SIMATIC NET
Industrial Ethernet switches
SCALANCE XC-200
Operating Instructions
04/2018
C79000
-G8976-C442-04
Introduction
1
Safety notices
2
Description of the device
3
Mounting
4
Connecting up
5
Maintenance and
troubleshooting
6
Technical specifications
7
Dimension drawings
8
Certifications and approvals
9

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C442-04
Ⓟ
04/2018 Subject to change
Copyright © Siemens AG 2016 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 3
Table of contents
1 Introduction............................................................................................................................................. 5
2 Safety notices ....................................................................................................................................... 11
2.1 Recommendations on network security..................................................................................12
3 Description of the device....................................................................................................................... 17
3.1 Product overview ....................................................................................................................17
3.1.1 Accessories.............................................................................................................................19
3.1.2 Spare parts .............................................................................................................................21
3.2 Device views ...........................................................................................................................22
3.2.1 Device view of a SCALANCE XC206-2 (ST/BFOC)...............................................................22
3.2.2 Device view of a SCALANCE XC206-2 (SC)..........................................................................23
3.2.3 Device view of a SCALANCE XC206-2SFP ...........................................................................24
3.2.4 Device view of a SCALANCE XC208 .....................................................................................25
3.2.5 Device view of a SCALANCE XC216 .....................................................................................26
3.2.6 Device view of a SCALANCE XC224 .....................................................................................27
3.3 SELECT / SET button .............................................................................................................28
3.4 LED display.............................................................................................................................30
3.4.1 Overview .................................................................................................................................30
3.4.2 "RM" LED ................................................................................................................................31
3.4.3 "SB" LED.................................................................................................................................31
3.4.4 "F" LED ...................................................................................................................................31
3.4.5 LEDs "DM1" and "DM2"..........................................................................................................32
3.4.6 LEDs "L1" and "L2" .................................................................................................................32
3.4.7 Port LEDs................................................................................................................................33
3.5 C-PLUG ..................................................................................................................................34
3.5.1 Function of the C-PLUG..........................................................................................................34
3.5.2 Replacing the C-PLUG ...........................................................................................................36
3.6 Near Field Communication .....................................................................................................37
4 Mounting............................................................................................................................................... 39
4.1 Safety notices for installation ..................................................................................................39
4.2 Types of installation ................................................................................................................41
4.3 Mounting on DIN rails .............................................................................................................42
4.4 Installation on a standard S7-300 rail .....................................................................................43
4.5 Installation on a standard S7-1500 rail ...................................................................................44
4.6 Wall mounting .........................................................................................................................45
4.7 Changing the position of the securing bar ..............................................................................46
4.8 General notes for SFP transceivers........................................................................................47

Table of contents
SCALANCE XC-200
4Operating Instructions, 04/2018, C79000-G8976-C442-04
5 Connecting up....................................................................................................................................... 49
5.1 Safety when connecting up.................................................................................................... 49
5.2 Wiring rules ............................................................................................................................ 51
5.3 Power supply.......................................................................................................................... 51
5.4 Signaling contact.................................................................................................................... 53
5.5 Serial interface ....................................................................................................................... 55
5.6 Functional ground .................................................................................................................. 56
6 Maintenance and troubleshooting.......................................................................................................... 57
6.1 Downloading new firmware using TFTP without WBM and CLI ............................................ 57
6.2 Restoring the factory settings ................................................................................................ 58
7 Technical specifications ........................................................................................................................ 59
7.1 Technical specifications SCALANCE XC206-2 (ST/BFOC) .................................................. 59
7.2 Technical specifications SCALANCE XC206-2 (SC)............................................................. 61
7.3 Technical specifications SCALANCE XC206-2SFP .............................................................. 63
7.4 Technical specifications of SCALANCE XC206-2SFP G ...................................................... 65
7.5 Technical specifications of SCALANCE XC206-2SFP EEC.................................................. 67
7.6 Technical specifications of SCALANCE XC206-2SFP G EEC.............................................. 69
7.7 Technical specifications of the SCALANCE XC208 .............................................................. 71
7.8 Technical specifications of SCALANCE XC208G.................................................................. 73
7.9 Technical specifications of SCALANCE XC208EEC ............................................................. 75
7.10 Technical specifications of SCALANCE XC208G EEC ......................................................... 77
7.11 Technical specifications of the SCALANCE XC216 .............................................................. 79
7.12 Technical specifications of SCALANCE XC216EEC ............................................................. 81
7.13 Technical specifications of the SCALANCE XC224 .............................................................. 83
7.14 Mechanical stability (in operation).......................................................................................... 84
7.15 RF radiation according to NAMUR NE21 .............................................................................. 84
7.16 Cable lengths ......................................................................................................................... 85
7.17 Switching properties............................................................................................................... 85
8 Dimension drawings.............................................................................................................................. 87
8.1 Dimension drawings SCALANCE XC-200............................................................................. 87
9 Certifications and approvals .................................................................................................................. 93
Index ...................................................................................................................................................101

SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 5
Introduction
1
Purpose of the Operating Instructions
These operating instructions support you when installing and connecting up devices of the
SCALANCE XC-200 product group.
The configuration and the integration of the devices in a network are not described in these
operating instructions.
Validity of the Operating Instructions
These operating instructions apply to the following devices:
●SCALANCE XC206-2 (ST/BFOC)
●SCALANCE XC206-2 (SC)
●SCALANCE XC206-2SFP
●SCALANCE XC206-2SFP G
●SCALANCE XC206-2SFP EEC
●SCALANCE XC206-2SFP G EEC
●SCALANCE XC208
●SCALANCE XC208G
●SCALANCE XC208EEC
●SCALANCE XC208G EEC
●SCALANCE XC216
●SCALANCE XC216EEC
●SCALANCE XC224
Unless mentioned otherwise, the descriptions in these operating instructions refer to all
devices of the SCALANCE XC-200 product group named above in the section on validity.

Introduction
SCALANCE XC-200
6Operating Instructions, 04/2018, C79000-G8976-C442-04
Designations used
Table 1- 1 Explanation of designations used
Classification
Description
Terms used
Product line The product line includes all devices and variants of all product
groups.
If information applies to all product groups within the product line, the
term SCALANCE X-200 is used.
SCALANCE X-200
Product group If information applies to all devices and variants of a product group,
the term SCALANCE XC-200 is used.
SCALANCE XC-200
Device
If information relates to a specific device, the device name is used.
e.g. SCALANCE XC206-2SFP
Device group If information applies to a specific group of devices, a corresponding
abbreviation is used.
If information applies to all gigabit variants of SCALANCE XC-200, the
following terms are used.
You can recognize the gigabit variants by the suffix "G" in the type
designation. Devices that only support gigabit via SFPs are not con-
sidered gigabit variants (e.g. SCALANCE XC206-2SFP).
SCALANCE XC-200G,
gigabit variants
If information applies to all SCALANCE XC-200 with coated circuit
boards, the following terms are used.
You can recognize the EEC variants by the suffix "EEC" in the type
designation.
SCALANCE XC-200EEC,
EEC variants
Additional documentation
In addition, note the Operating Instructions of the pluggable transceivers.
You will find the supplementary documentation here:
●On the data medium that ships with some products:
–Product CD / product DVD
–SIMATIC NET Manual Collection
●On the Internet pages of Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/15247)
Documentation on configuration
You will find detailed information on configuring the devices in the following configuration
manuals:
●SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Web Based Management
●SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface

