Silvercrest SUP 128 A1 User manual

IAN 60308
USB RECORD PLAYER SUP 128 A1
USB RECORD PLAYER
Operating instructions
USB-PLATTENSPIELER
Bedienungsanleitung

GB/IE Operating instructions Page 1
DE/AT / CH Bedienungsanleitung Seite 27
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

IAN 60308
USB-PLATTENSPIELER SUP 128 A1
USB-PLATTENSPIELER
Bedienungsanleitung USB RECORD PLAYER Operating instructions

1
SUP 128 A1
GB
IE
Contents
Introduction . . . . . . . . . . . . . . . 2
Foreword . . . . . . . . . . . . . . . . . . . . . . 2
Copyright. . . . . . . . . . . . . . . . . . . . . . 2
Limitation of liability . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . 3
Intended use . . . . . . . . . . . . . . . . . . . 4
Safety. . . . . . . . . . . . . . . . . . . . 5
Risks from electric current. . . . . . . . . . 5
Basic safety instructions . . . . . . . . . . . 6
Handling batteries . . . . . . . . . . . . . . . 7
Start-up . . . . . . . . . . . . . . . . . . 8
Check the package contents . . . . . . . 8
Disposal of packaging. . . . . . . . . . . . 9
Set-up location requirements . . . . . . . 9
General description . . . . . . . 10
Remote control. . . . . . . . . . . . . . . . .10
Overview of the device . . . . . . . . . .11
Before initial start-up . . . . . . 12
Setting the tracking pressure . . . . . .12
Electrical connection . . . . . . . . . . . .13
Inserting/changing the remote
control battery . . . . . . . . . . . . . . . . .13
Connection to an external amplifier.13
Handling and operation. . . . 14
Switching the device on and off . . .14
Automatic switch-off. . . . . . . . . . . . .14
Vinyl record operation . . . . . . . . . . .14
Fine adjustment of the rotation speed .15
USB and card operation . . . . . . . . .16
AUX-IN operation . . . . . . . . . . . . . .19
Recording function. . . . . . . . . . . . . .20
Cleaning. . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . 21
Fault causes and rectification. . . . . .22
Storage / Disposal. . . . . . . . . 23
Storage . . . . . . . . . . . . . . . . . . . . . .23
Disposal of the device . . . . . . . . . . .23
Disposal of batteries . . . . . . . . . . . .23
Appendix. . . . . . . . . . . . . . . . 23
Notes on the Declaration of
Conformity. . . . . . . . . . . . . . . . . . . .23
Technical details. . . . . . . . . . . . . . . .24
Warranty . . . . . . . . . . . . . . . . . . . . .25
Service. . . . . . . . . . . . . . . . . . . . . . .25
Importer . . . . . . . . . . . . . . . . . . . . . .25
IB_60308_SUP128A1_LB6.indb 1 08.04.14 10:15

2SUP 128 A1
GB
IE
Introduction
Foreword
Congratulations on the purchase of your new device.
You have selected a high-quality product.
The operating instructions are a part of this product. They contain important infor-
mation about safety, use and disposal. Before using the product, familiarise your-
self with all operating and safety instructions. Use this product only as described
and only for the specified areas of application. Please also pass these operating
instructions on to any future owner(s).
Copyright
This documentation is subject to copyright protection.
Any copying or reproduction, including extracts thereof, and the reproduction of
images (even in a modified state), is permitted only with the written authorisation
of the manufacturer.
Limitation of liability
All the technical information, data and instructions regarding installation, connec-
tion and operation contained in these operating instructions correspond to the
latest information available to us at the time of printing and take into account our
previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe these instructions, improper use, incompetent repairs, unauthorised
modifications or for the use of non-approved replacement parts.
IB_60308_SUP128A1_LB6.indb 2 08.04.14 10:15

