Continuous gas analysis
SIPROCESS GA700
Devices in explosion-proof design
Compact Operating Instructions
05/2018
A5E35134047
-03
Introduction
1
Safety instructions
2
General information
3
Installing
4
Connecting
5
Commissioning
6
Operation
7
Service and maintenance
8
Dismantling and disposal
9
Technical specifications
10
Appendix A
A

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E35134047
Ⓟ05/2018 Subject to change
Copyright © Siemens AG 2014 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 3
Table of contents
1 Introduction............................................................................................................................................. 7
1.1 Purpose of this document .........................................................................................................7
1.2 History.......................................................................................................................................7
1.3 Purpose.....................................................................................................................................7
1.4 Field of application....................................................................................................................8
1.5 Qualified personnel for applications in hazardous areas........................................................10
1.6 Delivery ...................................................................................................................................10
1.7 Transportation and storage.....................................................................................................11
1.8 Warranty conditions ................................................................................................................11
2 Safety instructions................................................................................................................................. 13
2.1 Prerequisites for safe use .......................................................................................................13
2.1.1 Laws and directives ................................................................................................................13
2.1.2 Conformity with European directives ......................................................................................14
2.2 Improper device modifications ................................................................................................14
2.3 For use in hazardous areas ....................................................................................................15
2.4 General directives for explosion protection.............................................................................16
2.4.1 Internal explosion protection...................................................................................................16
2.4.2 External explosion protection..................................................................................................16
2.4.2.1 Safety measures for all types of protection ............................................................................17
2.4.2.2 Type of protection "Ex p" ........................................................................................................17
2.4.2.3 Type of protection Ex t and Ex ec...........................................................................................18
3 General information .............................................................................................................................. 19
3.1 Requirements for special applications ....................................................................................19
3.2 Automatic reset .......................................................................................................................19
3.3 Measuring high oxygen concentrations ..................................................................................20
4 Installing ............................................................................................................................................... 21
4.1 General safety instructions .....................................................................................................21
4.2 Safety instructions for hazardous areas .................................................................................23
4.3 Installation instructions............................................................................................................23
4.4 Rack-mounted device .............................................................................................................25
4.4.1 Device-specific safety instructions..........................................................................................25
4.4.2 Installing the rack-mounted device .........................................................................................26
4.5 Wall-mounted device ..............................................................................................................27
4.5.1 Device-specific safety instructions..........................................................................................27
4.5.2 Installing the wall-mounted device..........................................................................................28

Table of contents
4
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
5 Connecting ........................................................................................................................................... 31
5.1 Gas connections .................................................................................................................... 31
5.1.1 General safety instructions .................................................................................................... 31
5.1.2 Safety instructions for hazardous areas ................................................................................ 32
5.1.3 Connection information .......................................................................................................... 32
5.1.4 Arrangement of the gas connections in the rack-mounted device......................................... 34
5.1.5 Arrangement of the gas connections in the wall-mounted device ......................................... 35
5.1.5.1 Overview ................................................................................................................................ 35
5.1.5.2 Purging gas connections........................................................................................................ 37
5.1.6 Connecting gas ...................................................................................................................... 38
5.1.7 Further information on the gas connection ............................................................................ 39
5.2 Electrical connections ............................................................................................................ 39
5.2.1 General safety instructions .................................................................................................... 39
5.2.2 Safety instructions for hazardous areas ................................................................................ 40
5.2.3 Connection information .......................................................................................................... 43
5.2.4 Requirements for electrical connection.................................................................................. 43
5.2.5 Electric connection of rack-mounted device .......................................................................... 44
5.2.5.1 Device-specific safety instructions ......................................................................................... 44
5.2.5.2 Connecting signal and Ethernet cables ................................................................................. 44
5.2.5.3 Connecting the power supply................................................................................................. 46
5.2.6 Wall-mounted device electrical connection............................................................................ 47
5.2.6.1 Device-specific safety instructions ......................................................................................... 47
5.2.6.2 Connecting the signal cables ................................................................................................. 49
5.2.6.3 Connecting the Ethernet cable............................................................................................... 50
5.2.6.4 Connecting the power supply................................................................................................. 52
6 Commissioning ..................................................................................................................................... 55
6.1 General safety instructions .................................................................................................... 55
6.2 Safety instructions for hazardous areas ................................................................................ 56
6.3 Information on commissioning ............................................................................................... 58
6.4 Requirements for commissioning........................................................................................... 59
6.5 Checking gas paths for leaks................................................................................................. 59
6.5.1 General information on leaks................................................................................................. 59
6.5.2 Recommended test setup ...................................................................................................... 60
6.5.3 Checking OXYMAT 7 for leaks .............................................................................................. 61
6.5.4 Checking ULTRAMAT 7 for leaks .......................................................................................... 61
6.5.5 Checking CALOMAT 7 for leaks............................................................................................ 62
6.6 Commissioning the device ..................................................................................................... 63
7 Operation.............................................................................................................................................. 67
7.1 Local User Interface (LUI)...................................................................................................... 67
7.2 Menu structure ....................................................................................................................... 71
7.2.1 Main menu ............................................................................................................................. 71
7.2.2 Subordinate menus................................................................................................................ 72

