Siemens SIMATIC NET RUGGEDCOM M969F User manual

Edition 11/2022
Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM M969F
https://www.siemens.com/ruggedcom

SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM M969F
Installation Manual
Preface
Introduction 1
Installing the Device 2
Device Management 3
Communication Ports 4
Technical Specifications 5
Accessories 6
Certification 7
11/2022
C79000-G8976-1349-04

Legal Information
Warning Notice System
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown
below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger
will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning
relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the
specific task in accordance with the relevant documentation, in particular its warning notices and safety
instructions. Qualified personnel are those who, based on their training and experience, are capable of
identifying risks and avoiding potential hazards when working with these products/systems.
Proper Use of Siemens Products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant
technical documentation. If products and components from other manufacturers are used, these must be
recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning,
operation and maintenance are required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The information in the relevant
documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens Canada Ltd.. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Digital Industries
Process Automation
300 Applewood Crescent
Concord, Ontario, L4K 4E5
Canada
C79000-G8976-1349-04
© 11/2022 Subject to change
Copyright © Siemens 2022
All rights reserved

Table of Contents
Preface ............................................................................................................................................ v
Related Documents ................................................................................................................. v
SIMATIC NET Glossary .............................................................................................................. v
Accessing Documentation ....................................................................................................... v
Registered Trademarks ............................................................................................................ v
Warranty ................................................................................................................................ vi
Training .................................................................................................................................. vi
Customer Support .................................................................................................................. vi
Contacting Siemens ............................................................................................................... vii
1 Introduction ........................................................................................................................... 1
1.1 Feature Highlights ................................................................................................. 1
1.2 Description ............................................................................................................ 2
1.3 Required Tools and Materials ................................................................................. 5
1.4 Decommissioning and Disposal ............................................................................. 6
1.5 Cabling Recommendations .................................................................................... 6
1.5.1 Supported Fiber Optic Cables ................................................................................ 6
1.6 Tamper-Evident Security Seals ............................................................................... 7
1.7 Ingress Protection ................................................................................................. 7
2 Installing the Device ............................................................................................................. 9
2.1 General Procedure ............................................................................................... 10
2.2 Unpacking the Device ......................................................................................... 10
2.3 Mounting the Device ........................................................................................... 10
2.4 Connecting the Failsafe Alarm Relay .................................................................... 11
2.5 Connecting Power ............................................................................................... 12
2.5.1 Power Supply Connector Pin-Out ......................................................................... 12
2.5.2 Power Supply Wiring ........................................................................................... 13
2.5.3 Disabling Line-to-Ground Transient Protection ..................................................... 16
3 Device Management ........................................................................................................... 17
3.1 Connecting to the Device .................................................................................... 17
3.2 Configuring the Device ........................................................................................ 18
4 Communication Ports .......................................................................................................... 19
4.1 Copper Ethernet Ports ......................................................................................... 20
4.2 Fiber Optic Ethernet Ports ................................................................................... 21
5 Technical Specifications ...................................................................................................... 23
5.1 Power Supply Specifications ................................................................................ 23
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 iii

Table of Contents
5.2 Failsafe Alarm Relay Specifications ...................................................................... 23
5.3 Copper Ethernet Port Specifications ..................................................................... 23
5.4 Fiber Optic Ethernet Port Specifications ............................................................... 24
5.5 Operating Environment ....................................................................................... 24
5.6 Mechanical Specifications .................................................................................... 25
5.7 Dimension Drawings ........................................................................................... 25
6 Accessories .......................................................................................................................... 29
6.1 Power (1/unit) ..................................................................................................... 29
6.2 Console (1/unit) .................................................................................................. 30
6.3 Failsafe (1/unit) ................................................................................................... 31
6.4 Ethernet (8/unit) ................................................................................................. 32
6.5 LC Fiber Optic (2/unit) ......................................................................................... 35
7 Certification ......................................................................................................................... 39
7.1 Approvals ............................................................................................................ 39
7.1.1 UKCA .................................................................................................................. 39
7.1.2 CSA ..................................................................................................................... 39
7.1.3 European Union (EU) .......................................................................................... 40
7.1.4 FCC ..................................................................................................................... 40
7.1.5 FDA/CDRH ........................................................................................................... 41
7.1.6 ISED .................................................................................................................... 41
7.1.7 ISO ...................................................................................................................... 41
7.1.8 RoHS ................................................................................................................... 41
7.1.9 Other Approvals .................................................................................................. 41
7.2 MIL-STD Test Specifications ................................................................................. 42
7.3 EMC and Environmental Type Tests ..................................................................... 43
iv RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Preface
This guide describes the RUGGEDCOM M969F. It describes the major features of the
device, installation, commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible
for the installation, commissioning and maintenance of the device. It is also
recommended for use by network and system planners, system programmers, and
line technicians.
Related Documents
Other documents that may be of interest include:
Document Title Link
RUGGEDCOM ROS Configuration Manual https://support.industry.siemens.com/cs/ww/en/
view/109757146
SIMATIC NET Glossary
The SIMATIC NET Glossary describes special terms that may be used in this
document.
The glossary is available online via Siemens Industry Online Support (SIOS) at:
https://support.industry.siemens.com/cs/ww/en/view/50305045
Accessing Documentation
The latest user documentation for RUGGEDCOM M969F is available online at https://
support.industry.siemens.com. To request or inquire about a user document, contact
Siemens Customer Support.
Registered Trademarks
RUGGEDCOM™ and ROS™ are trademarks of Siemens Canada Ltd..
Other designations in this manual might be trademarks whose use by third parties
for their own purposes would infringe the rights of the owner.
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 v

