Siemens 9810 Series User manual

9810 series
User manual
7EN05-0336-09
01/2023
www.usa.siemens.com/pds

Safety information
Important information
Read these instructions carefully and look at the equipment to become familiar with the
device before trying to install, operate, service, or maintain it. The following special
messages may appear throughout this manual or on the equipment to warn of potential
hazards or to call attention to information that clarifies or simplifies a procedure.
The addition of either symbol to a "Danger" or "Warning" safety label indicates that an
electrical hazard exists which will result in personal injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey
all safety messages that follow this symbol to avoid possible injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
Please note
Electrical equipment should be installed, operated, serviced and maintained only by qualified
personnel. No responsibility is assumed by Siemens for any consequences arising out of the use
of this material. A qualified person is one who has skills and knowledge related to the
construction, installation, and operation of electrical equipment and has received safety training to
recognize and avoid the hazards involved.

Notices
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that the
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
The user is cautioned that any changes or modifications not expressly approved by Siemens
could void the user’s authority to operate the equipment.
This digital apparatus complies with CAN ICES-3 (B) /NMB-3(B).
Open source software components
This Siemens product is provided with certain open source software components (collectively,
“OSS”) developed by third parties. Refer to "Open source software components" on page 279 for
details.

Metering equipment symbols
The following IEC 60417 and ISO 7000 symbols may be used on the metering equipment:
Symbol Reference Title and description
IEC 60417-5017
Earth; ground
To identify an earth (ground) terminal in cases where
neither the symbol 5018 nor 5019 is explicitly required.
IEC 60417-5018
Functional earthing; functional grounding (US) *
To identify a functional earthing (grounding) terminal, for
example, of a specially designed earthing (grounding)
system to avoid causing malfunction of the equipment.
IEC 60417-5019
Protective class I; Protective earth/ground
To identify any terminal which is intended for connection
to an external conductor for protection against electric
shock in case of a fault, or the terminal of a protective
earth (ground) electrode.
IEC 60417-5172
Protective class II equipment **
To identify equipment meeting the safety requirements
specified for Class II equipment (double or reinforced
insulation).
ISO 7000-0434B
Caution, refer to accompanying documents
To indicate that caution is necessary when operating the
device or control close to where the symbol is placed. To
indicate that the current situation needs operator
awareness or operator action in order to avoid
undesirable consequences.
ISO 7000-1641
Operator's manual; operating instructions
To identify the location where the operator's manual is
stored or to identify information that relates to the
operating instructions. To indicate operating instructions
should be considered when operating the device or
operating controls close to where the symbol is placed.
* There may be national differences concerning the use of this symbol.
** Protective class equipment requirements are outlined in IEC 61140.

About this manual
This manual discusses features of the Siemens 9410 series power meter and provides
configuration instructions.
Throughout the manual, the term “meter” refers to all models of the Siemens 9410 series meter.
All differences between the models, such as a feature specific to one model, are indicated with the
appropriate model number or description.
This manual assumes you have an understanding of power metering and are familiar with the
equipment and power system in which your meter is installed.
This manual does not provide configuration information for advanced features where an expert
user would perform advanced configuration. It also does not include instructions on how to
incorporate meter data or perform meter configuration using energy management systems or
software, other than ION Setup. ION Setup is a free configuration tool available for download from
www.usa.siemens.com/pds.
Contact your local Siemens representative to learn what additional training opportunities are
available regarding the Siemens 9410 series meter.
Make sure you are using the most up-to-date version of your meter’s firmware in order to access
the latest features.
The most up-to-date documentation about your meter is available for download from
www.usa.siemens.com/pds.
Document Number
Siemens 9410 series - Panel Mount installation guide MFR52309
Siemens 9410 series - DIN Mount installation guide NVE23945
ION Reference 7EN05-0290
ION device template reference –
Fiber Ethernet option module US2:948MFIBER
Related documents

