Silvercrest SWED 100 A1 Instruction sheet

V1.0
English.............................................................................. 2
Slovenščina .................................................................... 32
Slovenčina...................................................................... 62
Deutsch .......................................................................... 92

SilverCrest SWED 100 A1
2 - English
Content
Introduction.........................................................................3
Intended use........................................................................3
Supplied items .....................................................................5
Technical data......................................................................6
Safety instructions ...............................................................7
Copyright ..........................................................................12
Overview of the controls and button functions ..................13
Display indicators ......................................................................................15
Stand...........................................................................................................16
Prior to use ........................................................................16
Inserting the batteries.................................................................................17
Connecting a mains adapter ....................................................................18
First use .............................................................................18
Switching the device on and off ...............................................................18
Setting the time...........................................................................................18
Illuminated display.....................................................................................19
Setting the volume......................................................................................20
Setting the reception sensitivity .................................................................21
Selecting a station......................................................................................21
Automatic station scan with auto store function ......................................21
Manual station scan: .................................................................................22
Manual station tuning................................................................................22
Manually saving stations...........................................................................23
Select saved stations..................................................................................23
Stereo playback.........................................................................................23
SLEEP timer .................................................................................................24

SilverCrest SWED 100 A1
English - 3
Setting the alarm time................................................................................24
Activating the alarm function ....................................................................25
Enabling/disabling the button lock ..........................................................26
Connecting the earphones........................................................................27
Troubleshooting ................................................................ 28
Environmental and disposal information........................... 29
Conformity information..................................................... 30
Warranty and servicing advice ......................................... 30

Introduction
Thank you for purchasing a SilverCrest product.
The SilverCrest world receiver SWED 100 A1 allows you to receive
stations from 9 different shortwave bands, the FM band and the AM
band. The device is also equipped with a digital clock, which you can
programme as an alarm clock.
Intended use
This is a consumer electronics device which is used to receive and play
radio stations. The device can also be used as an alarm clock. It is only
designed for private use and not for industrial or commercial purposes.

SilverCrest SWED 100 A1
4 - English
Furthermore, the device may not be used in tropical climates. The
manufacturer does not accept any liability for any resulting damage or
faults in the event of unauthorised modifications to the device. Only use
accessories specified by the manufacturer. Please observe the regulations
and laws in the country of use.
Please note that different countries may have different national regulations
regarding free-to-air frequency ranges. Information received outside of the
permitted frequency ranges must not be exploited nor its content or the
fact of its reception forwarded to third parties.

SilverCrest SWED 100 A1
English - 5
Supplied items
A World receiver SWED 100 A1
B Pouch
C Earphones SWED 100 A1
D 2 batteries of type AA, 1.5V, (Mignon, LR6)
E These instructions (symbolic representation)

SilverCrest SWED 100 A1
6 - English
Technical data
These specifications describe only the technical features
of the device. Different legal regulations may apply in
different countries to the free-to-air frequency range.
Please note that reception outside of these regulations
may then be illegal and subject to punishment.
Power supply optional mains adapter: 3V
supplied batteries
Polarity of mains adapter
Maximum power
consumption
100mA
Battery type 2x AA, 1.5V (Mignon, LR6)
Power output 100mW
Frequency bands
Please note that the specified
upper and lower limits of the
reception range may vary
slightly due to production
tolerances.
FM 87.5 - 108 MHz
MW 522 - 1620 KHz
SW1 4.75 – 5.95 MHz
SW2 5.96 – 7.1 MHz
SW3 7.11 – 9.5 MHz
SW4 9.51 – 11.65 MHz
SW5 11.66 – 13.60 MHz
SW6 13.61 – 15.10 MHz
SW7 15.11 – 17.50 MHz
SW8 17.51 – 21.45 MHz
SW9 21.46 – 21.85 MHz
Station presets 60 (20 per frequency band)

SilverCrest SWED 100 A1
English - 7
Dimensions approx. 130 x 30 x 79mm (W x D x
H)
Weight 125g (without batteries)
Earphones SWED 100 A1
Impedance 32 Ohm
Wideband characteristic
voltage (WBCV)
approx. 100mV +/-10%
Maximum sound pressure
with the supplied earphones
approx. 90 dB(A)
Maximum output voltage at
the earphone jack
approx. 70mV
Operating temperature 5°C to 35°C
Storage conditions -10°C to 50°C,
Note: The device must not be stored
in hot places, for example, in a car in
summer.
Operating air humidity max. 85% rel. air humidity
The technical data and design may be changed without notification.
Safety instructions
Before using this device for the first time, please read the following
instructions carefully and take note of the safety warnings, even if you are
familiar with the use of electronic devices. Store these instructions in a safe
place for future reference. If you sell the device or pass it on, always
include these instructions. They are an integral part of the product.

