Sierra Wireless AirCard 59 Series User manual

Quick Start Guide
This document describes how to install and use the Sprint
Mobile Broadband Card or Sprint Mobile Broadband USB
Modem ("device") on a Mac® computer. For all technical
support issues, please contact Apple.
Note: The Mac software (Watcher® Lite) currently does
not support Sprint Location Services.
What you'll need
For this device: You'll need this type of computer:
AirCard 597E
ExpressCard
MacBookTM Pro
AirCard 595
PC Card
PowerBook® G4
AirCard 595U
USB modem
MacBook, MacBook Pro, PowerBook
G4, Power Mac® G5, or desktop iMac
computer.
Your computer must be running Mac OS X version 10.4
or later. To check your version, from the Apple menu ( )
choose About This Mac. If your version is earlier,
then visit www.apple.com/downloads/macosx/apple
for upgrading instructions, or, in FinderTM, choose
Go > Applications > System Preferences.
Double-click the System Preferences icon, then
double-click Software Update. Click Check Now.
If your device has not been activated, you'll also need a
telephone.
Installing Watcher Lite
1. Visit www.sierrawireless.com/mac/sprint to download
the Sierra Wireless Watcher Lite Installer program to
your computer.
The program will automatically mount the disk image
and start the installation.
2. In Finder, choose Go > Applications > Sierra
Wireless Watcher.
Watcher Lite should start:
3. Hold the device by its sides and insert the device into
your computer.
Warning! When inserting or removing your device,
always grip it by its sides. Gripping the device by its
antenna may damage the device.
4. If the New Port Detected window appears, click
Continue.
5. If the Authenticate window appears, enter your Mac
username and password, then click OK.
6. If Watcher Lite displays "Device is Locked", unlock the
device:
a) If the Unlock Device window is not displayed: from
the Extras item on the Sierra Wireless Watcher
menu, choose Unlock Device.
for the AirCard® 59x products
Page 1 of 3

b) In the Unlock Device window, enter the lock code
(PIN), and click OK.
If you can’t recall your lock code, try using the last
four digits of your device's wireless phone number
or try 0000. If none of these work, call Sprint
Customer Service at 1-888-788-4727 (business
use) or 1-888-715-4588 (personal use).
7. If the Activation Assistant window appears, your
device is not activated. To activate your device:
a) Click Continue.
b) Ensure you have the items listed on the screen,
and call the phone number listed.
c) Follow the instructions of the Sprint Customer
Service specialist to activate your device. Write
down this information:
My activation code (MSL): __________________
My phone number: _______________________
My MSID: ______________________________
My account password: ____________________
After Sprint sets up your account on the network,
your device is activated.
d) To complete the activation process, enter the infor-
mation (that you wrote down) into the fields on the
screen.
e) From the Extras item on the Sierra Wireless
Watcher menu, choose Data provisioning.
The device then retrieves the updates to your
account.
f) If the Authenticate window appears, enter your Mac
username and password, then click OK.
g) If the New Port Configuration window appears, click
Continue to automatically configure your computer
to use your device.
You can now connect to the Sprint network (see the
following section).
Connecting to the Sprint network
To connect to the Sprint network:
1. In Watcher Lite, click Connect.
Once you're connected to the network, Watcher Lite
shows the amount of time you've been connected, and
the amount of data received (Rx) and transmitted (Tx).
To end your network connection:
1. In Watcher Lite, click Disconnect.
Icons and text in Watcher Lite
Icon/text Description
CDMA network signal strength, indicated
by the number of bars.
You are not in coverage.
You are in 1X and EVDO Rev. 0 coverage.
You are in 1X and EVDO Rev. A coverage.
You are in 1X coverage.
You are in EVDO Rev. 0 coverage.
You are in EVDO Rev. A coverage.
You are roaming. Roaming charges may
apply.
You are not roaming.
Disconnected Ready to connect to the network. To
connect, in Watcher Lite click Connect.
Connected Connected to the network.
No device
detected
Ensure the device is properly inserted
into your computer.
Not activated To use your device, you must activate
it. From the Extras item on the Sierra
Wireless Watcher menu, choose
Activation.
Device is
Locked
From the Extras item on the Sierra
Wireless Watcher menu, choose Unlock
Device.
Rx Amount of data received from the
network.
Tx Amount of data transmitted to the
network.
Page 2 of 3

Menu options
From the Extras item on the Sierra Wireless Watcher
menu, you can:
• Turn the device off (for example, when you're in an
aircraft). Available only on the AirCard 595 PC Card.
• Activate your device
• Provision your device
• Lock/unlock your device
• View information about the device
• View, configure, and use the data and VPN connections
available on your computer (for example, WWAN)
Removing your device
To remove the device from your Mac:
1. End your network connection, as described on the
previous page.
2. If your device is an AirCard 595 PC Card: from the
Extras item on the Sierra Wireless Watcher menu,
choose Turn Sprint Device Off.
3. If your device is a PC Card or ExpressCard, eject the
device from the slot, and remove the device.
Warning! When inserting or removing your device,
always grip it by its sides. Gripping the device by its
antenna may damage the device.
4. If your device is a USB modem, remove the device.
Warning! When inserting or removing your device,
always grip it by its sides. Gripping the device by its
antenna may damage the device.
Care and maintenance
As with any electronic device, your device must be
handled with care to ensure reliable operation.
Follow these guidelines in using and storing the device:
• Do not apply adhesive labels to the device.
• The device should fit easily into the PC Card,
ExpressCard, or USB slot. Forcing the device into the
slot may damage connector pins.
• Protect the device from liquids, dust, and excessive
heat.
• When the device is not connected to your computer,
store the device in a safe place.
©2007 Sierra Wireless. All rights reserved.
The Sierra Wireless logo, Heart of the Wireless Machine, and AirCard are registered trademarks
of Sierra Wireless. Watcher is a trademark of Sierra Wireless, registered in the European
Community.
Mac is a registered trademark of Apple Inc. The Mac logo, Mac OS, MacBook, Finder, Power
Mac, and PowerBook are trademarks of Apple Inc.
Other logos, company or product names that appear in this document may be trademarks of
their respective owners. All product specifications are subject to change without notice.
2130766 Rev 2.1
Page 3 of 3
