Sinclair SDV5 Series User manual

INDOOR HIGH STATIC PRESSURE DUCT UNITS SDV5-xxDHA
COMMERCIAL AIR CONDITIONERS SDV5

Original instructions
IMPORTANT NOTE:
Read this manual carefully before installing or operating
your new air conditioning unit. Make sure to save this
manual for future reference.

201806 3
High Static Pressure Duct
1 Specifications .......................................................................................... 4
2 Dimensions ............................................................................................. 7
3 Unit Placement ..................................................................................... 10
4 Piping Diagrams .................................................................................... 11
5 Wiring Diagrams.................................................................................... 12
6 Fan Performance ................................................................................... 15
7 Capacity Tables...................................................................................... 18
8 Electrical Characteristics........................................................................ 28
9 Sound Levels ......................................................................................... 29

4 201806
1Specifications
SDV5-71DHA / SDV5-80DHA / SDV5-90DHA
Table 1.1: SDV5-71,80,90DHA specifications
Model name
SDV5-71DHA SDV5-80DHA SDV5-90DHA
Power supply
1-phase, 220-240V, 50Hz
Cooling1
Capacity
kW
7.1
8
9
kBut/h
24.2
27.3
30.7
Input
W
180
180
220
Heating2
Capacity
kW
8
9
10
kBut/h
27.3
30.7
34.1
Input
W
180
180
220
Fan motor
Model
WZDK750-38G-W
WZDK750-38G-W
WZDK750-38G-W
Type
DC
Brand
Panasonic/ Welling
Speed (H/M/L)
r/min 970/950/940/910/880/860/840 980/950/930/900/870/840/810
Coil
Number of rows
2
2
3
Tube pitch × row
pitch
mm 25.4×22
25.4×22
25.4×22
Fin spacing
mm 1.5
1.5
1.6
Fin type
Hydrophilic aluminum
Tube OD and type
mm Ф9.53 Inner groove
Dimensions (L×H
×W)
mm 700×356×44
700×356×44
700×356×66
Number of circuits
3
3
7
Airflow rate3
m3/h
1360/1327/1293/1260/1227/1193/1160
1420/1373/1327/1280/
1233/1187/1140
External static pressure4
Pa
100 (30~ 200)
Sound pressure level5
dB(A)
46/46/45/45/44/43/42
46/46/45/45/44/43/42
50/49/48/48/47/46/45
Unit
Net dimensions6
(W×H×D)
mm
965.5×423.5×690
Packed dimensions
(W×H×D)
mm
1090×440×768
Net/Gross weight
kg
41/47
41/47
51/57
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Model
BD20FKS(L)
Design pressure (H/L)
MPa
4.4/2.6
Pipe
connections
Liquid/Gas pipe
mm
Ф9.53/Ф15.9
Drain pipe
mm
OD Ф25
Notes:
1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
4. Stable operation external static pressure range. (Note: setting external static pressure outside the unit’s optimal static pressure range may lead to
higher noise levels and lower airflow rate. For the optimal external static pressure range refer to the unit’s installation manual.)
5. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1.4m below the unit in a
semi-anechoic chamber.
6. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.

