Sinclair SDV6 SCC-61 Operating manual

SCC-61
COMMERCIAL AIR CONDITIONERS SDV6
USER AND INSTALLATION MANUAL

01
CONTENTS
Safety Precautions ....................................................................02
Hardware Installation ...............................................................04
Product Description..................................................................06
1 Initial Use ....................................................................................09
● 1.1 Connection with VRF System .................................................09
● 1.2 Language Selection upon Initial Power-on .............................09
● 1.3 Login .......................................................................................10
● 1.4 Search (Topology) ..................................................................11
● 1.5 Modification of Device Name ..................................................13
● 1.6 Group Function Examples ......................................................15
● 1.7 Control Device ........................................................................21
● 1.8 Schedule Function Examples .................................................23
2 Function Description............................................................32
● 2.1 Homepage ..............................................................................32
● 2.2 Group and Device Management.............................................32
● 2.3 Device Monitoring ...................................................................44
● 2.4 Schedule Management...........................................................58
● 2.5 Reports ...................................................................................67
● 2.6 Setting.....................................................................................87

02
Icon description
Safety Precautions
The Installation & Owner's Manual of this product describes how to properly handle the product,
prevent personal injury and property losses, as well as how to use the product correctly and safely.
Read the following carefully, make sure you understand the content (symbols and marks), and
observe the precautions below.
Read the safety warnings carefully prior to installation.
Be sure to observe the important safety precautions provided below.
Meanings of labels:
After the installation is completed, confirm that no errors occur during the trial run, and hand
over the manual to the customer for safekeeping.
Indicates that improper handling may lead to personal injury or material loss.
Indicates that the operations will be affected due to ignoring a precaution.
Warning
Caution
Prohibited. Information about what is specifically prohibited is provided using graphs
or texts in the icon or nearby.
Ask your local dealer or professionals to install the product.
Installation personnel must have relevant professional knowledge.
Incorrect installation by non-professionals may lead to a fire, electric
shock, or injury.
Mandatory. A specific mandatory requirement is provided using graphs or texts in the
icon or nearby.
Commissioned
Installation
Do not directly spray combustible paints on the touch screen
centralized controller as this may cause a fire.
Do not handle the product with wet hands, and do not let water seep
into the device. Otherwise, an electric shock may occur.
Prohibited
Prohibited
Icon
Warning
of Use
Warning
Description
CAUTION

03
WARNING
CAUTION
This unit must be installed by professional technicians. Users are not allowed to install the unit
themselves; otherwise, personal injury or damage to the controller may occur.
Other electrical wiring work must be carried out by a professional technician according to the
circuit diagram. All wiring work must comply with electrical safety specifications.
It is forbidden to modify the use and function of the product without authorization.
● Do not install the product in places that are prone to flammable gas leaks. Flammable gas
that leaks and lingers around the touch screen centralized controller may cause a fire.
● Do not install the touch screen centralized controller in base stations and other places
where there is strong electromagnetic interference, where dust and other tiny particles can
easily gather, and locations that are wet or easily exposed to water and sunlight;
otherwise, the touch screen may perform poorly or stop working.
● Install the touch screen centralized controller indoors, with the distance between the
installation place and the ground of more than 50cm and less than 200cm.
● Keep the touch screen centralized controller away from other devices to ensure that there
is enough space for installation and heat dissipation. Keep away from heating devices;
otherwise, the touch screen centralized controller may not function properly.
● In the event of any malfunction, please contact a professional technician. DO NOT
disassemble or repair the unit without authorization.
This equipment is not suitable for places where children gather.

04
Hardware Installation
1 × Manual 6 × 5-port terminal with gap of 3.81mm
1 × SCC-61
Packing List
1 × 3-port terminal with gap of 5.08mm
1 × Mounting board 6 × Plastic expansion nails
8 × Plastic washers (Ø 4mm hole) 6 × GB/T950 M4*20 screws (short)
1 × Embedded junction box 4 × GB/T823 M5*25 screws (long)
Statement:
Along with upgrades in the product, the information in this document is subject to
change without notice.
Important information
Product serial No.: you can find the serial number on the back of the product.
Statement:
Along with upgrades in the product, the information in this document is subject to
change without notice.
Important information
Product serial No.: you can find the serial number on the back of the product.

