Siemens MAMMOMAT 1000 Nova Operating and maintenance instructions

© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted without express written
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
Print No.:
Friedrich
MAMMOMAT Nova - Opdima
System
Maintenance Instructions
SP
2003
SPB7-230.101.03.05.02
Replaces: SPB7-230.101.03.04.02
English
Doc. Gen. Date: 02.06
MAMMOMAT 1000/3000/3000 Nova - Opdima
The protocol SPB7-230.105.03.05.02 is required for
these instructions
06134709

2 Revision / Disclaimer
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 2 of 18 Medical Solutions
1Revision / Disclaimer
Document revision level
The document corresponds to the version/revision level effective at the time of system
delivery. Revisions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified
personnel who are employed by Siemens or one of its affiliates or who are otherwise
authorized by Siemens or one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated
with or authorized by Siemens or one of its affiliates are directed to contact one of the
local offices of Siemens or one of its affiliates before attempting installation or service pro-
cedures.

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
Table of Contents 3
Page 3 of 18
Medical Solutions
0Table of Contents
1 _______ General information______________________________________________ 4
Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Required documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Required tools, measurement and auxiliary devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Text emphasis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety information and preventive measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 _______ System status __________________________________________________ 9
Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 _______ System _______________________________________________________ 10
Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 _______ Testing _______________________________________________________ 12
Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 _______ Miscellaneous _________________________________________________ 15
Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Final tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 _______ Changes since the previous version _______________________________ 17

4 General information
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 4 of 18 Medical Solutions
1-
1 General information
1.1 Training
•Training workshop or at least 1 installation

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
General information 5
Page 5 of 18
Medical Solutions
1.2 Required documents
•Instructions for Use MAMMOMAT 1000/3000 Nova SPB7-230.201...
•Supplement to the Instructions for Use MAMMOMAT
3000- Opdima®(included in the Opdima®delivery)
SPB7-230.203.13...
•MAMMOMAT 1000/3000/3000 Nova - Opdima®Service
Instructions (included in the Opdima®delivery)
SPB7-230.061.11 ...

6 General information
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 6 of 18 Medical Solutions
1.3 Required tools, measurement and auxiliary devices
NOTE All listed tools, measurement and auxiliary devices, with the ex-
ception of those marked with "*", are specified in the STC (Service
Tools Catalog).
•Protective ground wire tester (44 15 899 RV090)
•Stereo calibration phantom (included in the Opdima®delivery) (part no. 64 30 701)
•Acrylic plastic (PMMA = Poly-methyl-met-acrylate) plates: 3 plates of AEC calibration
Plexiglas 150 mm x 150 mm x 19 mm (part no. 65 61 232) and one plate of calibration
Plexiglas, 150 mm x 150 mm x 9.7 mm (part mo. 65 61 224)
•Grid object table
•Mammography bar pattern (5-20 lp/mm), for instance Nuclear Associates Resolution
Test Pattern (07-555), http://www.nucl.com
•Cleaning agents* specified in the Instructions for Use MAMMOMAT 1000/3000 Nova,
chapter "Cleaning, disinfection"
•Standard service tools*

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
General information 7
Page 7 of 18
Medical Solutions
1.4 Text emphasis
DANGER DANGER indicates that there is an immediate danger of death or
serious physical injury.
¹n.a.
WARNING WARNING indicates that there is a risk of possible death or serious
physical injury.
¹n.a.
CAUTION CAUTION used with the safety alert symbol indicates that there is
a risk of slight or moderate physical injury and/or damage to prop-
erty.
¹n.a.
NOTICE NOTICE used without the safety alert symbol indicates that
non-compliance may cause a situation leading to an undesirable
result or state other than death, physical injury or damage to prop-
erty.
¹n.a.
NOTE NOTE contains information provided with special emphasis to fa-
cilitate proper use of the equipment or proper execution of a pro-
cedure, i.e. hints, tips.

8 General information
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 8 of 18 Medical Solutions
1.5 Safety information and preventive measures
NOTE •When conducting repair work and tests, please note:
- The product-specific safety information in the document
- The safety information in TD00-000.860.01...
•Tests or adjustments that must be made with the radiation ON
are identified by the radiation warning symbol.
During these types of adjustments, radiation protective cloth-
ing must be worn.

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
System status 9
Page 9 of 18
Medical Solutions
2-
2 System status
2.1 Checks
Check the system status and fill out the Maintenance Protocol.
•Check the serial no. and the part no. for the workstation, the CCD camera, and the biop-
sy controller.
•Check the license key (DICOM option).
•For instructions on how to check the hostname/hostid, see the Service Instructions
for Opdima®, chapter "Instructions for obtaining the system host ID and host name".
•Document country settings in the Maintenance Protocol
•If applicable, document the network and printer parameters in the Maintenance Proto-
col.