201806 5
SDV5-112DHA / SDV5-140DHA / SDV5-160DHA
Table 1.2: SDV5-112,140,160DHA specifications
Model name
SDV5-112DHA SDV5-140DHA SDV5-160DHA
Power supply
1-phase, 220-240V, 50Hz
Cooling1
Capacity
kW
11.2
14
16
kBut/h
38.2
47.8
54.6
Input
W
380
420
700
Heating2
Capacity
kW
12.5
16
17
kBut/h
42.7
54.6
58
Input
W
380
420
700
Fan motor
Model
WZDK750-38G-W
WZDK750-38GS-W
WZDK750-38GS-W
Type
DC
Brand
Panasonic/ Welling
Speed (H/M/L)
r/min
1110/1070/1010/970/
920/870/840
1015/975/935/905/
845/805/765
1080/1050/1000/960/
920/870/830
Coil
Number of rows
3
4
4
Tube pitch × row pitch
mm 25.4×22
25.4×22
25.4×22
Fin spacing
mm 1.6
1.6
1.6
Fin type
Hydrophilic aluminum
Tube OD and type
mm Ф9.53 Inner groove
Dimensions (L×H ×W)
mm 700×356×66
996×356×88
996×356×88
Number of circuits
7
7
7
Airflow rate3
m3/h 1870/1783/1697/1610/
1523/1437/1350
2240/2133/2027/1920/
1813/1707/1600
2660/2530/2400/2270/
2140/2010/1880
External static pressure4
Pa
100 (30~ 200)
Sound pressure level5
dB(A)
50/50/49/48/47/46/45
53/52/51/51/50/49/48
54/54/53/52/51/50/50
Unit
Net dimensions6(W×H×D)
mm
965.5×423.5×690
1322×423×691
1322×423×691
Packed dimensions
(W×H×D)
mm
1090×440×768
1436×450×768
1436×450×768
Net/Gross weight
kg
51/57
63/70
63/70
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Model
BD20FKS(L)
Design pressure (H/L)
MPa
4.4/2.6
Pipe
connections
Liquid/Gas pipe
mm
Ф9.53/Ф15.9
Drain pipe
mm
OD Ф25
Notes:
1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
4. Stable operation external static pressure range. (Note: setting external static pressure outside the unit’s optimal static pressure range may lead to
higher noise levels and lower airflow rate. For the optimal external static pressure range refer to the unit’s installation manual.)
5. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1.4m below the unit in a
semi-anechoic chamber.
6. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.

6 201806
SDV5-200DHA / SDV5-250DHA / SDV5-280DHA
Table 1.3: SDV5-200,250,280DHA specifications
Model name
SDV5-200DHA SDV5-250DHA SDV5-280DHA
Power supply
1-phase, 220-240V, 50Hz
Cooling1
Capacity
kW
20
25
28
kBut/h
68.2
85.3
95.5
Input
W
990
990
1200
Heating2
Capacity
kW
22.5
26
31.5
kBut/h
76.8
88.7
107.5
Input
W
990
990
1200
Fan motor
Model
ZKSN-920-8-12
ZKSN-920-8-12
ZKSN-920-8-12
Type
DC
Brand
Nidec/Yongan
Speed (H/M/L)
r/min
1210/1180/1150/1130/1100/1080/1050
Coil
Number of rows
4
4
4
Tube pitch × row pitch
mm 25.4×22
25.4×22
25.4×22
Fin spacing
mm 1.8
1.8
1.8
Fin type
Hydrophilic aluminum
Tube OD and type
mm Ф9.53 Inner groove
Dimensions (L×H ×W)
mm 1125×512×88
1125×512×88
1125×512×88
Number of circuits
20
20
20
Airflow rate3
m3/h 4330/4230/4130/4030/3930/3830/3730
External static pressure4
Pa 170 (20~250)
Sound pressure level5
dB(A) 57/56/55/54/53/52/50
Unit
Net dimensions6(W×H×D)
mm
1454×515×931
Packed dimensions
(W×H×D)
mm
1509×550×990
Net/Gross weight
kg
130/142
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Model
D20MISZ-1R(L)
Design pressure (H/L)
MPa
4.4/2.6
Pipe
connections
Liquid/Gas pipe
mm
Ф12.7/Ф22.2
Drain pipe
mm
OD Ф32
Notes:
1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.
4. Stable operation external static pressure range. (Note: setting external static pressure outside the unit’s optimal static pressure range may lead to
higher noise levels and lower airflow rate. For the optimal external static pressure range refer to the unit’s installation manual.)
5. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured 1.4m below the unit in a
semi-anechoic chamber.
6. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.

