Signature Hardware Maleko User manual

MALEKO SINGLE HOLE FAUCET INSTALLATION
GETTING STARTED
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, sink, counter top, or for personal injury
during installation.
Observe all local plumbing and building codes.
Unpack and inspect the faucet for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
Ensure that you have gathered all the required
materials that are needed for the installation.
For these instructions, it is assumed that the old
faucet has been completely removed and any
necessary repairs or modifications to the water
supply have been completed.
TOOLS AND MATERIALS:
Plumbers
Tape
Thread
Sealant
Adjustable
Wrench
Small
Bucket
Basin
Wrench
1Maleko Single Hole Faucet Installation Instructions
Phillips
Screwdriver
SKU(s): 933811, 933812

MALEKO SINGLE HOLE FAUCET INSTALLATION
INSTALLATION
3. Insert the faucet into its prepared mounting hole.
1. Ensure that the water supply below your sink is
completely shut off by turning the shutoff valves all the
way to the right.
Tip: Place a small bucket below your workspace to
catch any water that may drip during the installation
process.
2. Remove the lock nuts from the threaded mounting
posts, then attach the mounting posts to the faucet
body. Tighten firmly using a Phillip’s screwdriver.
2Maleko Single Hole Faucet Installation Instructions
4. From beneath the sink, slide the rubber washer
followed by the metal washer onto the faucet body.
Thread the locknuts back onto the mounting posts until
hand tight. Finish tightening using an adjustable wrench.
OFF

5. Apply plumber’s tape or thread sealant to the
threading on each of the faucet’s water lines, then
connect them to the main water supply. Use an
adjustable wrench to tighten, but be careful not to
overtighten. Ensure that you are connecting the hot
and cold lines appropriately.
MALEKO SINGLE HOLE FAUCET INSTALLATION
6. Proceed to the drain installation. Once complete,
remove the aerator from the spout and turn the faucet
on for approximately 60 seconds to remove any dust or
loose sediment from the water lines. Ensure that there
are no leaks, and that both hot and cold water are
running properly. Turn the water off and reattach the
aerator.
5. Once installation is complete, turn the main water
supply back on from underneath your sink. Check for
any leaks underneath.
3Maleko Single Hole Faucet Installation Instructions
ON

4Maleko Single Hole Faucet Installation Instructions
MALEKO SINGLE HOLE FAUCET INSTALLATION
INSTALLATION
1. Dissasemble the drain assembly and lay the parts
aside, in the same order they were removed. See the
illustration below as a reference if needed.
2. Apply plumber’s tape to the threading on the
tailpiece, then reattach the tail piece to the pop-up
drain flange.
3. Slide the flat rubber gasket up the tailpiece until it
meets the lip of the pop-up drain flange.
Pop-Up Drain Flange
Tailpiece
Flat Rubber Gasket
Tapered Rubber Gasket
Lock Nut
Plastic Friction Washer

5Maleko Single Hole Faucet Installation Instructions
MALEKO SINGLE HOLE FAUCET INSTALLATION
4. Insert the drain flange and tailpiece through the top
of your sink’s drain hole.
6. Thread the lock nut onto the drain flange. Hand
tighten until secure, then finish tightening with a basin
wrench once the drain is properly aligned.
Important: Be careful not to overtighten, which could
crack a porcelain sink or stone countertop.
5. From under your counter, slide the tapered rubber
gasket followed by the plastic friction washer onto the
tailpiece until they meet your sink or countertop. Be
sure that the tapered side of the rubber washer is
facing up.
COUNTERTOP COUNTERTOP
COUNTERTOP COUNTERTOP
COUNTERTOP COUNTERTOP
