Sirius Satellite Radio SV1 SIRIUS One Manual

SV1 SIRIUS One
SIRIUS Satellite Radio Plug and Play
User and Installation Guide

SV1 Receiver User and Installation Guide
2
CONGRATULATIONS! Your new SV1 SIRIUS One SIRIUS®Satellite Radio Plug and Play Receiver lets you
enjoy SIRIUS Satellite Radio’s digital entertainment in your vehicle, home, or boat. Use this guide to
familiarize yourself with all of SV1’s features and capabilities. For the latest information about this and other
SIRIUS products, please visit http://www.siriusradio.com.
Table of Contents
Safety Precautions ........................................................... 4
FCC Warning .................................................................... 5
Cleaning the Receiver ....................................................... 5
Package Contents ............................................................ 6
Installation ....................................................................... 7
Location ....................................................................... 7
Mounting the Receiver ................................................. 7
Installing the Magnetic Antenna .................................. 8
Connecting the Receiver ............................................ 10
Activating your SIRIUS Subscription .......................... 11
SV1 SIRIUS One Receiver Basic Operation .............. 13
Remote Control .......................................................... 14
Installing Batteries in the Remote ........................... 14
Changing Channels .................................................... 15
Display Button (DISP) ............................................... 15
Selecting Channels Directly ...................................... 16
Advanced Features ...................................................... 17
Channel Presets (BAND) ........................................... 17
Storing Channel Presets ......................................... 17
Using Channel Presets ........................................... 17
Searching for a Channel Preset (P.TUNE Mode) ....... 18
FM Preset Button ...................................................... 18
Menu Options ................................................................ 19
FM Transmitter .......................................................... 20
FM Presets ............................................................. 20
FM On/Off ............................................................... 21
Display Options ......................................................... 21
Parental Control ......................................................... 22
Lock/Unlock ............................................................ 22
Edit Code ................................................................ 23

SV1 Receiver User and Installation Guide 3
Table of Contents (continued)
©2005 SIRIUS Satellite Radio Inc.
® “SIRIUS,” the SIRIUS dog logo, channel names and logos
are trademarks of SIRIUS Satellite Radio Inc. “NFL” and the
NFL Shield logo, and the NFL Sunday Drive name and logo
are registered trademarks of the National Football League.
“NHL” and the NHL Shield are registered trademarks of the
National Hockey League. “NBA” and the NBA silhouette logo
are registered trademarks of NBA Properties Inc. Velcro is a
registered trademark of Velcro Industries B.V. All other
trademarks, service marks and logos are the property of their
respective owners. All Rights Reserved.
Audio Level ................................................................. 25
Signal Indicator .......................................................... 25
Factory Default .......................................................... 26
Troubleshooting ............................................................... 28
Specifications .................................................................. 29
12 MONTH LIMITED WARRANTY .................................. 30

SV1 Receiver User and Installation Guide
4
• If the LCD display on the Receiver becomes
damaged or broken, do not touch the liquid crystal
fluid. The fluid can be dangerous to your health. If
the liquid crystal fluid contacts your body or
clothing, immediately wash it off with soap and
water.
Caution
Take the following precautions to keep the Receiver
in proper working order:
• Do not open the Receiver.
• When replacing a fuse, use only a new one with
the proper rating. Using a fuse with the wrong
rating may cause the Receiver to malfunction.
• To prevent a short circuit when replacing a fuse,
first disconnect the wiring harness.
Note:
If the Receiver doesn’t seem to be working properly,
turn the Receiver’s power off, wait 5 – 10 seconds,
then turn the power on again.
Safety Precautions
Warning
Take the following precautions to prevent fire and
avoid personal injury:
• Be sure the Receiver is installed as described in
the Installation Guide.
• The use suggestions contained in this User Guide
are subject to any restrictions or limitations that
may be imposed by applicable law—the purchaser
should check applicable law for any restrictions or
limitations before installing and/or operating this
Receiver.
• Failure to follow these safety instructions and
warnings may result in a serious accident.
• To avoid short circuits, never put or leave any
metallic objects (coins, tools, etc.) inside the
Receiver.
• If the Receiver emits smoke or unusual odors, turn
the power off immediately.
• Do not drop the Receiver, or subject it to strong
shocks.