Table of contents
Devices inexplosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 5
8 Service and maintenance...................................................................................................................... 77
8.1 General safety instructions .....................................................................................................77
8.2 Safety instructions for hazardous areas .................................................................................79
8.3 Maintaining the analyzer .........................................................................................................80
9 Dismantling and disposal ...................................................................................................................... 81
9.1 Dismantling .............................................................................................................................81
9.2 Information on recycling..........................................................................................................82
10 Technical specifications ........................................................................................................................ 83
10.1 Scope......................................................................................................................................83
10.2 General technical specifications .............................................................................................83
10.2.1 Determining the technical specifications.................................................................................83
10.2.2 Technical specifications of rack-mounted housing .................................................................84
10.2.3 Technical specifications of the wall housing...........................................................................85
10.2.4 OXYMAT 7 technical specifications........................................................................................87
10.2.5 Technical data ULTRAMAT 7 .................................................................................................91
10.2.6 CALOMAT 7 technical specifications......................................................................................94
10.3 Technical specifications for operation in hazardous areas.....................................................97
A Appendix A ......................................................................................................................................... 101
A.1 Ex py safety equipment.........................................................................................................101
A.1.1 Overview ...............................................................................................................................101
A.1.2 Connection diagrams ............................................................................................................102
A.1.3 Technical specifications........................................................................................................104
A.2 References............................................................................................................................106
A.3 Certificate..............................................................................................................................108
A.4 Technical support..................................................................................................................109
Index................................................................................................................................................... 111

Table of contents
6
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03

Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 7
Introduction
1
1.1
Purpose of this document
These compact operating instructions are a brief summary of important features, functions
and safety instructions, and contains all information required for safe use of the device.
These are instructions on mounting, connecting, commissioning, operation, servicing,
dismantling and decommissioning of the device.
The compact operating instructions are intended for qualified personnel who have been
instructed in all the work on the device in hazardous areas and possible dangers resulting
from improper behavior and have been taught.
It is your responsibility to read the compact operating instructions thoroughly and understand
them before beginning any work. To guarantee correct handling, you should become
acquainted with the principle of operation of the gas chromatograph.
The compact operating instructions belong to the device. Keep them in the direct vicinity of
the device.
To achieve optimum usage of the device read the detailed version of the operating
instructions, see "References (Page 106)".
1.2
History
The following table includes information on the different editions of this document.
Edition
Remark
10/2014 First edition
05/2015
Expansion commissioning. Correction of the internal document links
05/2018 Expansion with new analyzer modules: ULTRAMAT 7 and CALOMAT 7 as well as high-
temperature variants of OXYMAT 7 and ULTRAMAT 7.
Expansion and updating of the document
1.3
Purpose
The device is designed for the concentration analysis of gases in gas mixtures. Depending
on the installed analyzer module, different gases can be examined.
Use the device only for measuring/analysis of gas concentrations in gas mixtures according
to the information in section "Technical specifications (Page 83)".
Note
This device meets the requirements of NAMUR Recomme
ndation 53.

