SIIG CE-VG0011-S1 User manual

1
IntroducingtheVGA/YPbPr&AudiotoHDMI
The VGA/YPbPr & Audio to HDMI Converter offers an easy
and inexpensive method of converting analog PC video
(VGA) or component video (YPbPr) with either digital
audio (S/PDIF) or analog stereo audio to digital HDMI.
FeaturesandBenefits
• HDMI 1.2a compliant
• Supports PC video display resolutions up to UXGA
(1600x1200) or WUXGA (1920x1200)
• Supports HD (1080i/720p) component video
• Coaxial S/PDIF and analog stereo audio inputs
• Front panel LED indicators
TechnicalSpecifications
• Bandwidth: 1.65 Gbps
• Input video signal: 1.2 volts (peak to peak)
• Output DDC signal: 5V (peak to peak)
• HDMI connector: 19-pin female
• DSUB connector: 15-pin female
• RCA connector: coaxial S/PDIF (PCM 48KHz)
• Phone jack (3.5mm): analog stereo audio
• Power supply: 5V, 4A DC
04-0510A
VGA/YPbPr & Audio to
HDMIConverter
QuickInstallationGuide

2
Figure 1: Front Panel
FrontPanel
• S/PDIFIn:RCAconnector,supports2-channelstereo
@ 48KHz audio sampling rate
• Audio In: 3.5mm stereo jack, supports 2-channel
audio
• VGA/YPbPr In: Connects to your VGA or YPbPr
video source
• YPbPr/VGA Switch Button: Selects your video
source type: Out for YPbPr; Push in for VGA
PackageContents
•VGA/YPbPr & Audio to HDMI Converter
• 4 rubber pads
• VGA to YPbPr adapter
• Power adapter (5V, 4A)
• Quick Installation Guide
Layout
S/PDIF In
Audio In
VGA/YPbPr In YPbPr/VGA
Switch Button

3
Figure 2: Rear Panel
RearPanel
•Mode (DIP) Switch: See table below for the different
settings
•HDMI Detect: Shows proper HDMI detection when
lit
•HDMI Output: Connects to HDMI video display
•Power Indicator: Shows that the unit is powered on
•Power Jack (5V DC): Connects to the power adapter
Mode(DIP)Switch
12 Mode
OFF OFF Analog Audio Input
OFF ON S/PDIF Audio Input
ON ON Write back default factory
EDID into Flash Memory
ON ON Learn Monitor's EDID and
Save into Flash Memory
Mode Switch
HDMI
Detect HDMI Out
Power LED Power Jack

4
Hardware Installation
Please read and follow the safety guidelines to protect
yourself from possible injury and to minimize the risk of
damage to your equipment.
• Provide proper ventilation and air circulation, do
not use near water
• Keep objects that might damage the device a safe
distance away and place the unit on a stable surface.
• Use only the power adapter and accessories that
came with the unit.
• Do not use liquid or aerosol cleaners to clean the
unit. Always unplug the power to the unit before
cleaning.
1. Connect your VGA or YPbPr source to the VGA/
YPbPr In connector. Using the YPbPr /VGA Switch
Button, select your video source. See Front Panel
on page 2 for more information.
2. Connect your S/PDIF or stereo audio source to
either the S/PDIF In (RCA) or Audio In (3.5mm).
3. Connect your HDMI enabled video display to the
HDMI Out connector.
4. Plug the power adapter into the Power Jack, then
plug the power adapter into a reliable power source.
Figure 3: Hardware Application

5
Notes
1. OnlyHDMI enabledTVswith Underscan/Overscan
support can accurately display full active video. If
your TV does not support Underscan/Overscan,
the top, bottom, left and right border of the active
video may be screened off and the S/PDIF audio
may not sound right.
Note: Underscan mode displays full video frame,
with reveals content on the frame edge that is
recorded. In Overscan mode, the field monitor
zooms in to the area that would be visible on most
TVs. Set the field monitor to underscan if your
video will be viewed on a computer monitor or
shown with a projector. Set the field monitor to
overscan mode to see how the video will look on a
TV.
2. Analog stereo audio only supports 2-channel audio.
The VGA/YPbPr & Audio to HDMI Converter does
not support 8-channel analog audio applications.
3. S/PDIF audio input supports 2-channel audio input
at 48KHz audio sampling rate. Adjust your digital
audio input to 48KHz in order to get the correct
audio signal.
4. YourHDMI enableddisplay maynot workproperly
if the EDID of the VGA/YPbPr & Audio to HDMI
Converter is not compatible with it. In this case, use
the Mode Switch to write the EDID of your HDMI
display into the converter's flash memory. See
Mode (DIP) Switch on page 3 for more information.

6
Blank Page

7
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support has answers! Simplyvisit our
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscould bejust afew clicks away. You can also submit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a 2-yearmanufacturer warranty with this product. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchase has passed the store's returnpolicy period,please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.
