Siemens 5SV60 MC Series User manual

3355484127-04 1
Technical Support (https://www.siemens.com/support-request)

23355484127-04

3355484127-04 3
0.75 ... 16 mm2
0.75 ... 10 mm2

43355484127-04
AFDD self test
Press button ≤ 3 s --> AFDD trips after button release.
Test result shown by LED after power on

3355484127-04 5
left LED
right LED
LED off
Device without power
LED off
Device without power
LED static green
AFDD alright
LED static green
MCB alright
LED static green
AFDD alright
LED flashes 0.75 Hz green
Not configured with master device
LED static green
AFDD alright
LED flashes 2 Hz green, min. for 3 s
Internal process running e.g. pairing, internal
test, firmware update, reset
LED flashes 5 Hz green
Device Identification after ext. command
LED flashes 5 Hz green
Device Identification after external command
LED static green
AFDD alright
LED flashes alternately 2 Hz yellow/green
Warning metering value threshold exceeded
(e.g. current, temperature) with auto reset.
LED static green
AFDD alright
LED flashes alternately 2 Hz yellow/red
Warning life cycle parameter threshold
exceeded (e.g. switching cycles, number of
trips) - reset only by changing threshold /
deactivate warning
LED static green
AFDD alright
LED flashes 2 Hz red
MCB tripped (Indication after power-on,
acknowledge necessary)
LED flashes 2 Hz red
AFDD tripped (Indication after power-on,
acknowledge necessary)
LED static green
MCB alright
LED off
Communication error
LED flashes 2 Hz yellow
Communication error
LED flashes 2 Hz red (different frequency left
and right)
Self-test failed, device error
LED flashes 4 Hz red (different frequency left
and right)
Self-test failed, device error
Reset device keys to factory default (unpair from
7KN Powercenter 1000)
Press button ≥ 10 s
After 3 s LED flashes 2 Hz green for 7 s.
Then the LED flashes 10 Hz green
Acknowledge after trip
1. Take care, that the cause of trip is removed
2. Switch ON the device and press button < 3 s

63355484127-04
Wireless Protocol
Operating
frequency
range:
2400-2483.5 MHz
Maximum
output power:
10 dBm EIRP
SIOS
https://sie.ag/3kWUa3j
→ Product / Article No.
Installation guide
https://sie.ag/3kPTjBf

3355484127-04 7

83355484127-04
https://support.industry.siemens.com/cs/de/en
→ Product / Article No. → Certificate → Declaration of Conformity
Security information
In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement
– and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and
solutions constitute one element of such a concept. For more information about industrial security, please visit
https://www.siemens.com/industrialsecurity

3355484127-04 9
3355484127-04
Last Update: 24 May 2022 © Siemens AG 2021 Subject to change without prior notice.