201806 7
2Dimensions
2.1 Unit Dimensions
SDV5-71DHA / SDV5-80DHA / SDV5-90DHA / SDV5-112DHA
Figure 2.1: SDV5-71,80,90,112DHA dimensions (unit: mm)
(L)
Size of ReturnAir Inlet
(L)
(W)
Refrigerant piping (gas side)
Refrigerant piping (liquid side) Position of lifting bolt
Connection for water discharge piping
Flange connection hole
ReturnAir Inlet Flange
Return Air Inlet Flange
Electric control box assembly
Return Air Inlet
Air Outlet
Size ofAir Outlet
(W)

8 201806
SDV5-140DHA / SDV5-160DHA
Figure 2.2: SDV5-140,160DHA dimensions (unit: mm)
(W)
Size of ReturnAir Inlet
(W)
(L)
Size ofAir Outlet
(L)
Refrigerant piping (gas side)
Refrigerant piping (liquid side) Connect to water
piping
Position of lifting bolt
ReturnAir Inlet Flange
ReturnAir Inlet Flange
Connection hole
Electric control box assembly
Return Air Inlet
Air Outlet

201806 9
SDV5-200DHA / SDV5-250DHA / SDV5-280DHA
Figure 2.3:SDV5-200,250,280DHA dimensions (unit: mm)
Size of ReturnAir Inlet
Position of lifting bolt
Size of Air Outlet
Refrigerant piping (gas side)
Refrigerant piping (liquid side)
Connect to water piping
Return Air Inlet
Air Outlet
Positions of 4-12*25 lifting bolts
Electric control box assembly
Connection hole (for the air duct)

10 201806
3Unit Placement
3.1 Placement Considerations
Unit placement should take account of the following considerations:
Units should not be installed in the following locations:
Where exposure to direct radiation from a high-temperature heat source or to interference from a source of
electromagnetic radiation may occur.
Where dust or dirt may affect heat exchangers.
Where exposure to oil or to corrosive or harmful gases, such as acidic or alkaline gases, may occur.
Where exposure to salinity may occur, such as seaside locations.
Where highly flammable materials are present.
Where exposure to oily air may occur, such as a kitchen.
Where exposure to very high humidity may occur, such as a laundry.
Units should be installed in positions where:
The ceiling is horizontal and is able to bear the unit’s weight.
There are no obstructions that could impede the airflow into and out of the unit.
The airflow out of the unit can reach throughout the room.
There is sufficient space for access during installation, servicing and maintenance.
The refrigerant piping and drain piping can be easily connected to the refrigerant piping and drain piping
systems.
Short-circuit ventilation (where outlet air returns quickly to a unit’s air inlet) will not occur.
3.2 Space Requirements
Figure 3.1: High Static Pressure Duct space requirements (unit: mm)
Maintenance space
Maintenance space
checking port
600mm* 600mm
500mm or up
600mm or up
Air outlet Air inlet
Canvas tie-in Canvas tie-in
Air dust filter
checkingorifice
Isolation booth
Isolation booth

201806 11
4Piping Diagrams
Figure 4.1: piping diagram
flare nut
flare nut
T2B
gas side
motor
heat exchanger
fan
EXV
liquid side
T2
T1
Legend
T1 Indoor ambient temperature sensor
T2 Indoor heat exchanger mid-point temperature sensor
T2B Indoor heat exchanger outlet temperature sensor

12
           
5
W
Figu
r
FANA
W
iringDia
r
e5.1:
CN3
FM
Rectifier
Blue
Black
grams
DC Fan Module A
CN13
Blue
~
~+
-
TA CS
XS2 XP2
XS3 XP3
XS1XP1
T2
T2B
Red
White
T1
681
MOV
SDV5-71,80,90,112,140,160DHA Du ct wiring diagram
CN24
CN7
CN27
CN4
Display
CN6
CN30
CN5
SW5 SW4 SW3 SW2 SW1
CN20 CN11
T2
Black
Brown
 
CN24
CN15
ON/OFF
P4X
S4X
CN27
SW6 SW7
Reactor
(0502)
CN55
CN1
9
ENC1
POWER_S
Brown


1
CN8
EEV
Brown
(0502)
CN21
CN22
CN14
9
(L) CN1
CN57+
CN58 -
Black
蓝
CN17
CN9
Main Board
CN3 CN18
EARTH
(N) CN16 CN20 CN29
CN2
Y
e
G
Bl
W
Bl
PUMP SVD
PQE X1X2
e
llow
reen
ack
W
hite
ue
XT2
N
Black
Y/G
2
0
XT1
220V~50Hz
Centralized
controller
E D2 D1
L
N
Red

