Silvercrest SFE 450 C1 User manual

IAN 311109
JUICER SFE 450 C1
ENTSAFTER
Bedienungsanleitung
JUICER
Operating instructions
ΑΠΟΧΥΜΩΤΉΣ
Οδηүίες χρήσης

GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 21
DE/AT/CH Bedienungsanleitung Seite 41
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

A
B

SFE 450 C1 GB│IE│NI│CY │ 1 ■
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................3
Safety instructions .............................................4
Assembling and operating the appliance ...........................7
Preparing the fruits/vegetables ..................................8
Juicing .......................................................8
Emptying the pulp container and the filter ........................10
Dismantling the juicer ..........................................10
Cleaning and care .............................................11
Storage .....................................................12
Troubleshooting ..............................................13
Disposal .....................................................14
Kompernass Handels GmbH warranty............................15
Service................................................................16
Importer ............................................................... 16
Recipes......................................................17
Summer drink...........................................................17
Apple-pear-strawberry drink ............................................... 17
Energy drink............................................................ 17
Breakfast drink.......................................................... 18
Honeydew melon drink ................................................... 18
Sweet fruit drink.........................................................19
Pineapple-mango drink ................................................... 19
Beetroot drink ..........................................................19
Fruit-bell pepper drink ....................................................20
Peach-pear-pineapple drink................................................ 20

SFE 450 C1
■ 2 │ GB│IE│NI│CY
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of
this product. They contain important information on safety, usage and disposal.
Before using the product, familiarise yourself with all operating and safety instruc-
tions. Use the product only as described and for the specified areas of applica-
tion. Please also pass on these operating instructions to any future owner.
Intended use
This appliance has been designed for the juicing of well ripened and peeled
fruits and vegetables. The appliance may only be used to process foods. Use
only the original attachments and accessories as described. Any other uses of or
modification to the appliance is deemed to be improper and carries the risk of
serious personal injury. The manufacturer accepts no responsibility for damage
attributable to misuse. This appliance is intended solely for use in private house-
holds. Not for commercial use.
Package contents
▯ Juicer
▯ Nylon brush (in the pusher)
▯ Operating instructions

SFE 450 C1 GB│IE│NI│CY │ 3 ■
Description of the appliance
Figure A:
1Pusher
2Feed tube
3Lid
4 Clamps
5Juice tank
6Juice outlet
7 Base
8 Power cable with mains plug
9 On/off switch (2 speed settings)
0 Cable retainer
q Container (for fruit and vegetable pulp)
Figure B:
w Filter
e Drive shaft
r Nylon brush (in the pusher on delivery)
Figure A:
t Separate juice collector (can be found in the container
for fruit and vegetable pulp on delivery)
zFoam separator
Technical data
Rated voltage 220–240V ~(alternating current), 50Hz
Rated power 450 W
CO time 30 minutes
Protection class II / (double insulation)
All parts of this appliance which come into
contact with food are food-safe.
CO time
The CO time (continuous operation time) is the amount of time an appliance can
be operated without the motor overheating and becoming damaged. After the
appliance has been operated for this duration of time, switch it off until the motor
has cooled down.

SFE 450 C1
■ 4 │ GB│IE│NI│CY
Safety instructions
DANGER – ELECTRIC SHOCK!
► The voltage of the power source must conform to the details
given on the type plate of the appliance.
► To prevent accidents, have defective plugs and/or power
cables replaced immediately by an authorised specialist
technician or our Customer Service department.
► Appliances which do not work properly or have been
damaged must be checked immediately and repaired by
customer service.
► Do not expose the appliance to rain, and never use it in
a humid or wet environment. Ensure that the power cable
never becomes wet or moist during use.
Never immerse the base of the machine in water or
other liquids!
WARNING! RISK OF INJURY!
► Never use the appliance for purposes other than those
described in these instructions.
► The appliance should always be disconnected from the
mains when unattended and before assembly, disassembly
or cleaning.
► This appliance may not be used by children.
► The appliance and its connecting cable must be kept away
from children.
► This appliance may be used by persons with lim-
ited physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they are under
supervision or have been told how to use the appliance
safely and are aware of the potential risks.
► Children must not use the appliance as a plaything.
► The appliance may not be used if the rotating filter is damaged!

