Sigma 3-16K User manual

———————————————
Refrigerated Centrifuge
3-16K
Operating Manual

Operating Manual SIGMA 3-16K, page 3 of 69
03/06
Thank you very much for your confidence in the products of our company.
Our centrifuges are manufactured carefully according to the highest quality standards and we
are sure that your demands will always be fulfilled.
Please read this manual carefully before installation of the centrifuge to ensure a proper and
safe operation.
We are wishing you a successful use of the centrifuge.
SIGMA Laborzentrifugen GmbH
P.O. Box 1713 - 37507 Osterode/Germany
Phone [phone] - Fax [phone]
Internet: www.sigma-zentrifugen.de
eMail: [e-mail]
SIGMA Service-Tel. [phone]

Operating Manual SIGMA 3-16K, page 5 of 69
03/06
Konformitätserklärung
(73/23/EWG; 89/336/EWG; 98/37/EWG)
Statement of Conformity
(73/23/CEE; 89/336/CEE; 98/37/CEE)
Déclaration de conformité
(73/23/CEE; 89/336/CEE; 98/37/CEE)
Die nachfolgend bezeichnete Maschine wurde in Übereinstimmung mit den Richtlinien
73/23/EWG; 89/336/EWG und 98/37/EWG hergestellt und geprüft.
The following machine is manufactured and tested in compliance with directions 73/23/CEE;
89/336/CEE and 98/37/CEE.
La machine désignée ci-dessous est produit et examiné conforme aux directives 73/23/CEE;
89/336/CEE et 98/37/CEE
Bezeichnung der Maschine: Laborzentrifuge
Machine: Laboratory Centrifuge
Désignation de la machine: Centrifugeuse de laboratoire
Maschinentyp : 3 – 16K
Type:
Type de la machine:
Bestell Nr. : 10280, 10281, 10282, 10283
Part No.:
Réf. usine:
Normen: EN 61010-2-020
Standards: EN 61000-3-2 ; EN 61000-3-3
Normes : EN 61326
Sigma Laborzentrifugen
An der Unteren Söse 50
D-37520 Osterode
19.08.2002 Geschäftsführer
Managing Director
Directeur Gérant
...........................................................................
Fabr. Nr. Serial No. Numéro de fabrique
Konformitätserklärung dreisprachig 3-16K 20020819.DOC

Operating Manual SIGMA 3-16K, page 7 of 69
03/06
General Information
1.1 Technical data
1.2 Suitable accessories
1.3 Scope of supply
1.4 Standards and regulations
1.5 Safety instructions
1.6 Symbol table
Description of the Centrifuge
2.1 General outlay
2.2 Construction and constructive safety measures
2.3 Drive
2.4 Operation and display
2.5 Electronics
2.6 Safety devices
2.6.1 Lid lock, cover closing device
2.6.2 Standstill monitoring
2.6.3 System check
2.6.4 Ground wire check
2.6.5 Imbalance Monitoring System
Installation and Start-up
3.1 Unpacking of the centrifuge
3.1.1 Transport safety device
3.2 Installation
3.2.1 Site
3.2.2 Connection
3.2.3 Fuses / emergency circuit breaker on site
3.3 Installation of rotors and accessories
3.3.1 Fastening of angle rotors with hermetically sealed lid
3.4 Initial start-up
3.4.1 Switching on of the centrifuge
3.4.2 Opening of the lid
3.4.3 Installation of a rotor
Operating Elements
4.1 Operating panel
4.1.1 Start-key / Saving a program
4.1.2 Stop-key with preselection of the soft stop and/or soft start function
4.1.3 Lid-key
4.1.4 Knobs

Operating Manual SIGMA 3-16K, page 8 of 69
03/06
4.2 Displays
4.2.1 Speed/RCF (Relative centrifugal force)
4.2.1.1 Speed
4.2.1.2 Relative centrifugual force (RCF)
4.2.2 Time
4.2.3 Standard time mode
4.2.3.1 Continuous operation mode
4.2.3.2 Short-time operation
4.2.3.2.1 Short-run 1
4.2.3.2.2 Short-run 2
4.2.4 Temperature
4.2.5 Preselection of a rotor
Notes for Centrifugation
5.1 Practical notes for centrifugation
5.2 Forbidden centrifuging operations
Care and Maintenance
6.1 Care and cleaning of centrifuge
6.2 Care and cleaning of accessories
6.3 Rotor pins
6.4 Glass breakage
6.5 Care and cleaning of the condenser
6.6 Sterilization and disinfection of rotor chamber and accessories
6.6.1 Autoclaving
6.7 Checks by operator
7. Appendix
7.1 Mathematical relations
7.1.1 Relative Centrifugal Force (RCF)
7.1.2 Density
7.2 Error correction
7.2.1 Centrifuge cannot be started
7.2.2 Centrifuge decelerates during operation
7.2.3 Lid cannot be opened/closed
7.2.4 Emergency lid release
7.2.5 Problems with the centrifuge?
7.3 Error mode
7.3.1 Error codes
7.4 Diagram speed/gravitational field
7.5 Declaration of decontamination/Return declaration
7.6 Leaflet