Introduction
1.4 Field of application
8
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
Note
Use in home environment
This equipment of Class A Group 1 is intended solely for use in industrial areas.
If used in homes, the device may cause radio interference.
Note
For more information on the compatibility of the hardware a
nd firmware, refer to:
Siemens Industry Online Support (
https://support.industry.siemens.com/cs/de/en/ps/17731).
You will find more information in the operating instructions, see
"References (Page 106)".
1.4
Field of application
These compact operating instructions describe SIPROCESS GA700 devices approved for
operation in hazardous areas. They refer to the rack-mounted and wall-mounted devices
with analyzer modules permanently installed in the factory by the manufacturer that are used
depending on the measuring task and local conditions.
The following analyzer modules are available for explosion-proof devices:
●Standard analyzer modules OXYMAT 7, ULTRAMAT 7 and CALOMAT 7 for rack-
mounted and wall-mounted devices. Up to two analyzer modules possible per basic
device.
●High-temperature analyzer modules OXYMAT 7 and ULTRAMAT 7 only for wall-mounted
devices. Only one analyzer module possible per wall-mounted device.
Note
Special conditions
You must also take into consideration the special conditions described in the following listed
certificates. These conditions relate, in parti
cular, to the following:
•
Areas of application
•
Requirements for operation in hazardous areas
•
Other precautionary measures important for operation
Note
Deviating technical specifications
For operation of the below
-indicated devices in hazardous areas, deviating technical
specifications may apply. The technical specifications listed in these Operating Instructions
are valid in such cases.

Introduction
1.4 Field of application
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 9
The following table provides an overview of the device variants that belong to the application
area.
Note
Designation of types of protection db / op is
The designation db
is only used if at least one module CALOMAT 7MB304x-2xxxx-xxxx is
installed.
The designation op
is
is only used if at least one module ULTRAMAT 7MB301x-2xxxx-xxxx
or 7MB301x
-3xxxx-xxxx is installed.
Table 1- 1 SIPROCESS GA700 Ex devices with analyzer modules
Device
variant
MLFB number1)
Ignition protection type
ATEX and IECEx
certificates
C 7MB3000-xxxxx-xxCx
7MB301x-2xxxx-xxAx
7MB302x-2xxxx-xxxx
7MB304x-2xxxx-xxxx
II 2/3G Ex ec db ic nA nC op is IIC T4 Gb/Gc
(for gases that are potentially explosive occasionally)
The following applies for products solely with OXYMAT
modules:
II 3G Ex ec ic nA nC IIC T4 Gc
Rack-mounted device:
BVS 15 ATEX E 007 X
IECEx BVS 15.0007X
D 7MB3000-xxxxx-xxDx
7MB301x-2xxxx-xxBx
7MB301x-3xxxx-xxBx
7MB302x-2xxxx-xxxx
7MB304x-2xxxx-xxxx
II 3G Ex ec db ic nA nC op is IIC T4 Gc Wall-mounted device:
BVS 14 ATEX E 154 X
IECEx BVS 14.0104X
7MB302x-3xxxx-xxxx
II 3G Ex ec ic nA nC IIC T3 Gc
E 7MB3000-xxxxx-xxEx
7MB301x-2xxxx-xxBx
7MB301x-3xxxx-xxBx
7MB302x-2xxxx-xxxx
7MB304x-2xxxx-xxxx
II 2G Ex pyb db ib op is IIC T4 Gb Wall-mounted device:
BVS 14 ATEX E 153 X
IECEx BVS 14.0104X
7MB302x-3xxxx-xxxx
II 2G Ex pyb ib IIC T3 Gb
G 7MB3000-xxxxx-xxGx
7MB301x-2xxxx-xxBx
7MB301x-3xxxx-xxBx
7MB302x-2xxxx-xxxx
7MB304x-2xxxx-xxxx
II 2G Ex pyb db ib op is IIC T4 Gb
II 3G Ex ec db ib nA nC op is IIC T4 Gc
II 3D/2G Ex pyb db ib op is IIIC/IIC T65°C/T4 Dc/Gb
(for gases that are potentially explosive occasionally)
II 3D Ex tc db ib op is IIIC T65°C Dc
Wall-mounted device:
BVS 14 ATEX E 153 X
IECEx BVS 14.0104X
7MB302x-3xxxx-xxxx II 2G Ex pyb ib IIC T3 Gb
II 3G Ex ec ib nA nC IIC T3 Gc
II 3D/2G Ex pyb ib IIIC/IIC 200°C/T3 Dc/Gb
(for gases that are potentially explosive occasionally)
II 3D Ex tc ib IIIC 200°C Dc
1) Machine-readable product designation