3
SUP 128 A1
GB
IE
Warnings
The following warnings are used in these operating instructions:
DANGER
A warning at this risk level indicates an imminently hazardous
situation.
If the hazardous situation is not avoided, it could lead to death or serious
physical injury.
► Follow the instructions in this warning to avoid a fatality or serious personal
injury.
WARNING
A warning of this risk level indicates a potentially hazardous
situation.
Failure to avoid this hazardous situation could result in physical injury or serious
damage to property.
► Follow the instructions in this warning to prevent physical injury or serious
damage to property.
CAUTION
A warning of this risk level indicates potential damage to
property.
Failure to avoid this situation could result in damage to property.
► Follow the instructions in this warning to prevent damage to property.
NOTE
► A note indicates additional information that will assist you in handling the
device.
IB_60308_SUP128A1_LB6.indb 3 08.04.14 10:15

4SUP 128 A1
GB
IE
Intended use
This is a consumer electronics device.
This device is exclusively intended for playing vinyl records, playing back MP3
files from USB data media and SD/MMC memory cards and also audio signals
from external audio devices.
This device can also be used to record audio signals from vinyl records and external
audio devices as MP3 files onto USB data media and SD/MMC memory cards.
It is not intended for any other use.
WARNING
Danger if not used for correct purpose
Failure to use the device for its intended purpose and/or other type of use can
be hazardous.
► Use the device only for its intended purpose.
► Observe the procedures described in these operating instructions.
Claims of any kind for damage arising as a result of incorrect use will not be
accepted.
The user is the sole bearer of the risk.
IB_60308_SUP128A1_LB6.indb 4 08.04.14 10:15

5
SUP 128 A1
GB
IE
Safety
This section provides you with important safety information regarding handling
of the device.
The device complies with the statutory safety regulations.
Incorrect usage can lead to personal injury and damage to property.
Risks from electric current
DANGER
Risk of electrocution!
Contact with live cables or components can result in fatal injury!
Observe the following safety instructions to avoid risks from electrical current:
► Do not operate the device if the power cable or the plug is damaged.
► Before using the device again, have a new mains power cable installed by
an authorised specialist.
► Connect the device only to a freely accessible, properly installed 230 V ~
50 Hz mains power socket.
► The device housing must not be opened under any circumstances. There is
a risk of electric shock if live connections are touched or electrical and/or
mechanical components are modified.
CAUTION
Notice regarding power disconnection
► The device consumes power in standby mode. The ON/OFF switch does
not completely disconnect the device from the mains power. To completely
disconnect the device from mains power, the power plug must be removed
from the mains power socket. The device should be positioned so that you
have unrestricted access to the mains power socket at all times, enabling
the plug to be removed immediately in an emergency situation.
► To prevent the risk of fire, you should completely disconnect the plug from
the mains power socket if the device is not going to be used for extended
periods such as holidays.
IB_60308_SUP128A1_LB6.indb 5 08.04.14 10:15

6SUP 128 A1
GB
IE
Basic safety instructions
Follow the safety instructions below to use the device safely:
■ Check the device for any visible external damage before use. Do not use a
device that has been damaged or dropped.
■ If the cables or connections are damaged, have them replaced by an authorised
specialist or customer service.
■ This device is not intended for use by persons (including children) with limited
physical, physiological or intellectual abilities or lack of experience and/or
knowledge unless they are supervised by a person who is responsible for
their safety, or receive instructions from this person on how to use the device.
■ Children should be supervised to ensure that they do not play with the device.
■ Packaging material must not be used as a plaything. Risk of suffocation!
■ All repairs must be carried out by authorised specialist companies or the
Customer Service department. Improper repairs can pose significant risks to
the user. Warranty claims also become void.
■ Repairs to the device during the warranty period may only be carried out by
a customer service department authorised by the manufacturer. Otherwise
no additional warranty claims can be considered for subsequent damage.
■ Defective components must always be replaced with original replacement
parts. Compliance with the safety requirements can only be guaranteed by
using these replacement parts.
■ Protect the device from penetration by moisture and liquids.
■ Do not expose the device to spray and/or dripping water and do not place
any objects filled with liquid, such as vases or open drink containers, on or
near the device.
■ Always take hold of the mains plug when disconnecting the cable from the
mains power socket. Never pull on the power cable itself and never touch it
with wet hands. Risk of electrocution!
■ Do not carry the device by the power cable.
■ Do not allow the power cable to hang down. There is a risk of the device
being pulled down by the cable.
■ Do not place the device itself or other heavy items such as furniture on the
power cable, and ensure that the cable cannot become jammed or trapped
in any way.
■ Never tie knots in the power cable, and do not bind it together with other cables.
IB_60308_SUP128A1_LB6.indb 6 08.04.14 10:15