Operating Manual SIGMA 3-16K, page 9 of 69
03/06
1.1 Technical Data
Manufacturer: S I G M A
Laborzentrifugen GmbH
37520 Osterode
Type: 3-16K
Electr. connection:
Protection class: see nameplate I
Rated power (kW)
Drive:
Refrigerating machine:
Max. current (A):
1,01
0,46
0,55
5,5 (230 V/50 Hz) respectively
11 (120 V/60 Hz)
Power data:
Max. speed (rpm):
Max. capacity (ml):
Max. gravitational field (x g):
Max. kin. energy (Nm):
15 300
1000
23 031
9 970
Further parameters
Time range:
Temperature setting range:
0 - 30 min/continuous run/
short-time operation
-10 to +40 °C
Dimensions:
Depth (mm):
Width (mm):
Height (mm):
Weight (kg):
EMC (acc. to EN 55011):
Noise level (dBA):
600
630
355
78
Class B
< 65
Notes of user:
Serial number:
Supply date:
Inventory number:
Location:
Responsibility:
.....................................................
.....................................................
.....................................................
.....................................................
.....................................................
The figures are valid for an ambient temperature of +23 °C +/- 2 °C and nominal voltage +/- 5
%. The minimum temperatures during run are < +4 °C and depend on type of rotor, speed and
ambient temperature.
(Allowable ambient temperature +10 °C - +35 °C; max . humidity 80 %.)
Subject to technical alterations.

Operating Manual SIGMA 3-16K, page 11 of 69
03/06
1.2 Accessories Suitable for SIGMA 3-16K
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
11180 Swing-out rotor for 4 buckets for the
following accessories: 4 500 3 871/3 894
13194 Bucket for rectangular carriers 18310,
18311 (culture tubes 15 resp. 50 ml), max.
radius 16.8 cm, min. radius 6.6 cm 4 500 3 803
18310 Rectangular carrier for 4 culture tubes
50 ml, e.g. 15151
18311 Rectangular carrier for 10 culture tubes
15 ml, e.g. 15115
13180 Rectangular bucket, aluminium, sealable
with cap 17112, suitable for the system of
rectangular carriers, suitable for 11180,
max. radius 17.1 cm, min. radius 7.6 cm 4 500 3 871
17112 Sealing cap, polysulfone, clear, incl. 2 clips
17118, suitable for 13180
18000 Rectangular carrier, undrilled for special
tubes 85 - 110 mm long, polyallomer
18002 Rectangular carrier for 20 reaction vials
1.5 - 2.2 ml, max. ∅
∅∅
∅11 mm, e.g. 15008,
15040, polypropylene
18003 Upper part for 18002 for 20 reaction vials
1.5 - 2.2 ml, e.g. 15008, 15040, can be used
together with 18002, polypropylene
18005 Rectangular carrier for 20 RIA-tubes 5 ml,
max. ∅
∅∅
∅12.2 x 60 - 75 mm, flat and round
bottom tubes, e.g. 15060, polyallomer
18007 Rectangular carrier for 20 glass tubes 7 ml,
max. ∅
∅∅
∅12.3 x 80 - 105 mm, flat and round
bottom tubes, e.g. 15007, 15027,
polyallomer

