Singer STI-1730-CRBB User manual

STI-1730-CRBB
Steam iron
Σίδερο ατμού
Парна ютия
GB INSTRUCTION MANUAL
GR ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
BG ИНСТРУКЦИИ ЗА ЕКСПЛОАТАЦИЯ

GB ENGLISH......................................................... 3
GR EΛΛΗΝΙΚΑ .................................................... 10
BG БЪЛГАРСКИ ................................................. 17

3
ENGLISH
For safety purposes please read these instructions carefully
before using the appliance for the first time. Save these
instructions for future reference.
IMPORTANT
• Ensure the voltage on the rating plate is the same as that in
your home
• The iron should always be turned off before plugging or
unplugging from the wall socket
• Never yank the cord to disconnect from the wall socket;
instead, hold the plug and pull to disconnect.
• Never use the appliance if damaged in anyway.
• When leaving, even when only for a short while, always
unplug the iron.
• Close supervision is necessary for any appliance being
used by or near children.
• Do not leave the iron unattended while connected or on an
ironing board
• Burns can occur from touching hot metal parts, hot water
or steam.
• Use caution when you turn a steam iron upside down –
there may be hot water in the reservoir.
• Never immerse the iron in water.
• Always place the iron with its back on a firm flat surface
when interrupting ironing and after use.
• Keep the sole plate smooth; avoid hard contact with metal
objects.
• The cord should not be allowed to touch the sole plate
when it is hot.
• Prevent water overflow, do not fill over max level.

4
ENGLISH
• When using the iron for the first time test on an old piece of
fabric to ensure the soleplate and water tank are completely
clean.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• The iron must be used and rested on a stable surface.
• When placing the iron on its stand, ensure that the surface
on which the stand is placed is stable.
• The iron is not to be used if it has been dropped, if there are
visible signs of damage or if it is leaking.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
HOUSEHOLD USE ONLY
SERVICE & REPAIR
1. For service or repair under warranty, please contact the authorized service
company that is mentioned on the guarantee card that accompanies the
product.
2. Do not operate any product with a damaged cord or plug. If the supply cord is
damaged, return the appliance to a SINGER service center for examination
repair or adjustment. Do not attempt to dismantle any part of the appliance.
This should only be done at an authorized SINGER service centre.

5
ENGLISH
3. The partial or total non-respect of the safety instructions in the present
instruction manual will automatically release Singer of any type of
responsibility in case of malfunction of the machine or injuries to persons
or animals.
4. In case of manipulation, repairing or any modification of the machine made
by unqualified persons or in case of improper use, the guarantee will be
automatically cancelled.
PARTS DESCRIPTION
A: Soleplate
B: Water Tank
C: Water Spray Nozzle
D: Water Fill Cover
E: Steam Knob
F: Water Spray & Burst of Steam Buttons
G: Cord Guard
H: Temperature Dial
I: Self-Clean Button
A
C
D
E
F
B
G
H
I

6
ENGLISH
FILLING WITH WATER
• Ensure the iron is disconnected from the power supply.
• Set the steam knob to the minimum position.
• Pull down the water fill cover and fill the water tank with water.
SETTING THE TEMPERATURE
• * Synthetics/Silk
• ** Wool
• *** Cotton/Linen
– Stand the iron upright.
– Set temperature dial to ironing temperature.
– Insert the mains plug into the main supply.
– After the indicator light has gone out and come again, you may start ironing.
The indicator light will go out from time to time during ironing.
STEAM-IRONING
This function can be used only at higher ironing temperature.
●● for moderate steam
●●● or MAX for maximum steam
– Fill water into the iron as described above.
– Stand the iron upright.
– Connect the iron to a suitable mains supply outlet
– Turn the temperature control dial to the “●●”, “●●●”or MAX setting
– The pilot light turns off when the required temperature is reached. The iron
is ready for use.
– Turn the steam control knob to the required position, steam starts coming
out from the holes in the sole plate.
Note: With conventional steam irons, water may leak from the soleplate if a
too low temperature has been select. If this happens, turn the temperature
control dial to the advised position. Steam will recommence as soon as the
appropriate temperature has been reached.

