Simex SPP-94 User manual

Assisting the automation
industry since 1986
User manual
FLOW METER
PP-94
•Firmware: v.6.01 or higher
•Input type: 0/4-20 mA
•Batching and tota izer function
Read the user's manual carefully before starting to use the unit or software.
Producer reserves the right to implement changes without prior notice.
2018.12.20 PP-94_IN XEN_v.2.10.001

User manual - FLOW METER SPP-94
CONTENTS
1. BASIC REQUIREMENTS AND USER SAFETY........................................................................................4
2. GENERAL CHARACTERISTICS................................................................................................................5
3. TECHNICAL DATA......................................................................................................................................6
4. DEVICE INSTALLATION............................................................................................................................8
4.1. UNPACKING.......................................................................................................................................8
4.2. ASSEMBLY........................................................................................................................................9
4.3. CONNECTION METHOD.................................................................................................................11
4.4. MAINTENANCE................................................................................................................................18
5. FRONT PANEL DESCRIPTION................................................................................................................19
6. PRINCIPLE OF OPERATION...................................................................................................................2
6.1. MEASUREMENT MODE..................................................................................................................20
6.2. DETECTION OF THE PEAK VALUES............................................................................................23
6.3. CONTROL OF THE RELAY OUTPUTS..........................................................................................24
6.3.1. O e threshold mode................................................................................................................26
6.3.2. Two thresholds mode..............................................................................................................27
6.3.3. Batcher mode a d „PrE r1” mode...........................................................................................28
6.3.4. Use of the batcher cou ter as a marker.................................................................................29
7. DEVICE PROGRAMMING.........................................................................................................................3
7.1. PROGRAMMING MENU..................................................................................................................30
7.2. PARAMETERS EDITION.................................................................................................................31
7.2.1. Numeric parameters (digit cha ge mode)...............................................................................31
7.2.2. Numeric parameters (slide cha ge mode)..............................................................................31
7.2.3. Switch parameters (“LIST” type).............................................................................................32
7.3. MENU DESCRIPTION.....................................................................................................................32
7.3.1. “rELAy1” me u........................................................................................................................32
7.3.2. “bEEP” me u...........................................................................................................................35
7.3.3. “FLouu” me u..........................................................................................................................36
7.3.4. “bAtCH” me u.........................................................................................................................40
7.3.5. “totAL” me u............................................................................................................................41
7.3.6. “Pr i P” me u..........................................................................................................................42
7.3.7. “I it d” parameter.....................................................................................................................43
7.3.8. “FiLtEr” me u..........................................................................................................................43
7.3.9. ”OutP” me u............................................................................................................................44
7.3.10. ”briGHt” parameter................................................................................................................47
7.3.11. ”HOLd” me u.........................................................................................................................47
7.3.12. ”SECU” me u........................................................................................................................48
7.3.13. ”rS-485” me u.......................................................................................................................48
7.3.14. ”Edit t” parameter..................................................................................................................49
7.3.15. ”dEFS” parameter..................................................................................................................49
7.3.16. ”SErv” me u..........................................................................................................................49
7.4. UNITS CALCULATIONS EXAMPLES.............................................................................................50
7.4.1. U its recalculati g examples..................................................................................................51
7.5. MENU STRUCTURE........................................................................................................................52
8. OVER-CURRENT PROTECTION.............................................................................................................54
9. DISPLAYED VALUES CALCULATION....................................................................................................54
9.1. ADDITIONAL CALCULATIONS (USED CONVERSION CHARACTERISTIC)...............................54
9.1.1. Li ear characteristic................................................................................................................54
9.1.2. Square characteristic..............................................................................................................55
9.1.3. Square root characteristic.......................................................................................................56
9.1.4. User defi ed characteristic.....................................................................................................56
9.2. EXAMPLES OF CALCULATIONS...................................................................................................57
1 . THE MODBUS PROTOCOL HANDLING...............................................................................................61
10.1. LIST OF REGISTERS....................................................................................................................61
10.2. TRANSMISSION ERRORS DESCRIPTION..................................................................................70
10.3. EXAMPLES OF QUERY/ANSWER FRAMES...............................................................................70
2

