SIIG SC-SA0412-S1 User manual

1
Introducing the Cool SATA to USB 2.0
The Cool Dual SATA to USB 2.0 Docking is designed to
support USB equipped computers. This adapter
provides large capacity mobile storage using 3.5" or 2.5"
SATA hard disk drives through high-speed, hot-
swapping USB 2.0 interface.
FeaturesandBenefits
• Two hard drive docking bays
• Supports Hi-Speed USB 2.0 port
• Supports SATA I/II (SATA 150/300)
• Supports 2.5" and 3.5" hard drive
• Plug and Play, no additional drivers needed
• Supports USB hot-swap and hot-plug
SystemRequirements
PC:
• Pentium®orequivalentcomputer with anavailable
USB port (USB 2.0 recommended)
• Windows®2000 / XP (32-/64-bit) / Server 2003 &
2008 (32-/64-bit) / Vista (32-/64-bit)
Mac®:
• An available USB port (USB 2.0 recommended)
• Mac OS®X v10.4.8 or higher
Cool Dual SATA to
USB 2.0 Docking
Quick Installation Guide
04-0523A

2
PackageContents
•Cool Dual SATA to USB 2.0 Docking
• Switching power adapter
• USB 2.0 cable (type A to type B)
• Quick Installation Guide
Layout
Note: You cannot use one hard drive in both
platforms, Windows and Mac. It is not supported
Figure 1. Front Layout
Figure 2: Back Layout
SATA Drive Slot
LED (Two LED's stay on
while the unit is on)
On/Off Switch
HDD LED (One LED per HDD;
LED flashes while transfering data)
USB Connector
Power Adapter Jack

3
Hardware Installation
1. Make sure the SATA connectors are in alignment.
Gently insert the SATA hard drive into the SATA
drive slot.
2. Plug the included switching power adapter into
the Cool Dual SATA to USB 2.0 Docking power
adapterjack,thenplugtheswitchingpoweradapter
into a reliable power source.
3. Use the USB 2.0 cable to plug the Cool Dual SATA
to USB 2.0 Docking into the computer.
4. Switch on the Cool Dual SATA to USB 2.0 Docking,
make sure that the 3 blue Power LEDs are lit.
Note: Do not insert or remove a hard drive when
the unit is powered on.
Go to Driver Installation below to complete the
installation.
Driver Installation
Windowsand Macoperatingsystems willautomatically
detect and install drivers for the Cool Dual SATA to USB
2.0 Docking. No additional driver installation is needed.
Note: In order to get high speed USB 2.0
performance, make sure your USB 2.0 controller
has the correct drivers installed.

4
Using the Cool Dual SATA to USB 2.0
Windows
One drive icon for each inserted SATA hard drive will
appear in My Computer when the converter is plugged
into a USB port. The drive(s) act just like a conventional
hard drive in your system.
Note: Be careful not to touch the hard drive while
in use. It will be warm.
DisconnectingFromTheComputer
Important: Do not insert or remove a hard drive while
the Cool Dual SATA to USB 2.0 Docking is powered on.
BeforeunpluggingtheCoolDualSATAto USB 2.0Docking
from the computer, it must first be stopped, by using
Windows' Safely Remove Hardware utility. Follow the
steps below for your version of Windows. The same
rule applies when turning off the Cool Dual SATA to USB
2.0Docking. Notfollowingthe instructions mayresultindata
corruption or damage to the hard drive.
Windows 2000
1. Verify that the HDD LED(s) are OFF before
proceeding.
2. Double click the Unplug or Eject Hardware icon
located in the system tray.
3. Highlight USB Mass Storage Device, click Stop.
4. Click OK, click OK again, then Close.
5. You can now unplug or turn off the Cool Dual SATA
to USB 2.0 Docking.

5
Windows XP/Server 2003 & 2008
1. Verify that the HDD LED(s) are OFF before
proceeding.
2. Double click the Safely Remove Hardware icon
located in the system tray.
3. Highlight USB Mass Storage Device, click Stop,
OK then Close.
4. You can now unplug or turn off the Cool Dual SATA
to USB 2.0 Docking.
Windows Vista™
1. Verify that the HDD LED(s) are OFF before
proceeding.
2. Double click the Unplug or Eject Hardware icon
located in the system tray.
3. Highlight USB Mass Storage Device, click Stop.
4. Click OK, click OK again, then Close.
5. You can now unplug or turn off the Cool Dual SATA
to USB 2.0 Docking.
Mac
One drive icon for each inserted SATA hard drive will
appear on the desktop when the Cool Dual SATA to USB
2.0 Docking is plugged into a USB port. The drive(s) act
just like a conventional hard drive in your system.
DisconnectingFromTheComputer
BeforeunpluggingtheCoolDualSATAto USB 2.0Docking
from the computer, drag the drive icon(s) into the
Trashcan and wait for the confirmation box. The same
rule applies when turning off the Cool Dual SATA to USB
2.0 Docking. Not following these instructions may result in
data corruption or damage to the hard drive.

6
Blank Page

7