05
Touch screen SCC-61 structure
1) Touch screen SCC-61: Front and side views
2) Structural dimensions of the embedded junction box
(Unit: mm)
267
170.8
③
③
3) Installation procedures
60
 ①
SCC-61
 ②
Metal parts
 ③
junction box
Embedded
 ④
Screws
Wall
Wall
Wall
Wall
Wall
Wall
③
②①
④
276
187
32
9.5
(Unit: mm) Before you drill an opening in the wall, make sure that the opening is large
enough to fit in the embedded junction box.
Attention: The controller is only suitable for installation at a height of ≤ 2m.

06
Note: In actual projects, an RS-485 bus may fail to be connected to 8 refrigerant systems or
64 IDUs in full. One SCC-61 may fail to be connected to 48 refrigerant systems or 384 IDUs
in full.
Example 1: 0# refrigerant system has 20 IDUs, 1# refrigerant system has 30 IDUs, and 2#
refrigerant system has 14 IDUs. As the 3 refrigerant systems have a total of 64 IDUs, the
RS-485 bus cannot be connected to additional systems (now there are less than 8 refrigerant
systems);
Example 2: The 8 refrigerant systems have a total of 40 IDUs (5 each for refrigerant systems
0# to 7#). The RS-485 bus cannot be connected to additional systems because it has been
connected to 8 refrigerant systems (now there are less than 64 IDUs).
Note: The addresses of the 8 refrigerant systems under an RS-485 bus must be different.
1 2 3
1. Mount the embedded 2. Install metal parts 3. Install SCC-61
junction box Make sure the hooks of the metal Once the connections are
Mount the embedded junction box parts face upwards. Use 4 screws ④ done, place the main unit
within the wall. Ensure that the provided as accessories to secure it vertically on the installation
outer surface ③ of the embedded on the installation base. base. You will feel a magnetic
junction box is level with the wall force at this point. Exert force
NOTE
surface. downwards to mount it on the
Special note: Make sure you exert
metal part.
appropriate force to secure the metal
parts with the screws. Excessive force
may cause deformation of the four
screw holes for the metal parts,
making it harder to mount the metal
mounting board.
Product Description
SCC-61 touch screen centralized controller [hereinafter referred to as "centralized controller"]
provides centralized management functions for VRF units.
It is compatible with all SDV6 series units, that is, SDV6 ODUs and SDV6 IDUs.
The product supports 6 RS-485 buses, and each RS-485 bus can be connected to up to 8
SDV6 refrigerant systems (8 refrigerant systems can have a maximum of 64 IDUs), that is, a
centralized controller can be connected to a maximum of 48 refrigerant systems (48 refrigerant
systems can have a maximum of 384 IDUs).

07
Note: There may not be a PQE interface between an IDU and an ODU. For details, refer to the
manual of ODU and IDU. This is only used to illustrate the centralized controller framework.
Touch screen centralized controller
Power
adapter
Power
supply
Router
ODUODUODU ODU
IDUIDUIDUIDU
Note: The dotted
line part is not
randomly marked.
LAN
24V ACIN
COM 1~6
R C
X
P Q E
Y E
P Q E P Q E
X
P Q E
Y E X
P Q E
P Q E
Y E X
P Q E
P Q E
Y E
Client PC
Access to the touch
screen is centralized
controller through Web
E XY
1 2 3 4 5 6
XY XY XY XY XY E E
One port supports up to
eight refrigerant systems
or up to 64 IDUs.
LAN USB
X6 Y6
Y5
X2
X1 DI1 DI2 NC NC
DO2
DO1 NCAI2
AI1
!
Caution
The SCC-61 is installed at one end of the M-net communication bus. Do not install it in
the middle of the bus.
You need a three-core shielded cable of 0.7~1.0 mm2 for the signalling wires.
For details, please consult a professional technician.
The controller is only suitable for installation at a height of ≤2m.