Introduction
1.5 Qualified personnel for applications in hazardous areas
10
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
1.5
Qualified personnel for applications in hazardous areas
Persons who install, connect, commission, operate, service, maintain and dismantle the
device in a hazardous area must have the following specific qualifications:
●They are authorized, trained or instructed in operating and maintaining devices and
systems according to the safety regulations for electrical circuits, high pressures and
aggressive as well as hazardous media.
●They are authorized and trained or instructed in carrying out work on electrical circuits for
hazardous systems.
●They are trained or instructed in maintenance and use of appropriate safety equipment
according to the pertinent safety regulations.
1.6
Delivery
WARNING
Damaged or incomplete device
Danger of explosion in hazardous areas
The use of damaged or incomplete devices can lead to an explosion.
•Do not use damaged or incomplete devices.
Checking delivery
1. Check the packaging and the device for visible damage caused by inappropriate handling
during shipping.
2. Report any claims for damages immediately to the shipping company.
3. Retain the damaged parts for clarification.
4. Check the scope of delivery for correctness and completeness on the basis of the
delivery note. Compare the serial numbers on the delivery note with the serial numbers
on the basic device or on the modules.
5. Check whether the package includes the following items:
–"Manual Collection" CD-ROM
–This printed copy of the Compact Operating Instructions

Introduction
1.7 Transportation and storage
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 11
Note
Checking expanded product packages for Ex devices
The following items
are included in the delivery of devices in the explosion-proof design:
•
IEC connector
•
Guard bracket for the IEC connector
•
Additionally for rack-mounted device: Ethernet strain relief
1.7
Transportation and storage
To ensure sufficient protection during transport and storage, observe the following:
●Keep the original packaging for subsequent transportation.
●Devices/replacement parts should be returned in their original packaging.
●If the original packaging is no longer available, please ensure that all shipments are
sufficiently protected during transport by the replacement packaging. The manufacturer
accepts no liability for additional costs resulting from damage during transportation.
●Store the device in a dry place, vibration-free and horizontal.
Note
Insufficient protection during storage
The packaging only provides limited protection against moisture and infiltration.
•
Provide additional packaging as necessary.
Special conditions for storage and transportation of the device are listed in section
"Technical specifications (Page 83)".
1.8
Warranty conditions
We expressly point out that the product quality is exclusively and conclusively described in
the sales contract. The content of this product documentation is neither a part of a previous
or existing agreement, promise or legal relationship, nor is it intended to modify these. All
obligations on the part of Siemens AG are contained in the respective sales contract, which
also contains the complete and solely applicable liability provisions. The provisions defined
in the sales contract for the responsibility for defects are neither extended nor limited by the
remarks in this document.

Introduction
1.8 Warranty conditions
12
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03

Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 13
Safety instructions
2
2.1
Prerequisites for safe use
In terms of safety, this device left the factory in perfect condition. In order to maintain this
status and to ensure safe operation of the device, observe these compact operating
instructions and all the information relevant to safety.
Observe the information and symbols on the device. Do not remove any information or
symbols from the device. Always keep the information and symbols in a completely legible
state and renew them, if required.
Symbol
Description
Consult operating instructions
Hot surface
Dangerous electrical voltage
2.1.1
Laws and directives
Observe the test certification, provisions and laws applicable in your country in the currently
valid version during connection, assembly and operation. These include, for example:
●National Electrical Code (NEC - NFPA 70) (USA)
●Canadian Electrical Code (CEC) (Canada)
Additional provisions for applications in hazardous areas are, for example:
●IEC 60079-14 (international)
●EN 60079-14 (EU)
Additional information is available at:
Certificates (https://support.industry.siemens.com/cs/ww/en/ps/17731/cert)