SilverCrest SWED 100 A1
8 - English
DANGER! This symbol indicates an imminent dangerous
situation which, if not prevented, could result in serious injury
or even death.
WARNING! This symbol indicates important information for
safe operation of the device and the safety of the user.
This symbol indicates other important information on the
topic.
Health risks due to excessively high volume levels
Take care when using earphones. Listening at high volume for
prolonged periods of time can impair your hearing.
Only use the supplied earphones (C) of type: SWED 100
A1. Other earphones may create harmful sound pressure.
Do not use the earphones (C) at high volumes. This impairs your hearing
and may disrupt your environment. Even if the device is designed to ensure
that ambient noise can still be heard, adjust the volume so that you can
continue to hear the ambient noise. In dangerous situations, for example,
driving in traffic, working with machinery or other situations that require
your full attention, the sound can distract you or cause you to fail to
perceive what is happening around you. Thus do not use the device in
such situations.
Operating environment
The device is not designed for use in environments with a high temperature
or humidity (e.g. bathrooms) or in extremely dusty conditions. Operating

SilverCrest SWED 100 A1
English - 9
temperatures and operating air humidity: 5°C to 35°C, max. 85% rel.
humidity.
Ensure that
air can always circulate freely (do not place the device on shelves, on a
carpet or a bed or anywhere where ventilation slots are covered, and
always leave at least 10 cm clearance on all sides)
no direct heat sources (e.g. heating) can affect the device
no direct sunlight or bright artificial light reaches the device
any contact with splashed and dripping water and corrosive liquids is
avoided and the device is not operated in the vicinity of water. In
particular, the device should never be submerged in liquid; do not place
any vessels filled with liquid, e.g. vases or drinks, on or near the device.
the device is not in the immediate vicinity of magnetic fields (e.g.
speakers)
no fire sources (e.g. burning candles) are placed on or near the device
no foreign objects penetrate the device
the device is not subjected to any extreme temperature fluctuations, as
this may result in moisture caused by condensation and thus a short
circuit. If the device was subjected to extreme temperature fluctuations,
however, wait (approx. 2 hours) until the device has reached ambient
temperature before use.
the device is never subjected to excessive shocks and vibrations.
the device or an optional mains adapter is not used during a
thunderstorm with lightning. During a thunderstorm with lightning,
remove the optional mains adapter from the mains socket if inserted.

SilverCrest SWED 100 A1
10 - English
when using a mains adapter, the mains socket to which the device is
connected is easily accessible at all times. Always lay cables in such a
manner that nobody can trip over them.
Batteries
Always ensure correct polarity of the batteries. Please note the markings in
the battery compartment. Never try to recharge batteries and never throw
them into an open fire. Never use different batteries (old and new, alkaline
and carbon, etc.) at the same time. Remove the batteries if you will not be
using the device for an extended period of time. In the event of improper
use, there is a risk of explosion and leakage.
Batteries may not be deformed or opened as leaking chemicals can cause
injuries. In the event of skin or eye contact with chemicals, they must be
immediately rinsed with generous amounts of water and a doctor must be
consulted.
Children and persons with disabilities
Electrical devices do not belong in the hands of children. Persons with
limited physical, sensory or mental abilities should also only use electrical
devices appropriately. Never allow children or persons with disabilities to
use electrical devices unsupervised unless they have been instructed
accordingly or are supervised by a person responsible for their safety.

SilverCrest SWED 100 A1
English - 11
Children should always be supervised to ensure that they do not play with
this device. Batteries and small parts may cause choking resulting in death
or serious injury. Store the batteries in a safe place. If a battery is
swallowed, seek medical help immediately.
Always keep plastic packaging out of reach also.
It poses a suffocation risk!
Cleaning / maintenance
It is necessary to repair the device if it has been damaged in any way, for
example, if the mains adapter or housing is damaged, if liquid or objects
have penetrated the device or if the product has been exposed to rain or
moisture. Repair work is also required if the device is not working properly
or has been dropped. If you notice any smoke, unusual noises or strange
odours, switch off the device immediately and remove the batteries or
remove the mains adapter from the mains socket. In such cases, the device
should not be used until it has been inspected by authorised service
personnel. Only have the device repaired by qualified personnel. Never
open the housing of the device. Only use a clean, dry cloth for cleaning
and never use any corrosive liquids. Never try to open the housing of the
device as this would void your warranty.
If the batteries have leaked, the device must be cleaned by authorised
service personnel.

