Signature Hardware ENGEL TRIPLE CORNER SHELF User manual

ENGEL TRIPLE CORNER SHELF INSTALLATION
GETTING STARTED
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing this type of product. Signature
Hardware accepts no liability for any damage to the
product, mounting surface, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
Ensure that you have gathered all the required
materials that are needed for the installation.
TOOLS AND MATERIALS:
Phillips
Screwdriver
1Engel Triple Corner Shelf Installation Instructions
Pencil
Tape Measure Level
Flathead
Screwdriver
Drill
SKU(s): 916691

ENGEL TRIPLE CORNER SHELF INSTALLATION
INSTALLATION
2Engel Triple Corner Shelf Installation Instructions
1. Before you begin, attach the front rails to each of
the glass shelves as shown.
corner
2. Hold the top shelf at the desired installation
location. Using a level and a pencil, draw a straight light
line on both walls along both edges of the shelf.
3. If installing the 11” version, measure 4” from the
corner along each line marked in step 2. For the larger
14“ version, measure 5”. Mark these locations on each
line using a pencil.
corner
4-5” 4-5”
4. From the center of each of the marks made in step
3, use a level to mark a straight line exactly 9¼” down
the wall. From the corner, use a level to mark a
straight line 4” or 5” from the corner, as you did in step
3. Mark the location where each of these two lines
cross, on each wall, as shown below.
corner
4-5” 4-5”
9¼”9¼”

ENGEL TRIPLE CORNER SHELF INSTALLATION
3Engel Triple Corner Shelf Installation Instructions
7. Loosely attach the mounting brackets to the
installed anchors using the provided screws. Do not
yet fully tighten the screws.
6. Drill a pilot hole into each of the six marked mount-
ing hole locations. Insert the provided anchors into
each hole. Once anchors are installed, erase all pencil
makings from the wall. Important: If drilling through tile,
ensure that you use a masonry drill bit and drill slowly to avoid
cracking.
5. Repeat step 4 for marking the locations of the shelf
brackets for the lower shelf. Begin from the holes
marked for middle shelf.
9¼”9¼”
Note: This shelving unit contains three mounting bracket
variations: upper, middle, and lower. Ensure that all of the
plastic set screws on each bracket are facing down, and that
each of the seats for the vertical brackets are facing one
another. If arranged correctly, the two upper brackets should
have a plain top. See below.
upper
middle
lower
bracket top bracket bottom
4-5” 4-5”

ENGEL TRIPLE CORNER SHELF INSTALLATION
9. Slide the glass shelves into the installed shelf
brackets. To secure the shelves, tighten each of the
plastic set screws on the bottom of each bracket.
8. Insert the vertical support brackets in between the
upper, middle, and lower shelf brackets. Ensure that
each of the upper and lower legs fit into the seats on
each bracket. Rearrange the brackets if needed.
Once in position, finish tightening the shelf bracket
screws.
x6
4Engel Triple Corner Shelf Installation Instructions