User manual - FLOW METER SPP-94
11. DEFAULT AND USER'S SETTINGS LIST.............................................................................................73
3

User manual - FLOW METER SPP-94
Explanation of symbols used in the manual:
- This symbol de otes especially importa t guideli es co cer i g the i stallatio a d
operatio of the device. Not complyi g with the guideli es de oted by this symbol
may cause a accide t, damage or equipme t destructio .
IF THE DEVICE IS NOT USED ACCORDING TO THE MANUAL THE USER IS
RESPONSIBLE FOR POSSIBLE DAMAGES.
- This symbol de otes especially importa t characteristics of the u it.
Read a y i formatio regardi g this symbol carefully
1. BASIC REQUIREMENTS AND USER SAFETY
-


- Installation should be conducted by qualified personnel . During installation all
available safety requirements should be considered. The fitter is responsible for
executing the installation according to this manual, local safety and EMC
regulations.
- If the device is equipped with PE connector, it should be connected to PE wire.
Otherwise PE wire should be connected to GND connector.
- The unit must be properly set-up, according to the application. Incorrect
configuration can cause defective operation, which can lead to unit damage or
an accident.
- 


- 


- Neighbouring and connected equipment must meet the appropriate standards
and regulations concerning safety and be equipped with adequate overvoltage
and interference filters.
-


4
i
!
!

User manual - FLOW METER SPP-94
- In order to minimize fire or electric shock hazard, the unit must be protected
against atmospheric precipitation and excessive humidity.
- Do not use the unit in areas threatened with excessive shocks, vibrations, dust,
humidity, corrosive gasses and oils.
- Do not use the unit in areas where there is risk of explosions.
- Do not use the unit in areas with significant temperature variations, exposure to
condensation or ice.
- Do not use the unit in areas exposed to direct sunlight.
- Make sure that the ambient temperature (e.g. inside the control box) does not
exceed the recommended values. In such cases forced cooling of the unit must
be considered (e.g. by using a ventilator).
 

2. GENERAL CHARACTERISTICS
Main task of !!"#$ is measurement of instantaneous flow (flow rate), and counting of
total flow (e.g. passage of fluid or gas ), The device can be used as regulator, to control
industrial process. Measurement of instantaneous flow can be indicated in range: 0 to 9999
(plus decimal point) and can be expressed in any scalable user units of flow and three time
measures (second, minute, hour). Total flow can be indicated in range from 0.000 to
4294967295 user units with maximum resolution of 0.00001 units.
!!"#$ can cooperate with flow sensors with current output (0-20mA or 4-20mA).
ensors can be powered from sensor supply output (stabilized, 24VDC +5%, -10% 100mA).
The meter is equipped in 2 or 4 relay outputs or Open Collector outputs, which can be
driven due to instantaneous flow, total flow or batcher counter value. Optionally !!"#$with
two relays outputs (or OC-type outputs) can be equipped with active current output, passive
isolated current output or active voltage output. Build in R 485 interface enables access to all
internal registers, and supports MODBU RTU communication protocol. The controller can be
ordered in two power supply versions.
Modern design guarantees high operational reliability. Front panel is protected from dust
and water spatters.
Additional features:
• alarm preset; alarm signal is released when measurement exceeds measurement range
• direct access to relays thresholds settings, without password,
• batcher mode.
5
!
!

