Siemens FP1801-A2 User manual

Building Technologies
Fire Safety & Security Products
FP1801-A2
DYF01-B1000 Power Supply
Product Manual
Overview
-Stable and reliable DC output
-Auto switch between main power and battery
-Alternative AC power switch
-Charge and protect battery
-Monitor main power, battery, trouble status
-Auto recoverable current protection circuit for overload and short circuit
Technical Data
Input voltage 110/220 VAC
Input frequency 60/50 Hz
Output voltage 24 VDC
Output current 10A
AC fuse capacity 110VAC: 6A 220VAC:3A
DC fuse capacity 10A
Operating temperature 0 ~ +40℃
when it is over 40℃, output power will reduce half
Storage temperature -20 ~ +60℃
Humidity ≤95% (40±2℃)
Size 326*130*88 mm

2
Building Technologies A6V10322583_a_en_--
Fire Safety & Security Products 08.2010
Installation
Screw power supply to the
housingusing 4 screws
Fig. 1 Installation
Fig. 2 Connection
Connect external
AC input
Connect to port “Pwr
Status
” on main unit
Connect to port” PS”
on main unit and line
card
Connect to battery

Beijing Siemens Cerberus Electronics Limited
No.1,Fengzhidonglu, Xibeiwang, HaiDian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
© 2010 Copyright by
Beijing Siemens Cerberus Electronics Ltd.
Data and design subject to change without notice.
Doc. No. A6V10322583_a_en_-- Version a Manual FC18
Date 08.2010 100954074
Fig. 3 AC input switch
Dimension (in:mm)
Order Information
Type Material No. Part No. Description Weight
FP1801-A2 S54420-C20-A1 100935680 DYF01-B1000 power supply 2.1Kg
Switch between
220VAC and 110VAC
