SimTech SIMCom SIM7100-PCIE Supplement

SIM7100-PCIE(A)_Hardware Design_V1.01

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 22014-11-03
Document Title SIM7100-PCIE(A) Hardware Design
Version 1.01
Date 2014-11-03
Status Draft
Document
Control ID SIM7100-PCIE(A)_Hardware_Design_V1.01
General Notes
SIMCom offers this information as a service to its customers, to support application and engineering efforts that
use the products designed by SIMCom. The information provided is based upon requirements specifically
provided to SIMCom by the customers. SIMCom has not undertaken any independent search for additional
relevant information, including any information that may be in the customer’s possession. Furthermore, system
validation of this product designed by SIMCom within a larger electronic system remains the responsibility of
the customer or the customer’s system integrator. All specifications supplied herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of SIMCom Limited, copying
of this document and giving it to others and the using or communication of the contents thereof, are forbidden
without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of
grant of a patent or the registration of a utility model or design. All specification supplied herein are subject to
change without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2014

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 32014-11-03
Contents
SIM7100-PCIE_Hardware Design_V1.01................................................................................................................1
General Notes.............................................................................................................................................................. 2
Copyright..................................................................................................................................................................... 2
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2014................................................................................ 2
Contents....................................................................................................................................................................... 3
Table Index.................................................................................................................................................................. 5
Figure Index................................................................................................................................................................ 6
Version History........................................................................................................................................................... 7
1 Introduction..........................................................................................................................................................8
2 SIM7100-PCIE(A) Overview..............................................................................................................................9
2.1. SIM7100-PCIE(A) Key Features.............................................................................................................. 11
2.2. Operating Mode.........................................................................................................................................14
2.3. Functional Diagram...................................................................................................................................15
3 Package Information......................................................................................................................................... 16
3.1. Pin Out Diagram........................................................................................................................................16
3.2. PCI Express Mini Card Connector Pin Description................................................................................. 17
3.3. Package Dimensions..................................................................................................................................19
4 Application Interface.........................................................................................................................................20
4.1 Power Supply.............................................................................................................................................20
4.2 Power Saving Mode.................................................................................................................................. 20
4.2.1 Minimum Functionality Mode and Sleep Mode................................................................................... 20
4.2.2 Wake Up SIM7100-PCIE(A) from Sleep Mode....................................................................................21
4.3 USB 2.0..................................................................................................................................................... 21
4.3.1 USB Port Specification.......................................................................................................................... 21
4.3.2 Firmware Update....................................................................................................................................21
4.4 SIM Card Interface....................................................................................................................................22
4.5 PERST#..................................................................................................................................................... 22
4.6 W_DISABLE#.......................................................................................................................................... 23
4.7 LED_WWAN#.......................................................................................................................................... 23
4.8 WAKE#......................................................................................................................................................24
4.9 UART Interface......................................................................................................................................... 25
4.10 PCM/Analog Audio Interface....................................................................................................................27
4.10.1 PCM Interface.....................................................................................................................................27
4.10.2 Analog Audio Interface...................................................................................................................... 28
4.11 GNSS (GPS and GLONASS)................................................................................................................... 30
4.12 RF Antenna Connector.............................................................................................................................. 30
5 Electrical, Reliability and Radio Characteristics........................................................................................... 32
5.1. Absolute Maximum Ratings......................................................................................................................32
5.2. Recommended Operating Conditions....................................................................................................... 32
5.3. SIM Card Interface Characteristics........................................................................................................... 32
5.4. USIM_VDD Characteristics..................................................................................................................... 33

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 42014-11-03
5.5. Current Consumption (VCC =3.3V+0.3V/-0.1V).................................................................................... 33
5.6. Electro-Static Discharge............................................................................................................................34
5.7. Radio Characteristics.................................................................................................................................35
5.7.1. Conducted Output Power.......................................................................................................................35
5.7.2. Conducted Receive Sensitivity.............................................................................................................. 36
5.7.3. Supported Band......................................................................................................................................36
Appendix....................................................................................................................................................................37
I. SIM7100-PCIE(A) Top and Bottom View............................................................................................... 37
II. Dimensions of SIM7100-PCIE................................................................................................................. 38
III. Related Documents....................................................................................................................................40
IV. Terms and Abbreviations...........................................................................................................................41
V. Safety Caution........................................................................................................................................... 43
Contact us:.................................................................................................................................................................44
Shanghai SIMCom Wireless Solutions Ltd........................................................................................................... 44

