Silvercrest KH 2355 User manual

KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID No.: KH2355-08/08-V2
B+C
BLUETOOTH HANDS-FREE SET KH2355
Operating instructions
BLUETOOTH HÅNDFRI TIL BILEN
Betjeningsvejledning
EÃKATAÓTAÓH ANOIKTHÓ AKPOAÓHÓ
BLUETOOTH KH2355
Ïäçãßåò ÷ñÞóçò
CV_KH2355_JO41165_LB3B_C 10.09.2008 14:18 Uhr Seite 1

1
3
4
5
62
CV_KH2355_JO41165_LB3B_C 10.09.2008 14:18 Uhr Seite 4

CONTENT PAGE
Safety instructions 3
Correct Usage 5
Introduction 6
Items supplied 6
Technical data 7
Operating Elements 7
Installing the hands-free appliance in a vehicle 7
Switching the hands-free appliance on and off 8
Coupling the hands-free appliance with a mobile
telephone 8
Coupling the hands-free appliance with several
mobile telephones 10
Separating the connection 10
Re-establishing the connection 11
1
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 1

Using the hands-free appliance 11
Troubleshooting 13
Cleaning and Care 14
Disposal 15
Warranty & Service 16
Importer 17
Declaration of conformity 18
2
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 2

BLUETOOTH HANDS-FREE SET KH 2355
Safety instructions
Please read these operating instructions carefully and fold out the page with
illustrations when you do so. Closely heed this information when operating the
appliance. Should you have any further questions regarding use, please contact
the service department responsible for your country . Keep these operating in-
structions in a safe place and pass them on to whomsover might later acquire the
appliance.
Traffic safety has priority!
• Comply with all local laws. When driving, your hands must ALWAYS be free to
operate the vehicle safely. Traffic safety must ALWAYS take priority whilst
driving.
• Only manipulate the hands-free appliance on those occasions in which the
traffic situation permits it and in which you will not endanger, injure, obstruct or
cause annoyance to other road users.
• Do not permit your concentration on the road traffic to be compromised by the
manipulation and displays of the handsfree appliance!
• Become familiar with the operation of it before driving off and practice the
safe operation of the facility!
• Install the hands-free appliance in the vehicle such that your view is not
obstructed and that the appliance is not located in an impact zone in the
passenger compartment or in the inflation area of airbags.
3
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 3

General safety instructions
• Do not attempt to open or repair the appliance. Should you do so, appliance
safety can no longer be assured and the warranty becomes void.
• Arrange for defective appliances to be repaired only by Customer Services or
by authorised specialists.
• Never subject the appliance to moisture, extreme temperatures or extreme
vibrations.
• Do not allow children and people subject to supervision play with the
appliance, they could injure themselves or cause damage to the appliance.
Connection to other mobile telephones
• If you wish to connect the appliance to another appliance, read the operating
instructions to obtain detailed safety instructions. Do not connect it to a product
that is not compatible.
High frequency signals in vehicles
HF signals can, under circumstances, negatively influence the function of not
properly installed or not sufficiently shielded electronic systems in vehicles, e.g.
electronic ABS, electronic tempo controllers and airbag systems. For further
information about your vehicle or its possible ancillaries make contact with the
respective manufacturer or their representative.
4
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 4

Correct Usage
The Bluetooth® Vehicle Hands-Free Phone System KH 2355 is de-signed for use
in vehicles with a voltage of 12-24 V. The handsfree phone system uses both
Bluetooth radio technology as well as a digital signal processor (DSP) to carry
out telephone functions.
This device may be used ONLY for private domestic purposes, not for industrial
or commercial applications. The product at hand is, by default, NOT intended
for use in medicinal, lifesaving or life support applications. All of the additional
connecting cables and external devices used MUST match the safety-related,
electromagnetic compatability and shielding quality standards of the device at
hand. With regard to CE Conformity, this device fulfills all of the relevant norms
and guidelines. In the event of modifications being made to the device without
agreement from the manufacturer, compliance with these norms and guidelines
can no longer be assured. Use only the accessories specified by the manufactu-
rer. If you are using the device outside the territory of the Federal Republic of
Germany you must pay heed to the national regulations resp. the laws of the
country in which it is being used.
5
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 5

Introduction
Bluetooth is a wireless communication system with a short range. It makes
possible wireless connections between Bluetooth appliances, such as for exam-
ple mobile telephones, PDA and PCs. Bluetooth relates itself to a worldwide
standard for operation in the internationally recognised ISM Frequency Range
(Industrial, Scientific and Medical). Within the ISM Frequency Range
(2,402 - 2,480 GHz), a data transfer range of ca. 10 Meters (Klasse II) is
achieved. The disturbance susceptibility through other users of the ISM
Frequency Range, such as for example microwaves, WLAN (802.116) or
garage door openers, is minimised by so-called „Frequency-Hopping“. With
Frequency-Hopping, a change of frequency levels takes place at up to 1600
times per second, thereby Bluetooth is also reckoned to be relatively tap-proof.
The HSP (Headset-Profil) makes possible standard functions such as voice
transference, as well as the acceptance and rejection of calls.
The HFP (Handsfree-Profil) makes possible the hands-free call functions of a
mobile telephone, for example with the help of voice commands.
Items supplied
Bluetooth®Hands-Free Set KH 2355
Operating instructions
6
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 6