08
Port Function
Power interface, 24V AC, 1 A
RC
Note: 24V AC for RC, positive and negative poles not
differentiated
X1 Y1 E is the 1st RS-485 bus, X2 Y2 E is the 2nd RS-485
bus, X3 Y3 E is the 3rd RS-485 bus, X4 Y4 E is the 4th
X1 Y1 E X2 Y2
RS-485 bus, X5 Y5 E is the 5th RS-485 bus, and X6 Y6 E is
X3 Y3 E X4 Y4
the sixth RS-485 bus.
X5 Y5 E X6 Y6
Each RS-485 bus interface can be connected to eight SDV6
refrigerant systems (up to 64 IDUs).
Note: Two RS-485 buses share one E port.
Note: The X port and Y port of the centralized controller are
connected to the X port and Y port of the ODU, respectively.
When multiple refrigerant systems are connected, they need
to use different addresses.
DI1 is a reserved interface, and DI2 is an emergency stop
DI1, DI2
interface. For more info about the emergency stop function,
go to "Settings" > "Advanced settings".
DO1, DO2
Reserved
AI1, AI2
Reserved
Provides Web functions, and the Web implements functions
similar to those on the touch screen.
When a computer accesses the centralized controller through
LAN
the Web, it is necessary to ensure that the computer and the
centralized controller are on the same network segment.
Note: Some functions are only available on the touch screen,
not on the Web.
USB 2.0 port: connected to a USB disk in FAT32 format, and
USB
used for some functions of the centralized controller. (such as
upgrading the centralized controller firmware)
Power Supply
Specifications
Voltage
Power
consumption
24V AC, 1A, 50/60Hz
Max. 24W
Operation
Conditions
Voltage
fluctuations Rated value+/-10%
Operating ambient
temperature
Storage
temperature
Operating
ambient humidity
Dimensions Unit (mm)
Weight
-10°C~+50°C
-20°C~+60°C
RH25%~RH90%
276(W)*187(H)*32(D)
0.76 kg

09
Before using the unit for the first time, read the following content carefully and operate and set the
centralized controller according to the prompts, so that you can fully understand how to use the
basic functions of the centralized controller and correctly configure related settings.
The centralized controller has six RS-485 bus interfaces (X1/Y1/E, X2/Y2/E, X3/Y3/E, X4/Y4/E,
X5/Y5/E, X6/Y6/E). Each RS-485 bus interface can be connected to eight refrigerant systems (up to
64 IDUs). When multiple refrigerant systems are connected to one RS-485 bus interface, connect the
X port of the master ODU of multiple refrigerant systems in series and connect it to the X port of the
centralized controller; connect the Y port of the master ODU of multiple refrigerant systems in series
and connect it to the Y port of the centralized controller; then connect the E port of the master ODU
of multiple refrigerant systems in series and connect it to the E port of the centralized controller.
After the connection between the VRF unit and the centralized controller is completed (X/Y/E wiring)
and the VRF unit is operating normally, turn on the power of the centralized controller to enter the
software debugging mode.
1 Initial Use
1.1 Connection with VRF System
1.2 Language Selection upon Initial Power-on
* The functions supported by the centralized controller (including function details) will be
increased with product updates. Due to the update cycle and other reasons, some function
details in the manual may be inconsistent with the actual product, such as interface
screenshots, display parameter names, etc., and the actual product shall prevail.

10
1.3 Login
When the centralized controller is powered on for the first time, select the display language of the
centralized controller.
After selecting the language here, you can re-select the interface display language of the
centralized controller through the language option in "Settings".
Select the language and enter the login interface as follows:
Debugging account: admin; debugging password: 123456
Enter the account number and password, and click "Login" to log in to the centralized controller.
*The languages supported by the centralized controller may increase with the product update.
The screenshots in the manual are only for function description, and the actual product shall
prevail.
*You may directly enter the login interface of individual centralized controllers due to factory
random inspection. You can re-select the interface language of the centralized controller
through the language option in "Settings".

11
1.4 Search (Topology)
A device search is required to display the refrigerant systems connected to the centralized controller.
Entry of the Settings interface (upper right corner)
Overview of device status: power-on, power-off,
disconnection, and failure, and statistics on the number of
devices; the list diagram shows general parameters.
Device monitoring: view device status (card form, list form),
managed groups, managed devices, control devices, etc.
Schedule management: View, edit, and modify schedules.
Report export
* The centralized controller must meet the requirements for the following two periods of time before
conducting "Device search"
Time 1: Time taken to wait for the VRF refrigerant system to run properly (about 15 minutes,
depending on the actual refrigerant system).
When the refrigerant system is powered on, system detection will take some time. During
this period, the centralized controller may obtain incorrect information about the refrigerant
system. If you conduct "Device search" at this moment, the information about the
refrigerant system obtained by the centralized controller will be incorrect (model
identification failure, improper set temperature range, and insufficient VRF units, etc.).
Time 2: time of communication between the centralized controller and VRFs (depending on the
number of connected refrigerant systems, about 5 minutes).
It takes more than 5 minutes for the centralized controller to connect with the properly
running VRF system. If you conduct a "Device search" before this, the information about
the refrigerant system obtained by the centralized controller will be abnormal (model
identification failure, improper set temperature range, and insufficient VRF units, etc.).
Steps: Power on the centralized controller 15 minutes after the communication cables are
connected and the VRF system is powered on. Wait 5 minutes, and search for the device.