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 52014-11-03
Table Index
TABLE 1: SIM7100-PCIE(A) SERIES FREQUENCY BANDS........................................................................................ 9
TABLE 2: SIM7100-PCIE(A) KEY FEATURES..............................................................................................................11
TABLE 3: CODING SCHEMES AND MAXIMUM NET DATA RATES OVER AIR INTERFACE............................ 12
TABLE 4: OPERATING MODE....................................................................................................................................... 14
TABLE 5: PCI EXPRESS MINI CARD CONNECTOR PIN DESCRIPTION................................................................ 17
TABLE 6: RECOMMENDED 3.3V POWER SUPPLY CHARACTERISTICS............................................................... 20
TABLE 7: THE CURRENT CONSUMPTION OF MINIMUM FUNCTIONALITY MODE (BS-PA-MFRMS=5)....... 20
TABLE 8: USB PORT SPECIFICATION......................................................................................................................... 21
TABLE 9: PERST# ELECTRICAL CHARACTERISTIC................................................................................................ 22
TABLE 10: FLIGHT MODE CONTROL FUNCTION.....................................................................................................23
TABLE 11: W_DISABLE# ELECTRICAL CHARACTERISTIC.................................................................................... 23
TABLE 12: NETWORK STATUS INDICATION PIN STATUS......................................................................................23
TABLE 13: UART ELECTRICAL CHARACTERISTIC..................................................................................................26
TABLE 14: PCM SPECIFICATION..................................................................................................................................27
TABLE 15: PCM DC CHARACTERISTICS.................................................................................................................... 28
TABLE 16: MIC INPUT CHARACTERISTICS............................................................................................................... 28
TABLE 17: AUDIO OUTPUT CHARACTERISTICS...................................................................................................... 28
TABLE 18: AUDIO PARAMETER...................................................................................................................................29
TABLE 19: RECOMMENDED PASSIVE ANTENNA CHARACTERISTICS................................................................30
TABLE 20: RECOMMENDED ACTIVE ANTENNA CHARACTERISTICS..................................................................30
TABLE 21: ABSOLUTE MAXIMUM RATINGS............................................................................................................ 32
TABLE 22: OPERATING CONDITIONS.........................................................................................................................32
TABLE 23: SIM CARD INTERFACE CHARACTERISTICS......................................................................................... 32
TABLE 24: USIM_VDD CHARACTERISTICS...............................................................................................................33
TABLE 25: CURRENT CONSUMPTION........................................................................................................................ 33
TABLE 26: ESD CHARACTERISTICS (TEMPERATURE: 25℃, HUMIDITY: 45 %)........................................... 35
TABLE 27: CONDUCTED OUTPUT POWER.................................................................................................................35
TABLE 28: CONDUCTED RECEIVE SENSITIVITY......................................................................................................36
TABLE 29: SUPPORTED BAND..................................................................................................................................... 36
TABLE 30: RELATED DOCUMENTS.............................................................................................................................40
TABLE 31: TERMS AND ABBREVIATIONS................................................................................................................. 41
TABLE 32: SAFETY CAUTION.......................................................................................................................................43