SV1 Receiver User and Installation Guide 5
FCC Warning
This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless
the modifications are expressly approved in this
User Guide. The user could lose the authority to
operate this equipment if an unauthorized change or
modification is made.
Note:
This equipment has been tested and found to
comply with Part 15 of the FCC Rules. These
rules are designed to provide reasonable
protection against harmful interference. This
equipment may cause harmful interference to
radio communications if it is not installed and
used in accordance with these instructions.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one of
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the other
equipment and the Receiver.
• Connect the other equipment to a different circuit
from that to which the Receiver is connected.
• Consult the dealer or an experienced radio
technician for help.
Warning
Do not operate the Receiver in a way that might
divert your attention from driving safely. As a driver,
you alone are responsible for safely operating your
vehicle in accordance with traffic safety laws at all
times.
Cleaning the Receiver
If the Receiver becomes dirty, turn its power off and
wipe it clean with a soft dry cloth. Do not use hard
cloths, paint thinner, alcohol, or other volatile
solvents to clean the Receiver. These may cause
damage to the plastic or remove indicator
characters.

SV1 Receiver User and Installation Guide
6
Package Contents
SurfacePreparation
CleaningKit
(To clean a surface of any
known / unknown emulsions
prior to applying adhesives.)
SV1 SIRIUS One
Receiver
Magnetic Antenna
SIRIUS One
Remote Control
Rubber Antenna
Cable Cover/Tail
& Adhesive Strip
Alcohol Swab and
Velcro®Strips
Suction Cup Mount
Visor/Dash Mount
Cigarette Lighter
Power Cord
User Guide
The following items are packaged with the SV1 SIRIUS One. Check the package to be all of the items are
included. If any of the items are missing, please contact the retailer where you purchased the product.
UserandInstallationGuide
SV1SIRIUSOne
SIRIUSSatelliteRadio PlugandPlay
1
4
7
2
5
8
BAND DISP
MUTE CH
SEL
CH
MENU
CAT CAT
0
3
6
9
BAND DISP
1 2 3 4 5

SV1 Receiver User and Installation Guide 7
Installation
Installation of your SV1 SIRIUS One is easy:
1. Choose a location in your vehicle where you will
mount the Receiver, either on the visor, the
dash, or the windshield.
2. Mount the Receiver on the visor using the visor/
dash mount, or on the dash using the visor/dash
mount and the velcro strips, or on the
windshield using the suction cup mount.
4. Install the magnetic antenna on the roof of the
vehicle, and route the antenna cable to the
Receiver.
4. Connect the power cord for the Receiver to your
vehicle’s cigarette lighter.
5. Subscribe to the SIRIUS service and begin
enjoying the SIRIUS entertainment!
Location
Choose a location in your vehicle where the
Receiver will not block your vision, interfere with the
vehicle controls, or obstruct the air bag. If you are
using the suction cup mount, the location should be
suitable for using the suction cup mount, such as
the windshield or other flat, smooth surface.
The location should be easily reachable and provide
good visibility of the Receiver.
Mounting the Receiver
Attach the desired mounting device, suction cup
mount or visor/dash mount, to the to the Receiver by
sliding the flat portion of the mount into slot on the
top edge of the Receiver. Gently slide the mounting
device in until it snaps into place.
S
N
A
P
S
N
A
P