Safety instructions
2.2 Improper device modifications
14
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
2.1.2
Conformity with European directives
The CE marking on the device shows conformity with the regulations of the following
European guidelines:
Electromagnetic compatibility
EMC 2014/30/EU
Directive of the European Parliament and of the Council
of 26 February 2014 on the harmonization of the laws of the
Member States relating to electromagnetic comp
atibility (new
version)
Low voltage directive LVD
2014/35/EU
Directive of the European Parliament and of the Council of 26
February 2014 on the harmonization of the laws of the Member
States relating to the making available on the market of electr
i-
cal eq
uipment designed for use within certain voltage limits
(new version)
Atmosphère explosible
ATEX 2014/34/EU
Directive of the European Parliament and of the Council of 26
February 2014 on the harmonization of the laws of the Member
States relating to equip
ment and protective systems intended
for use in potentially explosive atmospheres (new version)
Restriction of certain
Hazardous Substances
RoHS 2011/65/EU
Directive of the European Parliament and of the Council
of 8 June 2011 on the restriction of th
e use of certain hazard-
ous substances in electrical and electronic equipment (new
version)
The standards applied can be found in the EU Declaration of Conformity for the associated
device.
2.2
Improper device modifications
DANGER
Device modifications
Explosion hazard
Danger to personnel, system and the environment can result from modifications and repairs
to the device carried out by the customer, especially in hazardous areas.
•Modifications to or repairs of the explosion-protected device as well as retrofitting it with
further analyzer modules are not allowed. Failure to observe this requirement cancels
the manufacturer's warranty and the product approvals.
•Contact the local SIEMENS representative for repairs, modifications or retrofitting of the
device.

Safety instructions
2.3 For use in hazardous areas
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 15
2.3
For use in hazardous areas
WARNING
Unsuitable device for the hazardous area
Explosion hazard
•Only use devices that have been approved for use in the intended hazardous area and
are labeled accordingly.
WARNING
Use outside the permitted voltage limits
Explosion hazard
•Only use the device within the voltage limits specified on the nameplate.
Note
Open the enclosure only in case of maintenance or service
The enclosure must always remain closed during operation.
•
Keep the enclosure closed during operation.
•
Open the enclosure only for installation or maintenance. Close the enclosure after this
work has been completed.

Safety instructions
2.4 General directives for explosion protection
16
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
2.4
General directives for explosion protection
2.4.1
Internal explosion protection
Internal explosion protection refers to the sample gas path (containment system "CS") in the
analyzer and to the ignition protection of the process gas. A differentiation must be made
between the following cases:
Table 2- 1 Internal explosion protection: Differentiation of cases
Sample gas
Measures
Non-combustible gas
mixtures and gas mix-
tures below 25% of the
lower explosive limit
(LEL)
If you have ensured that the sample gas in the CS does not become explosive, flame arresters
are dispensable.
Occasionally explosive
gas mixtures
The introduction of an occasionally explosive gas mixture is permissible only at the type of pro-
tection Ex py!
If an occasionally explosive gas mixture is introduced in OXYMAT 7, each inlet / outlet for sam-
ple gas and reference gas must be equipped with one flame arrester each. The installed flame
arresters have to fulfil the safety-specific requirements of this ignitable gas mixture.
You do not need a flame arrestor at the reference gas input if the following requirements are
met:
•You use a non-combustible gas as the reference gas and
•You have ensured that the reference gas is introduced before the device is switched on and
afterwards uninterruptedly.
Gas mixtures which are
frequently or perma-
nently explosive
Do not introduce any frequently or permanently explosive gas mixtures!
Gas mixtures above the
upper explosive limit
(UEL)
A case-by-case assessment is required for these combustible gas mixtures!
2.4.2
External explosion protection
The external explosion protection serves to prevent penetration of explosive gas mixtures
(gas vapors) into the enclosure or ignition on the surfaces.

