Siemens FP120-Z1 User manual

FP120-Z1
Power supply kit A (70 W)
Technical Manual
A6V10393194_d_en_
--
Building Technologies
2018-11-05 Control Products and Systems

Imprint
2 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
Imprint
Technical specifications and availability subject to change without notice.
Transmittal, reproduction, dissemination and/or editing of this document as well as
utilization of its contents and communication thereof to others without express
authorization are prohibited. Offenders will be held liable for payment of damages.
All rights created by patent grant or registration of a utility model or design patent
are reserved.
Issued by:
Siemens Switzerland Ltd.
Building Technologies Division
International Headquarters
Theilerstrasse 1a
CH-6300 Zug
Tel. [phone]
www.siemens.com/buildingtechnologies
Edition: 2018-11-05
Document ID: A6V10393194_d_en_--
© Siemens Switzerland Ltd, 2014

3 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
Table of contents
1 About this document.............................................................................5
1.1 Applicable documents................................................................................. 6
1.2 Download center......................................................................................... 7
1.3 Revision history.......................................................................................... 7
2 Safety.................................................................................................8
2.1 Safety instructions ...................................................................................... 8
2.2 Safety regulations for the method of operation............................................ 9
2.3 Standards and directives complied with......................................................11
2.4 Release Notes...........................................................................................12
3 Structure and function......................................................................... 13
3.1 'Fault' signal transfer relay .........................................................................14
4 Mounting...........................................................................................15
4.1 Mounting the housing.................................................................................15
4.2 Mounting the optional components.............................................................16
4.3 Laying the cables and connecting the batteries..........................................17
4.3.1 Connecting the signal lines and DC 24 V.....................................19
4.3.2 Connecting the mains cable........................................................21
4.4 Installing and connecting the batteries .......................................................22
4.5 Mounting the cover cap..............................................................................22
5 Switching the mains voltage to AC 115 V ..............................................23
6 Battery capacity..................................................................................24
7 Checking functions .............................................................................25
8 Maintenance......................................................................................26
9 Faults / Troubleshooting......................................................................27
10 Components / accessories / spare parts................................................28
11 Technical data....................................................................................29
12 Disposal............................................................................................ 31

Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
4 | 32

About this document
Applicable documents
1
5 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
1 About this document
Goal and purpose
This manual describes the design and functions, as well as the key work steps
required for mounting and installation. Information about the function check,
maintenance, and troubleshooting makes it possible to use the product as
intended.
Scope
The information contained in this document is valid for FP120-Z1 power supply
kit A (70 W).
Intended use
This standalone power supply is intended for decentralized supply to external
devices. FP120-Z1 has an integrated operating and fault indicator, and makes it
possible to forward faults via potential-free contacts.
Target groups
The information in this document is intended for the following target groups:
Target group Activity Qualification
Installation personnel ●Assembles and installs the product
components at the place of
installation.
●Carries out a function check
following installation.
●Has received specialist training in
the area of building installation
technology or electrical installations.
Maintenance personnel ●Carries out all maintenance work.
●Checks that the products are in
perfect working order.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for the
products.
Source language and reference document
●The source/original language of this document is German (de).
●The reference version of this document is the international version in English.
The international version is not localized.
Document identification
The document ID is structured as follows:
ID code Examples
ID_ModificationIndex_Language_COUNTRY
-- = multilingual or international A6V10215123_a_de_DE A6V10215123_a_en_--
A6V10315123_a_--_--
Date format
The date format in the document corresponds to the recommendation of
international standard ISO 8601 (format YYYY-MM-DD).