SV1 Receiver User and Installation Guide
8
Depending upon your mounting choice, clip the
Receiver to the visor, or, use the velcro strips to
mount the Receiver to the dash, or, if you are using
the suction cup mount, lightly moisten the surface of
the suction cups which face the windshield (or other
surface) and press the suction cups to the mounting
surface.
Installing the Magnetic Antenna
The optimum mounting location for the antenna is
on the roof of the vehicle, with a minimum
unobstructed area of 12 inches by 12 inches, and
exactly 6½ inches from the rear roof edge of the
vehicle (the length of the rubber antenna cable
cover/tail). It is important to avoid any obstructions
that will block the SIRIUS signal, obstructions such
as a roof rack, a sunroof, roof mounted cargo
containers, or other antennas.
The following illustrations show the recommended
mounting locations of the antenna for several types
of vehicles. Follow these recommendations for best
performance from the antenna.
Sedan/Coupe : Mount the antenna along the rear
centerline of the vehicle roof, located at the rear of
the roof near the rear window.
SUV/Mini-Van: Mount the antenna along the rear
centerline of the vehicle roof, located at the rear of
the roof near the rear door/hatch.
Pickup Truck : Mount the antenna along the rear
centerline of the cab roof, located at the rear of the
roof near the rear window.

SV1 Receiver User and Installation Guide 9
Convertible :Mount the antenna along the centerline
of the trunk lid, with the rubber antenna cable cover/
tail directed toward the rear window.
Clean the area where the antenna and rubber
antenna cable cover/tail will be mounted with the
supplied alcohol swab.
Connect the rubber antenna cable cover/tail to the
antenna cable, making sure that the strain-relief on
the antenna seats into the rubber antenna cable
cover/tail groove. Route the antenna cable through
the wire channel in the rubber antenna cable cover/
tail. Do not yet attach the adhesive strip.
Temporarily position the antenna and rubber
antenna cable cover/tail in the selected mounting
area and route the cable from the antenna to the
vehicle’s interior by tucking it underneath the rubber
molding around rear window, as shown.
Route the cable from the lowest point of the rear
window into the trunk. Take advantage of any
existing cable channels or wiring conduits. For
SUVs, mini-vans & 5-door vehicles, bring the cable
into the vehicle under the rubber molding for the
tailgate, and continue under the interior trim.
From the trunk, or rear of the vehicle, route the cable
around the passenger compartment and to the front
of the vehicle, to the receiver. Take care not pull the
cable across sharp edges that could damage it, and
keep it away from areas where it might entangle
feet. Coil any excess antenna cable in a location
where it can be hidden.
Once the antenna cable is routed through the
vehicle, and you are satisfied with the cable routing,

SV1 Receiver User and Installation Guide
10
peel the yellow protective material from the
adhesive strip and adhere the adhesive strip to the
rubber antenna cover/tail. Next peel the red
protective material from the adhesive strip and
press the rubber antenna cable cover/tail firmly into
place on the vehicle.
Double check that the location of the antenna and
rubber antenna cable cover/tail are correct, and
continue to press firmly down on rubber antenna
cable cover/tail for another 30 seconds.
Note: At room temperature (68 degrees), maximum
adhesion usually occurs within 72 hours. During this
period, avoid car washes and other contact with the
antenna and rubber antenna cable cover/tail.
Connecting the Receiver
Connect the antenna and cigarette lighter power
adapter to the Receiver to complete the installation.
The illustration below shows the location of the
antenna and power connectors on the Receiver.
Plug the cigarette lighter power adapter cord into
your vehicle’s cigarette lighter, and turn the Receiver
On by pressing the power button. Once you have
verified that Receiver has powered on, you can
RUBBER ANTENNA
CABLE COVER/TAIL
VEHICLE
MOUNTING SURFACE
RUBBER ANTENNA
CABLE COVER/TAIL
ADHESIVE
STRIP
ANTENNA
CABLE
ANTENNA
(UNDERSIDE)
PROTECTIVE MATERIAL
(RED SIDE)