Safety instructions
2.4 General directives for explosion protection
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 17
2.4.2.1
Safety measures for all types of protection
The exhaust lines for the sample gas and reference gas must terminate
outside
the
hazardous area at a harmless position.
The sample gas exhaust line can also be returned to the sampling point.
OXYMAT 7: When conducting combustible or non-combustible sample gases into the
hazardous area, both the sample gas inlet and outlet must be provided with a flame arrester.
The maximum permissible sample gas pressure in the analyzer depends on the type of
connected gas. Make sure that no higher absolute sample gas pressures occur than
specified in the technical data of the respective device version. The exact specifications of
the sample gas inlet conditions can be found in the section "Technical specifications for
operation in hazardous areas (Page 97)".
Check the tightness of the containment system after all installation and maintenance work.
2.4.2.2
Type of protection "Ex p"
For gas/air mixtures above the LEL, fault tolerance of the containment system is not
guaranteed in the sense of EN IEC 60079-2 and EN IEC 60079-14. Because sample gas
can be released into the pressurized enclosure as a result of leaks (e.g. O-rings). However,
this release of sample gas can be assessed as limited. The maximum quantity released lies
below 200 µl/min, and is guaranteed by the quality assurance measures of the manufacturer
when the analyzer is delivered.
In order to minimize or avoid the accumulation of gases in the enclosure, Ex p devices are
purged continuously with a ignition shield gas (purging gas). Inert gas or air is chosen as the
purging gas.
During the pre-purging phase, before the device is switched on, the purging gas flows
through the enclosure in order to remove any combustible gases that may be present.
During the operating phase the purging gas continues to be fed into the enclosure. This
dilutes any sample gas released through leaks so that an ignitable gas mixture cannot arise.
OXYMAT 7: When conducting purging gas into the hazardous zone ensure that the purging
gas outlet is equipped with a flame arrester.
The specifications for the purging gas are available under: Technical specifications for
operation in hazardous areas (Page 97).
WARNING
Explosion hazard
The following applies for simplified pressurized devices with type of protection Ex pz for use
in hazardous Zone 2 and Zone 22:
•Never insert combustible gas/air mixtures whose composition lies above the LEL even
occasionally!

Safety instructions
2.4 General directives for explosion protection
18
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
2.4.2.3
Type of protection Ex t and Ex ec
WARNING
Explosion hazard
The devices that are operated with the types of protection Ex t "Dust protection through
enclosure" or Ex ec "Increased safety" are not designed for introducing combustible to
occasionally explosive gas mixtures. Otherwise there is a danger of explosion.
Therefore:
•For operation with the types of protection Ex t or Ex ec introduce only
non-
combustible
gases.
•Close all open connections, such as purging gas connections, gas-tight.

Devicesin explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03 19
General information
3
3.1
Requirements for special applications
Due to the number or possible applications, this document does not include all detailed
information on the described device versions. This means not every possible scenario for
commissioning, operating, maintenance or operation in plants is taken into consideration.
Should you require additional information which is not included in these instructions, please
contact your local SIEMENS office or your SIEMENS partner.
Note
Operation under special ambient conditions
If you want to use the device under special ambient conditions, for example, in nuclear
power plants or for research and developm
ent purposes,
we recommend:
First contact your local SIEMENS partner or our application department. Explain the specific
application and clarify the operating conditions.
3.2
Automatic reset
All SIPROCESS GA700 devices feature internal monitoring. When this monitoring is
activated, the standard digital outputs switch after about 4 seconds for a period of approx. 60
seconds to "inactive", i.e. to a recognized safe operating mode. These times are valid for
devices manufactured as of 09/2017. You can find this information on the nameplate. It can
take up to 10 seconds for older devices to switch over, and up to 100 seconds to switch to
safe operating mode.
If you are using SIPROCESS GA700 devices in critical processes, observe the following
information:
●Monitor the limits externally via the control system.
●If an option module 2.1 is installed,
read out the device status via the digital outputs of the
option module.
●Use an available manual measuring range switchover instead of the autoranging.
●Only use the "Total" parameter with the "Off" setting for the measuring range switchover.
●If you use the "Correction of cross-interference" and "External pressure compensation"
functions, store suitable substitute values.
●Only access the measured value via an analog output.

General information
3.3 Measuring high oxygen concentrations
20
Devices in explosion-proof design
Compact Operating Instructions, 05/2018, A5E35134047-03
3.3
Measuring high oxygen concentrations
Note
Measuring high oxygen concentrations
For the measurement of high O
2concentrations in excess of 25%, it is absolutely necessary
that all parts that come in contact with the sample gas ar
e free of oil and grease and do not
contain any particles that could react with O
2.
We highly recommend you use specially cleaned analyzer modules with the "Cleaned for
O2" option for such measurements.
Note
Measuring high oxygen concentration in hazardous areas
The analysis of gas mixtures with an oxygen content of more than 21% does not form part of
the EU type
-examination certificate. Therefore the analysis of these gas mixtures is not
permitted without further consideration.