About this document
Applicable documents
1
6 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
Conventions for text marking
Markups
Special markups are shown in this document as follows:
⊳Requirement for a behavior instruction
1.
2. Behavior instruction with at least two operation sequences
– Version, option, or detailed information for a behavior instruction
⇨Intermediate result of a behavior instruction
⇨End result of a behavior instruction
●Numbered lists and behavior instructions with an operation
sequence
[➙X] Reference to a page number
'Text' Quotation, reproduced identically
<Key> Identification of keys
>Relation sign and for identification between steps in a sequence,
e.g., 'Menu bar' > 'Help' > 'Help topics'
↑Text Identification of a glossary entry
Supplementary information and tips
The 'i' symbol identifies supplementary information and tips
for an easier way of
working.
1.1 Applicable documents
Document ID Title
A6V10393173 FP120-Z1 power supply kit A (70 W) – Mounting
A6V10416448 FP120-Z1 power supply kit A (70 W) – Data sheet
A6V10411051 FP2015-A1 power supply (70 W) – Technical manual

About this document
Download center
1
7 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
1.2 Download center
You can download various types of documents, such as data sheets, installation
instructions, and license texts via the following Internet address:
http://siemens.com/bt/download
lEnter the document ID in the 'Find by keyword' input box.
You will also find information about search variants and links to mobile
applications (apps) for various systems on the home page.
1.3 Revision history
The reference document's version applies to all languages into which the reference
document is translated.
The first edition of a language version or a country variant may, for example, be
version 'd' instead of 'a' if the reference document is already this version.
The table below shows this document's revision history:
Version Edition date Brief description
d 2018-11-05 Technical data revised, row 'Approvals' removed
c 2015-06-20 Technical data revised
b 2014-11-18 Technical data revised
a 2014-02-09 First edition

Safety
Safety instructions
2
8 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
2 Safety
2.1 Safety instructions
The safety notices must be observed in order to protect people and property.
The safety notices in this document contain the following elements:
●Symbol for danger
●Signal word
●Nature and origin of the danger
●Consequences if the danger occurs
●Measures or prohibitions for danger avoidance
Symbol for danger
This is the symbol for danger. It warns of risks of injury.
Follow all measures identified by this symbol to avoid injury or death.
Additional danger symbols
These symbols indicate general dangers, the type of danger or possible
consequences, measures and prohibitions, examples of which are shown in the
following table:
General danger Explosive atmosphere
Voltage/electric shock Laser light
Battery Heat
Signal word
The signal word classifies the danger as defined in the following table:
Signal word Danger level
DANGER 'DANGER' identifies a dangerous situation, which will result directly in death or
serious injury if you do not avoid this situation.
WARNING 'WARNING' identifies a dangerous situation, which may result in death or serious
injury if you do not avoid this situation.
CAUTION 'CAUTION' identifies a dangerous situation, which could result in slight to
moderately serious injury if you do not avoid this situation.
NOTICE
' NOTICE ' identifies a possibly harmful situation or possible damage to property
that may result from non-observance.
'
NOTICE ' does not relate to possible bodily injury.

Safety
Safety regulations for the method of operation
2
9 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
How risk of injury is presented
Information about the risk of injury is shown as follows:
WARNING
Nature and origin of the danger
Consequences if the danger occurs
●
Measures / prohibitions for danger avoidance
How possible damage to property is presented
Information about possible damage to property is shown as follows:
NOTICE
Nature and origin of the danger
Consequences if the danger occurs
●
Measures / prohibitions for danger avoidance
2.2 Safety regulations for the method of operation
National standards, regulations and legislation
Siemens products are developed and produced in compliance with the relevant
European and international safety standards. Should additional national or local
safety standards or legislation concerning the planning, mounting, installation,
operation or disposal of the product apply at the place of operation, then these
must also be taken into account together with the safety regulations in the product
documentation.
Electrical installations
WARNING
Electrical voltage
Electric shock
●Work on electrical installations may only be carried out by qualified
electricians or by instructed persons working under the guidance and
supervision of a qualified electrician, in accordance with the electrotechnical
regulations.
●Wherever possible disconnect products from the power supply when carrying
out commissioning, maintenance or repair work on them.
●Lock volt-free areas to prevent them being switched back on again by mistake.
●Label the connection terminals with external voltage using a
'DANGER External voltage' sign.
●Route mains connections to products separately and fuse them with their own,
clearly marked fuse.
●Fit an easily accessible disconnecting device in accordance with IEC 60950-1
outside the installation.
●Produce earthing as stated in local safety regulations.

