FDB181CDetector Base
Product Manual
Overview
The FDB181C detector bases is a universal base. It’s fixed on fire detection site and
used for installations of FD181Cseries detectors：
−FDO181Csmoke detector
−FDT181Cheat detector
Characteristics
– Universal bases，applicable to both surface install and conceal install
– Large opening in the detector base for easy cable insertion
– Adopt environmental friendly material
Installation
The installation of a base should strictly follow the engineering design drawings. The
bases should be evenly distributed.
Procedure of installation：
1．Insert the cables through the base and connect them to the terminals.
2．Fix the base to the ceiling with screws.
Note:
The detector should be installed after the construction has been finished.
In order to ensure the reliability of the connection between the base and the detector,
please do not use U-type terminals.
Twisted-pairs with the wiring requirement of 1.0~1.5mm2 are recommended.

Beijing Siemens Cerberus Electronics Limited
No.1,Fengzhidonglu, Xibeiwang, HaiDian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
© Data and design subject to change without notice.
Doc No.
A6V10326265_d_en_--
Manual FD18
Edition
07.2012
100858266
Dimensions
In：mm
95.6
R2.15 0.50±
74.0 0.1±20.1
Electric connection
51a
6 1b
To next base
Terminal resistor
is not necessary
To controller
FDB181CBase
PP
S
S
Technical data
Connecting terminals
1.0 ... 1.5 mm
2
Operating temperature
Storage temperature
Humidity
Protection category EGB4208-93
According to data of detectors
Color
White
，
RAL 9010
Details for ordering
Type
Material No.
Part No.
Designation
Weight
FDB181C
S54320-F1-A1
100856213
Detector base
0.027 kg