User manual - FLOW METER SPP-94
3. TECHNICAL DATA
Power supply voltage
(depending on version)
External fuse (required)
Power consumption
85...%&'...260V AC/DC; 50 ÷ 60 Hz (separated)
or 19...%$...50V DC and 16...%$...35V AC (separated)
T - type, max. 2 A
max. 6.5 VA @ 85 ÷ 260V AC/DC
max. 6.5 VA @ 16V ÷ 35V AC
max. 6.5 W @ 19V ÷ 50V DC
( 0÷20 mA, 4÷20 mA overload protected,
maximum input current about 40 mA
Current measurement accuracy ± 0,1% @ 25°C; ± one digit (for 0÷20 mA range)
Measurement input resistance: 50 W
Accepted prolonged input overload: 20%
!
low level:
high level:
not separated
0V ÷ 1V
10V ÷ 30V (about. 12 mA @ 24V)
 24V +5%, -10% / max. 100 mA, stabilized
) 0, 2 or 4 NO 1A/250V AC (cos j = 1)
*(" 0, 2 or 4; 30mA / 30VDC / 100mW
+
(optional, for two relays or two
OC-type output version only)
range max. 0 ÷ 24 mA
Load resistance max. 700 W
!
(optional, for two relays or two
OC-type output version only)
range max. 2.8 ÷ 24 mA
upply voltage Us = 9.5 ÷ 36V
Load resistance max. (Us – 9.5V) / 24mA [kW]
6

User manual - FLOW METER SPP-94
+
(optional, for two relays or two
OC-type output version only)
range max. 0 ÷ 11V
Load resistance min. 2000 W
Instantaneous flow range 0 ÷ 9999, plus decimal point
Temperature stability 50 ppm / °C
Instantaneous flow precision elected from range: 0 ÷ 0.000
Instantaneous flow unit User unit per min. or sec. or hour
Total flow range over 4 x 109 units (max. 16 digits )
Total flow precision elected from range: 0 ÷ 0.000
Total flow unit Any, with precision, settable by user
Batcher counter range 65536 units
Batcher counter precision elected from range: 0 ÷ 0.000
Batcher counter unit Any, with precision, settable by user
Number of batches counter range 0 ÷ 999999
Communication interface R 485, 8N1 and 8N2, Modbus RTU, not separated
Baud rate 1200 bit/s ÷ 115200 bit/s
Display LED, 6 digit, 13mm height, red
Data memory non-volatile memory, EEPROM type
Protection level IP 65
optional version with panel cut-out sealing available
Terminals protection IP 20
Housing type
Housing material
Housing dimensions
Mounting hole
Assembly depth
Panel thickness
panel
NORYL - GFN2 E1
96 x 48 x 100 mm
90.5 x 43 mm
102 mm
max. 5 mm
Operating temperature
(depending on version)
0°C to +50°C
or -20°C to +50°C
torage temperature
(depending on version)
-10°C to +70°C
or -20°C to +70°C
Humidity
Altitude
5 to 90% no condensation
up to 2000 meters above sea level
crews tightening max. torque 0,5 Nm
Max. connection leads cross section 2,5 mm2
7

User manual - FLOW METER SPP-94
afety requirements according to: PN-EN 61010-1
installation category: II
pollution degree: 2
voltage in relation to ground: 300V AC
insulation resistance: >20MW
insulation strength between power supply and
input/output terminal: 1min. @ 2300V
insulation strength between relays terminal:
1min. @ 1350V
EMC according to: PN-EN 61326-1
,
,
4. DEVICE INSTALLATION
The unit has been designed and manufactured in a way assuring a high level of user
safety and resistance to interference occurring in a typical industrial environment. In order to
take full advantage of these characteristics installation of the unit must be conducted correctly
and according to the local regulations.
- Read the basic safety requirements on page 4 prior to starting the installation.
- Ensure that the power supply network voltage corresponds to the nominal
voltage stated on the unit’s identification label.
- The load must correspond to the requirements listed in the technical data.
- All installation works must be conducted with a disconnected power supply.
- Protecting the power supply clamps against unauthorized persons must be
taken into consideration.
4.1. UNPACKING
After removing the unit from the protective packaging, check for transportation damage. Any
transportation damage must be immediately reported to the carrier. Also, write down the unit
serial number on the housing and report the damage to the manufacturer.
Attached with the unit please find:
- user’s manual,
- warranty,
- assembly brackets - 2 pieces.
8
!
!

