The Shower Fan
screwed to the joist
The Manrose Shower Fan is designed exclusively for safe ventilation
within a shower cubicle. This fan is a high performance axial model with
high static pressure which enables additional ducting to be added to this
system, while still maintaining high levels of extraction.
Thank you for selecting our Manrose 150mm In-Line Fan Kit.
Please read all instructions before commencing installation.
1. First select the grille you prefer in your room. There are two designs a circular ceiling
grille which we recommend as the interior grille, and a fixed lourve design which is
suitable for the exterior.
2. The interior grille comes in two parts, the chassis (or spigot) and the circular fascia. If
using fixing clips cut a 165mm hole in the ceiling ensuring first that the area above is
free from obstruction. Alternatively cut a 155mm hole.
3. Fit 2 fixing clips supplied to the grill chassis then push the chassis (or spigot) section
into the hole in the ceiling. Alternatively mark the position of the fixing holes on the
ceiling, drill the holes and screw the grille chassis to the ceiling. Then refit the fascia to
the chassis by aligning the locking tabs and twisting clockwise to secure.
4. Select a suitable place for the Fan to be screwed to a joist and secure using two screws
through the fixing bracket. The fan motor is of ball bearing design to prolong the life of
the motor.
5. Select a suitable position either in the soffit or on an outside wall for the other grille
(fixed lourve), Carefully remove the grille insert from its housing by levering gently
at the sides with a small screwdriver. Cut a 160mm hole ensuring first that the area
above is free from obstruction.
6. Attach one end of the flexible duct to the spigot with the duct tape provided and from
the outside feed the duct through the hole until the grille is flush with the soffit/wall.
Mark the position of the fixing holes on the soffit/wall. Drill the holes and screw the
grille to the soffit/wall then refit the grille to the chassis.
Note: It is best not to cut the flexible duct until the grille has been screwed to the
outside surface to avoid the possibility of cutting the duct too short.
7. Pull the flexible duct gently to the discharge spigot of the fan and cut it to length and
connect to the fan with duct tape provided.
Note: The discharge end of the Fan unit is the end where you can see the fan
blade clearly.There is also an arrow on the unit showing airflow direction.
8. Connect the remaining piece of duct to the ceiling grille and onto the fan using the
duct tape provided. Note: Make sure wherever possible to keep the duct running in a
straight line as this will improve the performance of the fan.
IMPORTANT
 • Isolate the mains supply before making any electrical connections.
 • This system should be installed by a qualified electrician.
 • Whenttingthroughanexternalwall,anexternalgrillemustbettedatalltimes.
• Fanshouldonlybeinstalledbyxedwiring,aexiblecordshouldnotbeused.
• Theapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithout 
supervision.
• Youngchildrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
• Precautionsmustbetakentoavoidtheback-owofgasesintotheroomfromtheopen 
 ueofgasorotheropen-reapplianceswhenmountedinoutsidewindowsorwalls.
We reserve the right to change specification without prior warning
PUB7018 iss:05 01/13
Manrose is proudly distributed by Simx Limited
PO Box 14 347, Panmure, Auckland, NZ. Technical Support [phone]
e: [email protected] | www.simx.co.nz | www.manrose.com.au
CLASSICIN-LINEFANSF150MODELS
CLASSIC
INSTALLATION INSTRUCTIONS

9. Make the electrical connection as follows:
 WiringofStandardModelFAN0101-SF150S(Diagram1).
The fan can be connected to the light switch so that the fan will start when the light
is switched on, or a dedicated fan switch (not supplied). The fan should not be
accessible to a person using either the shower or the bath.
Note: All wiring must be fixed securely and the cable to the fan should be a minimum
of 1mm2in section. All wiring must comply with current Regulations. This system should
be installed by a qualified electrician.
WiringofTimerModelFAN0102-SF150T(Diagram2).
The fan can be connected to the light switch so that the fan will start when the light
is switched on, or a dedicated fan switch (not supplied). The fan should not be
accessible to a person using either the shower or the bath.
Note: All wiring must be fixed securely and the cable to the fan should be a minimum of
1mm2in section. All wiring must comply with current Regulations. This system should be
installed by a qualified electrician.
The timer mechanism supplied is a fixed timer which is installed in the flush box. This
means that the fan will run on for approx 3-7 minutes after it has been switched off
depending on how long the switch was on for. (see diagram 2 for wiring instructions, and
also instructions included with FAN0372 timer).
Please Note:
Thereisa45seconddelayafterswitchingthefanonuntilthemotorstarts,thisisto
prevent accidental triggering. This unit must be mains earthed.
Specifications:
Electrical: 220-240V ~50Hz
Wattage: 38W
Max Temp: 70°C
Airflow: 89l/s, 320m3/hr
BROWN
BLUE
LIVE
EARTH
NEUTRAL
GREEN/YELLOW
RED
BLACK
TIMER
FAN0372
LIVE
NEUTRAL
EARTH
LIGHT SWITCH
FLUSH BOX
(WALL MOUNTED)
BLUE
BROWN
GREEN/YELLOW
YELLOW
ORANGE
Diagram1
Diagram2