Introduction
SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 7
You will find the configuration manuals here:
●on the data medium that ships with some products:
–Product CD / product DVD
–SIMATIC NET Manual Collection
●On the Internet pages of Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/24185/man).
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will find information on other
SIMATIC NET products that you can operate along with the devices of this product line in an
Industrial Ethernet network.
There, you will find among other things optical performance data of the communications
partner that you require for the installation.
You will find the system manuals here:
●On the data medium that ships with some products:
–Product CD / product DVD
–SIMATIC NET Manual Collection
●On the Internet pages of Siemens Industry Online Support:
–Industrial Ethernet / PROFINET Industrial Ethernet System Manual
(https://support.industry.siemens.com/cs/ww/en/view/27069465)
–Industrial Ethernet / PROFINET Passive Network Components System Manual
(https://support.industry.siemens.com/cs/ww/en/view/84922825)
SIMATIC NET manuals
You will find the SIMATIC NET manuals here:
●On the data medium that ships with some products:
–Product CD / product DVD
–SIMATIC NET Manual Collection
●On the Internet pages of Siemens Industry Online Support
(https://support.industry.siemens.com/cs/ww/en/ps/15247).

Introduction
SCALANCE XC-200
8Operating Instructions, 04/2018, C79000-G8976-C442-04
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary here:
●SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
●On the Internet under the following address:
50305045 (https://support.industry.siemens.com/cs/ww/en/view/50305045)
Catalogs
You will find the article numbers for the Siemens products of relevance here in the following
catalogs:
●SIMATIC NET Industrial Communication / Industrial Identification, catalog IK PI
●SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog
ST 70
●Industry Mall - catalog and ordering system for automation and drive technology, Online
catalog
(https://mall.industry.siemens.com/goos/WelcomePage.aspx?regionUrl=/de&language=
en)
You can request the catalogs and additional information from your Siemens representative.
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to
the specification.
If you use damaged parts, this can lead to the following problems:
•Injury to persons
•Loss of the approvals
•Violation of the EMC regulations
•Damage to the device and other components
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.

Introduction
SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 9
Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certified
disposal company for electronic scrap or your Siemens contact (Product return
(https://support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the different national regulations.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For additional information on industrial security measures that may be
implemented, please visit
http://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
http://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Trademarks
The following and possibly other names not identified by the registered trademark sign ®are
registered trademarks of Siemens AG:
SIMATIC NET, SCALANCE, C-PLUG, OLM

Introduction
SCALANCE XC-200
10 Operating Instructions, 04/2018, C79000-G8976-C442-04
Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
•Touch electronic modules only when you absolutely need to work on them.
•If electronic modules need to be touched, the body of the person involved must first be
electrostatically discharged and grounded.
•Do not bring electronic modules in contact with electrically isolating materials such as
plastic film, isolating table top pads or clothing made of synthetic fibers.
•Place the modules only on conductive surfaces.
•Pack, store and transport electronic modules and components only in conductive
packaging such as metalized plastic or metal containers, conductive foam or household
aluminum foil.

SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 11
Safety notices
2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury, read the manual before use.
NOTICE
Cleaning the housing
Only clean the outer parts of the housing with a dry cloth.
Do not use any liquids or solvents.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Do not open the device when the supply voltage is turned on.
Safety notices when using the device according to Hazardous Locations (HazLoc) and FM.
If you use the device under HazLoc or FM conditions you must also keep to the following
safety notices in addition to the general safety notices for protection against explosion:
This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D or non-
hazardous locations only.
This equipment is suitable for use in Class I, Zone 2, Group IIC or non-hazardous locations
only.

Safety notices
2.1 Recommendations on network security
SCALANCE XC-200
12 Operating Instructions, 04/2018, C79000-G8976-C442-04
2.1
Recommendations on network security
NOTICE
Information security
Connect to the device and change the standard password for the user set in the factory
"admin" and "" before you operate the device.
To prevent unauthorized access, note the following security recommendations.
General
●You should make regular checks to make sure that the device meets these
recommendations and/or other security guidelines.
●Evaluate your plant as a whole in terms of security. Use a cell protection concept with
suitable products (https://www.industry.siemens.com/topics/global/en/industrial-
security/pages/default.aspx).
●When the internal and external network are disconnected, an attacker cannot access
internal data from the outside. Therefore operate the device only within a protected
network area.
●For communication via non-secure networks use additional devices with VPN functionality
to encrypt and authenticate the communication.
●Terminate management connections correctly (WBM. Telnet, SSH etc.).
Physical access
●Restrict physical access to the device to qualified personnel because the plug-in data
medium can contain sensitive data.
●Lock unused physical interfaces on the device. Unused interfaces can be used to gain
access to the plant without permission.

