Siemens RUGGEDCOM RSG910C User manual

Edition 04/2022
Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RSG910C
https://www.siemens.com/ruggedcom

SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RSG910C
Installation Manual
Preface
Introduction 1
Installing the Device 2
Device Management 3
Communication Ports 4
Technical Specifications 5
Certification 6
04/2022
C79000-G8976-1405-11

Legal Information
Warning Notice System
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown
below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger
will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning
relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the
specific task in accordance with the relevant documentation, in particular its warning notices and safety
instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper Use of Siemens Products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant
technical documentation. If products and components from other manufacturers are used, these must be
recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning,
operation and maintenance are required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The information in the relevant
documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens Canada Ltd.. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Digital Industries
Process Automation
300 Applewood Crescent
Concord, Ontario, L4K 4E5
Canada
C79000-G8976-1405-11
© 04/2022 Subject to change
Copyright © Siemens 2022
All rights reserved

Table of Contents
Preface ............................................................................................................................................ v
Related Documents ................................................................................................................. v
SIMATIC NET Glossary .............................................................................................................. v
Accessing Documentation ....................................................................................................... v
Registered Trademarks ............................................................................................................ v
Warranty ................................................................................................................................ vi
Training .................................................................................................................................. vi
Customer Support .................................................................................................................. vii
Contacting Siemens ............................................................................................................... vii
1 Introduction ........................................................................................................................... 1
1.1 Feature Highlights ................................................................................................. 1
1.2 Description ............................................................................................................ 2
1.3 Required Tools and Materials ................................................................................. 3
1.4 Decommissioning and Disposal ............................................................................. 3
2 Installing the Device ............................................................................................................. 5
2.1 General Procedure ................................................................................................. 6
2.2 Unpacking the Device ........................................................................................... 6
2.3 Installing the Device in Hazardous Locations .......................................................... 7
2.4 Mounting the Device ............................................................................................. 8
2.4.1 Mounting the Device on a DIN Rail ........................................................................ 8
2.4.2 Mounting the Device to a Panel .......................................................................... 10
2.5 Connecting the Failsafe Alarm Relay .................................................................... 12
2.6 Connecting Power ............................................................................................... 14
2.6.1 Connecting AC or DC Power ................................................................................ 14
2.6.2 Wiring Examples .................................................................................................. 16
3 Device Management ........................................................................................................... 19
3.1 Connecting to the Device .................................................................................... 19
3.2 Configuring the Device ........................................................................................ 20
4 Communication Ports .......................................................................................................... 21
4.1 Copper Ethernet Ports ......................................................................................... 21
4.2 SFP Transceivers .................................................................................................. 22
5 Technical Specifications ...................................................................................................... 25
5.1 Power Supply Specifications ................................................................................ 25
5.2 Failsafe Alarm Relay Specifications ...................................................................... 26
5.3 Supported Networking Standards ........................................................................ 26
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 iii

Table of Contents
5.4 Copper Ethernet Port Specifications ..................................................................... 27
5.5 Operating Environment ....................................................................................... 27
5.6 Mechanical Specifications .................................................................................... 27
5.7 Dimension Drawings ........................................................................................... 28
6 Certification ......................................................................................................................... 31
6.1 Approvals ............................................................................................................ 31
6.1.1 CSA ..................................................................................................................... 31
6.1.2 CSA/Sira .............................................................................................................. 32
6.1.3 European Union (EU) .......................................................................................... 33
6.1.4 FCC ..................................................................................................................... 33
6.1.5 FDA/CDRH ........................................................................................................... 34
6.1.6 ISED .................................................................................................................... 34
6.1.7 TÜV SÜD ............................................................................................................. 34
6.1.8 RRA ..................................................................................................................... 34
6.1.9 ISO ...................................................................................................................... 35
6.1.10 ANATEL ............................................................................................................... 35
6.1.11 RoHS ................................................................................................................... 36
6.1.12 Other Approvals .................................................................................................. 36
6.2 EMC and Environmental Type Tests ..................................................................... 36
iv RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Preface
This guide describes the RUGGEDCOM RSG910C. It describes the major features of
the device, installation, commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible
for the installation, commissioning and maintenance of the device. It is also
recommended for use by network and system planners, system programmers, and
line technicians.
Related Documents
Other documents that may be of interest include:
Document Title Link
RUGGEDCOM ROS Configuration Manual https://support.industry.siemens.com/cs/ww/en/
view/109757207
RUGGEDCOM SFP Transceivers Catalog https://support.industry.siemens.com/cs/ww/en/
view/109482309
Time Synchronization Capabilities of RUGGEDCOM
Devices
https://support.industry.siemens.com/cs/ww/en/
view/109780448
SIMATIC NET Glossary
The SIMATIC NET Glossary describes special terms that may be used in this
document.
The glossary is available online via Siemens Industry Online Support (SIOS) at:
https://support.industry.siemens.com/cs/ww/en/view/50305045
Accessing Documentation
The latest user documentation for RUGGEDCOM RSG910C is available online at
https://support.industry.siemens.com. To request or inquire about a user document,
contact Siemens Customer Support.
Registered Trademarks
RUGGEDCOM®, ROS®, RCDP®, and RUGGEDCOM Discovery Protocol® are registered
trademarks of Siemens Canada Ltd.
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 v