Preface
Warranty
Warranty
Siemens warrants this product for a period of five (5) years from the date of
purchase, conditional upon the return to factory for maintenance during the
warranty term. This product contains no user-serviceable parts. Attempted service by
unauthorized personnel shall render all warranties null and void. The warranties set
forth in this article are exclusive and are in lieu of all other warranties, performance
guarantees and conditions whether written or oral, statutory, express or implied
(including all warranties and conditions of merchantability and fitness for a particular
purpose, and all warranties and conditions arising from course of dealing or usage
or trade). Correction of nonconformities in the manner and for the period of time
provided above shall constitute the Seller’s sole liability and the Customer’s exclusive
remedy for defective or nonconforming goods or services whether claims of the
Customer are based in contract (including fundamental breach), in tort (including
negligence and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com or contact a Siemens customer
service representative.
Training
Siemens offers a wide range of educational services ranging from in-house training
of standard courses on networking, Ethernet switches and routers, to on-site
customized courses tailored to the customer's needs, experience and application.
Siemens' Educational Services team thrives on providing our customers with the
essential practical skills to make sure users have the right knowledge and expertise
to understand the various technologies associated with critical communications
network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain
knowledge in the utility, transportation and industrial markets, allows Siemens to
provide training specific to the customer's application.
For more information about training services and course availability, visit https://
www.siemens.com or contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers.
For technical support or general information, contact Siemens Customer Support
through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a Support Request
(SR) or check on the status of an existing SR.
vi RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Preface
Contacting Siemens
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a local hotline
center, visit https://w3.siemens.com/aspa_app/?lang=en.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or
Windows mobile device and be able to:
• Access Siemens' extensive library of support documentation, including FAQs and
manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support, Training, etc.
• Ask questions or share knowledge with fellow Siemens customers and the support
community
Contacting Siemens
Address Siemens Canada Ltd.
Digital Industries
Process Automation
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-Mail [email protected]
Web https://www.siemens.com
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 vii

Preface
Contacting Siemens
viii RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Introduction 1
The RUGGEDCOM M969F is a MIL-STD hardened, fully managed Ethernet switch
providing dual fiber optical Fast Ethernet or Gigabit Ethernet ports and eight Fast
Ethernet copper ports in a MIL-STD 901D rated package (for protection against
vibration and shock impacts) and is IP65/IP67 rated for protection against strong jets
of water (IP65) or temporary immersion in water (IP67).
Designed to operate reliably in harsh environments, the RUGGEDCOM M969F
provides a high level of tolerance to vibrations and shock impact; high level of
immunity to electromagnetic interference; an operating temperature range of -40 to
85 °C (40 to 185 °F); and IP65/IP67 rated waterproof packaging. All of which allows
the RUGGEDCOM M969F to be placed in virtually any location.
The embedded RUGGEDCOM Rugged Operating System (ROS) provides advanced
layer 2 and layer 3 networking functions, advanced cyber security features, and a
full array of intelligent functionality for high network availability and manageability.
Coupled with the ruggedized hardware design, the RUGGEDCOM M969F is ideal for
creating mission-critical, real-time, control applications in any harsh environment.
1.1 Feature Highlights
Ethernet Ports
• Two Fiber Optical Fast Ethernet Ports (100Base-X) or Gigabit Ethernet Ports
(1000Base-X)
• Eight Fast Ethernet Ports (10/100Base-TX) with IP65/IP67 Rated M12 D-code
connectors or IP65/IP67 Rated shrouded RJ45 style connectors
• Full compliance with IEEE: 802.3, 802.3u and 802.3z
• Non-blocking, store and forward switching
• Full duplex operation and flow control (IEEE 802.3x)
RuggedRated for Reliability in Harsh Environments
• IP67 rated for protection against immersion in water
• IP65 rated for protection against high pressure jets of water
• -40 to 85 °C (40 to 185 °F) operating temperature (no fans)
• Conformal coated circuit boards (optional)
• Failsafe output relay for critical failure or error alarming
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 1

