Sinclair SDV5-MOD User manual

SDV5-MOD
COMMERCIAL AIR CONDITIONERS SDV5

CONTENTS
1 Overview
1.1 Maintenance by Customer
01
1.2 System Architecture
01
1.3 Installation Method
02
1.4 Preparation before installation
02
1.5 Function Codes for Commands
03
1.6 Error Responses
03
2 Using the Product
2.1 Configuring the PC IP Address
04
2.2 Configuring the Gateway
05
2.3 Restoring Factory Settings
06
2.4 Checking Air Conditioner Information
06
2.5 Examples
07
2.5.1 Modbus RTU Data Frame
07
2.5.2 Modbus TCP Data Frame
10
3 Mapping Tables of SDV5-MOD
3.1 Mapping Table Description — Discrete Inputs 12
3.1.1 IDU
12
3.1.2 ODU
13
3.2 Mapping Table Description — Input Registersles
14
3.2.1 IDU — HTHM
14
3.2.2 IDU — Non-HTHM
16
3.2.3 ODU
18
3.3 Mapping Table Description — Holding Registers 19

Once the installation work is completed, test to verify that the device is operating
normally, and hand over the manual to the customer for safekeeping.
Caution: Improper handling may lead to personal injury or material loss.
Warning: Improper handling may lead to death or serious injury.
!
!
Safety Precautions
The product, and its Operation and Installation Manual describes the following content, including
how to handle the product, prevent harm to others and prevent property losses, as well as how to
use the product correctly and safely. Read the following carefully and make sure you understand
the content (identifiers and marks), and observe the below precautions.
!
Caution
Read the safety precautions carefully prior to installation.
Make sure you observe the important safety precautions provided below.
Meanings of marks:
Get your distributor or a professional to install the product.
The installation personnel must be equipped with the
professional knowledge. When you install on your own, any
mistake you made during the operations may lead to a fire,
electric shock, or injury.
Icon
Warning
Name
Prohibited. Specific information about the prohibited item is described within the
icons or in the form of graphics or text next to where the symbol is located.
Mandatory. Specific information about the mandatory item is described within the
icons or in the form of graphics or text next to where the symbol is located.
Commissioned
installation
Do not use combustible paints to spray directly on the data
converter as this may cause a fire.
Do not handle the product with wet hands, and do not let water
seeps into the device, as this will cause electric shocks.
Using
Warning
Prohibited
Prohibited
!
Warning
Get your distributor or a professional to install the product.
Non-professionals may not install the equipment properly which may in turn lead to
electric shock or fire.
Do not install the product to where there is a danger of flammable gas leakages. Any
leakage within the vicinity of the device may cause a fire.
Caution
!
[Note] The "harm" means that the affected party does not need to be admitted to hospital or
require long-term treatment.This generally refers to wounds, scalds, or electric shocks.
Icons Material losses refer to property and material losses.

1 Overview
1.1 Maintenance by Customer
No. DescriptionName
1 Supplies power.GND 12V
2
Provides the Web service for debugging. Modbus settings
can be configured on the Web page.
Supports the Modbus TCP/IP protocol.
Supports Category 5 network cables.
LAN
3 Supports the Modbus RTU protocol.A1B1E
4 ReservedA2B2E
5 Connects to port X/Y/E of an ODU.XYE
SDV5-MOD supports the SDV5 and SDV5-3P models. *Note 1
SDV5-MOD supports a maximum of 8 refrigerant systems and 64 IDUs. The addresses of
IDUs and ODUs connected to SDV5-MOD cannot be duplicated. *Note 2 When a system
change occurs, SDV5-MOD needs to be restarted.
A third party can conduct integrated development through the Modbus RTU or Modbus TCP/IP
protocol.
*Note 1: For details about supported models, contact technical support engineers.
*Note 2: The addresses of IDUs connected to the same SDV5-MOD cannot be duplicated.
The addresses of ODUs must be unique.
1.2 System Architecture
01
X Y E
CTR1
X Y E
CTR2
X Y E
ODU

1.3 Installation Method
I. Structural Dimensions (Unit：mm)
Direction A
225
128
95
28
209
1.4
Preparation before installation
Check whether the following assemblies are complete
1
2
3
4
1
3
2
1
No. Name Qty. Remarks
SDV5-MOD
Installation Manual
For Mounting on the Wall
Plastic expansion pipe
Wall
6 mm bit drilling,
bit depth not less than 30 mm
Cross round head wood screw,
GB950-86 M4X20
II. Installation Diagram
02
Power Adapter
Accessory Bag
12V/2A