Operating Manual SIGMA 3-16K, page 12 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
18009 Rectangular carrier for 20 hemolyse tubes,
max. ∅
∅∅
∅12.8 x 70 - 90 mm, polypropylene
18010 Rectangular carrier for 12 tubes with screw
cap 10 - 12 ml, max. ∅
∅∅
∅16.8/17.5 x 60 -
85 mm, e.g. 15000, 15010, 15039,
polyallomer
18012 Rectangular carrier for 12 Vacutainer-tubes
∅
∅∅
∅13.5/18 x 65 - 90 mm, polypropylene
18015 Rectangular carrier for 12 tubes 10 - 15 ml,
max. ∅
∅∅
∅17 x 90 - 105 mm, e.g. 15015, 15020,
15022, 15023, 15024, polyallomer
18016 Rectangular carrier for 4 culture tubes
15 ml 15115, polypropylene
18017 Rectangular carrier for 10 tubes 15 ml, and
tubes with stopper, max. Ø 17.2/18 x 80 -
111 mm, e.g. Monovettes 9 ml and 10 ml,
polypropylene
18025 Rectangular carrier for 5 glass tubes 25 ml,
max. ∅
∅∅
∅24 x 85 - 105 mm, e.g. 15025, 15026,
polyallomer
18022 Rectangular carrier for 4 sterilin tubes
30 ml, graduated up to 20 ml, with skirt,
incl. cap, max. ∅
∅∅
∅25/31 x 65 - 95 mm,
polypropylene, see www.bibby-sterilin.co.uk ,
no. 03008
18030 Rectangular carrier for 5 tubes with screw
cap 27 - 30 ml, max. ∅
∅∅
∅25.4/27.5 x 80 -
110 mm, e.g. 15029, 15030, 15032,
polypropylene
18050 Rectangular carrier for 2 tubes 50 ml, max.
∅
∅∅
∅35/38 x 85 - 110 mm, e.g. 15049, 15050,
15056, polyallomer

Operating Manual SIGMA 3-16K, page 13 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
18051 Rectangular carrier for 2 tubes with screw
cap 40 - 50 ml, max. ∅
∅∅
∅29/35 x 80 - 110 mm,
e.g. 13055, 15051, 15052, 15054,
polypropylene
18052 Rectangular carrier for 2 culture tubes
50 ml 15151, polypropylene
18053 Rectangular carrier for 2 culture tubes
50 ml with skirt, max. ∅
∅∅
∅29.5/38 x 85 -
118 mm, polypropylene
18085 Rectangular carrier for 1 tube with screw
cap 78 - 85 ml, max. ∅
∅∅
∅38/40 x 85 - 112 mm,
e.g. 13085, 15074, 15075, 15076, 15080,
polyallomer
18100 Rectangular carrier for 1 tube 100 ml, max.
∅
∅∅
∅45.5/48 x 85 - 110 mm, e.g. 15100, 15102,
15103, 15106, polyallomer
18105 Rectangular carrier for 20 RIA-tubes 5 ml,
max. ∅
∅∅
∅12.2 x 60 - 75 mm, flat and round
bottom tubes, e.g. 15060, decantable,
polyallomer
18107 Rectangular carrier for 20 glass tubes 7 ml,
max. ∅
∅∅
∅12.3 x 80 - 105 mm, flat and round
bottom tubes, e.g. 15007, 15027,
decantable, polyallomer
18115 Rectangular carrier for 12 tubes 10 - 15 ml,
max. ∅
∅∅
∅17 x 90 - 105 mm, e.g. 15015, 15020,
15022, 15023, 15024, decantable,
polyallomer
18125 Rectangular carrier for 1 bottle with screw
cap 125 ml, max. ∅
∅∅
∅51 x 90 - 115 mm, e.g.
15125, polypropylene
18200 Rectangular carrier for 1 bottle with screw
cap 200 ml, max. ∅
∅∅
∅57 x 90 - 115 mm, e.g.
15202, 15203, polypropylene

Operating Manual SIGMA 3-16K, page 14 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
11181 Swing-out rotor 48 x 15 ml complete, con-
sisting of rotor 11180, 4 rectangular
buckets 13180, 4 carriers 18015 and 48 PS-
tubes 15020, max. radius 17.1 cm, min.
radius 7.6 cm 4 500 3 871
11182 Swing-out rotor 12 x 50 ml culture tubes
complete, consisting of rotor 11180,
4 round buckets 13190, 4 carriers 17346
and 12 culture-tubes 15151, max. radius
17.2 cm, min. radius 7.5 cm 4 500 3 894
13190 Round bucket, aluminium, sealable with
cap 17190, suitable for the following round
carriers, suitable for 11180, max. radius
17.2 cm, min. radius 7.5 cm 4 500 3 894
17190 Sealing cap, polysulfone, clear, suitable for
13190
17350 Round carrier for 24 reaction vials 0.5 -
0.75 ml, ∅
∅∅
∅8/10 x 28/31 mm, e.g. 15005,
polypropylene
17351 Round carrier for 12 Monovettes, max.
∅
∅∅
∅15.5/18 x 50 - 75 mm, polypropylene
17352 Round carrier for 25 RIA-tubes, max. ∅
∅∅
∅12.5
x 65 - 80 mm, e.g. 15060, polypropylene
17353 Round carrier for 16 reaction vials 1.5 -
2.2 ml, max. ∅
∅∅
∅11 mm, e.g. ml 15008, 15040,
polypropylene
17354 Round carrier for 16 glass tubes 7 ml, max.
∅
∅∅
∅12.5 x 85 - 115 mm, e.g. 15007, 15027,
polypropylene
17355 Round carrier for 12 tubes with screw cap
10 - 12 ml, max. ∅
∅∅
∅16.2/19 x 65 - 90 mm, e.g.
15000, 15010, 15039, polypropylene
17356 Round carrier for 16 Vacutainer/hemolyse
tubes/RIA-tubes 5 - 6 ml, max. ∅
∅∅
∅13.5/17.5 x
70 - 90 mm, e.g. 15060, polypropylene

