization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.2 Overview of the Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.3 Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.3.1 Startup-phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.3.2 Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.3.3 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
4.3.4 Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
4.3.5 Date / Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.3.6 Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.4 Basic Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.4.1 Settings Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.4.2 Connection / Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.4.2.1 Current Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.4.2.2 Voltage Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.4.3 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.4.3.1 Screen for Energy Pulses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.4.3.2 Screen for Limit Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.4.4 Communication Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4.4.4.1 General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4.4.4.2 IEC 60870-5-103 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
4.4.5 Changing the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.4.5.1 Password of Code 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.4.5.2 Password of Code 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.4.6 Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4.4.7 Additional Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4.4.8 Further Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.5 About SICAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
4.6 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
4.7 Reset Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.8 Parameterization Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.9 I/O Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
4.10 Memory Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Contents
9Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
4.11 Data Logger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
4.11.1 Data Logger Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
4.11.2 Data Logger Limit Violation Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
4.11.3 Data Logger Binary States. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4.12 Overflow of Measured Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
5 Parameterization via PC Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
5.1 Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5.2 Overview of Parameterization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5.2.1 Overview of Parameterization 7KG7750 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5.2.2 Overview of Parameterization 7KG7755 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5.3 Date / Time Settings and Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
5.4 Dialog Window SICAM P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
5.5 Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.5.1 Connection / Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5.6 Screens Setting on SICAM P 7KG7750 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5.6.1 Basic Screen Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.6.2 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.7 Input / Output Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
5.7.1 Binary / Relay Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
5.7.2 Information on Energy Pulse Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5.7.2.1 Parameterization via Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5.7.2.2 Pulse Time, Switch Off Time, Number of Pulses. . . . . . . . . . . . . . . . . . . . . 93
5.7.2.3 Parameterization of Energy Pulses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
5.7.2.4 Parameterization of Energy Pulses via Parameterization Software. . . . . . . 95
5.7.3 Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
5.7.4 Analog Outputs (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
5.7.5 Analog Inputs (optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
5.7.6 Binary Inputs (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
5.8 Additionals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5.8.1 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
5.8.2 Device Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
5.8.3 Limit Value Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
5.8.4 Clock Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
5.9 Memory Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
5.9.1 Splitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
5.9.2 Mean Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
5.9.3 Power Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5.9.4 Oscilloscope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
5.9.4.1 Characteristics of „Instantaneous Values“ Recording. . . . . . . . . . . . . . . . . 113
5.9.4.2 Characteristics of "RMS Value" Recording . . . . . . . . . . . . . . . . . . . . . . . . . 114
5.9.5 Parameterization Oscilloscope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
5.9.6 Limit Violation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
5.9.7 Binary States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
5.10 Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
5.11 Resetting Values in the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Contents
10 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
5.12 Reading the Device Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
5.12.1 Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
5.12.2 Charts / Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
5.12.3 Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
5.12.4 Timestamps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
5.12.5 Mean Value Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
5.12.6 Power Value Record. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
5.12.7 Oscilloscope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
5.12.8 Limit Violation Record. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
5.12.9 Binary States. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
5.12.10 Log Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
5.13 Changing the Communication Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
6Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
6.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
6.2 Connection Diagrams for Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
6.3 Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
7 Maintenance, Storage, Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
7.1 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
7.2 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
7.3 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
8 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
8.1 SICAM P 7KG7750. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
8.1.1 General Device Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
8.1.1.1 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
8.1.1.2 Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
8.1.1.3 Communication Interface (Connector J) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
8.1.1.4 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
8.1.1.5 General Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
8.1.2 Test Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
8.1.2.1 Electrical Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
8.1.2.2 Mechanical Stress Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
8.2 SICAM P 7KG7755. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

11Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Commissioning 1
Contents The following chapters describe all aspects of commissioning.
1.1 Application and Mode of Operation 12
1.2 Delivery 13
1.3 Ordering Data 14
1.4 Dimensions 16
1.5 Block Diagram 20
1.6 Interface and Terminals 22