Introduction
1.2Description
Universal Power Supply Options
• Fully integrated power supply
• Universal high-voltage range: 88-300 VDC or 85-264 VAC.
• Popular low-voltage DC ranges: 12, 24, 48 VDC
• Dual redundant, parallel load-sharing power supplies (option)
• Can be powered from different sources for ultimate redundancy
• Available with M23 style connectors
• CSA/UL 62368-1 safety approved to 85 °C (185 °F)
Simple Plug and Play Operation
• Automatic learning of up to 8192 MAC addresses
• Auto-negotiation on all 10/100Base-TX ports, 100FX on optic fiber ports
• Auto-MDI/MDIX (crossover) on all 10/100Base-TX ports
• LED indicators for link and activity
1.2 Description
The RUGGEDCOM M969F features various ports, controls and indicator LEDs for
connecting, configuring and troubleshooting the device.
2RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Introduction
1.2Description
1
2
4
3
5
7
6
8
10
9
11
1 Copper Ethernet Ports
2 Port Status LED
3 POWER 1 LED
4 POWER 2 LED
5 ALARM LED
6 RS-232 Console Port
7 Failsafe Output Relay
8 M12 Power Supply Port
9 Fiber Optic Ethernet Ports
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 3

Introduction
1.2Description
10 Surge Ground Connection
11 Chassis Ground Connection
Figure1.1 RUGGEDCOM M969F (M12 Connectors Shown)
10
9
11
1
2 4
3
5
7
6
8
1 Copper Ethernet Ports
2 Port Status LED
3 POWER 1 LED
4RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Introduction
1.3Required Tools and Materials
4 POWER 2 LED
5 ALARM LED
6 RS-232 Console Port
7 Failsafe Output Relay
8 M23 Power Supply Port
9 Fiber Optic Ethernet Ports
10 Surge Ground Connection
11 Chassis Ground Connection
Figure1.2 RUGGEDCOM M969F (RJ45 Connectors Shown)
Port Status LED Indicate the status of each port.
State Description
Yellow (Solid) Link established
Yellow (Blinking) Link activity
Off No activity
POWER LED 1/POWER LED 2 Illuminates when power is supplied to the associated internal
power supply.
ALARM LED Indicates when an alarm condition exists.
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
•"Connecting the Failsafe Alarm Relay" (Page 11)
•"Failsafe Alarm Relay Specifications" (Page 23)
Power Supply Terminal The power supply port. For more information, refer to:
•"Connecting Power" (Page 12)
•"Power Supply Specifications" (Page 23)
RS-232 Console Port For interfacing directly with the device and accessing initial
management functions. For information about connecting to
the device via the console port, refer to "Connecting to the
Device" (Page 17).
Copper/Fiber Ethernet Ports For information about available copper and fiber Ethernet ports,
refer to "Communication Ports" (Page 19).
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM M969F:
Tools/Materials Purpose
AC or DC power cord (16 AWG) For connecting power to the device.
CAT-5 Ethernet cables For connecting the device to the network.
Phillips screwdriver For mounting the device to a panel.
4 x #6-32 screws For mounting the device to a panel.
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 5