Table of Contents
Notices 3
Metering equipment symbols 4
Table of Contents 6
Safety precautions 15
Meter overview 17
9410 series overview 17
Your meter in an energy management system 18
Communications 18
Supported protocols 18
Meter configuration 18
ION Setup device configuration tool 18
Switching ION Setup to Advanced mode 19
Data display 19
Built-in web server and webpages 19
Localization 19
Display 19
Notification 19
Active and historical alarms 19
Email notifications 19
9410 meter models and accessories 20
Mounting adaptors 21
Terminal covers 21
Cybersecurity 22
Recommended actions 22
Plan 25
Cybersecurity awareness 25
System defense-in-depth assumptions 26
Device security capabilities 27
Security risks and mitigation strategies 30
Configure 31
Meter security configuration 32
Disabling and enabling protocols and changing port numbers 42
Verifying the meter security settings 43
Viewing the Device Configuration Checklist 44
Applying security settings to multiple meters 44
Updating passwords on multiple meters 45
Default meter security settings 46
Advanced security mode 47
Operate 49
Monitoring the event log 49
Reporting a security vulnerability 50
7EN05-0336-09 6

Table of Contents 9410 series - User manual
7 7EN05-0336-09
Maintain 50
Viewing and downloading an event log 50
Upgrades and security configuration 51
Decommission 51
Wiping the device 51
Overwriting the meter template file 53
Restoring default security configuration 53
Overwriting factory module registers 53
Overwriting communication module registers 54
Disposal, reuse, recycling 54
Installation and commissioning 56
Installation 56
Power system wiring 57
Residual current measurement 57
Option modules 57
Maximum number of option modules 58
Panel-mount meter and remote display mounting and wiring recommendations 59
Commissioning 59
Factory default settings 59
Commissioning using ION Setup 60
Configuring metering parameters 60
Using the Phasor Viewer 61
Basic setup using the webpages or display 61
Communications 63
Communications overview 63
Ethernet communications 63
Ethernet communications connections 63
Protocols, ports, and connections 65
Self-discovery over Ethernet 65
Ethernet configuration 67
DHCP 76
Meter domain name 77
Network protocol control 78
Serial communications 80
RS-485 80
RS-485 wiring 80
RS-485 configuration 81
Disabling serial communications ports 85
ION 86
Secure ION 86
ION sessions 89
Modbus 89
Key terms 90
Ethernet Modbus device prerequisites 90

Serial Modbus device prerequisites 91
Your meter as a Modbus client 91
Your meter as a Modbus server 94
Supported Modbus features 96
Modbus implementation 98
Modbus map 99
Configuring custom Modbus data using ION Setup 100
Ethernet gateway 102
EtherGate configuration 102
Modbus Ethernet gateway 104
Creating an Ethernet gateway site using ION Setup 106
HTTPS 107
Changing web protocol settings using ION Setup 107
Secure website indicator 107
Default SSL certificate and webpages security 108
Uploading a custom SSL certificate 108
Generating a new self-signed SSL certificate 108
Deleting a custom SSL certificate 108
Secure File Transfer Protocol (SFTP) 109
Transferring files using SFTP 109
Free up flash memory 109
SFTP folders and file permissions 109
SFTP filename requirements 110
Simple Network Management Protocol (SNMP) 110
Key terms 110
Your meter in an SNMP system 110
SNMP trapping 111
Configuring SNMP using ION Setup 111
Configuring SNMP using webpages 112
SNMP implementation 113
Default SNMP mapping 115
Configuring SNMP MIB files 115
IEC 61850 117
Mapping additional data to IEC 61850 117
Enabling IEC 61850 functionality 117
Configuring digital outputs for IEC 61850 control 118
Deleting an IEC 61850 configuration file 119
Distributed Network Protocol (DNP) 119
DNP supported features and default implementation 119
Inputs/Outputs 121
Inputs/Outputs overview 121
Input/output ION modules 121
Input/output ION modules, ports, and labels 122
Factory configured settings 122
9410 series - User manual Table of Contents
7EN05-0336-09 8