1.5 Function Codes for Commands
NO. Function Name Function
0x02 Read Discrete Inputs Reads data.
0x03 Read Holding Register Reads data.
0x04 Read Input Register Reads data.
0x06 Write Single Holding Register Writes data.
0x10 Write Holding Registers Writes data.
1.6 Error Responses
A third-party device serves as the master Modbus device while SDV5-MOD serves as the
slave device.
The master device sends a request and waits for a response from the slave device. When no error
occurs, the slave device responds normally. If a data check error occurs, the slave device does
not respond. When data sent by the master device have an error other than the data check error,
the slave device responds with an error.
Meaning
The slave device receives a function
code that cannot be executed.
The received data address is not supported by the
slave device.
Code
0x01
0x02
0x03
0x06
Name
Invalid function code
Invalid data address
Invalid data
The slave device is busy
The slave device is busy processing a time-consuming
programcommand and the master device needs to
send the messagewhen the slave device is idle.
The value queried in the data area is not supported
by the slave device.
03

2. Using the Product
2.1 Configuring the PC IP Address
The default IP address of the SDV5-MOD is 192.168.1.185. The PC used for accessing the
Web page of SDV5-MOD must be in the same network segment as SDV5-MOD.
Open the "Internet Protocol Version 4 (TCP/IPv4) Properties" dialogue box and set the IP address
and subnet mask, for example, set the IP address to 192.168.1.10 and the subnet mask to
255.255.255.0.
After configuration, click "OK".
Note: The above configuration is for reference purposes only. Please follow instructions of IT
personnel during actual projects.
04

2.2 Configuring the Gateway
In the address bar of the browser (*Note 3), enter "http://192.168.1.185:8586". The Web page of
the SDV5-MOD is displayed, as shown in the figure below.
*Note 3: Internet Explorer (IE) is the recommended browser.
The table below describes the parameters.
Parameter Description
SN Reserved
Version Software version
IP address of SDV5-MOD
IP address If the Modbus TCP/IP protocol is adopted, the IP addresses of the
SDV5-MOD gateways in the same network segment must be unique.
The default value is 255.255.255.0.
Mask
Enter the value according to actual project requirements.
Gateway Local gateway IP address
Baud rate: The default value is 9600.
Port setting Parity bit: There is no parity check by default.
Stop bit: The default value is 1 bit.
Modbus address
Modbus address If there are multiple SDV5-MOD gateways on the same bus,
their Modbus addresses cannot be duplicated.
After modifying parameters, click "Save" to save the settings.
After settings are modified, the SDV5-MOD automatically restarts.
05

2.3 Restoring Factory Settings
2.4 Checking Air Conditioner Information
Click the "DataView" tab on the Web page, and click "Discrete inputs" or "Holding registers" to
check information about air conditioners.
When "Discrete inputs" is selected, a page as shown in the figure below is displayed.
Press "SW1" three times consecutively within 5 seconds after SDV5-MOD is powered on, to
enable the device to enter the factory setting restoration mode. The RUN indicator blinks rapidly
at a frequency of 5 Hz. After factory settings are restored, the system automatically restarts, and
the RUN indicator blinks normally at a frequency of 1 Hz.
Click the address No. of an IDU or ODU. Operation information about the air conditioner is
displayed.
When "Holding registers" is selected, a page similar to the one shown in the figure below is
displayed.
06

In the figure above, the first column indicates addresses, the second column indicates register
names, the third column indicates original values, and the fourth column indicates parsed values.
2.5 Examples
2.5.1 Modbus RTU Data Frame
Request/Response:
Device Address Function Code Data Error Check and Correction
1 byte 1 byte N bytes 2 bytes
1) 0x02 Read Discrete Inputs
Example: Requesting the device to read discrete input addresses 0–15
Request packet: 01 02 00 00 00 0F 38 0E
Response packet: 01 02 02 05 05 7A EB
07