7
ENGLISH
BURST OF STEAM
• Set the temperature dial at the “●●●” or MAX position, then press down the
burst steam button.
• The soleplate will spray out bursting steam.
• To prevent water leaking from the soleplate, do not keep the burst steam
button pressed for more than 5 seconds.
SPRAY SETTING
Ensure that there is enough water in the water tank. By pressing the spray
button a couple of times at any temperature, the laundry can be damped down
to make them softer and easier to iron.
DRY IRONING
Turn the steam knob to the minimum position (=no steam) and set the
temperature dial to the suitable position.
SELF-CLEANING
It is important to apply “self-cleaning” often to remove impurities etc. The
harder the water the more the iron should be self-cleaned.
• Open the fill cover and fill the water tank with water up to the MAX position,
then close the fill cover.
• Set the temperature dial to MAX.
• Insert the mains plug into the wall socket.
• Allow the iron to heat up until the pilot light goes out. Then set temperature
dial to position MIN.
• Hold the iron horizontally over the sink, then press the self-clean button
enabling the iron to self clean.
• Boiling water and steam will be ejected from the holes in the soleplate.
Impurities are washed away with it. Move the iron forwards and backwards
while this happens.
• Set the steam control to “0” position when the water tank has emptied.
• Repeat self-cleaning if you notice that impurities haven’t been washed out.
• Move the iron over a (preferably) old piece of cloth. This is to ensure that
the soleplate will be dry during storage.
• Unplug and allow the iron to cool down before storing it.

8
ENGLISH
ANTI-DRIP
The appliance is equipped with a drip stop function; the iron will stop steaming
automatically when the temperature is too low to prevent water from dripping
out of the soleplate.
ANTI-CALC
The Anti-calc function filters the minerals from the water to prevent mineral
residue build up at the steam chamber and prolongs the operational life of the
iron.
STORAGE
• Remove the mains plug from the wall socket.
• Pour out any remaining water left in the water tank.
• Set the steam knob to “0” or minimum steam position.
• Stand the iron upright and let it cool down completely.
CLEANING
• Before cleaning the iron ensure it is disconnected from the power supply
and has completely cooled down.
• Deposits on the soleplate may be removed with a cloth soaked in a vinegar/
water solution.
• The casting may be wiped with a damp cloth and then polished with a dry
one.
• Do not use abrasives on the soleplate.
• Keep the soleplate smooth. Avoid hard contact with metal objects.

9
ENGLISH
Disposal of old Electrical & Electronic Equipment (Applicable in
the European Union and other European countries with separate
collection systems).
This symbol on the product or on its packaging indicates that this
product shall not be treated as household waste. Instead it shall be
handed over to the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the envi-
ronment and human health, which could otherwise be caused by inappropriate
waste handling ofthis product. The recycling of materials will help to conserve
natural resources. For more detailedinformation about recycling of this prod-
uct, please contact your local city office, your householdwaste disposal service
or the shop where you purchased the product.

10
ΕΛΛΗΝΙΚΑ
Για λόγους ασφαλείας, πριν χρησιμοποιήσετε τη συσκευή για
πρώτη φορά, θα πρέπει να διαβάσετε τις ακόλουθες οδηγίες.
Φυλάξτε το βιβλίο οδηγιών χρήσης για τυχόν μελλοντική ανα-
φορά.
ΣΗΜΑΝΤΙΚΕΣ ΟΔΗΓΙΕΣ ΑΣΦΑΛΕΙΑΣ
• Ελέγξτε ότι ηισχύς που υποδεικνύεται στη βάση της συ-
σκευής συμφωνεί με την τάση της κεντρικής παροχής στο
σπίτι σας.
• Το σίδερο θα πρέπει να είναι κλειστό (δηλαδή οδιακόπτης
στη θέση off) πριν βάλετε ήβγάλετε το φις από την πρίζα.
• Ποτέ μην τραβάτε το καλώδιο για να το αποσυνδέσετε από
την πρίζα. Αποσυνδέστε τη συσκευή τραβώντας πάντα το φις
από την πρίζα.
• Ποτέ μη χρησιμοποιείτε τη συσκευή αν έχει παρουσιάσει
οποιαδήποτε βλάβη.
• Πάντα να αποσυνδέετε τη συσκευή από το ρεύμα όταν απο-
μακρύνεστε από αυτή.
• Ηεπίβλεψη της συσκευής είναι απαραίτητη όταν χρησιμοποι-
είται από ήκοντά σε παιδιά.
• Ποτέ μην αφήνετε τη συσκευή χωρίς επίβλεψη όταν είναι
συνδεδεμένη στην παροχή ρεύματος ήεπάνω στη σιδερώ-
στρα.
• Μην ακουμπάτε τις ζεστές επιφάνειες της συσκευής. Υπάρ-
χει κίνδυνος εγκαυμάτων από τον ατμό, το ζεστό νερό και τα
ζεστά μεταλλικά σημεία.
• Δίνετε ιδιαίτερη προσοχή όταν σιδερώνετε κάθετα καθώς
ενδέχεται να υπάρχει καυτό νερό στο ρεζερβουάρ.
• Ποτέ μη βυθίζετε το σίδερο μέσα στο νερό ήάλλο υγρό.
• Μετά τη χρήση ήκατά τη διακοπή σιδερώματος, πάντα να
τοποθετείτε το σίδερο σε όρθια θέση και σε σταθερή και επί-
πεδη επιφάνεια.