10 System
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 10 of 18 Medical Solutions
3-
3System
3.1 Checks
PMP MO storage media and MO unit
The MO disks must be handled with care. They should never be forced into or out of the
drive. They should not be exposed to heat or fluids. Never place heavy objects on an MO
disk. The MO drive unit is relatively sensitive to dust.
•Be sure that the unit is installed in a clean environment and is not exposed to dust.
•Check that the correct MO media is used. Only Sony standard media
(Siemens part no. 66 33 734, Sony RMO-S561, 9.1 GB rewritable)
can be used as MO media.
•Check that the MO disks are stored in a clean and safe place.
•Check that the local disks and backup disks are properly labeled.
•Check that backup disks are stored separately.
•The MO disks used in the Opdima®system are equipped with a mechanical write pro-
tection lock. This lock should NEVER be used since the Opdima®system always at-
tempts to mount the MO disk as a read/write device.
Fig. 1: Write protection lock not activated.
PMP SCSI cables, CD-ROM
It is important to check that the SCSI cables are properly connected and the hardware is
terminated correctly. If not, this might result in a number of problems, e.g. failure to write
images to MO disk, corrupted MO disk, corrupted hard disk.
•Make sure the SCSI cables are properly connected and attached to the units and that
the cable is not bent too much just behind the MO.
•The MO drive is to be terminated with the external termination plug.
If the system is not able to store images on the MO disk due to the above problem, it will
take longer to save images when the system can save.

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
System 11
Page 11 of 18
Medical Solutions
NOTE It is important not to interrupt the system when it is saving images
on the MO disk because the MO disk can be destroyed.
PMP General cable information
•Check the connectors and cables between the biopsy controller and CCD camera.
•Check the connectors and cables between the biopsy controller and workstation.
•Check that all cables are undamaged, especially the monitor cables.
•Check that the connectors are properly attached.
SW Disk cache settings
For instructions on how to check the disk cache settings, see the Service Instructions for
Opdima®, chapter "Disk cache settings".
SI Biopsy unit
This unit contains the following safety-related parts which should be checked every year
and replaced as necessary:
•Biopsy unit connectors (25-pin DSUB connector and 9-pin object table connector). Vi-
sual inspection
•Sliding pads on the underside of the biopsy unit object table. Check that the sliding pads
are free of apparent and visible damage and that the biopsy unit object table runs
smoothly on the base plate.
•Check that the biopsy unit is safely locked to the MAMMOMAT.

12 Testing
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 12 of 18 Medical Solutions
4-
4Testing
4.1 Test
PMF Test of units
For instructions on how to test the units, see the Service Instructions for Opdima®,
chapter "Test of units".

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
Testing 13
Page 13 of 18
Medical Solutions
4.2 Calibration
PMF CCD camera calibration
For instructions on how to calibrate the CCD camera, see the Service Instructions for
Opdima®, chapter "CCD camera calibration and maintenance".
Q Calibration of the biopsy unit
•Check the biopsy unit accuracy according to the Service Instructions for Opdima®,
chapter "Verifying the calibration of the biopsy unit". Verify the calibration for all four tar-
get points of the stereo calibration phantom.
•If the biopsy unit accuracy is not satisfactory, perform calibration according to the Ser-
vice Instructions for Opdima®, chapter "Calibration of the biopsy unit".

14 Testing
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 14 of 18 Medical Solutions
4.3 Checks
QIQ Opdima®AEC
For instructions on how to check Opdima®AEC, see the Service Instructions for
Opdima®,
chapter "Check of Opdima AEC".
QIQ Resolution
For instructions on how to check the resolution, see the Service Instructions for Opdima®,
chapter "Check of resolution".

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
Miscellaneous 15
Page 15 of 18
Medical Solutions
5-
5 Miscellaneous
5.1 Checks
PMF Cassette locking
•Check that the camera is properly locked to the object table.
PMA UIs and SPEED info
•Check whether all relevant UIs and SPEED info has been completed.
•Check that the customer creates regular backups.

16 Miscellaneous
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 16 of 18 Medical Solutions
5.2 Final tests
SIE Protective conductor test
•Perform the protective conductor test according to ARTD-002.731.17...
PMP Cleaning/damaged paint
•Clean the unit using the materials recommended in the Instructions for Use for
MAMMOMAT 1000/3000 Nova (chapter "Cleaning, disinfection") and repair any dam-
aged paint.
•System ON.
QSQ Final test exposure
XTake one final test exposure.

Siemens AG SPB7-230.101.03.05.02 MAMMOMAT Nova - Opdima
02.06 CS PS SP
Changes since the previous version 17
Page 17 of 18
Medical Solutions
6-
6 Changes since the previous version
Document has been converted to the Data Management System - DMS.

18 Changes since the previous version
MAMMOMAT Nova - Opdima SPB7-230.101.03.05.02 Siemens AG
02.06 CS PS SP
Page 18 of 18 Medical Solutions