Preface
Warranty
Other designations in this manual might be trademarks whose use by third parties
for their own purposes would infringe the rights of the owner.
Warranty
Siemens warrants this product for a period of five (5) years from the date of
purchase, conditional upon the return to factory for maintenance during the
warranty term. This product contains no user-serviceable parts. Attempted service by
unauthorized personnel shall render all warranties null and void. The warranties set
forth in this article are exclusive and are in lieu of all other warranties, performance
guarantees and conditions whether written or oral, statutory, express or implied
(including all warranties and conditions of merchantability and fitness for a particular
purpose, and all warranties and conditions arising from course of dealing or usage
or trade). Correction of nonconformities in the manner and for the period of time
provided above shall constitute the Seller’s sole liability and the Customer’s exclusive
remedy for defective or nonconforming goods or services whether claims of the
Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com or contact a Siemens customer
service representative.
Training
Siemens offers a wide range of educational services ranging from in-house training
of standard courses on networking, Ethernet switches and routers, to on-site
customized courses tailored to the customer's needs, experience and application.
Siemens' Educational Services team thrives on providing our customers with the
essential practical skills to make sure users have the right knowledge and expertise
to understand the various technologies associated with critical communications
network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain
knowledge in the utility, transportation and industrial markets, allows Siemens to
provide training specific to the customer's application.
For more information about training services and course availability, visit https://
www.siemens.com or contact a Siemens Sales representative.
vi RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Preface
Customer Support
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers.
For technical support or general information, contact Siemens Customer Support
through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a
Support Request (SR) or check on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a
local hotline center, visit https://w3.siemens.com/aspa_app/?lang=en.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android,
Apple iOS or Windows mobile device and be able to:
• Access Siemens' extensive library of support documentation,
including FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support,
Training, etc.
• Ask questions or share knowledge with fellow Siemens customers
and the support community
Contacting Siemens
Address Siemens Canada Ltd.
Digital Industries
Process Automation
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-Mail [email protected]
Web https://www.siemens.com
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 vii

Preface
Contacting Siemens
viii RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Introduction 1
The RUGGEDCOM RSG910C is a 10-port utility-grade, fully managed Ethernet
switch specifically designed to operate reliably in electrically harsh and climatically
demanding environments.
•Removable SFP Transceivers
Ports 7 to 10 can be customized with a wide array of 1000Base-X Small Form-
factor Portable (SFP) transceivers offered by Siemens, making the device flexible
to the needs of the redundant network application.
•Fixed Ethernet Ports
In addition to removable SFP transceivers, the device also features six standard
10/100/1000Base-TX fixed copper Ethernet ports for Local Area Network (LAN)
access.
•Built for Harsh Environments
The device provides a high level of immunity to electromagnetic interference,
heavy electrical surges, extreme temperatures and humidity for reliable
operation in harsh environments.
The device features IP40 degree protection and does not use internal fans for
cooling.
The device supports an extended operating temperature range of -40 to 85 °C
(-40 to 185 °F).
•Compact Design
The small form factor of the RUGGEDCOM RSG910C allows for installation in
space-limited cabinets and on DIN rails.
•Dual Input Power
The device features dual power inputs to support redundant AC or DC power
sources.
•RUGGEDCOM ROS
RUGGEDCOM ROS provides advanced Layer 2 networking functions and cyber
security features.
1.1 Feature Highlights
Ethernet Ports
• 6 x 10/100/1000Base-TX copper Ethernet ports
• 4 x 1000Base-SX/LX SFP transceivers
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 1