User manual - FLOW METER SPP-94
4.2. ASSEMBLY
- The unit is designed for mounting inside housings (control panel, switchboard)
insuring appropriate protection against surges and interference. Metal housings
must be connected to ground in a way that complies with the governing
regulations.
- Disconnect the power supply prior to starting assembly.
- Check the connections are wired correctly prior to switching the unit on.
In order to install the unit, a 90.5 x 43 mm mounting hole (-$.,$%) must be
prepared. The thickness of the material of which the panel is made must not exceed
5mm. When preparing the mounting hole take the grooves for catches located on
both sides of the housing into consideration (-$.,$%). Place the unit in the
mounting hole inserting it from the front side of the panel, and then fix it using the
brackets (-$&). The minimum distances between the centre points of multiple
units - due to the thermal and mechanical conditions of operation - are 115 mm x
67mm (-$$).
Figure 4.1. Recomme ded mou ti g hole dime sio s
9
!
!
90,5 mm
13 mm
8 mm
8 mm
13 mm
1 mm max. 5 mm
43 mm
1 mm

User manual - FLOW METER SPP-94
Figure 4.2. Allowable mou ti g hole dime sio s
Figure 4.3. I stalli g of brackets, a d dime sio s of co ectors.
Figure 4.4. Mi imum dista ces whe assembly of a umber of u its
10
115 mm
67 mm
92 mm
5 mm
12 mm 10 mm
8,5 mm
16 mm
92 mm
max. 5 mm
43 mm

User manual - FLOW METER SPP-94
4.3. CONNECTION METHOD
Caution
- Installation should be conducted by qualified personnel . During installation all
available safety requirements should be considered. The fitter is responsible for
executing the installation according to this manual, local safety and EMC
regulations.
- The unit is not equipped with an internal fuse or power supply circuit breaker.
Because of this an external time-delay cut-out fuse with minimal possible nominal
current value must be used (recommended bipolar, max. 2A) and a power supply
circuit-breaker located near the unit. In the case of using a monopolar fuse it must
be mounted on the phase cable (L).
- The power supply network cable diameter must be selected in such a way that in
the case of a short circuit of the cable from the side of the unit the cable shall be
protected against destruction with an electrical installation fuse.
- Wiring must meet appropriate standards and local regulations and laws.
- In order to secure against accidental short circuit the connection cables must be
terminated with appropriate insulated cable tips.
- Tighten the clamping screws. The recommended tightening torque is 0.5 Nm.
Loose screws can cause fire or defective operation. Over tightening can lead to
damaging the connections inside the units and breaking the thread.
- In the case of the unit being fitted with separable clamps they should be inserted
into appropriate connectors in the unit, even if they are not used for any
connections.
"/

,
- If the unit is equipped with housing, covers and sealing packing, protecting
against water intrusion, pay special attention to their correct tightening or clamping.
In the case of any doubt consider using additional preventive measures (covers,
roofing, seals, etc.). Carelessly executed assembly can increase the risk of electric
shock.
- After the installation is completed do not touch the unit’s connections when it is
switched on, because it carries the risk of electrical shock.



–Avoid common (parallel) leading of signal cables and transmission cables together with
power supply cables and cables controlling induction loads (e.g. contactors). uch cables
should cross at a right angle.
–Contactor coils and induction loads should be equipped with anti-interference protection
systems, e.g. RC-type.
11
!