0
1806

To outdoor unit To wire controller

201
8
Figu
r
8
06

 
re 5.2:
SDV5-200,250, 280DHA wiring diagram
FM
FANB
CN3 CN3
FM
FANA
~
-
Rectifier 1

SDV5-200,250,2 80DHA
TA CS
XS2 XP2
XS1XP1
T2B
Red
White
CN13 CN13
黑
~
-
~+
681
DC Fan Module A
DC Fan Module B
Blue Red
 
Display
XS3 XP3
T2
Black
T1
~+
MOV
Rectifier 2
Blue Brown

CN7
CN15
ON/OFF
P4X
S4X
CN4
CN6
CN30
CN5
CN
CN20 CN11
CN24CN27
SW5 SW4 SW3 SW2 SW1
POWER_S
Brown Brown
1
CN8
EEV
55
C
N
C
N
CN14CN19
Reactor (1230)
SW6 SW7
ENC1
(L) CN1
CN17
N
21
N
22
CN9
Main Board
CN57+
CN58 -
Reacto
r
(1510)
Cap. (35uF)
Red
Black
Blue
CN3 CN18
EARTH
(L)
CN1
(N) CN16
CN20
CN2
Y
G
B
W
B
CN29 Red
PUMP
SVD
P
Q
EX1X2
Y
ellow
G
reen
B
lack
W
hite
B
lue
XT2
Black
Y/G
PUMP
SVD
XT1
220V~50Hz
Q
Centralized
controller
E D2 D1
LN
Red
Black
13

To outdoor unit To wire controller

14 201806
Caution
All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified
and accredited professionals and in accordance with all applicable legislation.
Units should be grounded in accordance with all applicable legislation. Metal and other conductive components
should be insulated in accordance with all applicable legislation.
Power supply wiring should be securely fastened at the power supply terminals –loose power supply wiring
would represent a fire risk.
After installation, servicing or maintenance, the electric control box cover should be closed. Failing to close the
electric control box cover risks fire or electric shock.
Switch ENC1 (indoor unit capacity setting) is factory-set and its setting should normally not be changed. The
only circumstances in which a switch ENC1 might need to be set in the field is when replacing a main PCB.
When replacing a main PCB, ensure that the capacity setting on switch ENC1 on the new PCB is consistent with
the unit capacity given on the unit’s nameplate.
Notes for installers and service engineers


201806 15
6Fan Performance
Figure 6.1: SDV5-71,80DHA fan performance
Figure 6.2: SDV5-90DHA fan performance
200Pa
190Pa
180Pa
170Pa
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa(default)
90Pa
80Pa
70Pa
60Pa
50Pa
30Pa
0
20
40
60
80
100
120
140
160
180
200
1150 1200 1250 1300 1350
Static pressure (Pa)
Air flow (m3/h)
200Pa
190Pa
180Pa
170Pa
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa(default)
90Pa
80Pa
70Pa
60Pa
50Pa
30Pa
0
20
40
60
80
100
120
140
160
180
200
1130 1180 1230 1280 1330 1380 1430
Static pressure (Pa)
Air flow (m3/h)
SSL
SL
L
M
H
SH
SSH
SSL
SL
L
M
H
SH
SSH

16 201806
Figure 6.3: SDV5-112DHA fan performance
Figure 6.4: SDV5-140DHA fan performance
200Pa
190Pa
180Pa
170Pa
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa(default)
90Pa
80Pa
70Pa
60Pa
50Pa
30Pa
0
20
40
60
80
100
120
140
160
180
200
1340 1390 1440 1490 1540 1590 1640 1690 1740 1790 1840 1890
Static pressure (Pa)
Air flow (m3/h)
200Pa
190Pa
180Pa
170Pa
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa(default)
90Pa
80Pa
70Pa
60Pa
50Pa
30Pa
0
20
40
60
80
100
120
140
160
180
200
1590 1640 1690 1740 1790 1840 1890 1940 1990 2040 2090 2140 2190 2240
Static pressure (Pa)
Air flow (m3/h)
SSL
SL
L
M
H
SH
SSH
SSL
SL
L
M
H
SH
SSH