Introduction
1.4Decommissioning and Disposal
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated "Configuration Manual".
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related
accessories, contact a facility certified to dispose of waste electrical and electronic
equipment. Recycling and disposal must be done in accordance with local
regulations.
1.5 Cabling Recommendations
Siemens recommends using RUGGEDCOM industrial Ethernet shielded cables for all
Ethernet ports.
Siemens does not recommend the use of copper cabling of any length for critical,
real-time substation automation applications. All copper Ethernet ports on
RUGGEDCOM products include transient suppression circuitry to protect against
damage from electrical transients and conform with IEC 61850-3 and IEEE 1613 Class
1 standards. This means that during a transient electrical event, communications
errors or interruptions may occur, but recovery is automatic.
Siemens also does not recommend using copper Ethernet ports to interface with
devices in the field across distances that could produce high levels of ground
potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
1.5.1 Supported Fiber Optic Cables
The following fiber optic cable types are supported under the stated conditions.
Distance (m)Cable Type Wavelength (nm) Modal Bandwidth
(MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
850 200 — 275 33OM1 (62.5/125)
1300 500 2000 — —
850 500 — 550 82OM2 (50/125)
1300 500 2000 — —
OM3 (50/125)a850 1500 — 550 300
6RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Introduction
1.6Tamper-Evident Security Seals
Distance (m)Cable Type Wavelength (nm) Modal Bandwidth
(MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
1300 500 2000 — —
850 3500 — 550 400OM4 (50/125)a
1300 500 2000 — —
aLaser optimized.
1.6 Tamper-Evident Security Seals
In compliance with the security requirements of the Federal Information Processing
Standards (FIPS140-2), FIPS-compliant tamper-evident security seals are applied
to potential access points on this device. Security seals provide evidence of
unauthorized tampering or removal of components.
NOTICE
Worn, damaged or missing seals must be replaced immediately.
Replacement seals are available for purchase from Siemens. For more information,
contact a Siemens Sales representative.
There are three ways to determine if a security seal has been tampered with:
• The seal is cut or torn
• A pattern is left on the device when the top layer of the seal is removed
• Residue left by the seal is visible on the device under ultra-violet light
For information about the placement of security seals, refer to the
"RUGGEDCOM M969F FIPS 140-2 Non-Proprietary Security Policy [https://
support.industry.siemens.com/cs/ww/en/view/109757984]".
1.7 Ingress Protection
IEC International Standard 60529 (Edition 2.1: 2001-02) is a "classification of degrees
of protection provided by enclosures as a system for specifying the enclosures
of electrical equipment on the basis of the degree of protection provided by the
enclosure." These ratings are determined by specific tests.
The RUGGEDCOM M969F Industrial Ethernet Switch is manufactured and tested
to IP67 standards. With an IP67 rating a product will be "dust tight" and remain
completely sealed when immersed in water to a depth of 1 meter for 1 hour (IEC
60529).
These caps completely seal off unused ports on the IP67 Industrial Ethernet Switch. It
has an IP67 rated seal that keeps out all contaminants like dirt, oil, and water.
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 7

Introduction
1.7Ingress Protection
Figure1.3 Caps
8RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Installing the Device 2
This chapter describes how to install the device, including mounting the device,
connecting power, and connecting the device to the network.
DANGER
Electrocution hazard – risk of serious personal injury and/or damage to
equipment
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
WARNING
Radiation hazard – risk of serious personal injury
This product contains a laser system and is classified as a CLASS 1 LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
CAUTION
Burn hazard – risk of personal injury
The surface of the device may be hot during operation, or as a result of the ambient
air temperature.
Wear appropriate personal protective equipment and use caution when working
with or around the device.
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd. could
invalidate specifications, test results, and agency approvals, and void the user's
authority to operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use
of a tool, lock and key, or other means of security, and controlled by the authority
responsible for the location.
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 9

Installing the Device
2.1General Procedure
2.1 General Procedure
The general procedure for installing the device is as follows:
NOTICE
The user is responsible for the operating environment of the device, including
maintaining the integrity of all protective conductor connections and checking
equipment ratings. Make sure to review all operating and installation instructions
before commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory requirements.
For more information, refer to "Approvals" (Page 39).
2. Mount the device.
3. Connect the failsafe alarm relay.
4. Connect power to the device and ground the device to safety Earth.
5. Connect the device to the network.
6. Configure the device.
2.2 Unpacking the Device
When unpacking the device, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
Note
If any item is missing or damaged, contact Siemens for assistance.
2.3 Mounting the Device
The RUGGEDCOM M969F is designed to be mounted on a panel by affixing the top
and bottom flanges of the device to a panel using screws.
NOTICE
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
10 RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04

Installing the Device
2.4Connecting the Failsafe Alarm Relay
Note
For detailed dimensions of the device with panel mount hardware installed, refer to
"Dimension Drawings" (Page 25).
To mount the device to a panel, do the following:
1. Place the device against the panel and align the flanges with the mounting
holes.
1
1 Flange
Figure2.1 Panel Mounting (Typical)
2. Install the supplied screws to secure the flanges to the panel.
2.4 Connecting the Failsafe Alarm Relay
The Failsafe output relay is provided to signal critical error conditions that may occur
on the RUGGEDCOM M969F series switches. The contacts are energized upon power
up of the unit and remain energized until a critical error occurs.
One common application for this output is to signal an alarm if a power failure or
removal of control power occurs.
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04 11