Safety
Safety regulations for the method of operation
2
10 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
CAUTION
Noncompliance with the following safety regulations
Risk of injury to persons and damage to property
●
Compliance with the following regulations is required.
●Specialist electrical engineering knowledge is required for installation.
●Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.
Mounting, installation, commissioning and maintenance
●If you require tools such as a ladder, these must be safe and must be intended
for the work in hand.
●When starting the fire control panel ensure that unstable conditions cannot
arise.
●Ensure that all points listed in the 'Testing the product operability' section below
are observed.
●You may only set controls to normal function when the product operability has
been completely tested and the system has been handed over to the customer.
Testing the product operability
●Prevent the remote transmission from triggering erroneously.
●If testing building installations or activating devices from third-party companies,
you must collaborate with the people appointed.
●The activation of fire control installations for test purposes must not cause
injury to anyone or damage to the building installations. The following
instructions must be observed:
– Use the correct potential for activation; this is generally the potential of the
building installation.
– Only check controls up to the interface (relay with blocking option).
– Make sure that only the controls to be tested are activated.
●Inform people before testing the alarm devices and allow for possible panic
responses.
●Inform people about any noise or mist which may be produced.
●Before testing the remote transmission, inform the corresponding alarm and
fault signal receiving stations.
Modifications to the system design and the products
Modifications to the system and to individual products may lead to faults,
malfunctioning and safety risks. Written confirmation must be obtained from
Siemens and the corresponding safety bodies for modifications or additions.

Safety
Standards and directives complied with
2
11 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
Modules and spare parts
●Components and spare parts must comply with the technical specifications
defined by Siemens. Only use products specified or recommended by
Siemens.
●Only use fuses with the specified fuse characteristics.
●Wrong battery types and improper battery changing lead to a risk of explosion.
Only use the same battery type or an equivalent battery type recommended by
Siemens.
●Batteries must be disposed of in an environmentally friendly manner. Observe
national guidelines and regulations.
Disregard of the safety regulations
Before they are delivered, Siemens products are tested to ensure they function
correctly when used properly. Siemens disclaims all liability for damage or injuries
caused by the incorrect application of the instructions or the disregard of danger
warnings contained in the documentation. This applies in particular to the following
damage:
●Personal injuries or damage to property caused by improper use and incorrect
application
●Personal injuries or damage to property caused by disregarding safety
instructions in the documentation or on the product
●Personal injury or damage to property caused by poor maintenance or lack of
maintenance
2.3 Standards and directives complied with
A list of the standards and directives complied with is available from your Siemens
contact.

Safety
Release Notes
2
12 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
2.4 Release Notes
Limitations to the configuration or use of devices in a fire detection installation with
a particular firmware version are possible.
WARNING
Limited or non
-
existent fire detection
Personal injury and damage to property in the event of a fire.
●Read the 'Release Notes' before you plan and/or configure a fire detection
installation.
●Read the 'Release Notes' before you carry out a firmware update to a fire
detection installation.
NOTICE
Incorrect planning and/or configuration
Important standards and specifications are not satisfied.
Fire detection installation is not accepted for commissioning.
Additional expense resulting from necessary new planning and/or configuration.
●Read the 'Release Notes' before you plan and/or configure a fire detection
installation.
●Read the 'Release Notes' before you carry out a firmware update to a fire
detection installation.

Structure and function
Release Notes
3
13 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
3 Structure and function
Figure 1: Installation situation FP120-Z1
1 LED function display 6 Connection card FP120-Z1 mainboard
2 Battery 7 U-rail TS35, 122 mm long
3 Housing 8 Installation positions for input/output
modules and relay modules
4 Power supply (70 W) 9 Front panel
5 Mains connection terminals 10 Cover cap
Symbol LED function display Status LED Description
System: Green ON System operational
OFF System not operational
Fault: Yellow OFF No fault
ON Mains or battery fault
5
1
4
7
8
3
9
10
6
2

Structure and fun
ction
'Fault' signal transfer relay
3
14 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
3.1 'Fault' signal transfer relay
The power supply has two relays with changeover contact for the 'Fault' signal
transfer.
Contact Normal operation Fault
MAINS Relay is activated.
NC contact is open.
NO contact is closed.
Relay is deactivated.
NC contact is closed.
NO contact is open.
BATT Relay is activated.
NC contact is open.
NO contact is closed.
Relay is deactivated.
NC contact is closed.
NO contact is open.