201806 17
Figure 6.5: SDV5-160DHA fan performance
Figure 6.6: SDV5-200,250,280DHA fan performance
200Pa
190Pa
180Pa
170Pa
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa(default)
90Pa
80Pa
70Pa
60Pa
50Pa
30Pa
0
20
40
60
80
100
120
140
160
180
200
1870 1920 1970 2020 2070 2120 2170 2220 2270 2320 2370 2420 2470 2520 2570 2620 2670
Static pressure (Pa)
Air flow (m3/h)
80Pa
250Pa
230Pa
210Pa
200Pa
190Pa
180Pa
170Pa(default)
160Pa
150Pa
140Pa
130Pa
120Pa
110Pa
100Pa
90Pa
70Pa
60Pa
50Pa
30Pa
0
50
100
150
200
250
3720 3770 3820 3870 3920 3970 4020 4070 4120 4170 4220 4270 4320
Static pressure (Pa)
Air flow (m3/h)
SSL
SL
L
M
H
SH
SSH
SSL
SL
L
M
H
SH
SSH

18 201806
7Capacity Tables
7.1 Cooling Capacity Table
Table 7.1: High Static Pressure Duct cooling capacity
Capacity
(kW)
Outdoor air
temperature
(°C DB)
Indoor air temperature (°C WB/DB)
14/20
16/23
18/26
19/27
20/28
22/30
24/32
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
7.1
10.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.2
5.6
12.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.1
5.5
14.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
9.0
5.5
16.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.9
5.4
18.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.7
5.2
20.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.5
5.2
21.0
4.9
4.3
5.8
4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.4
5.6
8.4
5.1
23.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.3
5.6
8.3 5.0
25.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.2
5.5
8.2 5.0
27.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.2
5.5
8.2 5.0
29.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.1
5.4
8.1 5.0
31.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.0
5.4
7.8 4.8
33.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.4
8.0
5.3
7.8 4.8
35.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.5
5.3
7.7
5.1
7.7 4.8
37.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.4
5.3
7.7
5.1
7.6 4.8
39.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
42.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
44.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
46.0
4.9 4.3 5.8 4.7
6.7
5.3
7.1
5.4
7.2
5.2
7.4
5.0
7.6 4.8
8.0
10.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.4
6.3
12.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.2
6.2
14.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.2
6.1
16.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
10.0
6.0
18.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.8
5.9
20.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.6
5.8
21.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.5
6.3
9.4
5.7
23.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.4
6.3
9.4
5.7
25.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.3
6.2
9.3
5.6
27.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.2
6.2
9.2
5.7
29.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.1
6.1
9.1
5.6
31.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.0
6.1
8.8
5.4
33.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.5
6.0
9.0
6.0
8.8
5.4
35.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.4
6.0
8.6
5.8
8.6
5.4
37.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.3
5.9
8.6
5.8
8.6
5.4
39.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
42.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
44.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
46.0
5.5
4.8
6.5
5.3
7.5
5.9
8.0
6.0
8.2
5.8
8.3
5.7
8.6
5.5
Abbreviations:
TC: Total capacity
SC: Sensible capacity
Notes:
1. Shaded cells indicate rating condition.
Table continued on next page …