7
SUP 128 A1
GB
IE
■ Route the power cable so that it cannot be stepped on or stumbled over.
■ To avoid overheating during operation, do not cover the device.
■ Do not insert metal or flammable objects into the device.
■ When a cold device is taken into a warm environment, condensation can
occur. Do not connect the device to the mains: let the device acclimatise at
room temperature for about one hour.
■ Avoid direct sunlight and strong artificial light.
■ Do not operate the device in the vicinity of naked flames (e.g. candles).
■ In the event of malfunctions and during thunderstorms, remove the mains
plug from the mains power socket.
Handling batteries
WARNING
Danger from improper use!
In order to handle batteries safely, please observe the following safety instructions:
► Do not throw the batteries into a fire and do not subject them to high
temperatures.
► Do not open, deform or short-circuit batteries, since this can lead to chemical
leakage.
► Do not attempt to recharge batteries.
► Check the condition of the batteries at regular intervals. Leaking chemicals
can cause permanent damage to the device. Take particular care when
handling damaged or leaking batteries. Risk of chemical burns!
Wear protective gloves.
► The chemicals that leak from a battery can cause skin irritation. In event of
contact with the skin, rinse with copious amounts of water. If the chemicals
come into contact with your eyes, rinse thoroughly with water, do not rub
and consult a doctor immediately.
► Keep batteries out of the reach of children. Children can put batteries into
their mouth and swallow them. If a battery has been swallowed, seek medical
assistance IMMEDIATELY.
► Do not mix different types of batteries.
► Always insert the batteries the right way round (observe correct polarity)
otherwise there is a danger that they could explode.
► Remove the batteries from the remote control if you do not intend to use
the device for extended periods of time.
IB_60308_SUP128A1_LB6.indb 7 08.04.14 10:15

8SUP 128 A1
GB
IE
Start-up
Check the package contents
See illustrations on the fold-out page.
NOTE
► Check the delivery for completeness and for signs of visible damage.
► If the delivery is incomplete, or has been damaged due to defective
packaging or during transportation, contact the Service Hotline
(see chapter Service).
This device is supplied with the following components:
● Record player
● Turntable mat
● Pickup arm counterweight
● Adapter for singles (45's)
● Remote control
● 2 x 1.5 V Batteries type AAA/micro
● These operating instructions
♦ Remove all packaging material.
♦ Remove all adhesive tape from the turntable and place the turntable mat
on the turntable.
♦ Remove the wire securing the pickup arm to the arm rest.
CAUTION
► The protective cap for the stylus is not part of the packaging material and
must not be discarded.
► The protective cap should only be pulled forwards off the pickup arm.
To protect the stylus, the protective cap should be replaced whenever the
record player is not in use.
DANGER
► Packaging material must not be used as a plaything.
Risk of suffocation!
IB_60308_SUP128A1_LB6.indb 8 08.04.14 10:15