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 62014-11-03
Figure Index
FIGURE 1: SIM7100-PCIE(A) FUNCTIONAL DIAGRAM........................................................................................... 15
FIGURE 2: SIM7100-PCIE(A) PIN OUT DIAGRAM..................................................................................................... 16
FIGURE 3: DIMENSIONS OF SIM7100-PCIE(UNIT: MM).......................................................................................... 19
FIGURE 4: SIM CARD HOLDER REFERENCE CIRCUIT........................................................................................... 22
FIGURE 5: RESET TIMING............................................................................................................................................. 23
FIGURE 6: LED_WWAN# REFERENCE CIRCUIT....................................................................................................... 24
FIGURE 7: WAKE# BEHAVIOUR................................................................................................................................... 24
FIGURE 8: WAKE# BEHAVIOR AS A CALLER............................................................................................................25
FIGURE 9: WAKE# REFERENCE CIRCUIT.................................................................................................................. 25
FIGURE 10: UART1 FULL MODEM...............................................................................................................................26
FIGURE 11: NULL MODEM............................................................................................................................................26
FIGURE 12: REFERENCE CIRCUIT OF LEVEL SHIFT............................................................................................... 27
FIGURE 13: RECEIVER INTERFACE CONFIGURATION...........................................................................................28
FIGURE 14: MICROPHONE INTERFACE CONFIGURATION....................................................................................29
FIGURE 15: SIM7100-PCIE(A) TOP AND BOTTOM VIEW......................................................................................... 37
FIGURE 16: DIMENSIONS OF SIM7100-PCIE(A) (UNIT: MM TOP VIEW)...............................................................38
FIGURE 17: DIMENSIONS OF SIM7100-PCIE(A) (UNIT: MM BOTTOM AND SIDE VIEW)................................. 39

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 72014-11-03
Version History
Date Version Description of change Author
2014-11-03 1.01 Origin Yang Hongliang,
Li Ya

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 82014-11-03
1 Introduction
SIM7100-PCIE(A) module is PCI Express Mini Card. This document describes SIM7100-PCIE(A) hardware
interface in great detail, which can help user to quickly understand SIM7100-PCIE(A) interface specifications,
electrical and mechanical details.

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 92014-11-03
2 SIM7100-PCIE(A) Overview
SIM7100-PCIE(A) series support dual-band GSM/GPRS/EDGE and dual-band UMTS /HSPA+ that works on
frequencies of GSM 850MHz/EGSM 900 MHz, DCS 1800 MHz/PCS 1900MHz and WCDMA 850/900MHz,
1900/18000 MHz, 2100MHz,TDSCDMA band A and band B,LTE-FDD band1/2/3/4/5/6/7/8/13/17/20,
LTE-TDD band 38/39/40/41.
The modules can be chosen based on the wireless network configuration. In this document, the entire radio band
configuration of SIM7100-PCIE(A) series is described in the following table.
Table 1: SIM7100-PCIE(A) Series Frequency Bands
Standard Frequency SIM7100C-PCIE(A) SIM7100E-PCIE(A) SIM7100A-PCIE(A)
GSM
GSM 850MHz
EGSM 900MHz  
DCS1800MHz  
PCS1900MHz
WCDMA
WCDMA 850MHz 
WCDMA 900MHz  
WCDMA 1900MHz 
WCDMA 2100MHz  
TD-SCDM
A
1880-1920MHz 
2010-2025MHz 
HSPA HSDPA   
HSUPA   
HSPA+ HSPA+   
DC-HSPA+   
GNSS GPS   
GLONASS   
LTE-FDD
LTE-FDD B1  
LTE-FDD B2 
LTE-FDD B3  
LTE-FDD B4 
LTE-FDD B5 
LTE-FDD B7  
LTE-FDD B8  
LTE-FDD B13
LTE-FDD B17 
LTE-FDD B20 
LTE-TDD LTE TDD B38  
LTE TDD B39 

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 10
2014-11-03
LTE TDD B40  
LTE TDD B41
(100M BW)

SIM7100-PCIE(A) provides various hardware interfaces via Mini PCI Express card connector.
Power supply: : 3.3V+0.3/-0.1V
USB Interface
Audio Interface
UART Interface
SIM Interface
PCM Interface
W_DISABLE#
WAKE#
PERST#
LED_WWAN#