Operating Manual SIGMA 3-16K, page 15 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17358 Round carrier for 12 tubes 10 - 15 ml, max.
∅
∅∅
∅17.2/19.5 x 90 - 115 mm, e.g. 15015,
15020, 15022, 15023, 15024, and
Monovettes 9 ml and 10 ml, polypropylene
17345 Round carrier for 5 culture tubes 15 ml
15115, polypropylene
17362 Round carrier for 5 sterilin tubes 30 ml,
graduated up to 20 ml, with skirt, incl. cap,
max. ∅
∅∅
∅25/31 x 65 - 95 mm, polypropylene,
see www.bibby-sterilin.co.uk , no. 03008
17370 Round carrier for 5 tubes 25 - 30 ml, max. ∅
∅∅
∅
25.4/29 x 85 - 115 mm, e.g. 15025, 15026,
15029, 15030, 15032, 15033, polypropylene
17375 Round carrier for 3 tubes 50 ml, max.
∅
∅∅
∅35/38 x 90 - 110 mm, e.g. 15049, 15050,
15056, polypropylene
17376 Round carrier for 4 tubes with screw cap
40 - 50 ml, max. ∅
∅∅
∅29/34 x 85 - 110 mm, e.g.
15051, 15052, 15054, polypropylene
17346 Round carrier for 3 culture tubes 50 ml
15151, polypropylene
17385 Round carrier for 1 tube with screw cap
78 - 85 ml, max. ∅
∅∅
∅38/40 x 85 - 115 mm, e.g.
13085, 15074, 15075, 15076, 15080,
polypropylene
17390 Round carrier incl. rubber cushion 16051
for 1 tube 100 ml, max. ∅
∅∅
∅45/50 x 85 -
110 mm, e.g. 15100, 15102, 15103, 15106,
polypropylene
17395 Round carrier for 1 bottle with screw cap
125 ml, max. ∅
∅∅
∅51 x 90 - 115 mm, e.g. 15125,
polypropylene
17400 Round carrier for 1 bottle with screw cap
200 ml, max. ∅
∅∅
∅57 x 90 - 115 mm, e.g. 15202,
15203, polypropylene

Operating Manual SIGMA 3-16K, page 16 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17347 Round carrier for 1 bottle with screw cap
250 ml, max. ∅
∅∅
∅61.5 x 90 - 125 mm, e.g.
15247, 15248, 15249, polypropylene
11240 Swing-out rotor for microtiter-plates, incl. 2
buckets 13145 and plate holder 17977,
radius edge 12.7 cm,
radius max. 10.5 cm
radius min. 4.65 cm,
max. plate height 64 mm
3 850 2 105
1 740
770
11222 Swing-out rotor for microtiter plates, incl. 2
carriers 13222
radius edge 12.3 cm,
radius max. 10.5 cm,
radius min. 6.5 cm
max. plate height 56 mm
3 000 1 238
1 057
654
11133 Swing-out rotor for 4 round buckets, for the
following accessories: 5 500 5 445
13104 Round bucket, aluminium, sealable with
caps 17109, 17111, for the following round
carriers and the 200 ml bottles 15202 and
15203, suitable for 11133, max. radius
16.1 cm, min. radius 5.7 cm: 5 500 5 445
17109 Sealing cap, aluminium, for hermetic
sealing of bucket 13104
17111 Sealing cap, polysulfone, clear, for
hermetic sealing of bucket 13104
13117 Round bucket, aluminium, for the following
round carriers and the 200 ml bottles 15202
and 15203, suitable for 11133, max. radius
16.1 cm, min. radius 5.7 cm 5 500 5 445
17000 Round carrier, two-piece, undrilled, for
tubes 90 - 110 mm long, polyallomer
17006 Round carrier for 12 tubes 5 ml, max. ∅
∅∅
∅
12.5 x 55 - 75 mm, e.g. hemolyse tubes or
RIA-tubes 15060, polyallomer

