Compact operating instructions

Power supply PS598-1 for SCALANCE XR-500M
A5E03275848A-01, 09/2011 3
Table of contents
Introduction .............................................................................................................. 6
Safety notes ............................................................................................................. 7
Important notes on using the device ......................................................................7
Description ............................................................................................................... 8
Product characteristics ..........................................................................................8
Unpacking and checking........................................................................................9
Mounting ................................................................................................................ 10
19" rack mounting of the PS598-1 .......................................................................10
Mounting the PS598-1 on the rear panel of an XR-500M ....................................12
Connection............................................................................................................. 15
Connecting devices with 100 to 240 VAC power supply......................................15
Upkeep and maintenance....................................................................................... 20
Changing the air filter...........................................................................................20
Technical data........................................................................................................ 21
Mechanical and electrical data.............................................................................21
Dimension drawings ............................................................................................23
Approvals............................................................................................................... 24
EMC directive ......................................................................................................24
Mechanical stability (in operation)........................................................................26

© Siemens 2011
4 A5E03275848A-01, 09/2011
Legal information
Qualified Personnel
The product/system described in this documentation may be operated only by personnel
qualified for the specific task in accordance with the relevant documentation, in particular its
warning notices and safety instructions. Qualified personnel are those who, based on their
training and experience, are capable of identifying risks and avoiding potential hazards when
working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the
relevant technical documentation. If products and components from other manufacturers are
used, these must be recommended or approved by Siemens. Proper transport, storage,
installation, assembly, commissioning, operation and maintenance are required to ensure that
the products operate safely and without any problems. The permissible ambient conditions
must be complied with. The information in the relevant documentation must be observed.

© Siemens 2011
A5E03275848A-01, 09/2011 5
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as
well as to prevent damage to property. The notices referring to your personal safety are
highlighted in the manual by a safety alert symbol, notices referring only to property damage
have no safety alert symbol. These notices shown below are graded according to the degree of
danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions
are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions
are not taken.
NOTICE
indicates that an unintended result or situation can occur if the relevant information is not
taken into account.
If more than one degree of danger is present, the warning notice representing the highest
degree of danger will be used. A notice warning of injury to persons with a safety alert symbol
may also include a warning relating to property damage.

Introduction
Introduction
Purpose of the compact operating instructions
Based on the compact operating instructions, you will be able to install and connect
up the PS598-1 correctly.
Validity of these compact operating instructions
These compact operating instructions apply to the product PS598-1 as of product
version 1.
Power supply PS598-1 for SCALANCE XR-500M
6 A5E03275848A-01, 09/2011

Safety notes
Safety notes
Important notes on using the device
Safety notices on the use of the devices
The following safety notices must be adhered to when setting up and operating the
device and during all work relating to it such as installation, connecting up, replacing
devices or opening the device.
Important notices 100 to 240 VAC
DANGER
Danger from line voltage
Devices with this mark have a 100 to 240 VAC power supply.
This product can only function correctly and safely if it is transported, stored, set up,
and installed correctly, and operated and maintained as recommended.
Connecting and disconnecting may only be performed by an electrical specialist.
Connect or disconnect power supply cables only when the power is turned off!
General notices
WARNING
Opening the device
Do not open when energized. Note that this does not apply to opening the panel in
the housing.
Power supply PS598-1 for SCALANCE XR-500M
A5E03275848A-01, 09/2011 7

Description
Description
Product characteristics
Connectors
Type Power Input voltage Output voltage
PS598-1 300 W 100 to 240 VAC 24 VDC
Note
Two connectors for the 24 VDC output voltage
The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can
only use one connector on the front or the connector on the rear of the PS598-1. You
cannot operate the device with the connectors on the front and rear at the same time.
Note
Requirement for connecting at the rear
Note that the connector on the rear of the PS598-1 can only be used if the power
supply is mounted on the SCALANCE XR-500M.
Power supply PS598-1 for SCALANCE XR-500M
8 A5E03275848A-01, 09/2011

Description
Components of the product
The following parts make up the components of the PS598-1:
● 4-pin terminal block for the 24 VDC power supply.
● 2 mounting brackets
● 8 screws (M3 x 6 countersunk, drive: Torx) for mounting the fixing brackets for
19" rack installation
● Compact Operating Instructions
Order numbers
Type Order number
PS598-1 (300 W) 6GK5 598-1AA00-3AA0
Note
Replacing the filter mat
To replace the filter mat, use the material Viledon P 15/150 G2 EN 779. The
dimensions of the filter mat are 38 x 135 x 8 mm (H x W x D).
Unpacking and checking
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
WARNING
Do not use any parts that show evidence of damage!
If the consignment is incomplete or if there is damage to the exterior, contact your
supplier or your local Siemens office.
Power supply PS598-1 for SCALANCE XR-500M
A5E03275848A-01, 09/2011 9

Mounting
Mounting
19" rack mounting of the PS598-1
Power supply unit for 19" rack installation
The PS598-1 was developed specifically for use with devices of the XR-500M
product group. This power supply unit can be mounted directly above or below a
SCALANCE XR-500M since the ventilation openings are on the sides of both the
basic device and the power supply unit.
CAUTION
Damage to the device due to inadequate cooling
If the ventilation grilles are fully or partly covered or the air filters are contaminated,
the temperature inside the housing can rise and exceed the maximum permitted
temperature and damage the device.
During installation, select a mounting position so that the ventilation grilles are
always free so that the air can circulate. The ventilation grilles are located on the
side panels of the housing. You will find information about cleaning the air filter in
the section "Upkeep and maintenance".
Power supply PS598-1 for SCALANCE XR-500M
10 A5E03275848A-01, 09/2011