Domain Name (Hexadecimal Value) Domain Name (Hexadecimal Value)
Modbus address 1 Modbus address 1
Function code 2 Function code 2
Start address Hi (high byte) 0 Byte quantity 2
Start address Lo (low byte) 0 Input status 7-0 5
Output quantity Hi 0 Input status 15-8 5
Output quantity Lo 0F Check code Hi 7A
Check code Hi 38 Check code Lo EB
Check code Lo 0E
Request Packet Response Packet
2) 0x03 Read Holding Register
Example: Requesting the device to read data from holding registers 1–5
Request packet: 01 03 00 01 00 05 D4 09
Response packet: 01 03 0A 00 01 00 02 00 03 00 14 00 17 4E EC
"Hi" indicates the high byte while "Lo" indicates the low byte.
Request Packet Response Packet
Domain Name (Hexadecimal
Value)
Modbus address 1
Function code 3
Start address Hi 0
Start address Lo 1
Hi of the input register quantity 0
Lo of the input register quantity 5
Check code Hi D4
Check code Lo 9
Domain Name
Modbus address
Function code
Byte quantity
Hi of holding register 1
Lo of holding register 1
Hi of holding register 2
Lo of holding register 2
Hi of holding register 3
Lo of holding register 3
Hi of holding register 4
Lo of holding register 4
Hi of holding register 5
Lo of holding register 5
Check code Hi
Check code Lo
(Hexadecimal
Value)
1
3
0A
0
1
0
2
0
3
0
14
0
17
4E
EC
08

3) 0x04 Read Input Register
Example: Requesting the device to read data from input registers 32–34
Request packet: 01 04 00 20 00 03 B1 C1
Response packet: 01 04 06 00 05 00 0A 00 10 8D 5D
Domain Name (Hexadecimal
Value) Domain Name
Modbus address 1 Modbus address
Function code 4 Function code
Start address Hi 0 Byte quantity
Start address Lo 20 Hi of input register 32
Hi of the input register quantity 0 Lo of input register 32
Lo of the input register quantity 3 Hi of input register 33
Check code Hi B1 Lo of input register 33
Check code Lo C1 Hi of input register 34
Lo of input register 34
Check code Hi
Check code Lo
(Hexadecimal
Value)
1
4
6
0
5
0
0A
0
10
8D
5D
Request Packet Response Packet
4) 0x06 Write Single Holding Register
Example: Requesting the device to write the hexadecimal 00 14 to register 4
Request packet: 01 06 00 04 00 14 C8 04
Response packet: 01 06 00 04 00 14 C8 04
Domain Name (Hexadecimal
Value) Domain Name (Hexadecimal Value)
Modbus address 1 Modbus address 1
Function code 6 Function code 6
Register address Hi 0 Output address Hi 0
Register address Lo 4 Output address Lo 4
Register value Hi 0 Output value Hi 0
Register value Lo 14 Output value Lo 14
Check code Hi C8 Check code Hi C8
Check code Lo 4 Check code Lo 4
Request Packet Response Packet
09

5) 0x10 Write Multiple Holding Registers
Example: Requesting the device to write the hexadecimal 00 02 and 00 01 to two registers beginning with 2
Request packet: 01 10 00 02 04 00 02 00 01 12 76
Response packet: 01 10 00 02 00 02 E0 08
(Hexadecimal
Value) Domain Name
1 Modbus address
10 Function code
0 Start address Hi
2 Start address Lo
4 Hi of the register quantity
0 Lo of the register quantity
2 Check code Hi
0 Check code Lo
(Hexadecimal
Value)
1
10
0
2
0
12
E0
8
1
12
Domain Name
Modbus address
Function code
Start address Hi
Start address Lo
Byte quantity
Register value Hi
Register value Lo
Register value Hi
Register value Lo
Check code Hi
Check code Lo 76
Request Packet Response Packet
2.5.2 Modbus TCP Data Frame
10