Operating Manual SIGMA 3-16K, page 17 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17007 Round carrier for 12 glass tubes 7 ml, max.
∅
∅∅
∅12.3 x 90 - 105 mm, e.g. 15007, 15027,
polyallomer
17008 Round carrier for 12 reaction vials 1,5 -
2,2 ml, max. ∅
∅∅
∅11 mm, e.g. 15008, 15040,
polypropylene
17027 Round carrier for 7 Vacutainer-tubes, max.
∅
∅∅
∅13.5/17.5 x 65 - 90 mm, polypropylene
17012 Round carrier for 6 tubes with screw cap
10 - 12 ml, max. ∅
∅∅
∅16.5/17.5 x 58 -90 mm,
e.g. 15000, 15010,15039, polyallomer
17013 Round carrier for 9 hemolyse tubes, max. ∅
∅∅
∅
12,9 x 85 mm, polypropylene
17015 Round carrier for 7 tubes 10 - 15 ml, max. ∅
∅∅
∅
16.8 x 90 - 105 mm, e.g. 15015, 15020,
15022, 15023, 15024, polyallomer
17018 Round carrier for 4 tubes with sealing cap
10 - 15 ml, max. ∅
∅∅
∅17/20 x 90 - 110 mm and
Monovettes, polyallomer
17019 Round carrier for 3 culture tubes 15 ml
15115, polypropylene, suitable for 13104
without sealing cap
17025 Round carrier for 2 glass tubes 25 ml, max.
∅
∅∅
∅24.5 x 90 - 105 mm, e.g. 15025, 15026,
polyallomer
17032 Round carrier for 1 sterilin tube 30 ml,
graduated up to 20 ml, with skirt, incl. cap,
max. ∅
∅∅
∅25/31 x 65 - 95 mm, polypropylene,
see www.bibby-sterilin.co.uk , no. 03008
17030 Round carrier for 2 tubes with screw cap
27 - 30 ml, max. ∅
∅∅
∅25.4/27.5 x 85 - 100 mm,
e.g. 15029, 15030, 15032, polypropylene
17049 Round carrier for 1 culture tube 50 ml
15151, polypropylene

Operating Manual SIGMA 3-16K, page 18 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17050 Round carrier for 1 tube 50 ml, max. ∅
∅∅
∅
35/38 x 85 - 115 mm, e.g. 15049, 15050,
15056, polyallomer
17052 Round carrier for 1 tube with screw cap
40 - 50 ml, max. ∅
∅∅
∅29/35 x 85 - 115 mm, e.g.
13055, 15051, 15052, 15054, polyallomer
17085 Round carrier for 1 tube with screw cap
78 - 85 ml, max. ∅
∅∅
∅38/40 x 85 - 112 mm, e.g.
13085, 15074, 15075, 15076, 15080,
polyallomer
17100 Round carrier for 1 tube 100 ml, max.
∅
∅∅
∅45.5 x 85 - 105 mm, e.g 15100, 15103,
15106, polyallomer
17101 Round carrier for 1 tube 100 ml, max.
∅
∅∅
∅45.5 x 85 - 105 mm, e.g. 15100, 15102,
15103, 15106, polypropylene
17125 Adapter for 1 bottle with screw cap 125 ml,
max. ∅
∅∅
∅51 x 90 - 120 mm, e.g. 15125,
polypropylene
11132 Swing-out rotor 28 x 15 ml complete, con-
sisting of rotor 11133, 4 round buckets
13117, 4 carriers 17015 and 28 PS-tubes
15020, max. radius 14.9 cm, min. radius
5.7 cm 5 500 5 039
11224 Swing-out rotor for cytology, complete,
incl. 4 buckets and carriers for different
object carriers. The buckets with object
carriers could be locked in 90°position,
max. radius 11.3 cm 3 000 1 137
11136 Rotor for reaction vials (max. 60/120 pcs.)
incl. cover, for carriers 14000, 14002, 14020
and 14021, max. radius 7 cm, min. radius 3
cm. Attention: The vessels could be
damaged at speeds exceeding 13 000 rpm 14 500 16 454
14000 Casset for 20 reaction vials 0.25 - 0.4 ml
15014, suitable for 11136, polyallomer

