Service Instructions
Replacing the horizontal lift brake

SIREMOBIL Iso-C SPR2-230.076.01 Page 2 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
2 Replacing the horizontal lift brake1
General 1
Safety information 1
When performing service work and tests, adhere to the product-specific safety information
in the documents as well as the general safety information contained in Register 2 of the
TI folder.
Miscellaneous information 1
These instructions describe the replacement of the horizontal lift brake on the SIREMO-
BIL Iso-C.
Required parts 1
Required measurement and auxiliary devices
or
Required tools 1
•Standardservicekit
•1 set of Allen keys
•1Ratchet
•1 nutwitha 30mm socket
•Springscaleto 200N
Additional auxiliary devices 1
•Block of hardwood, approx. 80mm x 60mmx 60mm (Height x length x width)
•Work table approx. 850mm x 1800mm x 800mm (height xlength xwidth)with abearing
capacityof > 1200N.
or
2 worktables approx. 850mm x 1000mmx 600mm (height x length xwidth)witha
bearingcapacityof>600N.
•Magneticbrake (Item number: refer to the SIREMOBIL Iso-C spare parts
list)
•Protectiveconductormeter 44 15 899 RV090
•BenderSafetytester 97 06 979 Y0526
•Loctite648 20 48 601

Replacing the horizontal lift brake 3
Siemens AG SPR2-230.076.01 Page 3 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
Preliminary steps 1
•ConnecttheSIREMOBILIso-Cto power .
•Positionthewoodenblock (1/Fig.1)underneath.
•Move theC-arm into the horizontal position (Fig. 1).
•PositiontheC-armover the work table.
•Slowly move theliftingcolumndown inincrements until the C-arm is positioned just flat
on the table.When doing this, make sure that the worktable is centered around the C-
arm and thatas much of the railing as possible is lying on the table.
Disassembly 1
•SwitchOFF the SIREMOBILIso-C.
•Removethe docking plate for the MODULARIS,ifitisconnected.
•Removethe cover with the brake switches (2/Fig.1)(screwsareonthe underside).
When doing this,remove the ground cable and disconnect the connection to the switch
board.
Push the wooden block under the SIREMOBIL frame prior to removing
the C-arm for service. Otherwise, the frame may tip over when the C-arm
is removed from the lifting column.
When placing the C-arm on the table, lower the lifting column only far
enough until the C-arm is positioned flat on the table with the entire rail-
ing.
Fig. 1
Fig. 1 shows one possible arrangement using 2 smaller work tables.
CAUTION
2
1
NOTICE

SIREMOBIL Iso-C SPR2-230.076.01 Page 4 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
4 Replacing the horizontal lift brake
•Remove the lower cover (1/Fig. 2). Loosen the screws only (2/Fig.2), but do not remove
them.
•Remove the back cover (3/Fig. 2) (Velcro closure).
•Removethe upper cover plate (1/Fig.3).Also remove thecabletiesand the fastener
clamps(2/Fig.3)
•Remove the back cover (1/Fig. 4).
•Removethe guide bearings(1/Fig.5).
•Removeplug connectionsX22 and X23 (2/Fig.5).
•Removethe cable clamps (3/Fig.5).
•Removethecable guide (4/Fig.5).
Fig. 2 Fig. 3
Fig. 4 Fig. 5
1
2
S3 S4
1
2
3
5
4
1
3
2
1

Replacing the horizontal lift brake 5
Siemens AG SPR2-230.076.01 Page 5 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
•Removethe cable clamp (1/Fig.6).
•Removethe cable clamp (2/Fig.6)and remove thecableties(2/Fig.6).
•Removethe cable ties around thecablebundle(5/Fig.5).
•Remove the cover plates (1/Fig.7).
•Removethe nut (1/Fig.8).(30mmsocket)
•Remove the threeAllen screws (2/Fig.8) andremove theangulation brake completely.
Whendoing this,make sure tohold onto the 3 screwsof the angulation brake oruse
adhesivetapetopreventthemfromfalling.Fig.9 shows the completeangulationbrake.
Fig. 6 Fig. 7
Fig. 8 Fig. 9
1
1
2
2
1

SIREMOBIL Iso-C SPR2-230.076.01 Page 6 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
6 Replacing the horizontal lift brake
•Removethe screws for the end stop(1/Fig.10).
•Connectthecablestoboth microswitches(refertoS3,S4/Fig.3andFig.11).
•ReconnectX23.
•Place the coverwith the brake switcheson theC-arm andplug inthe test board.
•SwitchON the SIREMOBIL.
•Release the horizontal lift brake(press the switch, the LED lights).
•Move the vertical lifting column up anddown until you areable to hammertheendstop
(1/Fig.10) out of thehorizontal carriage in the direction of the arrows (arrows/Fig.10)
withoutapplyingpressure to the shaft.
•Once the end stop has been removed, the shaft should lie horizontal within the
horizontal carriage and shouldnot be pressing against it.
•SwitchOFF the SIREMOBIL.
Fig. 10 Fig. 11
S3.2
S3.NL
S3.Comm S4.Comm
S4.N
L
S4.2
1