5) 0x10 Write Multiple Holding Registers
Example: Requesting the device to write the hexadecimal 00 02 and 00 01 to two registers beginning with 2
Request packet: 01 10 00 02 04 00 02 00 01 12 76
Response packet: 01 10 00 02 00 02 E0 08
1) 0x02 Read Discrete Inputs
Example: Requesting the device to read discrete input addresses 0–15
Request packet: 46 25 00 00 00 06 01 02 00 00 00 0F
Response packet: 46 25 00 00 00 05 01 02 02 05 05
2) 0x03 Read Holding Register
Example: Requesting the device to read data from holding registers 1-5
Request packet: C5 E4 00 00 00 06 01 03 00 01 00 05
Response packet: C5 E4 00 00 00 0D 01 03 0A 00 01 00 03 00 05 00 14 00 17
3) 0x04 Read Input Register
Example: Requesting the device to read data from input registers 32–34
Request packet: 46 9F 00 00 00 06 01 04 00 20 00 03
Response packet: 46 9E 00 00 00 09 01 04 06 00 05 00 0A 00 10
4) 0x06 Write Single Holding Register
Example: Requesting the device to write the hexadecimal 00 14 to register 4
Request packet: 47 A6 00 00 00 06 01 06 00 04 00 14
Response packet: 47 A6 00 00 00 06 01 06 00 04 00 14
5) 0x10 Write Multiple Holding Registers
Example: Requesting the device to write the hexadecimal 00 02 and 00 01 to two registers
beginning with 2
Request packet: 48 03 00 00 00 0B 01 10 00 02 04 00 02 00 01
Response packet: 48 03 00 00 00 06 01 10 00 02 00 02
11

3. Mapping Tables of SDV5-MOD
3.1 Mapping Table Description — Discrete Inputs
Type Offset Address (Modbus Poll Actual Input Address)
Discrete input Protocol address = Register address – 10001
Input register Protocol address = Register address – 30001
Holding register Protocol address = Register address – 40001
3.1.1 IDU
Discrete inputs are applicable only to IDUs and ODUs. High temperature hydraulic modules
(HTHMs) are a type of IDU.
Discrete Input Function
Code Register Address Data Length Meaning
2 10001 1bit 0 - Off, 1 - On
2 10002 1bit 0 - No error, 1 - Error
2 10003 1bit 0 - Offline, 1 - Online
2 10004 1bit Reserved
2 10005 1bit Reserved
2 10006 1bit Reserved
2 10007 1bit Reserved
2 10008 1bit Reserved
2 10009 1bit 0 - Off, 1 - On
2 10010 1bit 0 - No error, 1 - Error
2 10011 1bit 0 - Offline, 1 - Online
2 10012 1bit Reserved
2 10013 1bit Reserved
2 10014 1bit Reserved
2 10015 1bit Reserved
2 10016 1bit Reserved
... …
IDU0
IDU1
12

2 n*8+1+10000 1bit 0 - Off, 1 - On
2 n*8+2+10000 1bit 0 - No error, 1 - Error
2 n*8+3+10000 1bit 0 - Offline, 1 - Online
2 n*8+4+10000 1bit Reserved
2 n*8+5+10000 1bit Reserved
2 n*8+6+10000 1bit Reserved
2 n*8+7+10000 1bit Reserved
2 n*8+8+10000 1bit Reserved
IDUn
(The valid
value of n
ranges from 0
to 63.)
Discrete Input Function
Code Register Address Data Length Meaning
3.1.2 ODU
Discrete inputs are applicable only to IDUs and ODUs. High temperature hydraulic modules
(HTHMs) are a type of IDU.
Discrete Input Function
Code Register Address Data Length Meaning
2 11001 1bit 0 - Off, 1 - On
2 11002 1bit 0 - No error, 1 - Error
2 11003 1bit 0 - Offline, 1 - Online
2 11004 1bit Reserved
2 11005 1bit Reserved
2 11006 1bit Reserved
2 11007 1bit Reserved
2 11008 1bit Reserved
... …
2 n*8+1001+10000 1bit 0 - Off, 1 - On
2 n*8+1002+10000 1bit 0 - No error, 1 - Error
2 n*8+1003+10000 1bit 0 - Offline, 1 - Online
2 n*8+1004+10000 1bit Reserved
2 n*8+1005+10000 1bit Reserved
2 n*8+1006+10000 1bit Reserved
2 n*8+1007+10000 1bit Reserved
2 n*8+1008+10000 1bit Reserved
ODUn
(The valid
value of n
ranges from 0
to 31.)
ODU0
13