Table of Contents 9410 series - User manual
9 7EN05-0336-09
I/O option modules 123
Viewing I/O option module data 124
I/O option module configuration 124
Analog inputs 125
Analog input applications 125
Analog input voltage and current mode 125
Analog input behavior 125
Analog input zero scale and full scale values 125
Configuring option module analog inputs using ION Setup 126
Analog outputs 127
Analog output applications 127
Analog output behavior 127
Analog output zero scale and full scale values 127
Configuring option module analog outputs using ION Setup 128
Digital inputs 128
Digital input applications 128
IRIG-B time synchronization 129
Configuring onboard digital inputs using ION Setup 130
Configuring option module digital inputs using ION Setup 130
WAGES monitoring 131
Input metering 132
Digital outputs 134
Digital output applications 134
Configuring onboard digital outputs using ION Setup 135
Configuring option module digital outputs using ION Setup 135
Energy pulsing 136
Default energy pulsing LED sources 136
Configuring LED energy pulsing using IONSetup 137
Configuring digital output energy pulsing using ION Setup 138
Calculate your maximum kWh/pulse (pulse weight) value 139
Webpages 140
Webpage interface 140
Default meter webpages 140
Accessing webpages for data viewing and meter configuration 142
Embedding images and files in meter webpages 143
Creating custom webpages 143
Deleting custom webpages 144
Loading webpages using ION Setup 144
Loading webpages using SFTP 144
Sample data viewing webpage 145
Sample webpage data viewing result 145
Sample HTML code for data viewing webpage content 147
Sample setup webpage 150
Sample HTML code for setup webpage content 152

Display 156
Display overview 156
Home button 156
Revenue lock icon 157
Alarm icon 157
Alarm and status LED indicators 157
Navigation symbols 158
Using the onscreen keyboard 159
More screens access 160
Overrange indication 160
Auto-scaling feature 160
Display screens 161
Data display screens 161
Setup menu 162
Meter setup using your display 163
Display setup 165
Language setup 166
Creating custom displays using ION Setup 166
Remote display troubleshooting icons 167
Alarms and alerts 168
Alarms 168
Alarm types 168
Standard and high-speed alarms 168
Relative setpoint 171
Sag/swell alarms 171
Digital alarms 171
Alarm event priorities 171
Alarm indicators 172
Default alarms 173
Alarm information 174
Viewing and acknowledging alarms using the display 174
Alarm configuration 174
Alerts 180
Setpoint learning 181
Learning installation mode and learning duration 181
Implementing standard alarm setpoint learning using ION Setup 182
Implementing sag and swell limit learning using ION Setup 183
Power quality 185
Power quality configuration 185
Power quality logging 186
Sags and swells 186
Configuring Advanced Power Quality 188
Harmonics 190
Viewing harmonics information using the display 191
9410 series - User manual Table of Contents
7EN05-0336-09 10

Table of Contents 9410 series - User manual
11 7EN05-0336-09
Voltage crest factor 191
Current crest factor 191
K-factor 191
Harmonic content calculations 192
THD% calculations 192
thd and TDD 192
Phasors 192
Power quality standards compliance 193
IEC 61000-4-30 193
EN 50160 193
IEEE 519 193
IEC 60255-24 (COMTRADE) 193
Disturbance direction detection overview 194
Disturbance direction detection events 195
COMTRADE 195
COMTRADE implementation 195
Waveforms on the meter webpages 196
Viewing waveforms on meter webpages 197
Burst data logging 198
Data recorder burst data 199
Waveform capture 200
Standard waveform capture 200
Delayed waveform capture 201
Extended waveform capture 201
Logging 204
Logging overview 204
Default data logging configuration 204
Revenue log 204
Historic data logs 205
Loss log 206
Harmonics logs 206
Energy and demand log 207
Daily nominal log 207
Sag/swell log 207
Sg/Sw HS log 208
EN 50160 compliance logs 208
IEC 61000-4-30 compliance logs 208
IEEE 519 compliance logs 210
Configuring data logging using ION Setup 210
Waveform recording 211
Waveform data storage format 211
Types of waveform data 211
Key terms 212
Default waveform recording configuration 212