Mounting
Mounting the housing
4
15 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
4 Mounting
Scope of delivery
The power supply kit (70 W) is supplied mounted with housing, a left-hand
installation frame with integrated power supply (70 W) FP2015 and FP120-Z1
mainboard, a right-hand installation frame for optional components, and a pre-
wired connection for the battery, as well as mounting instructions for wall mounting
and optional components: Document ID A6V10393173.
NOTICE
Electrostatic discharge
Damage to electronics
●
Take protective measures against electrostatic discharges (ESD).
Observe the following order for mounting the FP120-Z1:
1. Mount the housing
2. Mount the optional components
3. Connect the signal lines
4. Disconnect the mains voltage, disconnect the mains cable, and connect the
mains cable
5. Install and connect the batteries
6. Mount the cover cap
7. Switch on the mains voltage
4.1 Mounting the housing
Use the mounting instructions, document ID A6V10393173, from the scope of
delivery.

Mounting
Mounting the optional components
4
16 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
4.2 Mounting the optional components
A component can be mounted on the rear panel of the housing without a U-rail. Up
to seven components can be mounted on a U-rail, depending on the size of the
component.
Installation on rear panel of the housing Installation on U-rail
1 Input/output module 3 Large component, e.g., FDCIO223
2 U-rail 4 Small component, e.g., FDCIO221
1
2
4
3

Mounting
Laying the cables and connecting the batteries
4
17 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
4.3 Laying the cables and connecting the batteries
Primary wiring
WARNING
Electrical voltage
Electric shock
●Before connecting the mains cable, make sure that the cable is current-free.
●
Ensure that the mains is secured against inadvertently being switched on.
Secondary wiring
NOTICE
Short
-
circuit
Damage to hardware
●Before removing or fitting the power supply, remove the jumper wire between
the two batteries.
aThis ensures that the secondary side is current-free and that no components
can be damaged due to a short circuit.
1 Mains cable
2 Boundary of mains zone: White
3 Current-limited area: Gray
4 Signal lines
}
123
4

Mounting
Laying the cables and connecting the batteries
4
18 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
The following instructions must be observed.
●The cable cross section for each of the three lines of the mains cable is
1.5…2.5 mm2.
●The mains cable must be inserted from above on the left of the housing and
must not be laid outside the boundary of the mains zone.
●The lines of the mains cable must be secured with a cable tie.
●Signal lines must only be fed into the housing on the right from above or from
the rear.
●Signal lines must be secured with a cable tie.
●Cable entries must be closed completely.
●No cable entries should be made in the back box.
●Batteries must be installed so that they cannot leak.

Mounting
Laying the cables and c
onnecting the batteries
4
19 |
32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
4.3.1 Connecting the signal lines and DC 24 V
Figure 2: x = cable tie
The figure above shows the cable ties (x), which are also required for the mains
lines, even though these are only connected after the signal lines.
Figure 3: Stripping the cables
Max. current for AUX
1
or
AUX
2 is 2
A.
Max. current for AUX 1 and AUX 2 total is 2 A.
Figure 4: Terminal block
xx
xx
x
x
5 mm

Mounting
Laying the cables and connecting the batteries
4
20 | 32
Building Technologies
A6V10393194_d_en_
--
Fire Safety
2018
-
11
-
05
1. Strip the signal cables and lay these in the housing as shown above.
2. Connect the lines to the terminal block in accordance with the following wiring
diagram.
3. Strip the DC 24 V lines and lay these in the housing as shown above.
4. Connect the DC 24 V lines to the terminal block.
5. Secure the lines with cable ties (x).
'Fault' signal transfer via input/output module
The line for the 'Fault' signal transfer of the power supply is wired to an input/output
module, such as an FDCIO221, for example.
'Fault' signal transfer to a fire control panel
The line for the 'Fault' signal transfer of the power supply is wired to a fire control
panel, such as an FC120, for example.
This connection is only permitted if the housings are mounted side by side.
Otherwise, the connection must be monitored.
3.3 k
Ω
FCnet /
C-Net
FDCIO221
Input LINE
OUTA
+
-
-
FC120
AUX. 24V INPUT
+
-1
FP120-Z1