Introduction
1.2Description
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• Certified for use in explosive environments in accordance with the ATEX directive
• Hazardous Location Certification: Class I Division 2
• -40 to 85 °C (-40 to 185 °F) ambient operating temperature (no fans)
• Die Cast Aluminum
• Panel mounting option provides secure mechanical reliability
• [Optional] Conformal coated printed circuit boards
Power Supply
• Fully integrated power supply
• Dual LO AC/DC inputs: 88-300 VDC or 85-264 VAC
• Dual low-voltage DC inputs: 12, 24 or 48 VDC
• Terminal blocks for reliable maintenance free connections
• CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1.2 Description
The RUGGEDCOM RSG910C features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
79
10
86
2
3
57
8
1
4
1 POWER LED
2 ALARM LED
3 USB Console Port
4 SFP Tranceiver Ports (Ports 7 to 10)
5 Copper Ethernet Ports (Ports 1 to 6)
6 Failsafe Alarm Relay
2RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Introduction
1.3Required Tools and Materials
7 Power Supply Terminal Blocks
8 Chassis Ground Screw
Figure1.1 RUGGEDCOM RSG910C
POWER LED Illuminates green during boot up and when power is supplied to the
device.
ALARM LED Illuminates red when an alarm condition exists.
Console Port The USB Type-B console port is for interfacing directly with the
device and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page 19)".
Communication Ports Communication ports in general receive and transmit data, as
well as provide access to the RUGGEDCOM ROS Web interface.
For more information about the various ports available, refer to
"Communication Ports (Page 21)".
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
•"Connecting the Failsafe Alarm Relay (Page 12)"
•"Failsafe Alarm Relay Specifications (Page 26)"
Power Supply Terminal Blocks Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to "Connecting Power (Page
14)" and "Power Supply Specifications (Page 25)".
Chassis Ground Terminal Protects the device from power surges and accumulated static
electricity. For information about grounding the device, refer to
"Connecting Power (Page 14)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RSG910C:
Tools/Materials Purpose
AC power cord (16 AWG) For connecting power to the device.
USB Type-B console port cable For connecting to the RUGGEDCOM ROS console
interface.
CAT-5 Ethernet cables For connecting the device to a LAN.
Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
Torx screwdriver For attaching mounting brackets to the device.
4 x M5 or #10-24 screws For mounting the device to a panel.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 3

Introduction
1.4Decommissioning and Disposal
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated "Configuration Manual".
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related
accessories, contact a facility certified to dispose of waste electrical and electronic
equipment. Recycling and disposal must be done in accordance with local
regulations.
4RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Installing the Device 2
The following sections describe how to install the device, including mounting the
device, installing/removing modules, connecting power, and connecting the device
to the network.
DANGER
Electrocution hazard – risk of serious personal injury and/or damage to
equipment
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
WARNING
Radiation hazard – risk of serious personal injury
This product contains a laser system and is classified as a Class I LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
CAUTION
Burn hazard – risk of personal injury
The surface of the device may be hot during operation, or as a result of the ambient
air temperature.
Wear appropriate personal protective equipment and use caution when working
with or around the device.
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could
invalidate specifications, test results, and agency approvals, and void the user's
authority to operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 5

