----Push-to-trip and reclose recloserF12L20
User definedUser definedF11L19
User definedUser definedF10L18
User definedUser definedF9L17
Instantaneous protection is OFFPush-to-toggle instantaneous protection ON/OFFF8L16
All protection is OFFPush-to-toggle all protection ON/OFFF7L15
SEF protection is OFFPush-to-toggle SEF protection ON/OFFF6L14
Ground fault protection is OFFPush-to-toggle ground fault protection ON/OFFF5L13
Hot line tag is ONPush-to-toggle hot line tag ON/OFFF4L12
Reclose functionality is ONPush-to-toggle reclose functionality ON/OFFF3L11
Recloser is CLOSEDPush-to-close recloserF2L10
Recloser is OPENPush-to-open recloserF1L9
If associated LED is lit, status:DescriptionButtonLED
Serial numberSerial No.
Firmware revision numberConfig
Voltage to activate a binary inputBI
Power supply voltage range (dc volts)Vx
Voltage supplied to relay from voltage sensorsVn
50 Hz/60 Hz (user defined)Fn
CT secondary current (1 A for recloser)In
DescriptionItem
Capacitors charged and system ready to recloseL8
AC input power to control cubicle okL7
Recloser is locked outL6
Sensitive earth fault (SEF) targetL5
Ground fault targetL4
Phase C targetL3
Phase B targetL2
Phase A targetL1
DescriptionLED
Programming portC
Ratings labelB
MLFB model numberA
DescriptionItem
7SR224
Relay
A PH Fault
B PH Fault
C PH Fault
Gnd Fault
SEF
Lockout
Aux Power OK
Recloser OK
Close
Reclose ON
Gnd Fault
Prot’n OFF
SEF
Prot’n OFF
All Prot’n
OFF
Inst Prot’n
OFF
Trip &
Reclose
Open
Hot Line
Tag ON
A
B
C
L1
L2
L3
L4
L5
L6
L7
L8
L9
L10
L11
L12
L13
L14
L15
L16
L17
L18
L19
L20
01: 1/4/2012
TGH 02/12
TGH 02/12
----
Type 7SR224 Relay
Quick Reference Guide
For Three-Phase SDR Recloser
01-12

Quick reference navigation tree guide
for type 7SR relay
Press enter. If LCD screen does not say “ENTER to CONTROL”, press the Cancel button until it
does. This will not cause the recloser to operate.
Quick Logic Meters
Comm Meters
Virtual Meters
Misc Meters
General Alarm MetersCommunicationsSet L or R
Maintenance MetersData StorageSet Local
Fault 10Loss of Voltage MetersMaintenanceBattery Test Initiate
Fault 9Autoreclose MetersOutput ConfigLoss of Voltage IN/OUT
Fault 8Thermal MetersInput ConfigInst Prot’n IN/OUT
Fault 7Directional MetersControl & LogicSGF Prot’n IN/OUT
Fault 6Energy MetersSupervisionG/F Prot’n IN/OUT
Fault 5Power MetersVoltage Prot’nHotline Working IN/OUT
Fault 4Frequency MetersCurrent Prot’nAR: Trip & Lockout
Fault 3VoltageFunction ConfigAR: Trip & Close
Fault 2Current MetersCT/VT ConfigAR: Out of Service IN/OUT
Fault 1Favorite MetersSystem ConfigCB: Open/Closed/Travel
Binary Input Meters
Demand Meters
Power Quality Meters
Refer to page three for
detailed “Settings Mode” tree.
Capacitor ConditionSet Service
Battery ConditionSet Remote
Settings Mode Instrument Mode Fault DataControl Mode
For all arrows pointing ,
push the button.
For all arrows pointing ,
push the button.
To go back one level,
push the button.
Notes:
For all arrows pointing ,
push the button.
To select,
push the button.
CH: _______
Name:
Similar To: Bulletin:
Scale: Sheet: Part No: Issue/Rev:
NONE 2 of 4 18-671-296-402 01
DR: _______
AP: _______
01: 1/4/2012
TGH 02/12
TGH 02/12
----
Type 7SR224 Relay
Quick Reference Guide
For Three-Phase SDR Recloser
01-12

59NDT
Voltage Prot’n
U/O Frequency
Neutral Overvoltage
NPS Overvoltage
Settings Mode
Vx U/O Voltage
Phase U/O Voltage
Thermal
Undercurrent
NPS Overcurrent
47-1 & 47-2
59NIT
Restricted E/F
50SEF-1 thru 50SEF-4
67-NSensitive E/F
50G1- thru 50G-4
51-G thru 51G-4Measured E/F
Cold Load
Voltage Cont O/C
50-1 thru 50-4
51-N thru 51-4
67-NPhase OvercurrentCurrent Prot’n
Function Config
CT/VT Config
27/59-1 thru 27/59-4
46DT
46IT
System Config Establish system parameters, recloser name, active settings group, viewing/editing settings group and other parameters.
Establish current transformer (CT) and voltage transformer.(VT) parameters.
Enable functions..
Settings mode
detailed tree