201806 19
Table 7.1: High Static Pressure Duct cooling capacity (continued)
Capacity
(kW)
Outdoor air
temperature
(°C DB)
Indoor air temperature (°C WB/DB)
14/20
16/23
18/26
19/27
20/28
22/30
24/32
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
9.0
10.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
11.7
7.1
12.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
11.5
7.0
14.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
11.4
6.9
16.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
11.3
6.8
18.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
11.0
6.6
20.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
10.8
6.5
21.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.7
7.1
10.6
6.4
23.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.5
7.1
10.5
6.4
25.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.4
7.0
10.4
6.3
27.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.4
6.9
10.4
6.4
29.0
6.2
5.4
7.3
6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.3
6.9
10.3
6.3
31.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.2
6.8
9.9 6.1
33.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.5
6.8
10.1
6.7
9.9 6.1
35.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.5
6.7
9.7
6.5
9.7 6.1
37.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.4
6.7
9.7
6.5
9.6 6.0
39.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.2
6.5
9.4
6.4
9.6 6.1
42.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.2
6.5
9.4
6.4
9.6 6.1
44.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.2
6.5
9.4
6.4
9.6 6.1
46.0
6.2 5.4 7.3 6.0
8.5
6.7
9.0
6.8
9.2
6.5
9.4
6.4
9.6 6.1
11.2
10.0
7.7 6.8 9.1 7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
14.6 8.8
12.0
7.7 6.8 9.1 7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
14.3 8.7
14.0
7.7 6.8 9.1 7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
14.2 8.6
16.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
14.0
8.5
18.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
13.7
8.3
20.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
13.4
8.1
21.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.3
8.8
13.2
8.0
23.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.1
8.8
13.1
7.9
25.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
13.0
8.7
13.0
7.9
27.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
12.9
8.6
12.9
7.9
29.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
12.8
8.5
12.8
7.9
31.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
12.7
8.5
12.3
7.6
33.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.9
8.5
12.5
8.4
12.3
7.6
35.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.8
8.4
12.1
8.1
12.1
7.6
37.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.6
8.3
12.1
8.1
12.0
7.5
39.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.4
8.1
11.6
7.9
12.0
7.6
42.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.4
8.1
11.6
7.9
12.0
7.6
44.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.4
8.1
11.6
7.9
12.0
7.6
46.0
7.7
6.8
9.1
7.4
10.5
8.3
11.2
8.5
11.4
8.1
11.6
7.9
12.0
7.6
Abbreviations:
TC: Total capacity
SC: Sensible capacity
Notes:
1. Shaded cells indicate rating condition.
Table continued on next page …

20 201806
Table 7.1: High Static Pressure Duct cooling capacity (continued)
Capacity
(kW)
Outdoor air
temperature
(°C DB)
Indoor air temperature (°C WB/DB)
14/20
16/23
18/26
19/27
20/28
22/30
24/32
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
TC
SC
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
14.0
10.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
18.2
11.0
12.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
17.9
10.8
14.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
17.8
10.8
16.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
17.5
10.6
18.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
17.1
10.3
20.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
16.8
10.2
21.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.7
11.0
16.5
10.0
23.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.4
11.0
16.4
9.9
25.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.2
10.9
16.2
9.8
27.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.1
10.8
16.1
9.9
29.0
9.7
8.5
11.3
9.3
13.2
10.4
14.0
10.6
14.8
10.6
16.0
10.7
16.0
9.8
31.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.8
10.6
15.8
10.6
15.4 9.5
33.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.8
10.6
15.7
10.5
15.4 9.5
35.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.7
10.5
15.1
10.1
15.1 9.5
37.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.6
10.4
15.1
10.1
15.0 9.4
39.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.3
10.2
14.6
9.9
15.0 9.5
42.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.3
10.2
14.6
9.9
15.0 9.5
44.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.3
10.2
14.6
9.9
15.0 9.5
46.0
9.7 8.5 11.3 9.3
13.2
10.4
14.0
10.6
14.3
10.2
14.6
9.9
15.0 9.5
16.0
10.0
11.0 9.7 13.0 10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
20.8 12.6
12.0
11.0 9.7 13.0 10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
20.5 12.4
14.0
11.0 9.7 13.0 10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
20.3 12.3
16.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
20.0
12.1
18.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
19.5
11.8
20.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
19.2
11.6
21.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
19.0
12.5
18.9
11.4
23.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
18.7
12.5
18.7
11.3
25.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
18.6
12.4
18.6
11.2
27.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
18.4
12.3
18.4
11.3
29.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
18.2
12.2
18.2
11.2
31.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
18.1
12.1
17.6
10.8
33.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
17.0
12.1
17.9
12.0
17.6
10.8
35.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.8
12.0
17.3
11.6
17.3
10.8
37.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.6
11.9
17.3
11.6
17.1
10.7
39.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.3
11.6
16.6
11.3
17.1
10.9
42.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.3
11.6
16.6
11.3
17.1
10.9
44.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.3
11.6
16.6
11.3
17.1
10.9
46.0
11.0
9.7
13.0
10.6
15.0
11.9
16.0
12.1
16.3
11.6
16.6
11.3
17.1
10.9
Abbreviations:
TC: Total capacity
SC: Sensible capacity
Notes:
1. Shaded cells indicate rating condition.
Table continued on next page …