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 11
2014-11-03
2.1. SIM7100-PCIE(A) Key Features
Table 2: SIM7100-PCIE(A) Key Features
Feature Implementation
Power supply Single supply voltage 3.3V+0.3V/-0.1V
Transmission data
GPRS multi-slot class 12
EDGE multi-slot class 12
UMTS R99 speed: 384 kbps DL/UL
HSPA+: 5.76 Mbps(UL), 42 Mbps(DL)
TD-HSDPA/HSUPA: 2.2 Mbps(UL), 2.8 Mbps(DL)
LTE Category 3 - 100 Mbps (DL)
●LTE Category 3 - 50 Mbps (UL)
SMS
●MT, MO, CB, Text and PDU mode
●SMS storage: SIM card or ME(default)
●Support transmission of SMS alternatively over CSD or GPRS.
User can choose preferred mode.
SIM interface Support identity card: 1.8V, 3V.
USB Support USB2.0 Slave mode
Audio features(optional)
Only available on SIM7100X-PCIEA
Speech codec modes:
●Half Rate (ETS 06.20)
●Full Rate (ETS 06.10)
●Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80)
●AMR (WCDMA)
Serial interface
●Serial Port standard or null modem mode on Serial Port Interface
●Serial Port can be used to control module by sending AT command
Rx-diversity Support UMTS Rx-diversity.
Phonebook management Support phonebook types: SM, FD, LD, RC, ON, MC.
SIM application toolkit Support SAT class 3, GSM 11.14 Release 98
Support USAT
Physical characteristics Size: 50.95*31*4.95mm
Weight:10.8 g
Firmware upgrade Firmware upgrade over USB interface
PCM
Multiplex on GPIOs.
Only available on SIM7100X-PCIE
Used for analog audio function with external codec.
Support long frame sync and short frame sync.
Support 8-bit A-law, μ-law and 16-bit linear data formats.
Support master and slave mode, but must be the master in long frame
sync.
Temperature range
●Normal operation temperature: -30°C to +80°C
●Extended operation temperature: -40°C to +85°C
●Storage temperature -45°C to +90°C

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 12
2014-11-03
Table 3: Coding schemes and maximum net data rates over air interface
Multislot definition(GPRS/EDGE)
Slot class DL slot number UL slot number Active slot number
1 1 1 2
2 2 1 3
3 2 2 3
4 3 1 4
5 2 2 4
6 3 2 4
7 3 3 4
8 4 1 5
9 3 2 5
10 4 2 5
11 4 3 5
12 4 4 5
GPRS coding scheme Max data rata（4 slots）Modulation type
CS 1 = 9.05 kb/s / time slot 36.2 kb/s GMSK
CS 2 = 13.4 kb/s / time slot 53.6 kb/s GMSK
CS 3 = 15.6 kb/s / time slot 62.4 kb/s GMSK
CS 4 = 21.4 kb/s / time slot 85.6 kb/s GMSK
EDGE coding scheme Max data rata（4 slots）Modulation type
MCS 1 = 8.8 kb/s/ time slot 35.2 kb/s GMSK
MCS 2 = 11.2 kb/s/ time slot 44.8 kb/s GMSK
MCS 3 = 14.8 kb/s/ time slot 59.2 kb/s GMSK
MCS 4 = 17.6 kb/s/ time slot 70.4 kb/s GMSK
MCS 5 = 22.4 kb/s/ time slot 89.6 kb/s 8PSK
MCS 6 = 29.6 kb/s/ time slot 118.4 kb/s 8PSK
MCS 7 = 44.8 kb/s/ time slot 179.2 kb/s 8PSK
MCS 8 = 54.4 kb/s/ time slot 217.6 kb/s 8PSK
MCS 9 = 59.2 kb/s/ time slot 236.8 kb/s 8PSK
HSDPA device category Max data rate（peak）Modulation type
Category 1 1.2Mbps 16QAM,QPSK
Category 2 1.2Mbps 16QAM,QPSK
Category 3 1.8Mbps 16QAM,QPSK
Category 4 1.8Mbps 16QAM,QPSK
Category 5 3.6Mbps 16QAM,QPSK
Category 6 3.6Mbps 16QAM,QPSK
Category 7 7.2Mbps 16QAM,QPSK
Category 8 7.2Mbps 16QAM,QPSK
Category 9 10.2Mbps 16QAM,QPSK