Waveform Recorder modules 212
COMTRADE modules 213
Event log 213
Default event log configuration 213
Syslog 215
Configuring Syslog network settings using ION Setup 215
Syslog severity to event log priority mapping 215
Advanced log setup and memory optimization 216
Viewing log configuration and memory usage information 216
Log depth configuration 216
Log interval configuration 217
Log mode configuration 217
Log buffer configuration 218
Changing log interval and depth settings using ION Setup 221
Time and timekeeping 223
Time and timekeeping overview 223
Internal clock temperature compensation 223
Time synchronization 223
Supported time synchronization sources 224
Clock source 224
Clock source time quality flag 225
PTP system setting recommendations 225
Star network topology 226
Configuring time information using ION Setup 227
Configuring time information using the display 229
Measurements 231
Energy 231
Demand 231
Instantaneous measurements 231
Harmonics 231
Min/max recording 232
Power quality 232
Power and power factor 232
Power factor (PF) 233
Apparent, active, and reactive power (PQS) 233
Current phase shift from voltage 234
Power demand 235
Peak demand 236
Peak demand reset lockout 236
Sliding window demand 236
Examples of sliding window demand 236
Incremental energy 237
Example:Incremental energy 238
Configuring incremental energy using ION Setup 238
9410 series - User manual Table of Contents
7EN05-0336-09 12

Table of Contents 9410 series - User manual
13 7EN05-0336-09
Conditional energy 239
Configuring conditional energy using ION Setup 239
Trending and forecasting overview 240
Trending and forecasting implementation 240
Viewing trending and forecasting data on your meter’s webpages 240
Resets 242
Resets overview 242
Option modules reset 242
Available resets 242
Resetting the meter using ION Setup 243
Resetting the meter using the meter webpages 244
Resetting the meter using the display 245
Firmware upgrades 248
Firmware upgrades overview 248
Obtaining meter upgrades 248
Upgrade information 248
Meter firmware 248
Restart requirement 248
Legacy security support 248
Meter firmware upgrade prerequisites 249
Back up custom meter webpages 249
Back up custom meter frameworks 249
Back up accumulated energy values 250
Download latest ION Setup 250
Connection requirements 250
Meter firmware upgrades 250
Option 1 (recommended) – Upgrading using ZIP file 251
Option 2 – Upgrading using individual upgrade files 253
Status 253
Upgrading display firmware 253
Upgrading option module firmware 253
Loading option module firmware using ION Setup 254
Loading option module firmware using SFTP 255
Maintenance 256
Maintenance overview 256
Editing accumulated energy values using ION Setup 256
Cleaning instructions 256
Device-specific information 258
Revenue 259
Revenue metering components 259
Revenue firmware security features 259
Protected features and settings 259
Revenue locking 259

Revenue-locking summary 260
Revenue lock switch 260
Revenue lock LED behavior 260
Revenue locking your meter 261
Anti-tamper sealing 261
Time of use 262
Energy pulsing LED behavior 262
Verifying accuracy 263
Verifying accuracy overview 263
Accuracy test requirements 263
Signal and power source 263
Control equipment 263
Environment 264
Reference device or energy standard 264
Energy pulsing 264
Verifying accuracy test meter settings 265
Verifying accuracy test 265
Calculate the number of required pulses 266
Percentage error calculation for accuracy verification testing 267
Typical sources of test errors 267
Accuracy verification test points 268
Troubleshooting 269
Setting up Advanced security troubleshooting 269
Option module troubleshooting 270
Technical assistance 270
9410 specifications 271
Mechanical characteristics 271
Mechanical compliance 271
Electrical characteristics 271
Environmental characteristics 274
LEDs 274
EMC (electromagnetic compatibility) 275
Safety 275
Ethernet communications 275
RS-485 communications 276
Real-time clock 276
Display 276
Option modules 277
Other 277
Open source software components 279
9410 series - User manual Table of Contents
7EN05-0336-09 14