3.2 Mapping Table Description — Input Registers
The specific functions of input registers depend on the models. For example, register address
30002 indicates the set temperature for heating when the IDU is an HTHM and indicates the fan
speed when the IDU is a non-HTHM VRF unit.
3.2.1 IDU — HTHM
If an HTHM is used, the register addresses are parsed as shown in the table below.
Read Input
Register
Function
Code
Register
Address
Data
Length
Variable Name (HTHM) Meaning
4 30001 2bytes Operating mode 0 - Off, 3 - Heat, 7 - Water heating
4 30002 2bytes Set temperature for heating Actual temperature (Celsius) × 10
4 30003 2bytes Set temperature for water heating Actual temperature (Celsius) × 10
4 30004 2bytes Water inlet temperature Actual temperature (Celsius) × 10
4 30005 2bytes Water outlet temperature Actual temperature (Celsius) × 10
4 30006 2bytes Water tank temperature Actual temperature (Celsius) × 10
4 30007 2bytes Error code
4 30008 2bytes Heating mode lock 0 - Unlimit, 1 - On, 2 - Off
4 30009 2bytes Water heating mode lock 0 - Unlimit, 1 - On, 2 - Off
4 30010 2bytes
Lock of set temperature
for heating
0xFFFF indicates Unlimit.
0xFFFE indicates Lock.
Specific temperature values:
Actual temperature (Celsius) × 10
4 30011 2bytes
Lock of set temperature
for water heating
It is parsed according to the
protocol.
0xFFFF indicates Unlimit.
0xFFFE indicates Lock.
Specific temperature values:
Actual temperature (Celsius) × 10
4 30012 2bytes Reserved Reserved
4 30013 2bytes Reserved Reserved
4 30014 2bytes Model Model: 0 – VRF unit, 1 – HTHM
4 30015 2bytes Reserved Reserved
4 30016 2bytes Reserved Reserved
...
IDU0
14

4 30001+n*16 2bytes Operating mode 0 - Off, 3 - Heat, 7 - Water heating
4 30002+n*16 2bytes Set temperature for heating Actual temperature (Celsius) × 10
4 30003+n*16 2bytes Set temperature for water heating Actual temperature (Celsius) × 10
4 30004+n*16 2bytes Water inlet temperature Actual temperature (Celsius) × 10
4 30005+n*16 2bytes Water outlet temperature Actual temperature (Celsius) × 10
4 30006+n*16 2bytes Water tank temperature Actual temperature (Celsius) × 10
4 30007+n*16 2bytes Error code
4 30008+n*16 2bytes Heating mode lock 0 - Unlimit, 1 - On, 2 - Off
4 30009+n*16 2bytes Water heating mode lock 0 - Unlimit, 1 - On, 2 - Off
4 30010+n*16 2bytes Lock of set temperature for heating
0xFFFF indicates Unlimit.
0xFFFE indicates Lock.
Specific temperature values: Actual
temperature (Celsius) × 10
4 30011+n*16 2bytes Lock of set temperature for water
heating
It is parsed according to the protocol.
0xFFFF indicates Unlimit.
0xFFFE indicates Lock.
Specific temperature values: Actual
temperature (Celsius) × 10
4 30012+n*16 2bytes
4 30013+n*16 2bytes
4 30014+n*16 2bytes Model Model: 0 – VRF unit, 1 – HTHM
4 30015+n*16 2bytes
4 30016+n*16 2bytes
IDUn
Low byte of error code + bit 0 of high byte of error code
0: No error
1~20: A0~AF,AH,AL,AP,AU
21~40: b0~bF,bH,bL,bP,bU
41~60: C0~CF,CH,CL,CP,CU
61~80: E0~EF,EH,EL,EP，EU
81~100: F0~FF,FH,FL,FP,FU
101~120: H0~HF,HH,HL,HP,HU
121~140: L0~LF,LH,LL,LP,LU
141~160: J0~JF,JH,JL,JP,JU
161~180: n0~nF,nH,nL,nP,nU
181~200: P0~PF,PH,PL,PP,PU
201~220: r0~rF,rH,rL,rP,rU
221~240: t0~tF,tH,tL,tP,tU
241~260: U0~UF,UH,UL,UP,UU
15