1
1.1 Application and Mode of Operation
12 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.1 Application and Mode of Operation
Range of Application
The Power Meter SICAM P is capable of recording several different power system measure-
ments. In addition, the SICAM P is designed to be utilized in a number of different industries.
The display of measured quantities can be easily configured to the specific requirements of the
user.
Network linking is possible with the integral RS485 port equipped with the standard PROFIBUS
DP-V1,ModbusRTU/ASCIIorIEC 60870-5-103protocolwhichprovide forindication, evaluation
and processing of several SICAM P measurements at a central master station.
Mode of Operation
Input voltages and currents are sampled for calculation of the corresponding RMS values. All
measurementsderivedfromsampledvaluesarecalculatedbya processor. Measuredquantities
can be displayed on the screens and/or transmitted via the serial interface.
With the SICAM P, it is possible to program limit value groups for various measured quantities
toactivatelimit violationswhenthe valueofa specificmeasuredquantityexceedsa programmed
threshold. In addition, it is possible use logical elements (AND, OR) to combine two or more mea-
sured quantities for the purpose of generating a limit violation. Limit violations are counted, indi-
cated on the screen and/or utilized to operate the binary output contacts. The oscilloscope may
be triggered via a limit violation as well.
All measured quantities can be displayed on the SICAM P screens as required by the user. Up
to 20 screens can be selected with the front keys. The number, type, content and sequence of
the screens are configurable. SICAM P is delivered with pre-programmed default settings.
A status line displayed in the measured value screens indicates status, interfacing and diagnos-
tic messages for the SICAM P. The display is automatically refreshed every second.

1
1.2 Delivery
13Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.2 Delivery
Delivery note
The power meter will be delivered in a cardboard box containing the SICAM P logo.
Contents of delivery
1 Device SICAM P
2 Panel mounting fittings (only 7KG7750)
1 Operating Instruction (Ordering no. E50417-B1074-C339)
1 Return Card
1 Device Test Report
1 Battery VARTA CR2032
WARNING
Warning: Danger of explosion of the battery.
Nonobservance of the safety instructions means that death, severe
injuries or considerable material damages can occur.
•Servicing of the battery circuit and replacing of the battery must be performed by qualified
personnel only. Battery may explode if mistreated.
•Do not reverse the polarity!
•Do not disassemble the battery!
•Do not completely discharge the battery!
•Do not throw the battery into a fire!
WARNING
Warning about battery disposal.
Nonobservance of the safety instructions means that death, severe
injuries or considerable material damages can occur.
•When discharged, or when properly secured against short-circuit, lithium batteries can be
disposed of through retailers or at depots run by competent organizations (e.g. in Germany
GRS collection points).
Note
The lithium-batteries in the equipment are subject to special provision 188/A45 of the dangerous
goods regulations of the different transport modes (as in edition 2003, lithium content and tests
of UN Manual of Tests and Criteria).
This is only valid for the original battery or original spare batteries. For general transport security
by shipment as freight: Electric equipment is only to be sent as freight if shut off.

1
1.3 Ordering Data
14 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.3 Ordering Data
1.3.1 SICAM P 7KG7750
Description
Power Meter
SICAM P 7KG7750
Built in device for control panels 96 mm x 96 mm
with graphic display
I/O module (optional) A
2 binary outputs B
2 binary inputs C
2 analog outputs
DC 0 mA to 20 mA/DC 4 mA to 20 mA D
2 analog inputs
DC 0 mA to 20 mA E
3 relay outputs G
Front protection class
IP 41 1
IP 65 3
Communication interface and protocols
PROFIBUS DP and Modbus RTU/ASCII / RS485 0
IEC 60870-5-103 and Modbus RTU/ASCII / RS485 1
-A0- 0 0 0AA
Without (standard)
Order No.
7KG775