9
SUP 128 A1
GB
IE
Disposal of packaging
The packaging protects the device from transport damage. The packaging
materials have been selected for their environmental friendliness and disposal
attributes, and are therefore recyclable.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste that is generated. Dispose of packaging material
which is no longer needed in accordance with applicable local regulations.
NOTE
► If possible, keep the original packaging of the device during the warranty
period, so that the device can be packed properly for returning in the event
of a warranty claim.
Set-up location requirements
For safe and trouble-free operation of the device, the set-up location must fulfil
the following requirements:
■ The device must be placed on a firm, flat and level surface.
■ Do not place the device in a hot, wet or extremely moist environment or in
the vicinity of flammable materials.
■ Do not remove the feet of the device. Otherwise there may be insufficient
air circulation.
■ The mains power socket must always be easily accessible so that the mains
plug can be quickly removed from the mains power socket in the case of an
emergency.
■ The surfaces of furniture and also furniture care products/polishes may possibly
contain substances that could attack the rubber feet of the device and soften
them. Put something beneath the feet of the device if necessary.
■ This device is not intended for use in areas where special conditions may exist,
such as a corrosive or potentially explosive atmosphere (dust, vapour or gas).
■ Operating temperature range: +5 to +35°C
■ Humidity (no condensation): ≤ 75 %
IB_60308_SUP128A1_LB6.indb 9 08.04.14 10:15

10 SUP 128 A1
GB
IE
General description
Remote control
INFO: Display/hide ID3 tags in MP3
mode
●REC: Start recording
►►I: Skip to next track/fast forward
■: Stop playback
►►Ix10: Skip 10 tracks forward in
MP3 mode
PROGRAM: Activate track program-
ming
TRACK-CUT: Carry out track cutting
during recording
USB/SD: Switch to USB or SD mode
PHONO: Switch to PHONO mode
AUX: Switch to AUX mode
RPT/INTRO/RND: Repeat track
or medium/intro function/random
playback
I◄◄ x10: Skip 10 tracks back in MP3
mode
I◄◄: Skip to previous track/rewind
►II: Start/pause playback
SEARCH : Start the search for
tracks or directories in MP3 mode
NOTE
► Operation using the remote control is shown in the following text using posi-
tive numbers ( ) and operation at the device using negative numbers ( ).
IB_60308_SUP128A1_LB6.indb 10 08.04.14 10:15

11
SUP 128 A1
GB
IE
Overview of the device
See illustrations on the fold-out page.
Dust cover
Turntable
Counterweight for the pickup arm
Anti-skating control
Pickup arm elevator
Arm rest for pickup arm
Pickup arm
Turntable speed selection switch
Adjustment control PITCH ADJ.:
fine adjustment of the rotation speed
Stylus
EJECT button: Stop vinyl record
playback
ON/OFF button Switch the device
on/off
PHONO button: Switch to PHONO
mode
AUX button: Switch to AUX mode
▸II/■ button: Start/pause/stop
playback (for USB and SD opera-
tion only)
USB/SD button: Switch to USB or
SD mode
▸▸Ibutton: Fast forward, skip to
next track
▸▸Ix10 button: Skip 10 tracks
forward in MP3 mode
I◂◂ button: Rewind, skip to previous
track
RPT/INTRO/RND button: Repeat
track or medium/intro function/
random playback
●REC button: Record vinyl record
onto USD stick or SD/MMC card
PROG button: Activate track
programming
Display
POWER "On" lamp
Sensor for remote control
AUX IN: 3.5 mm stereo input
socket for connecting an external
audio device
USB port
Card slot for SD/MMC cards
Stroboscope: Scanning light for
rotation speed
Adapter for singles (45's)
Power cable
LINE OUT: Audio cinch output
L/R for amplifier
Remote control
Batteries
Operating instructions
IB_60308_SUP128A1_LB6.indb 11 08.04.14 10:15