Safety notices
2.1 Recommendations on network security
SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 13
Software (security functions)
●Keep the firmware up to date. Check regularly for security updates for the device. You
can find information on this at the Industrial Security
(https://www.siemens.com/industrialsecurity) website.
●Inform yourself regularly about security recommendations published by Siemens
ProductCERT (https://www.siemens.com/cert/en/cert-security-advisories.htm).
●Only activate protocols that you require to use the device.
●Restrict access to the management of the device with rules in an access control list
(ACL).
●The option of VLAN structuring provides protection against DoS attacks and unauthorized
access. Check whether this is practical or useful in your environment.
●Use a central logging server to log changes and accesses. Operate your logging server
within the protected network area and check the logging information regularly.
Passwords
●Define rules for the assignment of passwords.
●Regularly change your passwords to increase security.
●Use passwords with a high password strength.
●Make sure that all passwords are protected and inaccessible to unauthorized persons.
●Do not use the same password for different users and systems.
Certificates and keys
●On the device there is a preset SSL certificate with key. Replace this certificate with a
self-made certificate with key. We recommend that you use a certificate signed either by
a reliable external or by an internal certification authority.
●Use a certification authority including key revocation and management to sign certificates.
●Make sure that user-defined private keys are protected and inaccessible to unauthorized
persons.
●It is recommended that you use password-protected certificates in the PKCS #12 format
●Verify certificates and fingerprints on the server and client to prevent "man in the middle"
attacks.
●It is recommended that you use certificates with a key length of at least 2048 bits.
●Change certificates and keys immediately, if there is a suspicion of compromise.

Safety notices
2.1 Recommendations on network security
SCALANCE XC-200
14 Operating Instructions, 04/2018, C79000-G8976-C442-04
Secure/non-secure protocols and services
●Avoid or disable non-secure protocols and services, for example HTTP, Telnet and TFTP.
For historical reasons, these protocols are available, however not intended for secure
applications. Use non-secure protocols on the device with caution.
●Check whether use of the following protocols and services is necessary:
–Non authenticated and unencrypted ports
–MRP, HRP
–IGMP snooping
–LLDP
–Syslog
–RADIUS
–DHCP Options 66/67
–TFTP
–GMRP and GVRP
●The following protocols provide secure alternatives:
–HTTP → HTTPS
–Telnet → SSH
–SNMPv1/v2c → SNMPv3
Check whether use of SNMPv1/v2c. is necessary. SNMPv1/v2c is classified as non-
secure. Use the option of preventing write access. The device provides you with
suitable setting options.
If SNMP is enabled, change the community names. If no unrestricted access is
necessary, restrict access with SNMP.
Use the authentication and encryption mechanisms of SNMPv3.
●Use secure protocols when access to the device is not prevented by physical protection
measures.
●If you require non-secure protocols and services, operate the device only within a
protected network area.
●Restrict the services and protocols available to the outside to a minimum.
●For the DCP function, enable the "Read Only" mode after commissioning.
●If you use RADIUS for management access to the device, activate secure protocols and
services.

Safety notices
2.1 Recommendations on network security
SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 15
Interfaces security
●Disable unused interfaces.
●Use IEEE 802.1X for interface authentication.
●Use the function "Locked Ports" to block interfaces for unknown nodes.
●Use the configuration options of the interfaces, e.g. the "Edge Type".
●Configure the receive ports so that they discard all untagged frames ("Tagged Frames
Only").
Available protocols
The following list provides you with an overview of the open protocol ports.
The table includes the following columns:
●
Protocol
●
Port
●
Port status
–Open
The port is always open and cannot be closed.
–Open (when configured)
The port is open if it has been configured.
●
Factory setting
–Open
The factory setting of the port is "Open".
–Closed
The factory setting of the port is "Closed".
●
Authentication
Specifies whether or not the protocol is authenticated.
●
Encryption
Specifies whether or not the transfer is encrypted.