12
Click the "Setting" function icon in the upper right corner to enter the "Setting" interface, as
shown in the figure below:
Click "Device search" in the left menu and "Auto topology" in the right area. The centralized controller
will start to obtain information about the refrigerant system connected to the centralized controller and
automatically construct the topological relationship. After this, the interface will appear as follows:
Refri. system Refrigerant system address, automatically generated after search, unmodifiable
Device address, automatically generated after search, unmodifiable
IDU: 00-63, ODU: 96-99 (master unit 96, slave units 1-3 correspond
to 97-99, respectively)
Device type (IDU or ODU), automatically generated after search, unmodifiable
Power of IDU fan, modifiable
Power of IDU auxiliary heater, modifiable
Device name in the centralized controller, modifiable
The following names are displayed by default:
IDU: "IDU_Port_System_IDU Address"
ODU: "ODU_Port_System_ODU Address"
Device model code, automatically generated after search, unmodifiable
For details about the mapping between models and codes, see "Model
Information" in the appendix.
Parameter Remarks
Unit address
Unit type
Model
Unit name
Fan(W)
EH(W)

13
1.5 Modification of Device Name
The following chapters will use examples to describe how to use
SCC-61 to manage devices.
The device name can be modified in two ways.
Mode 1: Modify the device name on the "Device search" interface.
In the "Setting" - "Device search" interface, directly click the cell with a device name that needs to
be modified in the "Unit Name" column, enter the name to be modified, and click in the upper
right corner to save the modified information.
Mode 2: Modify the unit name on the "Device monitoring" interface.
1. Click to enter device monitoring, and click "Device".
Click the parameter information to be modified ("Unit name", "Fan(W)", "EH(W)"), and finally click
to save.
* Causes for the failure of the centralized controller to locate the device.
1. The preconditions of SCC-61 and the "Precautions" at the beginning of this chapter are not met.
Solution: Re-power on the SCC-61 centralized controller. After the preconditions are met, search
for the device again.
2. During power-on of SCC-61, the system address, IDU address and other information of the
refrigerant system have been modified.
Solution: Re-power on the SCC-61 centralized controller. Wait 5 minutes and search for the
device again.
For other matters, please consult relevant technical support personnel.

14
2. Select the device you want to modify, click .
3. Enter a name in the pop-up box, such as "Test name", and click "Save".
4. Click "Save".

15
1.6 Group Function Examples
1.6.1 Creating a group
5. The device name has been modified.
The centralized controller supports level-3 groups, through which the devices can be managed
conveniently. In the example, the groups are divided according to their physical locations.
Connect the centralized controller to all the refrigerant systems in Buildings A and B.
In the following example, the IDU name has been modified based on the requirements in the
above table. For modification of the device name, refer to "1.5 Modifying a device name".
Click "Group" to enter the group function interface:
A
B
A-1
A-1
A-2
A-2
A-101
A-102
A-201
A-202
A101
A102
A201
A202
B-1 B-101 B101
B-2 B-202 B202
Building Name Floor Name Room Name IDU Name

16
Create a level-1 group.
Click "Add group" in the first column to create a level-1 group: A, B
Create a level-2 group.
Select "A" and click "Add group" in the second column to create level-2 groups of A: A-1 and A-2.
In the pop-up interface, enter the level-1 group name A, click "Save", repeat the above steps,
and create B.

17
Create a level-3 group.
Select "A", click "A-1", and click "Add group" in the third column to create level-3 groups of A:
A-101 and A-102.
Follow the same steps to create a level-2 group of B: B-1.

18
The group is now created.
Click "OK" to submit all group information.
Follow the same steps to create other level-3 groups.
Note: Before clicking "OK", no operations will be saved. If you do not click "OK" but click the X in
the upper right corner, all changes will be lost.

19
Note: Immediately after the centralized controller is debugged, all IDUs are in "Ungroup".
Click , and select the target group to be moved in the group information that slides
out on the right.
1.6.2 Adding a device to a group
Enter the "Device" interface.
Select the IDU to be removed from the group.
Select the desired group to accept the air conditioner.