12 SUP 128 A1
GB
IE
Before initial start-up
Setting the tracking pressure
The supplied counterweight must be fitted to the pickup arm . This is used
to set the correct weight so that the stylus moves over the records without
jumping or pressing too firmly into the groove.
CAUTION
Possible stylus damage.
► Hold the pickup arm firmly so that the stylus is not touching the turntable .
♦ Remove the protective cap from the stylus.
♦ Release the arm rest clip from the pickup arm.
♦ Set the anti-skating control to "0".
♦ Slide the counterweight (with the scale at the front) onto the pickup arm
from the rear all the way to the front (see Fig. A).
♦ Rotate the counterweight clockwise on the pickup arm until you reach the
white stop mark (T) on the pickup arm (see Fig. B).
♦ Set the scale ring to "1" without changing the weight. To do this, hold the
silver part of the counterweight firmly and rotate the front black scale ring
only (see Fig C).
♦ Now set the tracking pressure by rotating the counterweight anticlockwise.
We recommend a value between 4–6 (see Fig. D).
Fig. A Fig. B Fig. C Fig. D
NOTE
► If in doubt, start by selecting a lower weight for the stylus. If the stylus still
jumps, increase the weight in small increments. Too much weight will make
the needle cut into the groove, causing excessive wear.
IB_60308_SUP128A1_LB6.indb 12 08.04.14 10:15

13
SUP 128 A1
GB
IE
Setting the anti-skating force
Due to the friction between the rotating disc and the stylus , the pickup arm
is pulled inwards and the stylus presses more heavily on the inner flank of the
groove on the record. This is compensated for by the anti-skating setting.
The anti-skating force should be set to the same value as the tracking pressure,
e.g. a value between 4–6.
♦ Set the anti-skating control to the same value as the pickup arm counter-
weight .
Electrical connection
■ Before connecting the device, compare the connection data (voltage and
frequency) on the rating plate with that of your mains power supply.
This data must correspond in order to avoid damaging the product.
■ Make sure that the power cable is not damaged and is not routed over
hot surfaces and/or sharp edges.
■ Ensure that the power cable is not taut or kinked.
■ The mains power socket must be easily accessible so that the power cable
can be quickly disconnected in an emergency.
Inserting/changing the remote control battery
♦ Open the battery compartment on the rear of the remote control .
♦ Insert 2 new type AAA batteries into the battery compartment.
♦ Close and secure the battery compartment.
Connection to an external amplifier
NOTE
► The record player is equipped with a LINE OUT output . The record
player must be connected to a sound output device with speakers and
volume control, e.g. an amplifier.
♦ Connect a stereo cinch cable to the LINE OUT connectors on the record
player and connect these to the AUX IN connectors of your external amplifier.
Follow the operating instructions for the external amplifier when doing this.
CAUTION
Potential damage to external amplifier!
► Do not connect the LINE OUT output of the record player to the PHONO
input of your amplifier. Due to the internal amplification of this special input,
it can be destroyed by connecting the record player
IB_60308_SUP128A1_LB6.indb 13 08.04.14 10:15

14 SUP 128 A1
GB
IE
Handling and operation
This section provides you with important information on handling and using
the device.
Switching the device on and off
♦ To switch the device on, press the ON/OFF button .
♦ The POWER "On" lamp comes on and PHONO operating mode appears
on the display .
♦ To switch off the device press the ON/OFF button again.
Automatic switch-off
The device has an automatic switch-off function and will turn itself off after
15 minutes of inactivity.
♦ To switch the device back on, press the ON/OFF button twice.
Vinyl record operation
Starting playback of vinyl records
♦ Use the PHONO or button to select the operating mode for vinyl
record playback. The display will read PHONO.
♦ Open the dust cover .
♦ Place the record onto the turntable .
NOTE
► Make sure that the record is clean and free of dust. Appropriate record-
cleaning brushes and cloths in are available from specialist retailers.
► Use the adapter to play records with a large centre hole (singles).
♦ Use the turntable speed selection switch to set the required rotation speed.
NOTE
► On most records, the rotation speed is printed on the record label.
♦ Remove the protective cap from the stylus .
♦ Release the arm rest clip from the pickup arm .
IB_60308_SUP128A1_LB6.indb 14 08.04.14 10:15