Replacing the horizontal lift brake 7
Siemens AG SPR2-230.076.01 Page 7 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
•Removethe spring ring (1/Fig.12).
•Removethe stopwheel (1/Fig.12).
•Removetheend stop(1/Fig.13).
•Removethe spring ring (2/Fig.13).
Fig. 12 Fig. 13
2
1
2
1

SIREMOBIL Iso-C SPR2-230.076.01 Page 8 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
8 Replacing the horizontal lift brake
•SwitchON the SIREMOBILIso-Cand releasethehorizontalbrake(theLED in the
switchlights).
•Move the horizontal carriage so that the opening in the horizontal carriage,
(1/Fig.14)as shownin Fig.14is located oppositethe opening in thebearingsupport(2/
Fig.14).
•Insert the cable bundle(3/Fig.14) betweenthe horizontal carriageand the bearing
supportin the direction of the C-arm. When doing this, be careful not to damage or crimp
thecables!
•Subsequentlymovethehorizontalcarriagecarefully forwardoutofthebearing support
until thehorizontal lift brake (1/Fig.15)with the plate(2/Fig.15) is accessible.
•Notethefollowing:
- Becarefulnottocrimpordamage thecables.
- The C-arm must remaincentered onthe work table. Move the work table, if necessary.
- Securethecoverwiththeswitchestopreventitfromfalling.
- When removing the horizontal carriage,keep it centered to the ballbearings. Do not tilt
it.
- You may have to adjustthe position of the vertical lifting column until the horizontal
carriagemoveseasily.
•SwitchOFF the SIREMOBIL Iso-C.
•Disconnecttheplugconnectionsforthehorizontalbrake.
•Removethe plate (2/Fig.15).
•Remove the horizontal brake cable from the plate and lift the horizontal brakeout of the
bearingsupport.
Fig. 14 Fig. 15
Two persons are required to remove the horizontal carriage. One person
should be at the bearing surface of the C-arm. The second person at the
horizontal carriage.
When removing the horizontal carriage, make sure that none of the
cables is crimped or damaged.
2
1
2
1
3
NOTICE

Replacing the horizontal lift brake 9
Siemens AG SPR2-230.076.01 Page 9 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
Installation 1
•Lift thehorizontal brake out ofthe bearing support. Reserve the two springs (2/Fig.16).
•Remove both screwsfrom theold horizontal brake (1/Fig. 16) and install them on the
newhorizontalbrake.
•Placethenew horizontalbrakein the bearing support.The two screwsshouldnotstick
inthe slots.(Checkthisby pressing down on the horizontalbrake).Youmay have to
take outthe horizontal brake again and slightly bend the screws to the side (hit the screw
headlightlyon the side)
•Routethe horizontalbrakecablebackthroughtheplate(1/Fig.17).The cable must be
positioned in the recess(1/Fig.18, 1/Fig.19).
•Routethe cable end of thehorizontalbrakeparallelto the cable bundle inthe horizontal
carriage.
Fig. 16 Fig. 17
Fig. 18 Fig. 19
21
1
2
2
1
1

SIREMOBIL Iso-C SPR2-230.076.01 Page 10 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
10 Replacing the horizontal lift brake
•Reattachtheplate(1/Fig.17)withthescrews.
•Clean thebraking surface of the horizontal brake (2/Fig.17).(Dirt and metal particles)
•Reattachthehorizontalbrake.
•SwitchON the Siremobiland releasethehorizontalbrake.
•Insert the horizontalcarriage back in the bearing support.
•Notethefollowing:
- Becarefulnottocrimpordamage thecables.
- Becarefulofthehorizontalbrakecable.RefertoFig.18and19.
- The C-arm must remaincentered onthe work table. Move the work table, if necessary.
- Securethecoverwiththeswitchestopreventitfromfalling.
- Wheninsertingthehorizontalcarriage, keepitcenteredtothe ball bearings.
- You may have to adjustthe position of the vertical lifting column until the horizontal
carriagemoveseasily.