SFE 450 C1 GB│IE│NI│CY │ 5 ■
WARNING! RISK OF INJURY!
► Before changing any accessories or additional parts that
move during operation, the appliance must be switched off
and disconnected from mains power.
► The blades are very sharp. Handle them with care.
► Do not operate the appliance if the rotating sieve is
damaged.
► To prevent injuries, ensure that all parts are inserted correctly.
Never put your hands or other objects into the filler
opening. This could lead to grave personal injuries or
serious damage to the appliance. If pieces of fruit or
vegetable cannot be removed with the pusher, switch the
appliance off, remove the plug from the power socket
and open the appliance.
► Ensure that the power plug is easily accessible in case of
emergency, and that there is no risk of tripping over the
cable.
► Switch off the appliance and unplug it after use. Do not
dismantle the appliance until the motor has come to a
complete standstill.
► Do not touch any rotating parts.
► Never leave the appliance unattended during operation.
► Provide a stable location for the appliance.
► Do not operate the device if the filter, the power cable or
the plug is damaged.
► Do not operate the appliance in the event of any
malfunctions or if it has been damaged in any other way
or has been dropped.
► The use of accessories that have not been recommended or
sold by the manufacturer can cause a fire, electric shock or
injury.

SFE 450 C1
■ 6 │ GB│IE│NI│CY
Tips for safety:
► In case of danger, remove the plug from the socket
immediately.
► Remain alert at all times! Always pay attention to what
you are doing and act with common sense. Never use the
appliance when you are distracted or don’t feel well.
► Ensure that the appliance is completely assembled before
using it for the first time. The appliance can only be started
up once the clamps have been closed. Should the clamps
become loose during operation, the appliance stops auto-
matically.
► After using the juicer, always ensure that the on/off switch is
in the "OFF" position ("0"). Do not dismantle the appliance
until the motor has come to a complete standstill.
► Do not use the appliance outdoors.

SFE 450 C1 GB│IE│NI│CY │ 7 ■
Assembling and operating the appliance
■ Before using the appliance for the first time, clean all component parts
thoroughly as described in the section “Cleaning and care”.
■ Select a safe and secure positioning for the juicer. For optimal handling we
recommend that the appliance is positioned with the power cable 8running
from the rear of the appliance to the wall socket. All operating elements can
now be directly and easily handled:
–the On/Off switch 9at the front,
–the container for fruit and vegetable pulp qon the left,
–the juice outlet 6on the right.
WARNING! RISK OF INJURY!
► Ensure that the appliance is switched off and the plug 8removed from the
wall socket before assembling the appliance.
1) Place the juice tank 5on the appliance base 7, so that the three catches
and the juice outlet 6grip into in the recesses.
2) Place the filter won the drive shaft eand press it down so that it audibly
clicks into place. Ensure that it is firmly seated before continuing with the
assembly.
3) Slide the container for fruit and vegetable pulp qfrom below under the
outlet (see fold-out page).
4) Place the lid 3onto the juice tank 5, so that the feed tube 2is sitting
above the blades of the filter w.
5) Ensure that the lid 3is sitting firmly in the recess on the juice tank 5.
Lift the clamps 4and clip them into the notches on the lid 3.
6) Press the lower part of the clamps 4against the appliance until they click
into place.
7) Push the foam separator zinto the juice collector tand put the lid on.
Place the separate juice collector tnext to the appliance so that the juice
outlet 6protrudes into the separate juice collector t.
8) Insert the plug 8into a mains power socket.

SFE 450 C1
■ 8 │ GB│IE│NI│CY
Preparing the fruits/vegetables
■Important: Use only well-ripened fruit, as otherwise the filter wwill get
blocked. This would require repeated cleaning of the filter w.
■ Wash or peel the fruits/vegetables that you wish to process.
■ Large seeds or stones should always be removed before filling the appliance.
■ Cored fruit (such as apples, pears) can be processed along with the skin and
core. Remove all other stones (peaches, plums etc.), all large seeds (melons
etc.) and stalks to avoid possible damage to the appliance.
■ Fruits and vegetables with thick peels (e.g. citrus fruits, melons, kiwis, root
vegetables) must always be peeled first.
■ Remove the stalks from grapes.
■ Cut the fruit or vegetables into pieces that will fit easily into the feed tube 2.
NOTE
► Raisins are not suitable for juicing as they contain too little juice. Rhubarb
or other fibrous vegetables/fruits are not suitable for juicing as the fibres
will block the juicer.
Juicing
WARNING! RISK OF INJURY!
► NEVER insert your hands or other objects into the feed tube 2when working
with the appliance. This could lead to serious injuries and/or damage to
the appliance.
CAUTION! PROPERTY DAMAGE!
► DO NOT operate the juicer for longer than 30 minutes (CO time) without
a break. After 30 minutes of continuous use allow the juicer to cool down.
Otherwise the appliance could be damaged.