Operating Manual SIGMA 3-16K, page 19 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
14002 Casset for 10 reaction vials 1.5 - 2.2 ml
15008, 15040, suitable for 11136,
polyallomer
14020 Casset for 10 PCR tubes 0.2 - 0.5 ml,
suitable for 11136, polypropylene
14021 Casset for 32 PCR tubes 0.2 ml or 4 strips
with 8 PCR tubes 0.2 ml each, suitable for
11136, polypropylene
11135 Swing-out rotor 24 x 1.5 - 2.2 ml for reaction
vials e.g. 15008, 15040, incl. hermetic
aluminium lid, max. radius 7.4 cm, min.
radius 3.5 cm 14 000 16 215
12154 Angle rotor 24 x 1.5 - 2.2 ml for reaction
vials e.g. 15008, 15040, incl. hermetic
aluminium lid, max. radius 8.2 cm, min.
radius 5 cm, angle 45° 15 300 21 460
12131 Angle rotor 30 x 1.5 - 2.2 ml for reaction
vials e.g. 15008, 15040, incl. hermetic
aluminium lid, max. radius10 cm, min.
radius 6.7 cm, angle 45° 14 000 21 913
12348 Angle rotor 48 x 1.5 - 2.2 ml for reaction
vials e.g. 15008, 15040, incl. hermetic
aluminium lid, max. radius 8.4 cm, min.
radius 5.1 cm 15 300 21 984
12115 Angle rotor for 12 strips with 8 PCR tubes
0.2 ml each, incl. hermetic aluminium lid,
max. radius 9.8 cm, min. radius 7.2 cm,
angle 45° 14 000 15 777/21 475
12111 Angle rotor 10 x 10 - 12 ml for sealed tubes
15000, 15010, 15039, incl. hermetic
aluminium lid, max. radius 7.6 cm, min.
radius 2.8 cm, angle 35° 15 300 19 890
12157 Angle rotor 20 x 10 - 12 ml for sealed tubes
15000, 15010, 15039, incl. hermetic
aluminium lid, max. radius 9.8 cm, min.
radius 5.9 cm, angle 25° 10 000 10 956

Operating Manual SIGMA 3-16K, page 20 of 69
03/06
Part No. Description Max. speed
(rpm)
Max.
gravitational
field (x g)
12112 Angle rotor 12 x 15 ml for Greiner-tubes
with cap 15065 (Greiner no. 187261), max.
Ø 17/22 x 95/100 mm, max. radius 10 cm,
min. radius 4.8 cm 9 000 9 056
19777 Angle rotor for 10 culture tubes 15 ml
15115, incl. hermetic aluminium lid, max.
radius 9.3 cm, min. radius 3.7 cm, angle 25° 9 500 9 384
12158 Angle rotor 6 x 27 - 30 ml for sealed tubes
15029, 15030, 15032, incl. hermetic
aluminium lid, max. radius 7.9 cm, min.
radius 2.3 cm, angle 30° 15 300 20 675
12150 Angle rotor 6 x 40 - 50 ml for sealed tubes
13055 plus 17054, 15051, 15052, 15054, incl.
hermetic aluminium lid, max. radius 8.4 cm,
min. radius 2.1 cm, angle 25° 11 000 11 363
12156 Angle rotor 8 x 50 ml for sealed tubes 13055
plus 17054, 15051, 15052, 15054, incl.
hermetic aluminium lid, max. radius 9.6 cm,
min. radius 3.3 cm, angle 25° 10 000 10 733
19776 Angle rotor for 6 culture tubes 50 ml 15151,
incl. hermetic aluminium lid, max. radius
9.3 cm, min. radius 3.1 cm, angle 25° 9 500 9 384
13060 Adapter for 1 culture tube 15 ml 15115,
suitable for 19776, polypropylene
13079 Bottom adapter for 1 tube 40 - 42 ml 15051,
15052, 15054, suitable for 19776,
polypropylene
12155 Angle rotor 4 x 78 - 85 ml for sealed tubes
13085 plus 17185, 15074, 15075, 15076,
15080, incl. hermetic aluminium lid, max.
radius 9.1 cm, min. radius 1.4 cm, angle 30° 10 000 10 174
12159 Angle rotor 6 x 78 - 85 ml for sealed tubes
13085 plus 17185, 15074, 15075, 15076,
15080, incl. hermetic aluminium lid, max.
radius 9.8 cm, min. radius 2.8 cm, angle 25° 8 000 7 012