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 13
2014-11-03
Category 10 14.4Mbps 16QAM,QPSK
Category 11 0.9Mbps QPSK
Category 12 1.8Mbps QPSK
Category 13 17.6Mbps 64QAM
Category 14 21.1Mbps 64QAM
Category 15 23.4Mbps 16QAM
Category 16 28Mbps 16QAM
Category 17 23.4Mbps 64QAM
Category 18 28Mbps 64QAM
Category 19 35.5Mbps 64QAM
Category 20 42Mbps 64QAM
Category 21 23.4Mbps 16QAM
Category 22 28Mbps 16QAM
Category 23 35.5Mbps 64QAM
Category 24 42.2Mbps 64QAM
HSUPA device category Max data rate（peak）Modulation type
Category 1 0.96Mbps QPSK
Category 2 1.92Mbps QPSK
Category 3 1.92Mbps QPSK
Category 4 3.84Mbps QPSK
Category 5 3.84Mbps QPSK
Category 6 5.76Mbps QPSK
LTE-FDD device category
(Downlink) Max data rate（peak）Modulation type
Category 1 10Mbps QPSK/16QAM/64Q
AM
Category 2 50Mbps QPSK/16QAM/64Q
AM
Category 3 100Mbps QPSK/16QAM/64Q
AM
Category 4 150Mbps QPSK/16QAM/64Q
AM
LTE-FDD device category
(Uplink) Max data rate（peak）Modulation type
Category 1 5Mbps QPSK/16QAM
Category 2 25Mbps QPSK/16QAM
Category 3 50Mbps QPSK/16QAM
Category 4 50Mbps QPSK/16QAM

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 14
2014-11-03
2.2. Operating Mode
The table below summarizes the various operating modes of SIM7100-PCIE.
Table 4: Operating Mode
Mode Status Function
Normal
operati
on
Sleep
GSM/GPRS/E
DGE/WCDM
A
/TD-SCDMA/
LTE
Module will automatically go into sleep mode if the
conditions of sleep mode are enabling and there is no on air
and no hardware interrupt (such as USB wake-up operation or
data on serial port).
In this case, the current consumption of module will be
reduced to the minimal level.
In sleep mode, the module can still receive paging message
and SMS.
Idle
GSM/WCDM
A/TD-SCDM
A/LTE
Software is active. Module is registered to the
GSM/WCDMA/LTE network, and the module is ready to
communicate.
Talk
GSM/WCDM
A/
TD-SCDMA/
LTE
Connection between two subscribers is in progress. In this
case, the power consumption depends on network settings
such as DTX off/on, FR/EFR/HR, hopping sequences,
antenna.
Standby
EDGE/HSPA
+/LTE
Module is ready for EDGE/HSPA+ /LTE data transfer, but no
data is currently sent or received. In this case, power
consumption depends on network settings and EDGE/HSPA+
/LTE configuration.
Data
transfer
EDGE/HSPA
+ /LTE
There is EDGE/HSPA+/LTE data transfer in progress. In this
case, power consumption is related to network settings (e.g.
power control level); uplink/downlink data rates and GPRS
configuration (e.g. used multi-slot settings).
Minimum
functionality mode
AT command “AT+CFUN” can be used to set the module to a minimum
functionality mode without removing the power supply. In this mode, the RF
part of the module will not work or the USIM card will not be accessible, or
both RF part and USIM card will be closed, and the serial port is still
accessible. The power consumption in this mode is lower than normal mode.

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 15
2014-11-03
2.3. Functional Diagram
The following figure is SIM7100-PCIE(A) functional diagram.
Figure 1: SIM7100-PCIE(A) Functional Diagram

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 16
2014-11-03
3 Package Information
3.1. Pin Out Diagram
Figure 2: SIM7100-PCIE(A) Pin Out Diagram