SFE 450 C1 GB│IE│NI│CY │ 9 ■
1) Switch the appliance on with the On/Off switch 9.
Use speed level 1 for juicing fruit/vegetables containing a lot of liquid.
For drier fruit/vegetables, select speed level 2.
You can use the following table as an orientation guide. Please bear in mind,
however, that the required speed may vary depending on the ripeness of the
fruit.
Fruits/vegetables Speed setting
Tomatoes 1
Honeydew melon 1
Watermelon 1
Peaches (without stone) 1
Kiwis (peeled) 1
Pears (without stalk) 1
Apricots (without stone) 1
Cucumber (peeled) 1
Pineapple (peeled) 2
Oranges (peeled) 2
Carrots 2
Apples 2
Broccoli 2
Fennel 2
2) Hold the pusher 1in one hand and feed the fruit or vegetable pieces with the
other hand into the feed tube 2. Always use the pusher 1to carefully press
the fruit/vegetable pieces into the feed tube 2. While the fruit/vegetables
are being processed, insert further pieces into the feed tube.
Do not switch the appliance off.
NOTE
► Add carrots one after the other into the feed tube 2: the top of the carrot
must be at the bottom and the pointed end at the top.

SFE 450 C1
■ 10 │ GB│IE│NI│CY
NOTE
► To avoid fruit or vegetables becoming blocked in the feed tube 2, only
fill it when the appliance is switched on. If fruit or vegetable pieces get
stuck in the feed tube 2and cannot be promptly freed with the pusher 1,
proceed as follows to avoid damage to the appliance:
–Switch the off appliance immediately and pull the power plug 8
from the wall socket.
–Undo the clamps 4and remove the lid 3.
–Remove the fruit or vegetable pieces causing the blockage.
–Reassemble the appliance and continue with juice extraction.
3) Always switch the off appliance immediately after all of the fruit/vegetables
have been processed.
CAUTION! PROPERTY DAMAGE!
► To avoid blockage of the juice outlet 6and/or damage to the appliance,
clean the juice outlet 6and the juice tank 5regularly and after every use.
Emptying the pulp container and the filter
■ You can extract juices continuously until the container for fruit and vegetable
pulp qis completely full.
WARNING! RISK OF INJURY!
► Remove the plug 8from the power outlet when emptying the filter w.
This prevents unintentional starting of the appliance.
If the extracted juice suddenly starts getting thicker, or if you hear that the motor is
running more slowly, the filter wneeds to be emptied. When you have removed
the fruit pulp, reassemble the appliance.
Dismantling the juicer
If you wish to dismantle the juicer, e.g. to clean it, proceed as follows:
1) Remove the mains plug 8from the socket.
2) Open the clamps 4.
3) Remove the lid 3with the pusher 1.
4) Lift up the juice tank 5carefully. This disengages the filter wfrom the drive
shaft e. You can now remove the filter wfrom the juice tank 5.

SFE 450 C1 GB│IE│NI│CY │ 11 ■
Cleaning and care
DANGER – ELECTRIC SHOCK!
► Always remove the mains plug 8from the wall socket before cleaning the
appliance.
To avoid receiving an electrical shock, never submerse the motor/
appliance base 7in water or other fluids.
WARNING! RISK OF INJURY!
► Always pull out the mains plug before fitting or removing accessories.
CAUTION! PROPERTY DAMAGE!
► To avoid blockage of the juice outlet 6and/or damage to the appliance,
all fruit and vegetable pulp must be regularly cleaned off the appliance
and accessories. Also clean after every use.
► Do not use any aggressive cleaning agents to clean the juicer. The appliance
and its accessories may not be cleaned in boiling water.
NOTE
► Soiling or overflowing fruit juices should be cleaned away immediately, as
fruit stains are more difficult to remove later.
■ Switch the appliance on with the On/Off switch 9.
■ Clean the appliance housing and the power cable 8using a lightly mois-
tened cloth.
■ Clean the pusher 1, the juice container 5, the separate juice collector t,
the foam separator z, the housing lid 3and the container for fruit and
vegetable pulp qin warm soapy water and rinse them carefully.
NOTE
► The pusher 1 , the juice container 5 , the housing lid 3 , the separate
juice collector t , the foam separator z and the container for fruit
and vegetable pulp q are dishwasher safe and can be cleaned in the
dishwasher.
► If possible, use the upper basket of the dishwasher and make sure the
components are not jammed in.

SFE 450 C1
■ 12 │ GB│IE│NI│CY
To clean the filters w , use the supplied nylon brush r :
■ Turn the lid of the pusher 1until the arrow points to the opened lock on
the pusher shaft. You can now remove the lid. The nylon brush rcan be
found inside the pusher 1. To re-close the lid, place it on the pusher so that
the arrow points to the opened lock . Then turn it until the arrow points at
the closed lock . The lid now sits firmly in place.
■ Hold the filter w(with the underside upwards) under running water and
clean it with the nylon brush r.
Colouring:
■ Some fruits or vegetables can permanently discolour parts of the juicer.
This is not damaging and does not impair the appliance in its functions.
Storage
If you do not intend to use the juicer for a long time, wrap the cable around the
cable retainer
0 on the underside of the juicer.