Technical data
Operating voltage : 12-24 Volt DC / 500mA
Bluetooth Specification: Version 1.2, Class II, 10 Meter
Supported Bluetooth Profiles: HSP and HFP
Operating Elements
1Vehicle connector plug
2Loudspeaker
3Volume control
4Multi-function button
5Microphone
6LED status display
Installing the hands-free appliance in a vehicle
So that the hands-free appliance can function correctly, it is con-nected to the
vehicle cigar lighter socket and provided with electricity from there.
• Ensure that the hands-free appliance engages completely and that the
operation of the vehicle is not negatively influenced. The LED status display
6blinks every 3 seconds. The appliance is in standby mode.
Note:
It is possible that the cigar lighter only functions when the vehicle ignition is
switched on. In cases of doubt, consult the operating instructions for the
particular vehicle.
7
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 7

CAUTION:
For vehicles in which the cigar lighter, resp. the vehicle circuit plug, also functions
when the ignition is switched off:
• Use the hands-free appliance only when the motor is running. Otherwise, the
vehicle batteries could become discharged over an extended period of time.
Switching the hands-free appliance on and off
Switching on: The appliance is switched off.
• Press and hold the multi-function button 4for 3 seconds, until a short and
high signal tone is heard. The LED status display 6blinks every 3 seconds.
Switching off: The appliance is in standby mode.
• Press and hold the multi-function button 4for 3 seconds, until a long and
deep signal tone is heard. The LED status display 6extinguishes.
Coupling the hands-free appliance with a mobile
telephone
The hands-free appliance has been especially developed for mobile telephones
that support the Bluetooth Profile „Handsfree (HFP) and Headset (HSP)“. Further
information about Bluetooth radio technology is to be found in the operating
instructions for your mobile telephone.
Before you can use the hands-free appliance, you must connect it with a
compatible mobile telephone (pairing).
• Check to make sure the mobile telephone is switched on.
8
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 8

• Programme the mobile telephone so that it searches for Bluetooth appliances.
A detailed description of how to do this is to be found in the operating
instructions for your mobile telephone.
• Ensure that the hands-free appliance is correctly set up and switched off.
• To switch the device off, press and hold the multi-function button 4for about
3 seconds. A long, low signal tone will be heard and the LED condition
indicator 6extinguishes.
• Position the hands-free appliance and the mobile telephone so that they are
not more than 1 metre away from each other.
• Press and hold the multi-function button 4for ca. 6 seconds, until after 3
seconds a short signal tone and, after a further 3 seconds, a long and deep
signal tone is heard.
The LED status display 6glows constantly. The hands-free appliance is now
in the coupling mode.
• Select the hands-free provision „Car Kit“ from the list of available appliances
for the mobile telephone.
• Enter in the pre-programmed pass code „9999“ and then confirm it, which
couples the appliances with each other. This mobile telephone will now
become the standard telephone for the hands-free appliance. You will hear
a longer signal tone and the LED status display 6blinks every 3 seconds.
• You can now use the hands-free appliance.
Note:
If the coupling is not completed within 2 minutes, the hands-free appliance swit-
ches itself off. The LED status display 6extinguishes and you will hear a long
and deep signal tone.
9
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 9

Coupling the hands-free appliance with several mobile
telephones
You can couple the hands-free appliance with up to eight mobile telephones.
However, it can only be connected with one mobiletelephone. If a further mobile
telephone is coupled with the hands-free appliance, the coupling information of
the first coupled mobile telephone is erased.
When the hands-free appliance is switched on, within a few seconds it tries to
create a connection with the standard or the last used mobile telephone. Should
no connection be possible, the hands-free appliance remains nonetheless recog-
nisable for other mobile telephones. To use the hands-free appliance with a cou-
pled mobile telephone which is not the standard or the last used mobile telepho-
ne, a connection must be made over the Bluetooth menu of the mobile
telephone.
Separating the connection
If you wish separate the mobile telephone from the hands-free appliance, for
example, to connect it to another Bluetooth appliance:
• Switch the hands-free appliance off
or
• separate the connection over the Bluetooth menu in the mobile telephone.
You need not erase the coupling with the hands-free appliance in the Bluetooth
menu to separate the connection.
10
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 10