Safety precautions 9410 series - User manual
15 7EN05-0336-09
Safety precautions
Installation, wiring, testing and service must be performed in accordance with all local and
national electrical codes.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
Failure to follow these instructions will result in death or serious injury.
•Apply appropriate Personal Protective Equipment (PPE) and follow safe electrical work
practices. See NFPA 70E, CSA Z462 or other local standards.
•Turn off all power supplying this device and the equipment in which it is installed before
working on or in the equipment.
•Follow guidelines in the Wiring section of the related Installation Guide.
•Always use a properly rated voltage sensing device to confirm that all power is off.
•Do not use the data from the meter to confirm power is off.
•Do not exceed the maximum ratings of this device.
•Do not short secondary terminals of Voltage Transformer (VT).
•Do not open secondary terminals of Current Transformer (CT).
•Ground secondary circuit of CTs.
•Do not install CTs in equipment where they exceed 75% of the wiring space of any cross-
sectional area in the equipment.
•Do not install CTs in areas where ventilation openings may be blocked or in areas of breaker
arc venting.
•Do not install CTs using Class 2 wiring methods or connect to Class 2 equipment. See NFPA
70.
•Secure CT secondary conductors to ensure they do not contact live circuits.
•Assume communications and I/O wiring are hazardous live until determined otherwise.
•Replace all devices, doors and covers before turning on power to this equipment.
NOTE: See IEC 60950-1 for more information on communications and I/O wiring connected to
multiple devices.

WARNING
UNINTENDED OPERATION
Failure to follow these instructions can result in death, serious injury, or equipment
damage.
Do not use this device for critical control or protection of persons, animals, property, or
equipment.
WARNING
POTENTIAL COMPROMISE OF SYSTEM AVAILABILITY, INTEGRITY, AND
CONFIDENTIALITY
Failure to follow these instructions can result in death or serious injury or equipment
damage.
•Change default passwords/passcodes to help prevent unauthorized access to device
settings and information.
•Disable unused ports/services and default accounts, where possible, to minimize pathways
for malicious attacks.
•Place networked devices behind multiple layers of cyber defenses (such as firewalls, network
segmentation, and network intrusion detection and protection).
•Use cybersecurity best practices (for example: least privilege, separation of duties) to help
prevent unauthorized exposure, loss, modification of data and logs, interruption of services,
or unintended operation.
9410 series - User manual Safety precautions
7EN05-0336-09 16

Meter overview
9410 series overview
The 9410 energy and power quality meters help meet the needs of your energy monitoring and
cost management applications.
9410 meters comply with international metering accuracy standards. You can customize your
meter by loading specialized frameworks, adding option modules and incorporating mounting
accessories into the physical installation.
Power quality readings (THD)
Sag/swell capture for voltage and currents
True RMS metering to the 63rd harmonic
Active (kW), reactive (kVAR) and apparent (kVA) power
600 V direct connection on voltage inputs
Minimum/maximum readings of metered data
Water Air Gas Electricity Steam (WAGES) support
Time of use support
Trending and forecasting
Time synchronization to 1 ms accuracy
Dual port Ethernet (two physical ports, one Ethernet IP address)
Multiple languages supported
Web interface
Configuration through integrated or remote display
Alarms (active and historic) display viewing and acknowledgment
Modbus client and Ethernet gateway protocols supported
Downloadable firmware and templates
Advanced security
Variety of industry-standard communications protocols supported
Meter features
Account management
If your meter’s user access information is lost, the meter is inoperable and cannot be returned to
the factory.
7EN05-0336-09 17

Meter overview 9410 series - User manual
18 7EN05-0336-09
NOTICE
DATA LOSS
Failure to follow these instructions can result in loss of data.
Record your device's user and password information in a secure location.
Your meter in an energy management system
As a key piece in your energy management system, the Siemens 9410 series meter provides
highly accurate measurements and calculations for a wide variety of power system values,
performs analysis on collected data, alerts you of potential issues and integrates with a variety of
display and analysis software.
Communications
Supported protocols
Your meter’s fundamental protocol and architecture is ION.
You can integrate the meter into various industry-standard networks. Data that the meter
measures can be made available to other devices using:
•Modbus
•DNP 3.0
•SNMP
You can configure the meter to import data from other devices on these networks. Your meter
supports the IEC 61850 protocol and COMTRADE waveform data format.
Your meter also supports IPv6, Devices Profile for Web Services (DPWS), and Rapid Spanning
Tree Protocol (RSTP) Ethernet protocols.
Meter configuration
ION Setup device configuration tool
ION Setup is a free configuration tool for your meter that lets you remotely configure your meter’s
features over Ethernet or serial communications.
•Use the setup screens to guide you through the process of configuring your meter.
•Use the real-time data screens to verify your meter’s configuration.
•Use the data screens to view your meter’s recorded data.
•Use the charting function to view your meter’s recorded waveforms.
•Use ION Setup in Advanced mode to work directly with modules.
Download ION Setup from www.usa.siemens.com/pds.