1
1.3 Ordering Data
15Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.3.2 SICAM P 7KG7755
1.3.3 Parameterization Package
Description
Power Meter
SICAM P 7KG7755
Snap on mounting unit 96 mm x 96 mm, without
grafic display, front protection class IP 20
I/O Module (optional)
2 binary outputs B
2 binary inputs C
2 analog outputs
DC 0 mA to 20 mA/DC 4 mA to 20 mA D
2 analog inputs
DC 0 mA to 20 mA E
3 relay outputs G
Communication interface and protocols
PROFIBUS DP and Modbus RTU/ASCII / RS485 0
IEC 60870-5-103 and Modbus RTU/ASCII / RS485 1
Without (standard)
Order No.
77KG 7 5 5 - 0
A
-0AA0A0
Description
SICAM P Parameterization Package
Type
RS485 / 5 V-power supply unit /
supply voltage AC 230 V/50 Hz
B
50- A
Software SICAM P PAR,
RS232/RS485 adapter
RS485 / 5 V-power supply unit /
supply voltage AC 120 V/60 Hz
A
Order No.
07KG 7 8

1
1.4 Dimensions
16 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.4 Dimensions
1.4.1 Device Variant SICAM P 7KG7750
Fig. 1-1 SICAM P 7KG7750, variant IP 41
Note: All dimensions in mm

1
1.4 Dimensions
17Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Fig. 1-2 SICAM P 7KG7750, variant IP 65
Note: All dimensions in mm

1
1.4 Dimensions
18 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
Fig. 1-3 SICAM P 7KG7750
Technical Data for Housing
Housing: Flush mounting according to IEC 61554/DIN 43700
Panel section: 92.0+0,8 mm x 92.0+0,8 mm
Protection class: front IP 41 or IP 65
terminals IP 20
for personal security IP 1x
Terminals Terminals for power supply, voltage inputs, current inputs, binary outputs, I/O modules
(optional):
Conductor cross section, rigid max.: 2.5 mm2
Conductor cross section with ferrule: 1.5 mm2
Stripping length: 9 mm
Tightening torque: 0.4 Nm to 0.5 Nm
RS485 interface 9-pole D-Sub miniature female connector
Note: All dimensions in mm

1
1.4 Dimensions
19Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.4.2 Device Variant SICAM P 7KG7755
Fig. 1-4 SICAM P 7KG7755, snap on mounting unit
Technical Data for Housing
Housing snap on mounting unit
Protection class front / terminals IP 20
for personal security IP 1x
Terminals Terminals for power supply, voltage inputs, current inputs, binary outputs, I/O modules
(optional):
Conductor cross section, rigid max.: 2.5 mm2
Conductor cross section with ferrule: 1.5 mm2
Stripping length: 9 mm
Tightening torque: 0.4 Nm to 0.5 Nm
RS485 interface 9-pole D-Sub miniature female connector
105,1
Note: All dimensions in mm

1
1.5 Block Diagram
20 Power Meter SICAM P 7KG7750/55, Manual
E50417-B1076-C340-A6, Edition 09.2013
1.5 Block Diagram
Fig. 1-5 Block diagram SICAM P 7KG7750/55
SICAM P 7KG775x
Terminal block F
L1 L2 L3 N L1
kl
L2 L3
Measurement Auxiliary Voltage
N/- L/+
Binary Outputs
communication
J
RS485, Modbus and
IEC 60870-5-103
1Protective Ground 3A 4RTS 5GND 6+5V 8B PROFIBUS DP 1Protective Ground 3B 4CTRL-A 5GND 6+5V 8A
RS485
RS232
Voltage Current
k
k
l
l
L3
N
DC 24 to 250 V AC 100 to 230V
Terminal block ETerminal block H
B2 B1R
Terminal block G
L1
L2
PG
Note
The integrated battery serves to buffer the memory and the real-time clock.