Re-establishing the connection
If you wish to re-connect the hands-free appliance with the standard, resp. the
last used, mobile telephone:
• Check to see that Bluetooth is activated in the mobile telephone, then switch
the hands-free appliance on.
With the connection of a previously coupled mobile telephone, a pass code
need not be entered. You can programme your mobile telephone such that a
connection with the mobile telephone automatically takes place when the hands-
free appliance is switched on. Further information regarding automatic coupling
is to be found in the operating instructions for your mobile telephone.
Using the hands-free appliance
After successful coupling, the following functions are available to you. Some of
the described functions are only possible with a mobile telephone that supports
the Handsfree Profile (HFP).
Call function
• Use your mobile telephone in the usual way to make a call.
• For redialing of the last number called, shortly press the multi-function button
4twice.
• For activation of voice dialling, shortly press the multi-function button 4once.
Voice dialing is only available with mobile telephones that support this function.
Further information regarding voice dialing is to be found in the operating
instructions for your mobile telephone.
11
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 11

Accepting and ending a call
When you receive a call the LED status display 6blinks and you hear a call
tone from the hands-free appliance. If the ringing tone is switched off on your
mobile phone, a call tone will not be emitted by the hands-free appliance.
• Press the multi-function button 4shortly once, to accept the call.
• Press the multi-function button 4shortly once, to terminate the accepted call.
You can also accept and terminate the call over the mobile telephone.
Automatic call acceptance
If automatic call acceptance is activated in the mobile telephone, it accepts the
incoming call after a determined time period and then passes it on to the
hands-free appliance. Further information regarding automatic call acceptance
is to be found in the operating instructions for your mobile telephone.
Rejection of a call
• Press the multi-function button 4for 3 seconds to reject an incoming
telephone call.
Adjusting the volume of the hands-free appliance
You can adjust the volume of the hands-free appliance with the assistance of the
volume controller 3.
• During a call, turn the volume controller 3until the desired volume level is
heard.
12
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 12

Troubleshooting
If you cannot connect the hands-free appliance with a compatible mobile
telephone, proceed as follows:
• Ensure that the Bluetooth function in the mobile telephone is activated.
• Ensure that the hands-free appliance is correctly installed, switched on and
supplied with electricity.
• If you use several Bluetooth appliances, ensure that a previously created
Bluetooth connection of the mobile telephone is separated.
• Ensure that the hands-free appliance is distanced a maximum of 10 metres
from the mobile telephone and that there are no barriers or electronic devices
between them.
If these measures do not correct the problem, please contact the appropriate
service partner for your country.
13
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 13

Cleaning and Care
Danger of electrocution!
• Before cleaning, always separate the electricity supply from the appliance!
• NEVER submerse the appliance in water or other liquids!
• Do not permit liquids to permeate into the housing!
• Never open the housing of the appliance! There are no user-serviceable
elements inside.
• Do not use strong detergents, solvents or abrasive cleaning agents to clean
the appliance. These could damage the housing surfaces.
• Clean the housing surfaces with a slightly moist soft cloth.
14
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 14

Disposal
Do not dispose of the appliance in your normal domestic waste.
This product is subject to the European guideline 2002/96/EC.
Dispose of the appliance through an approved dis-posal centre or at your
community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal centre.
Dispose of all packaging materials in an environmentally responsible
manner.
15
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 15

Warranty & Service
The warranty for this appliance is for 3 years from the date of purchase. This
appliance has been manufactured with care and meticulously examined before
delivery. Please retain your receipt as proof of purchase date. Should a claim
need to be made under the warranty, please make contact by telephone with
our service department. Only in this way can a post-free despatch for your
goods be assured.
The warranty covers ONLY claims for material and maufacturing defects, not for
wearing or consumable or for damage to fragile components. This product is for
private use only and is not intended for commercial applications.
The warranty will become void in the event of abusive and improper handling,
use of force and internal tampering not carried or approved by our authorized
service branch. Your statutory rights are not restricted in any way by this
warranty.
DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
16
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 16

Irish Connection
Harbour view
Howth
Co. Dublin
Tel: 00353 (0) 87 99 62 077
Fax: [phone]
e-mail: [e-mail]
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM, GERMANY
www.kompernass.com
17
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 17

Declaration of conformity
We, Kompernaß GmbH, declare that the product KH 2355 Bluetooth®Vehicle
Hands-Free Phone System complies with the fundamental requirements and other
relevant regulations of the Vehicle Directive 2004/104/EC and the R&TTE Di-
rective 99/5/EC from the Council of the European Union.
The complete Conformity Declaration can be viewed at the Importers premises.
Bluetooth®is a registered trademark of Bluetooth SIG, Inc.
The content of this document is presented as it currently exists. Kompernaß
GmbH does not accept, neither emphatically nor tacitly, any guarantee for the
correctness or completeness of the content of this document. Kompernaß GmbH
retains for itself the right, at any time and without previous notice, to make
amendments to this document or to withdraw it completely.
18
IB_KH2355_JO41165_UK.qxd 10.09.2008 14:16 Uhr Seite 18