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 17
2014-11-03
3.2. PCI Express Mini Card Connector Pin Description
Table 5: PCI Express Mini Card Connector Pin Description
Pin name Pin number I/O Description Comment
Power supply
VCC 2,24,39,41,52 I 3.3 Power supply for module -
GND
4,9,15,18,21,
26,27,29,34,3
5,37,40,43,50
Ground -
Reset
PERST# 22 I Reset input (Active low) If this pin is unused,
keep open.
USB 2.0
USB_DP 38 I/O USB 2.0 high speed port for data transfer, voice
call, debug and FW download, etc.
If this pin is unused,
keep open.
USB_DN 36
SIM card interface
USIM_VDD 8 O 1.8/3.0V Configurable LDO output, default
1.8V output, maximum output current is 30mA -
USIM_DATA 10 I/O
SIM data input/output
-
USIM_CLK 12 O SIM clock -
USIM_RST 14 O SIM reset -
PCM interface
PCM_CLK 45 O PCM clock If these pins are
unused, keep open.
The PCM interface
can be used only on
SIM7100X-PCIE.
PCM_OUT 47 O PCM data output
PCM_IN 49 I PCM data input
PCM_SYNC 51 O PCM synchrony
UART interface
UART_CTS 11 I Clear to Send
If these pins are
unused, keep open
UART_RTS 13 O Request to send
UART_RXD 17 I Receive Data
UART_TXD 19 O Transmit Data
UART_RI 44 O Ring Indicator
UART_DTR 46 I DTE get ready
GPIO interface
GPIO9 30 I/O General input/output PIN. If these pins are
unused, keep open
GPIO6 32 I/O General input/output PIN.

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 18
2014-11-03
GPIO42 16 I/O General input/output PIN.
others
WAKE#/MIC1P 1
I Default: Wake up host
Optional：MIC positive input * If these pins are
unused, keep open.
If Analog audio is
available, wake up
function is invalid.
Analog audio is
only available on
SIM7100X-PCIEA
MIC1N 3
I Default：NC
Optional: MIC negative input *
EAR1P 5 O
Default: NC
Optional: Receiver positive output *
EAR1N 7 O Default: NC
Optional: Receiver negative output *
W_DISABLE# 20 IRF Control Input If this pin is unused,
keep open.
LED_WWAN# 42 O Network Status Indication output If this pin is unused,
keep open.
NC 6,23,25,28,31
,33,48 -- No connection Keep open

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 19
2014-11-03
3.3. Package Dimensions
Figure 3: Dimensions of SIM7100-PCIE(Unit: mm)
Note ： Please refer to appendix for package dimension details.

Smart Machine Smart Decision
SIM7100-PCIEA_Hardware_Design 20
2014-11-03
4 Application Interface
4.1 Power Supply
The recommended power supply voltage of SIM7100-PCIE(A) is 3.3V.
Table 6: Recommended 3.3V Power Supply Characteristics
Symbol Parameter Min Type Max Unit
VOPower supply voltage 3.2 3.3 3.6 V
IOSupply current capability 2000 - - mA
4.2 Power Saving Mode
SIM7100-PCIE(A) has two power saving modes: minimum functionality mode and sleep mode. When
SIM7100-PCIE(A) is in sleep mode and minimum functionality mode, the current of module is lowest.
4.2.1 Minimum Functionality Mode and Sleep Mode
The AT command “AT+CFUN=<fun>” can be used to set SIM7100-PCIE(A) into minimum functionality.
There are three functionality modes, which could be set by the AT command “AT+CFUN=<fun>”. The command
provides the choice of the functionality levels <fun>=0, 1, 4.
AT+CFUN=0: Minimum functionality.
AT+CFUN=1: Full functionality (default).
AT+CFUN=4: Flight mode (disable RF function).
Table 7: The Current Consumption of Minimum Functionality Mode (BS-PA-MFRMS=5)
<fun> Current consumption(mA) (sleep mode)
0 1.4
1 1.6
4 1.4
Minimum functionality mode minimizes the current consumption to the lowest level. If SIM7100-PCIE(A) is set
to minimum functionality by “AT+CFUN=0”, the RF function and SIM card function will be disabled. In this
case, the serial port and USB port are still accessible, but all AT commands correlative with RF function and SIM
card function will not be accessible.
Note: For detailed information about the AT Command “AT+CFUN=<fun>”, please refer to document
[1].