Switching ION Setup to Advanced mode
1. Open ION Setup.
2. Ctrl + click on the meter to select it. This switches ION Setup to Advanced mode.
Data display
Built-in web server and webpages
Your meter’s onboard internal web server and built-in webpages provide quick and easy access
to real-time energy, basic power quality information and meter configuration without having to use
specialized software.
Localization
The meter can be customized to use different regional settings.
Localization settings determine:
•The language used for the display and webpages
•Time, date, and digit formats
•Displayed phase labels (123/ABC)
•Institute of Electrical and Electronics Engineers (IEEE) or International Electrotechnical
Commission (IEC) conventions for power, power factor, and energy
Configure your meter’s localization settings using ION Setup or the display.
Display
Use the meter’s display for local monitoring and standalone applications.
The color LCD display lets you view real-time values, events and alarms, and perform basic
device configuration. Connect a remote display to a meter without an integrated display to view
meter data and perform basic meter configuration.
Notification
Active and historical alarms
The meter’s display shows an alarm icon and the alarm LED flashes if your meter detects an
active alarm condition.
Depending on the priority of the alarm, the display also flashes. You can view and acknowledge
active alarms, historic alarms, and events using the display and webpages.
An active alarm becomes a historic alarm when the alarm condition no longer exists.
Email notifications
Configure your meter to automatically email information such as notification of a high-priority
event or a regularly scheduled send of logged data.
9410 series - User manual Meter overview
7EN05-0336-09 19

Meter overview 9410 series - User manual
20 7EN05-0336-09
Specify the type of event that triggers an email alert, such as a power quality disturbance or
interval for logged data. Email messages from your meter are received like any other email
message.
9410 meter models and accessories
Commercial references for the 9410 series meter and accessories.
Commercial reference Description
US2:9410DC Panel-mounted meter with integrated display
US2:9410D24VDC Same as the 9410DC, except with low-voltage DC control power
US2:9410DCAN
Same as the 9410DC with the addition of a sealable hardware lock
which prevents modification of revenue related settings and
functions. Meter is physically sealed at the factory. Available to
Canada only.
US2:9410TC DIN rail-mounted meter without display, which can be connected
to a remote display
US2:9410T24VDC Same as the 9410TCION7403, except with low-voltage DC control
power
US2:9410RC DIN rail-mounted meter packaged with a remote display
US2:9410R24VDC Same as the 9410RC, except with low-voltage DC control power
US2:948DISP96
Remote display, 3 meter cable, mounting hardware for 30 mm
hole (nut and centering pin), mounting hardware for DIN 96 cutout
(92 x 92 mm) adapter plate
US2:948M2DO6DI 9410 I/O Module with 2 relay outputs, and 6 digital inputs (wetted)
US2:948M2AO4AI 9410 I/O Module, 2 analog outputs (4 - 20 mA, 0- 10 VDC), and 4
analog inputs (4 - 20 mA, 0 - 30 VDC)
US2:948MFIBER Fiber Ethernet option module
US2:9410SK 9410 Voltage and Current Sealing Kit (included with base meter)
US2:948DCAB10 9410 Remote display, 10 meters
US2:94PMAK 9410 Remote Display Mounting Adapter kit for 4" round hole -
requires 9410RC
US2:94PMHWK 9410 Replacement hardware kit for 9410 meter
US2:94PMRDHWK 9410 Replacement hardware kit for remote display
US2:94PMHWKDC 9410 24 Vdc Meter replacement hardware kit for remote display
Refer to your meter’s catalog pages, available from www.usa.siemens.com/pds, for updated
information on meter types and accessories.