User manual - FLOW METER SPP-94
–Use of screened signal cables is recommended. ignal cable screens should be
connected to the earthing only at one of the ends of the screened cable.
–In the case of magnetically induced interference the use of twisted couples of signal
cables (so-called “spirals”) is recommended. The spiral (best if shielded) must be used
with R -485 serial transmission connections.
–In the case of measurement or control signals are longer than 30m or go outside of the
building then additional safety circuits are required.
–In the case of interference from the power supply side the use of appropriate anti-
interference filters is recommended. Bear in mind that the connection between the filter
and the unit should be as short as possible and the metal housing of the filter must be
connected to the earthing with largest possible surface. The cables connected to the filter
output must not run in parallel with cables with interference (e.g. circuits controlling relays
or contactors).
Connections of power supply voltage and measurement signals are executed using the
screw connections on the back of the unit’s housing.
Figure 4.5. Method of cable i sulatio replaci g a d cable termi als
0 +1
0 -

0 (
 !!"#$
                

12
!
6-7 mm
max. 2 mm
.2
&.

User manual - FLOW METER SPP-94
Figure 4.6. Termi als descriptio (relay outputs)
Figure 4.7. Termi als descriptio (OC-type outputs)
Figure 4.8. Termi als descriptio (relay a d active curre t outputs)
13
!

(depending on version)
34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
). )% )&
)$
  

'"%'+
$"%'+

34
5



34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
*(. *(%
"5
*(.:*($; Umax = 30V DC,
Imax = 30mA, Pmax = 100mW
*(&
*($
5"5"
5"
  

!

(depending on version)
'"%'+
$"%'+

34
5



34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
).
"5
)%
 
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
!

(depending on version)
 
ACTIVE
current output

'"%'+
$"%'+

34
5




User manual - FLOW METER SPP-94
Figure 4.9. Termi als descriptio (relay a d passive curre t outputs)
Figure 4.10. Termi als descriptio (relay a d active voltage outputs)
Figure 4.11. Termi als descriptio (OC-type a d active curre t outputs)
14
34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
). )%
 
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
!
(
$:%'+

!

(depending on version)
  '"%'+
$"%'+

34
5



34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
).
"5
)%
 
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
!

(depending on version)
 
ACTIVE
voltage output

'"%'+
$"%'+

34
5



34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
"5
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
*(. *(%
"5
*(.:*(%; Umax = 30V DC,
Imax = 30mA, Pmax = 100mW
<
<
5"
 
ACTIVE
current output

!

(depending on version)
'"%'+
$"%'+

34
5




User manual - FLOW METER SPP-94
Figure 4.12. Termi als descriptio (OC-type a d passive curre t outputs)
Figure 4.13. Termi als descriptio (OC-type a d active voltage outputs)
15
34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
*(. *(%
"5
*(.:*(%; Umax = 30V DC,
Imax = 30mA, Pmax = 100mW
5"
 
 
!
(
$:%'+

!

(depending on version)
'"%'+
$"%'+

34
5



34 ++5
++"
) "$67
5/"
5%$8 +5%, -10%
Imax = 100mA
. % 7 2 9 6 #
.' .. .% .& .$ .7
& $
.2
&.
.9
&%
.6
&&
.#
&$
%'
&7
*(. *(%
"5
*(.:*(%; Umax = 30V DC,
Imax = 30mA, Pmax = 100mW
5"
 
 
!

(depending on version) "5
ACTIVE
voltage output

'"%'+
$"%'+

34
5




User manual - FLOW METER SPP-94
Depe di g o versio :
85...23 ...260V AC/DC or
19...24...50V DC; 16...24...35V AC
Figure 4.14. Co ectio of power supply a d relays
(,=
  
            ,       
         $9->   %7'8+(     
.'')>7=
      ,             


a) b)
Figure 4.15. Examples of suppressio circuit co ectio :
a) to relay termi als; b) to the i ductive load
16
)$
-/ ?
. %
@4
@4
.' .. .% .& .$ .7
& $
-/ ?
). )% )&
!
!
4
& $ & $
@@
4
!

User manual - FLOW METER SPP-94
Figure 4.16. Example of OC-type outputs co ectio
Figure 4.17. Example of active curre t outputs co ectio
(for device with active curre t output o ly)
Figure 4.18. Example of passive curre t outputs co ectio
(for device with passive curre t output o ly)
17
7 2.' ..
+
voltage input
24 V
-
Logic controller
"5
*(.
5"
/
7 2.' ..
"5
*(.
5"
/
)
%%
@?.'+
+
current input
0-20 mA
-
Logic controller
& $
"5
+(8?