Safety notices
2.1 Recommendations on network security
SCALANCE XC-200
16 Operating Instructions, 04/2018, C79000-G8976-C442-04
Protocol
Port
Port status
Factory setting
Authentication
Encryption
TELNET
TCP/23 Open
(when configured)
Open Yes No
SSH
TCP/22 Open
(when configured)
Open Yes Yes
HTTP
TCP/80 Open
(when configured)
Open Yes No
HTTPS
TCP/443 Open Open Yes Yes
SNMP
UDP/161 Open
(when configured)
Open Yes Yes
(when configured)
PROFINET
UDP/34964,
UDP/49154 -
UDP/49157
Open Open No No
EtherNet/IP
TCP/44818,
UDP/2222,
UDP/44818
Open
(when configured)
Closed
(Open with Ether-
net/IP variants)
No No
DHCP
UDP/67,
UDP/68
Open
(when configured)
Closed No No

SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 17
Description of the device
3
3.1
Product overview
Article numbers
For some devices, there are two versions with different article numbers. The two variants
differ only in their factory settings. All other properties are identical.
Device
Description
Article number
(Ethernet/IP)
Article number
(PROFINET)
SCALANCE XC206-2 (ST/BFOC) 6 x 10/100 Mbps RJ-45 ports,
2 x 100
Mbps ST/BFOC ports,
multimode FO cable
- 6GK5 206-2BB00-2AC2
SCALANCE XC206-2 (SC) 6 x 10/100 Mbps RJ-45 ports,
2 x 100 Mbps SC ports, mul-
timode FO cable
- 6GK5 206-2BD00-2AC2
SCALANCE XC206-2SFP 6 x 10/100 Mbps RJ-45 ports,
2 x pluggable transceiver
slots with 100/1000 Mbps
- 6GK5 206-2BS00-2AC2
SCALANCE XC206-2SFP G 6 x 10/100/1000 Mbps RJ45
ports, 2 x pluggable trans-
ceiver slots with 1000 Mbps
6GK5 206-2GS00-2TC2 6GK5 206-2GS00-2AC2
SCALANCE XC206-2SFP EEC 6 x 10/100 Mbps RJ45 ports,
2 x pluggable transceiver
slots with 100/1000 Mbps,
coated PCB
- 6GK5 206-2BS00-2FC2
SCALANCE XC206-2SFP G EEC 6 x 10/100/1000 Mbps RJ45
ports, 2 x pluggable trans-
ceiver slots with 1000 Mbps,
coated PCB
- 6GK5 206-2GS00-2FC2
SCALANCE XC208
8 x 10/100 Mbps RJ-45 ports
-
6GK5 208-0BA00-2AC2
SCALANCE XC208G 8 x 10/100/1000 Mbps RJ45
ports
6GK5 208-0GA00-2TC2 6GK5 208-0GA00-2AC2
SCALANCE XC208EEC 8 x 10/100 Mbps RJ45 ports,
coated PCB
- 6GK5 208-0BA00-2FC2
SCALANCE XC208G EEC 8 x 10/100/1000 Mbps RJ45
ports, coated PCB
- 6GK5 208-0GA00-2FC2
SCALANCE XC216
16 x 10/100 Mbps RJ-45 ports
-
6GK5 216-0BA00-2AC2
SCALANCE XC216EEC 16 x 10/100 Mbps RJ45 ports,
coated PCB
- 6GK5 216-0BA00-2FC2
SCALANCE XC224
24 x 10/100 Mbps RJ-45 ports
-
6GK5 224-0BA00-2AC2