3.2.2 IDU — Non-HTHM
If a non-HTHM IDU is used, the register addresses are parsed as shown in the table below.
Read Input
Register
Function
Code
Register
Address
Data
Length
Variable Name
(VRF Unit) Meaning
4 30001 2bytes Mode
VRF unit mode
0 - Off, 1 -Fan, 2 - Cool, 3 - Heat, 4 - Auto, 5 -
Dry
HRV mode
0 - Off, 1 - Free cool, 2 - Heat exchange, 3 -
Bypass, 4 - Auto
4 30002 2bytes Fan speed
0 - Fan stop, (DC fan: seven fan speeds)
speeds 1-7; (AC fan: three fan speeds),
8 - Breeze, 9 - Low speed, 10 - Medium speed,
11 - High speed, 12 - Auto
4 30003 2bytes Set temperature/Dual-setpoint
cooling temperature Actual temperature × 10
4 30004 2bytes Dual-setpoint heating
temperature Actual temperature × 10
4 30005 2bytes Indoor temperature Actual temperature × 10
4 30006 2bytes Error code Error codes: 0 to 255
4 30007 2bytes Mode lock Mode lock: 0 - Unlock, 1 - Lock cool, 2 - Lock
heat
4 30008 2bytes Fan speed lock
Fan speed lock: 0 - Unlock (DC fan, seven fan
speeds), 1 - Lock speed 1, 2 - Lock speed 2, 3
- Lock speed 3, 4 - Lock speed 4, 5 - Lock
speed 5, 6 - Lock speed 6, 7 - Lock speed 7;
(AC fan, three fan speeds) 9 - Lock low
speed,10 - Lock medium speed, 11 - Lock high
speed
4 30009 2bytes Remote controller lock Remote controller lock: 0 - Unlock, 1 - Lock
4 30010 2bytes Wired controller lock Wired controller lock: 0 - Unlock, 1 - Lock
4 30011 2bytes Lower limit of cooling
temperature
Lower limit of cooling temperature:
0xFFFF - Unlock
Other values: Actual temperature × 10
4 30012 2bytes Upper limit of heating
temperature
Upper limit of heating temperature:
0xFFFF - Unlock
Other values: Actual temperature × 10
4 30013 2bytes Swing lock Swing lock: 0 - Unlock, 1 - Lock
4 30014 2bytes Model Model: 0 – VRF unit, 1 – HTHM
4 30015 2bytes Reserved Reserved
4 30016 2bytes Reserved Reserved
IDU0
…
16

4 30001+n*16 2bytes Mode
VRF unit mode
0 - Off, 1 -Fan, 2 - Cool, 3 - Heat, 4 - Auto, 5 - Dry
HRV mode
0 - Off, 1 - Free cool, 2 - Heat exchange, 3 - Bypass, 4 -
Auto
4 30002+n*16 2bytes Fan speed
0 - Fan stop, (DC fan: seven fan speeds) speeds 1-7; (AC
fan: three fan speeds), 8 - Breeze, 9 - Low speed, 10 -
Medium speed, 11 - High speed, 12 - Auto
4 30003+n*16 2bytes Set temperature/Dual-setpoint
cooling temperature Actual temperature × 10
4 30004+n*16 2bytes Dual-setpoint heating
temperature Actual temperature × 10
4 30005+n*16 2bytes Indoor temperature Actual temperature × 10
4 30006+n*16 2bytes Error code Error codes: 0 to 255
4 30007+n*16 2bytes Mode lock Mode lock: 0 - Unlock, 1 - Lock cool, 2 - Lock heat
4 30008+n*16 2bytes Fan speed lock
Fan speed lock: 0 - Unlock (DC fan, seven fan speeds), 1
- Lock speed 1, 2 - Lock speed 2, 3 - Lock speed 3, 4 -
Lock speed 4, 5 - Lock speed 5, 6 - Lock speed 6, 7 -
Lock speed 7; (AC fan, three fan speeds) 9 - Lock low
speed,10 - Lock medium speed, 11 - Lock high speed
4 30009+n*16 2bytes Remote controller lock Remote controller lock: 0 - Unlock, 1 - Lock
4 30010+n*16 2bytes Wired controller lock Wired controller lock: 0 - Unlock, 1 - Lock
4 30011+n*16 2bytes Lower limit of cooling
temperature
Lower limit of cooling temperature:
0xFFFF - Unlock
Other values: Actual temperature × 10
4 30012+n*16 2bytes Upper limit of heating
temperature
Upper limit of heating temperature:
0xFFFF - Unlock
Other values: Actual temperature × 10
4 30013+n*16 2bytes Swing lock Swing lock: 0 - Unlock, 1 - Lock
4 30014+n*16 2bytes Model Model: 0 – VRF unit, 1 – HTHM
4 30015+n*16 2bytes Reserved
4 30016+n*16 2bytes Reserved
IDUn
17