"5
current input
4-20 mA
Logic controller
& $ 7 2
!+ 8?
 /
5"

!

User manual - FLOW METER SPP-94
Figure 4.19. Example of active voltage outputs co ectio
(for device with active voltage output o ly)
4.4. MAINTENANCE
The unit does not have any internal replaceable or adjustable components available to
the user. Pay attention to the ambient temperature in the room where the unit is operating.
Excessively high temperatures cause faster ageing of the internal components and shorten the
fault-free time of unit operation.
In cases where the unit gets dirty do not clean with solvents. For cleaning use warm water with
small amount of detergent or in the case of more significant contamination ethyl or isopropyl
alcohol.
Using any other agents can cause permanent damage to the housing.
Product marked with this symbol should not be placed in municipal waste. Please
check local regulations for disposal and electronic products.
18
!
+
voltage input
0 - 10V
-
Logic controller
& $
"5
+(8?


User manual - FLOW METER SPP-94
5. FRONT PANEL DESCRIPTION
Symbols and functions of push-buttons:
ymbol used in the manual:A? (>B?4/C
Functions:
• Enter to main menu ( press and hold by at least 2 sec.)
• Exit the current level and Enter to previous menu (or measure mode)
• Cancel the changes made in parameter being edited
or ymbol used in the manual:A?4?)CorA!+/ ?C
Functions ;
• tart to edit the parameter
• Enter to the sub-menu,
• Confirmation of changes made in parameter being edited
• While batcher mode: pause/start batching.
ymbol used in the manual:ADCAC
Functions ;
• Change of the present menu,
• Modification of the parameter value,
• Change of the display mode,
• witching of the display between relay thresholds and number of batches
counter
or ymbol used in the manual: ASCorA)? ?C
Functions ;
• witching of the display between total and instantaneous measurements
or batcher counter (while batcher mode only)
• Zeroing the currently displayed counter (press and hold by at least 2
sec.), the zeroing must be confirmed by A?4?)C button.
19
S
). )% )$ )&

!+/ ?
?4?)
)? ?

B?4/
? (
display
Thresholds exceedi g
LED i dicators (R) total flow mode
a d batchi g mode
LED i dicator ( S )
programmi g
pushbutto s
E

B?4/
? (
?4?)
S
-@

)? ?
E

!+/ ?
?4?)

User manual - FLOW METER SPP-94
6. PRINCIPLE OF OPERATION
After turning the power supply on, device ID and software version are showed on the
display, next the controller goes to the measurement mode.
6.1. MEASUREMENT MODE
In the measure mode, device displays instantaneous measurement (flow value or time
per one unit of flow, depending on „-!” parameter value) equivalent to input current, total
flow or batcher counter value.
Displayed value presentation is defined by parameters F-G, FG and FG
with resolution defined by parameters F-!?G, F!?G and F!?G.
... 879 876 543 . 219
“F unit” “F PrEc”
... 876 543 . 219
“F unit” “F PrEc”
Instantaneous flow (flow rate) is displayed in units defined by parameter F-G and
F-G (min., sec. or h), with resolution defined by F!G (max. 3 digits after decimal
point). Device converts measured current to selected units accordingly to conversion
characteristic selected by user. The measurement range equal to the nominal range is called:
nominal measurement range, and the measurement range equal to the extended nominal
range is called: permissible measurement range (Figure 6.1, 6.2).
Figure 6.1. Defi itio s of measureme t ra ges i mode 4 ÷ 20 mA
If the result of measurement exceeds the permissible measurement range, warning G"H"G or
G"@"G is displayed rather than input signal,depends on exceeded value (see description of
F@G or FHGparameters, paragraph ”FLouu” menu).
20
”@” parameter ”H” parameter
4 mA 20 mA
permissible measurement range
nominal measurement range