SilverCrest SWED 100 A1
12 - English
Copyright
All information contained in these instructions is subject to copyright and is
provided for information purposes only.
It is only permitted to copy or duplicate data and information with the
express and written consent of the author. This also includes commercial
use of the content and data.
The text and illustrations are based on the state of the art at the time of
printing.

SilverCrest SWED 100 A1
English - 13
Overview of the controls and button functions

SilverCrest SWED 100 A1
14 - English
1 Telescopic aerial
2 SNOOZE button (postpone alarm for approx. 5 minutes)
3 VOLUME - button (reduce volume)
4 VOLUME + (increase volume)
5 Display
6 POWER button (turn on/off; set sleep timer)
7 Strap
8 BAND button (select frequency band)
9 UP button (tune up, minute setting +)
10 ALARM button (set or activate/deactivate alarm)
11 DOWN button (tune down, minute setting -)
12 LOCK button (button lock)
13 M+ button (select next preset)
14 TIME/MEM button (setting time, presetting radio stations)
15 M- button (select previous preset)
16 Loudspeaker
17 DX/LOCAL switch (set reception sensitivity)
18 (earphone jack)
19 (jack for optional mains adapter)
20 Stand (at the back)
21 Battery compartment (at the back)
These operating instructions have a fold-out cover. Fold out the inside
cover so that you always keep the controls in sight.

SilverCrest SWED 100 A1
English - 15
Display indicators
22 PM display
23 Frequency band
24 Volume warning symbol
25 SLEEP
26 LOCK (button lock)
27 Alarm
28 Time/frequency display
29 Unit of frequency
30 Low battery power
31 VOLUME
32 SCAN
33 PRESET (station presets)
34 STEREO (only in earphone mode)
35 Preset location (0-19)

SilverCrest SWED 100 A1
16 - English
Stand
A stand (20), with which you can position the world receiver at an angle,
is located at the back of the device. Open out the stand (20).
Prior to use
You can use the device either with the supplied batteries (D) of type AA
(Mignon, LR6) or with an optional mains adapter (not supplied). The
adapter must have a suitable DC voltage plug and an operating voltage
of 3V.
Do not use both operating options at the same time.
Remove the batteries before you connect the device with
the mains adapter.

SilverCrest SWED 100 A1
English - 17
Inserting the batteries
Remove the connection cable of the mains adapter if such a cable is
connected. Open the battery compartment (21) at the back of the device
by sliding the battery compartment cover downwards and removing it.
Insert the batteries with the correct polarity (note + and -) as shown in the
following illustration. The polarity is illustrated on the batteries and in the
battery compartment. Make sure that the ribbon (arrow) runs completely
under the batteries when you have inserted them. This makes it easier to
remove the batteries the next time it is necessary. Now insert the two
plastic tabs of the battery compartment cover into the slots provided for
this purpose at the lower end of the battery compartment (21) and then
slide the battery compartment cover upwards until it snaps into place.

SilverCrest SWED 100 A1
18 - English
If the display (5) indicates a low battery power (30), the batteries are
almost empty. Replace them with new batteries of the same type.
Remove the batteries if you will not be using the device
for an extended period of time.
Connecting a mains adapter
Remove the batteries from the battery compartment (21) at the back of the
device if you have previously inserted them. Insert the plug of the mains
adapter into the jack (19) of the world receiver (A). Then insert the mains
adapter into an easily accessible mains socket.
First use
Switching the device on and off
To switch on the device, press the "POWER" button (6) once briefly. When
it is switched on, the display (5) shows the tuned frequency and the
frequency band:
FM FM band
MW medium wave band
SW shortwave band
To switch off the device, press the POWER button (6) again. When it is
switched off, the display (5) shows the time that is currently set.
Setting the time
You can set the time only when the device is switched off. Switch off the
device with the POWER button (6) if it is switched on.