Replacing the horizontal lift brake 11
Siemens AG SPR2-230.076.01 Page 11 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
•Push the horizontal lift until the cable bundle is in theposition shown in Fig. 20.
•Leave the C-arm in the horizontal position (Fig.1). This position is used to determine the
endstop (1/Fig22).
•Reinstallthespring ring (1/Fig.21).
•Reattachthestop(2/Fig.21)withthescrew.
•Reinstallthe stop wheel(1/Fig.22).
•Reinstallthespring ring (2/Fig.22).
Fig. 20
Fig. 21 Fig. 22
1
2
1
2

SIREMOBIL Iso-C SPR2-230.076.01 Page 12 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
12 Replacing the horizontal lift brake
•Reinstalltheend stop(Fig.23).Do not insert any screws in the threaded hole(1/Fig. 23)
(ThisisthethreadedholefortheMODULARIS docking plate)
•Remountthe completeangulationbrakeand attachitwiththe screws (Fig.24).
•ConnectplugsX22/X23.
•Remount the horizontal guide bearings for the horizontal carriage. (1/Fig.25)
•Thecenterguidebearing(2/Fig.25)is equippedwithaneccentricbolt.
•Switch ON the SIREMOBIL and release the horizontal lift brake.
•Move the verticallift until the C-arm is no longer on the work table.
•Move the horizontal carriage slowly from end stop to end stop.Whendoing this, the
horizontal carriage should be centeredon theshaft and should not drag at any point
(Fig.26indicatestheschematictopviewof the horizontalcarriage).Youmayhaveto
adjusttheeccentric bolt(2/Fig.25).
Fig. 23 Fig. 24
Fig. 25 Fig. 26
1
1
2

Replacing the horizontal lift brake 13
Siemens AG SPR2-230.076.01 Page 13 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
•Releasetheangulationbrake(pressthebrake switch,theLED lights).
•Applyone drop of Loctitetothethreads(1/Fig.27).
•Placethespringwashersand the nut backon thethreads.
•First, hand-tighten the nut.
•Remove thework table from the C-armand movethe C-arm into the verticalposition (I.I.
above,SIREPHOS below).
•Suspend aspringscalefrom anattachment point on theupperrailing and check the
movement force of the angulation movementwithin an angulation range of approx. +/-
45° from the verticalposition.
•Thebrakingforcewithoutthebrakeappliedcanbe adjustedby tighteningorloosening
the nut.Whendoingthis,movethe horizontal carriage several timesfrom endstop to
endstop to eliminatetheplayon theshaft.
Fig. 27
After applying Loctite to the threads, the following adjustments and
tests should be performed immediately, so that the threadlocker does
not set before the adjustment is done.
➪Force of movement, unbraked: > 20N...< 30N
➪Force of movement, unbraked with MODULARIS: > 20N...< 22N
1
NOTICE

SIREMOBIL Iso-C SPR2-230.076.01 Page 14 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
14 Replacing the horizontal lift brake
•Reattachthebackcover(1/Fig.28).
•Reattachtheplate(1/Fig.29.
•Reattach thecable guide (1/Fig.30). Makesure that the cable bundle isrouted properly.
•Reattachthecablebundle(2/Fig.30).When doingthis,makesurethatthe horizontal
brake cable cannot rub against the horizontal carriage. If necessary, press it slightly in
therecesswitha flat object.
•Placethecableclamp over thebracket(3/Fig.30).
•Reattach thecable bundle with the cable clamp (1/Fig. 31).When doing this, makesure
thatthecablebundle is routed correctly.(RefertoFig.30).
•Donot attach the cable forthebrakeswitches(connectorX1)withtheothercablesin the
cableclamp(1/Fig.31).
Fig. 28 Fig. 29
Fig. 30 Fig. 31
1
1
1
2
5
1
3
2
4

Replacing the horizontal lift brake 15
Siemens AG SPR2-230.076.01 Page 15 of 16 SIREMOBIL Iso-C
Medical Engineering Rev. 01 02/99 TD SD 24
•Securethecablebundlewithcable ties at the points indicated(boldlines/Fig.30):
- atconnectorX22
- atconnectorX23
- in front of the bracket (Fig. 30/3)
•ReconnectplugsX22 andX23 (4/Fig.30).
•Routethe cablesto microswitchesS3 and S4andconnect them
(2/Fig. 31).
•Securethecablesto the microswitchestothe side oftheplatewithcable ties (2/Fig.31).

SIREMOBIL Iso-C SPR2-230.076.01 Page 16 of 16 Siemens AG
Rev. 01 02/99 TD SD 24 Medical Engineering
16 Replacing the horizontal lift brake
•Reattachthecoverplate(1/Fig.32).
•Securethecableto the switchboardwithcableclamps.
•Reattach thelower telescope cover (1/Fig. 33).
•Reattachthecover(2/Fig.33)attheVelcroclosures.
•Reconnect plugX1 tothe cover with thebrake switches.
•Reconnecttheprotectiveconductortothecoverwith the brake switches.
•Remountthe coverwith the brake switches to thehorizontalcarriage.
Concluding work 1
•Checkthehorizontalliftforeaseofmovement.
•Checktheangulationforeaseofmovement.
•After completing all servicework and reattaching the covers, perform the protective
conductortestin accordancewithARTD-002.731.17.
•Perform a function test on the SIREMOBIL.
TD SD 24 / Arnold
TD SD 24 / Groß
SMS Iselin / O’Donnell
Fig. 32 Fig. 33
1
2
1
2
S3 S4