Installing the Device
2.1General Procedure
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
2.1 General Procedure
The general procedure for installing the device is as follows:
Note
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory
requirements.
For more information, refer to "Approvals (Page 31)".
2. Unpack and inspect the device.
For more information, refer to "Unpacking the Device (Page 6)".
3. Mount the device.
For more information, refer to "Mounting the Device (Page 8)".
4. Connect the failsafe alarm relay.
For more information, refer to "Connecting the Failsafe Alarm Relay (Page
12)".
5. Connect power and ground the device.
For more information, refer to "Connecting Power (Page 14)".
6. Configure the device.
For more information, refer to "Configuring the Device (Page 20)".
2.2 Unpacking the Device
When unpacking the device, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
Note
If any item is missing or damaged, contact Siemens for assistance.
6RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Installing the Device
2.3Installing the Device in Hazardous Locations
2.3 Installing the Device in Hazardous Locations
The RUGGEDCOM RSG910C is designed to comply with the safety standards for Class
I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases,
vapors or liquids may be present, as opposed to normal operating environments.
Special Conditions for Safe Use
Installation and use of the device in a hazardous location must meet the following
special conditions for safe use:
• The equipment shall be installed in an additional enclosure that is considered
to be not accessible in normal operation without the use of a tool and provides
a degree of protection of not less than IP54 according to IEC 60079-0 and IEC
60079-7. The installer shall make sure the maximum ambient temperature of the
equipment when installed is not exceeded.
• The equipment shall be used in an area of not more than pollution degree 2, as
defined by IEC 60664-1.
• Transient protection shall be provided that is set at a level not exceeding 140% of
the peak rated voltage value at the supply and failsafe relay contacts terminals to
the equipment.
• The console ports (USB Type-B) shall be used in a non-hazardous area only.
• Pluggable communication modules shall not be connected or disconnected in
hazardous locations.
• The end user must make sure the equipment is appropriately earthed upon
installation.
• The ambient operating temperature must not exceed limits. For more
information, refer to "Operating Environment (Page 27)".
Note
For further details of the device's compliance with Class I, Division 2, Zone 2
standards, refer to "Approvals (Page 31)".
NOTICE
Do not disconnect or open equipment unless power has been switched off or the
area is known to be non-hazardous.
NOTICE
Substitution of the components may impair suitability for Class I, Division 2.
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 7

Installing the Device
2.4Mounting the Device
Sample Hazardous Location Label
The following is an example of the RUGGEDCOM RSG910C hazardous location label:
Figure2.1 Compliance Label (Example)
2.4 Mounting the Device
The RUGGEDCOM RSG910C is designed for maximum mounting and display
flexibility. It can be equipped with adapters that allow it to be attached to a DIN rail
or panel.
Note
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with either DIN rail or panel hardware installed,
refer to "Dimension Drawings (Page 28)".
2.4.1 Mounting the Device on a DIN Rail
The RUGGEDCOM RSG910C can be ordered with a DIN rail adapter preinstalled on the
back of the chassis. Use the adapter to mount the device to a standard 35 mm (1.4
in) by 15 mm (0.6 in) IEC/EN 60715 or TS35 DIN rail.
8RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Installing the Device
2.4.1Mounting the Device on a DIN Rail
NOTICE
DIN rail mounting is not recommended for constant vibration environments.
Mounting the Device
To mount the device to a DIN rail, do the following:
1. Hook the top teeth of the adapter onto the DIN rail.
Note
The adapter features a sliding release with a slot at the bottom for a flathead
screwdriver.
2
2
3
1
1
1 DIN Rail
2 DIN Rail Adapter
Figure2.2 Mounting the Device to a DIN Rail
2. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
3. Push the device against the bottom of the DIN rail, then let go of the sliding
release to latch the device.
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 9

Installing the Device
2.4.2Mounting the Device to a Panel
Removing the Device
To remove the device from a DIN rail, do the following:
1. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
3
2
1
2
1
1 DIN Rail
2 DIN Rail Adapter
Figure2.3 Removing the Device from a DIN Rail
2. Swing the bottom of the device away from the DIN rail.
3. Lift the device off the DIN rail.
2.4.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RSG910C can be equipped with panel
adapters on the top and bottom of the chassis. The adapters allow the device to be
attached to a panel using screws.
10 RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11

Installing the Device
2.4.2Mounting the Device to a Panel
To mount the device to a panel, do the following:
1. Secure the mounting adapters to the top and bottom of the device using the
four M4 screws included with the device.
2
1
2
1
1 Screw (M4)
2 Panel Mount Adapter
Figure2.4 Panel Mount Adapter Assembly
2. Prepare mounting holes in the panel where the device is to be installed.
RUGGEDCOM RSG910C
Installation Manual, 04/2022, C79000-G8976-1405-11 11