Description of the device
3.1 Product overview
SCALANCE XC-200
18 Operating Instructions, 04/2018, C79000-G8976-C442-04
Factory settings
EtherNet/IP variants
●Industrial Ethernet protocol: Ethernet/IP
●Base Bridge mode: 802.1Q VLAN Bridge
●Redundancy mechanism: RSTP
●Trust mode: Trust CoS-DSCP
●IGMP Snooping/IGMP Querier: On
●IPv4 Address Collision Detection: Attempt to defend
PROFINET variants
●Industrial Ethernet protocol: PROFINET
●Base Bridge mode: 802.1D transparent bridge
●Redundancy mechanism: Ring redundancy
Device
Factory setting ring ports
•SCALANCE XC206-2 (ST/BFOC)
•SCALANCE XC206-2 (SC)
P0.7 and P0.8
•SCALANCE XC206-2SFP
•SCALANCE XC206-2SFP G
•SCALANCE XC206-2SFP EEC
•SCALANCE XC206-2SFP G EEC
•SCALANCE XC208
•SCALANCE XC208G
•SCALANCE XC208EEC
•SCALANCE XC208G EEC
•SCALANCE XC216
•SCALANCE XC216EEC
•SCALANCE XC224
P0.1 and P0.2
●Trust mode: Trust CoS
●IGMP Snooping/IGMP Querier: Off
●IPv4 Address Collision Detection: Never give up

Description of the device
3.1 Product overview
SCALANCE XC-200
Operating Instructions, 04/2018, C79000-G8976-C442-04 19
Type designation
The type designation of a SCALANCE XC-200 is made up of several parts that have the
following meaning:
Interfaces of devices with optical connectors:
Interface
Property
SFP Pluggable transceiver port with 100/1000 Mbps
G
Gigabit
EEC Enhanced Environment Conditions (coated PCB)
Components of the product
The following components are supplied with a SCALANCE XC-200:
●One IE switch
●A 4-pin terminal block for the power supply
●A 2-pin terminal block for the signaling contact
●One product DVD with documentation and software
The following components are also supplied with a SCALANCE XC206-2SFP:
●2 covers for the pluggable transceiver slots
The following components are also supplied with a SCALANCE XC206-2:
●2 covers for optical ports
3.1.1
Accessories
The following accessories are available for SCALANCE XC-200:

Description of the device
3.1 Product overview
SCALANCE XC-200
20 Operating Instructions, 04/2018, C79000-G8976-C442-04
C-PLUG
Component
Description
Article number
C-PLUG Configuration plug, exchangeable storage medium
for saving configuration data, 32 MB
6GK1 900-0AB00
Configuration plug, exchangeable storage medium
for saving configuration data, 32 MB, coated (con-
formal coating)
6GK1 900-0AQ00
Configuration plug, exchangeable storage medium
for saving configuration data, 256 MB
6GK1 900-0AB10
Cable
Component
Description
Article number
Connecting cable
(RJ-11/RS-232)
Preassembled, serial cable with RJ-11 and RS-232
plug,
Length: 3 m
pack of 1
6GK5 980-3BB00-0AA5
Pluggable transceiver SFP (100 Mbps)
Type
Property
Article number
SFP991-1 1 x 100 Mbps, LC port optical for glass FO cable
(multimode), up to max. 5 km
6GK5 991-1AD00-8AA0
SFP991-1LD 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 26 km
6GK5 991-1AF00-8AA0
SFP991-1LH+ 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 991-1AE00-8AA0
SFP991-1ELH200 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 200 km
6GK5 991-1AE30-8AA0
Note
Pluggable transceiver SFP (100 Mbps) does not work with devices with the "G" suffix in the
type designation.
Pluggable transceiver SFP (1000 Mbps)
Type
Property
Article number
SFP992-1 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 750 m
6GK5 992-1AL00-8AA0
SFP992-1LD 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AM00-8AA0
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