15
SUP 128 A1
GB
IE
♦ Move the pickup arm lever to the rear position to raise the pickup arm.
♦ Swing the pickup arm to the desired position on the record. The turntable
starts to rotate.
♦ Move the pickup arm lever to the forward position to lower the pickup
arm and to place the stylus onto the record.
♦ Control the volume on the connected amplifier.
♦ If you want to pause the playback, use the lever to raise the pickup arm.
♦ Press the EJECT button to stop playback and return the pickup arm
automatically to the arm rest.
NOTE
► At the end of the record, the pickup arm automatically returns to its starting
position and the turntable switches off.
Fine adjustment of the rotation speed
The stroboscope beams a blue flashing light onto the edge of the turntable.
While the turntable is turning, this light will be reflected and you can see a
dashed line on the edge of the turntable. Use the PITCH ADJ. controller to
fine-tune the rotation speed:
- The upper dashed line on the edge of the turntable is used for setting the rota-
tion speed to 33⅓ rpm.
- The middle dashed line on the edge of the turntable is used for setting the rotation
speed to 45 rpm.
- The rotational speed is correctly set when the dashed line can be seen firmly in
one position.
♦ If the dashes move towards the left the rotational speed is too high.
Slide the PITCH ADJ. control to the rear in the direction "−".
♦ If the lines move towards the right, push the PITCH ADJ. control forwards in
the direction "+".
IB_60308_SUP128A1_LB6.indb 15 08.04.14 10:15

16 SUP 128 A1
GB
IE
Adjusting the movement radius of the pickup arm
On some records, the pickup arm may return before playback has completely
ended. Sometimes the pickup arm may not return all the way to the arm rest .
The movement radius of the pick-up arm can be adjusted with a setting screw.
It is located beneath the rubber cover next to the pickup arm axis.
♦ Remove the rubber cover.
♦ To increase the pickup arm movement inwards, turn the screw with a small
Phillips-head screwdriver a little to the right.
♦ To increase the pickup arm movement outwards, turn the screw a little to the left.
NOTE
► The record player is set to the most common record settings by default.
Do not turn the setting screw unnecessarily or too often.
USB and card operation
There are connections for a USB stick or another USB device (MP3 player), and
an SD/MMC card on the front of the device.
CAUTION
The USB connection is only designed for USB memory sticks. Other external
storage media such as external hard drives cannot be operated via the USB port.
► To avoid damaging the device, do not use a USB extension cable and do
not connect the record player directly to the USB port of a computer.
► Storage media can only be inserted in one direction. Do not use force to
connect them as this may damage the storage medium and the device.
IB_60308_SUP128A1_LB6.indb 16 08.04.14 10:15

17
SUP 128 A1
GB
IE
Connecting a USB data medium
♦ Slide the cover of the USB connection upwards and insert your USB device.
Connecting a memory card
♦ Slide a memory card into the memory card slot with the labelling facing
upwards.
Activating the operating mode
♦ Press the USB/SD or button repeatedly until USB or CARD and
the corresponding icon ( / ) appears in the display . The device
searches for MP3 files on the data medium. After reading the data, play-
back starts automatically.
NOTE
► If no data medium is connected or if the data medium is empty, NO USB
or NO CARD is shown on the display.
Pausing or stopping playback
♦ Press the ▸II/■ or ▸II button to pause playback.
♦ To resume playback press the ▸II/■ or ▸II button again.
♦ To stop playback, hold the ▸II/■ button down for for approximately
2 seconds or press the ■ button once.
Skip title
♦ Press the ▸▸Ior button to select the next track.
♦ Press the I◂◂ or button to select the previous track.
Fast forward/rewind
♦ During playback press and hold the I◂◂ or ▸▸Ibuttons to fast forward
or rewind. The sound will be muted.
Skip 10 tracks
♦ Press the ▸▸Ix10 button or to skip forward ten tracks.
♦ Press the I◂◂x10 button to skip backward ten tracks.
IB_60308_SUP128A1_LB6.indb 17 08.04.14 10:15