SFE 450 C1 GB│IE│NI│CY │ 13 ■
Troubleshooting
Faults Possible causes Possible solutions
The appliance is
not working.
The mains plug 8is not
connected.
Connect the appliance to
a mains power socket.
The appliance is not switched on. Switch the appliance on with
the On/Off switch 9.
The clamps 4are not secured. Close the clamps 4.
The motor stops
still while juicing or
it turns noticeably
more slowly or
unevenly.
The filter wis blocked.
Switch the juicer off immediately
and pull out the mains plug 8.
Remove the blockage (see sec-
tion "Juicing").
The pulp is moist
and you obtain too
little juice.
You are working too fast. Work a little more slowly.
The filter wis blocked. Clean the filter w(see section
"Cleaning and Care").
The juice wells out
between the edge
of the lid 3and
the juice tank 5.
You are working too fast. Work a little more slowly.
The filter wor the juice tank 5
is blocked.
Clean the filter wand
the juice tank 5(see section
"Cleaning and care").
The speed setting is too high. Use the on/off switch 9to
select speed level 1.
The juice sprays
out of the juice
outlet 6.
You are working too fast.
Work a little more slowly.
Do not press too hard with the
pusher 1when inserting more
fruit/vegetables.
The speed setting is
too high.
Use the on/off switch 9to
select speed level 1.
During the
processing, juice
runs down the
appliance base
7.
The filter wor the juice outlet 6
is blocked.
Clean the filter wand the juice
outlet 6(see section "Cleaning
and Care").
The speed setting is too high. Use the on/off switch 9to
select speed level 1.

SFE 450 C1
■ 14 │ GB│IE│NI│CY
Disposal
Do not dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance via an approved waste disposal company or your
municipal waste disposal facility. Please comply with all applicable regulations.
Please contact your waste disposal facility if you are in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
The packaging is made from environmentally friendly material and can be
disposed of at your local recycling plant.

SFE 450 C1 GB│IE│NI│CY │ 15 ■
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase. Please keep
your original receipt in a safe place. This document will be required as proof of
purchase.
If any material or production fault occurs within three years of the date of purchase
of the product, we will either repair or replace the product for you at our discretion.
This warranty service is dependent on you presenting the defective appliance
and the proof of purchase (receipt) and a short written description of the fault
and its time of occurrence.
If the defect is covered by the warranty, your product will either be repaired or
replaced by us. The repair or replacement of a product does not signify the begin-
ning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and defects
present at the time of purchase must be reported immediately after unpacking.
Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines
and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or fragile parts such as
switches, batteries, baking moulds or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the product
regarding proper use of the product are to be strictly followed. Uses and actions
that are discouraged in the operating instructions or which are warned against
must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications/ repairs which have not been carried out by one of
our authorised Service centres.

SFE 450 C1
■ 16 │ GB│IE│NI│CY
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g. IAN 12345) available
as proof of purchase.
■ You will find the item number on the type plate, an engraving on the front
page of the instructions (bottom left), or as a sticker on the rear or bottom of
the appliance.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals,
product videos and software on www.lidl-service.com.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: kom[email protected]
IAN 311109
Importer
Please note that the following address is not the service address. Please use the
service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
DE-44867 BOCHUM
GERMANY
www.kompernass.com

SFE 450 C1 GB│IE│NI│CY │ 17 ■
Recipes
Summer drink
2 people
Ingredients
▯ 1 large slice of watermelon
▯ 1 lemon
▯ 4 apples, sweet yet slightly sour (e.g. “Jonagold” or “Jonathan”)
Preparation
1) Prepare the watermelon, lemon and apples as per the
instructions given in the instruction manual for the juicer.
2) Juice the watermelon, the lemon and the apples.
3) Serve the summer drink chilled.
Apple-pear-strawberry drink
2 people
Ingredients
▯ 1 apple, green (e.g. “Granny Smith”)
▯ 3 small, ripe pears
▯ 10 medium-sized strawberries
Preparation
1) Prepare the apple, pears and strawberries as per the instructions
given in the instruction manual for the juicer.
2) Juice everything using the juicer.
3) Mix the juices together and serve the drink immediately.
Energy drink
2 people
Ingredients
▯ 2 apples, sweet (e.g. “Red Delicious”)
▯ 2 large apricots
▯ 1 large pear
▯ 250 ml of mineral water (carbonated)
▯ A little crushed ice
