Simplex 4100ES-S1 Maintenance and service guide

574-xxx
Rev. 4
Fire
Australian
Installation
Manual
4100ES-S1 Fire Indicator Panel
Installation & Maintenance
Australian
Installation &
Maintenance
Manual
LT0394
Issue 1.5

iii
Copyrights and Trademarks
2006, 2012 Tyco Australia Pty Limited. All Rights Reserved.
All specifications and other information shown were current as of document revision date,
and are subject to change without notice.
Tyco, Simplex, the Simplex logo, MAPNET II, IDNet, TrueAlarm, SmartSync,
WALKTEST, MINIPLEX, and TrueAlert are trademarks of Tyco International Services
AG or its affiliates in the U.S. and/or other countries. VESDA is a trademark of Xtralis.
Simplex fire alarm technology is protected by the following U.S. Patent Numbers:
TrueAlarm analog smoke detection: 5,155,468; 5,173,683 and 5,543,777. IDNet and
MAPNET II addressable communications; 4,796,025. TrueAlert addressable notification;
6,313,744 and 6,426,697. SmartSync horn/strobe control; 6,281,789.
Australian Standard AS 4428.1
ActivFire Listing Number afp1682
The 4100ES-S1 is a Fire Indicator Panel manufactured by Tyco Fire Protection Products
for:
Tyco Services Fire & Safety
47 Gilby Road
Notting Hill
VIC 3168
AUSTRALIA
Phone : [phone]
Fax : [phone]
Name
Serial #
Manufacture Date
Approvals
Manufacture
Product / Site

iv
Non-Disclosure Agreement
Tyco (THE COMPANY) and the User of this/these document(s) desire to share
proprietary technical information concerning electronic systems.
For this reason the company is disclosing to the User information in the form of this/these
document(s). In as much as the company considers this information to be proprietary and
desires that it be maintained in confidence, it is hereby agreed by the User that such
information shall be maintained in confidence by the User for a period of TEN YEARS
after the issue date and only be used for the purpose for which it was supplied.
During this period, the User shall not divulge such information to any third party without
the prior written consent of the company and shall take reasonable efforts to prevent any
unauthorised disclosure by its employees. However, the User shall not be required to
keep such information in confidence if it was in their possession prior to its receipt from
the company; if it is or becomes public knowledge without the fault of the User; or the
information becomes available on an unrestricted basis from a third party having a legal
right to disclose such information.
The User's receipt and retention of this information constitutes acceptance of these terms.
This information is copyright and shall not be reproduced in any form whatsoever.
The 4100ES-S1 Fire Indicator Panel provides a configuration programming facility,
which may be accessed via a programming computer using a “dongle”. Because this
programming facility allows the user to define in detail the operation of the 4100ES-S1
System being customised, changes may be made by the user that prevent this installation
from meeting statutory requirements.
The Company, therefore cannot accept any responsibility as to the suitability of the
functions generated by the user using this programming facility.
End User Liability Disclaimer

v
Model Number & Firmware Revision
This manual applies to product with the following:
Model number : 4100ES-S1
Firmware revision : 1.02.04 and on
Document Name : LT0394 4100ES-S1 Installation & Maintenance Manual
Issue : V1.5 14 June 2012
5 July 2006 Issue 1.0 Original based on LT0350 1.0.7
6 October 2006 Issue 1.1 References to LT0432 and 1976-181 Wiring Diagrams
added.
30 Nov. 2006 Issue 1.2 Updated drawings 1976-181 Sheets 102, 203, 500.
23 Jan. 2007 Issue 1.3 Changes to T-GEN connection, checking system wiring.
21 Feb. 2007 Issue 1.4 Changes to AIU/PPU Brigade Interface mounting
14 June 2012 Issue 1.5 Changes for 4100ES introduction
Document
Amendment Log

vi
Cautions, Warnings, and Regulatory Information
READ AND SAVE THESE INSTRUCTIONS. Follow the instructions in this
installation manual. These instructions must be followed to avoid damage to this product
and associated equipment. Product operation and reliability depends upon proper
installation.
DO NOT INSTALL ANY SIMPLEX®PRODUCT THAT APPEARS DAMAGED.
Upon unpacking your Simplex product, inspect the contents of the carton for shipping
damage. If damage is apparent, immediately file a claim with the carrier and notify your
Simplex product supplier.
SAFETY HAZARD - The 4100ES-S1 CPU Card includes a lithium battery. There is
danger of explosion if the battery is incorrectly replaced. Replace only with the same
or equivalent type recommended by the manufacturer. Dispose of used batteries according
to the manufacturer‟s instructions.
ELECTRICAL HAZARD -Disconnect electrical field power when making any internal
adjustments or repairs. All repairs should be performed by a representative or authorized
agent of your local Simplex product supplier.
STATIC HAZARD - Static electricity can damage components. Therefore, handle as
follows:
Ground yourself before opening or installing components (use a suitable wrist-strap
and cable clipped to the frame or an earth connection of the 4100ES-S1).
Prior to installation, keep components wrapped in anti-static material at all times.
EYE SAFETY HAZARD -Under certain fibre optic application conditions, the optical
output of this device may exceed eye safety limits. Do not use magnification (such as a
microscope or other focusing equipment) when viewing the output of this device.
RADIO FREQUENCY ENERGY - This equipment generates, uses, and can radiate
radio frequency energy and if not installed and used in accordance with the instruction
manual, may cause interference to radio communications. It has been tested and found to
comply with the limits defined in AS 4428.0-1997 and Amendment 1:2002.
SYSTEM REACCEPTANCE TEST AFTER SOFTWARE CHANGES -To ensure
proper system operation, this product must be tested in accordance with AS 1670 after
any programming operation or change in site-specific software. Reacceptance testing is
required after any change, addition or deletion of system components, or after any
modification, repair or adjustment to system hardware or wiring.
IMPORTANT: Verify 4100ES Programmer, Executive, and Slave Software
compatibility when installing or replacing system components. Refer to the relevant
Product Bulletins from Simplex Fire Products Australia (www.simplexfire.com.au) for
compatibility information.

vii
