Silicon Solar EDUSOL-AVD-BEGINNERLEVEL User manual

Silicon Solar Online Inc | www.SiliconSolar.com | P: 1.800.786.0329








Silicon Solar Online Inc | www.SiliconSolar.com | P: 1.800.786.0329
Material Included In This Kit:
● 1 Low voltage electric motor
● 1 Plastic propeller
● 1 Rechargeable battery
● 1 Battery Holder
● 1 Diode
● 1 Test leads
● 1 switch
● 1.5v @ 250mA Solar Panel
● 2 Spare wires*
Tools You Will Need For Assembly:
● Soldering Iron
● Solder
● Flux (or flux core solder)

Silicon Solar Online Inc | www.SiliconSolar.com | P: 1.800.786.0329

1. Take all the components out of the bag and compare to component list
2. Insert rechargeable battery into battery holder.
3. Insert Propeller on to motor.
4. Connect one end of the test lead to the negative terminal on the battery
5. Connect the remaining end of the test lead to the negative terminal of the motor.
6. Solder the positive wire from the battery holder to the grey/white banded side of the diode
7. Solder the remaining end of the diode to the positive soldering pad on the backside of the solar panel
8. Solder the negative wire from the battery holder to the negative soldering pad on the backside of the solar
panel
9. Solder one wire from your switch to the positive terminal of the battery.
10. Solder the remaining wire of the switch to the positive terminal wire coming off of the motor.
11. Place the solar panel out in the sun to recharge the battery and use your switch to turn the motor and
propeller on and off.


Tools You Will Need For Assembly:

2917 State Highway 7, Bainbridge, NY 13733