SV1 Receiver User and Installation Guide 11
proceed with activating your SIRIUS subscription.
Activating your SIRIUS Subscription
Before you can listen to the SIRIUS service, you
need to subscribe to the SIRIUS Satellite Radio
service.
1. Be sure that the Receiver is correctly installed
and that the antenna is oriented to receive the
SIRIUS signal.
2. Press the power button to turn Receiver On.
After displaying the SIRIUS logo, the Receiver
will update the SIRIUS channel line up. The
display will show, “UPDATING CHANNELS” and
show the status of the update.
HCDP %U X Xs
Wait until the channel updates have completed
before pressing any buttons on the Receiver.
3. Once the channels have been updated, the
display will change to “Call 1-888-539-SIRIUS to
Subscribe” and will place you in SIRIUS Satellite
Radio’s Preview Channel, channel 184.
You will not be able to tune to any other
channels until you activate your SIRIUS
subscription.
1l 8a 8 5C 8 -l-
4. To listen to the audio from your Receiver, you will
need to tune the FM radio in your vehicle and the
FM transmitter in the Receiver to the same FM
frequency. The FM transmitter in the Receiver
defaults to 88.1 MHz, so you can begin by tuning
your FM radio to 88.1 MHz. If there is an FM station
broadcasting on that frequency, you will have to
ANT FM OUTAUDIO OUT DC IN
ANTENNA FM
OUT
AUDIO
OUT
DC
IN

SV1 Receiver User and Installation Guide
12
search for a quiet frequency to use. Refer to the
section titled, FM Transmitter in this User Manual
for instructions on how to tune the FM transmitter
to other FM frequencies.
5. Using the channel up and down buttons, tune
the Receiver to channel 000 to display the
Receiver’s unique 12-digit SIRIUS ID Number
(SID). You can also tune to channel 000 by
using the remote: Press the Select button, then
the 0 (zero) button, and then the Select button
again. (This SID number is also available on the
SV1 packaging.) Write the SID number down in
the space provided at the end of this manual.
332 41 5 61 5 624
6. Have your credit card handy and contact SIRIUS
on the Internet at:
https://activate.siriusradio.com/
and follow the prompts to activate your
subscription. You can also call SIRIUS toll-free
at:
1-888-539-SIRIUS (1-888-539-7474)
7. When you have successfully subscribed to the
SIRIUS service, and the Receiver has been
updated with your subscription information, an
alert will be displayed.
USDPU B
To continue, press any key on the Receiver.
The installation of your Receiver is now complete,
and you are ready to begin enjoying SIRIUS Satellite
Radio’s digital entertainment!

SV1 Receiver User and Installation Guide 13
SV1 SIRIUS One Receiver Basic Operation
3
4
7
6
5
BAND DISP
1 2 3 4 5
18
9
2
1. POWER Button : Turns the Receiver’s power
On and Off.
2. Channel Up/Down Buttons: Navigates through
channels and display screens.
3. BAND Button (P.Tune): Pressing and releasing
switches between the five preset banks (A, B, C, D
and E), which hold five presets each. Pressing and
holding enables “Preset Tune Mode”, which allows
for viewing and listening of stored presets with the
channel up/down buttons.
4. Preset Number Buttons (1-5): Sets and selects
preset channels. Also used to directly tune
channels by entering the channel number.
5. DISP (Display) Button: Toggles display between
the channel number and name, channel number
and category, channel number and artist name,
and channel number and song title. Holding the
DISP button down flips the display screen 180
degrees to enable mounting the Receiver upside
down on a vehicle visor.
6. Category Previous/Next Buttons: Navigates
through the category (genre) list screen which
displays SIRIUS channel categories.
7. Select Button: Selects items displayed on the
screen.
8. FM Preset Button: Selects between preset FM
frequencies used for the built-in wireless
transmitter.
9. Mounting Release Button: This button releases
the mount which is connected to the Receiver.

SV1 Receiver User and Installation Guide
14
Remote Control
1. Power Button : Turns the Receiver power On and
Off.
2. Number Buttons (0-9): Used for directly selecting
channels and for presets.
3. BAND Button: Switches between preset bands A , B,
C, D, and E.
4. MUTE Button: Mutes the audio.
5. Category Previous/Next Buttons: Navigates through
categories (genres).
6. Channel Up/Down Buttons: Navigates through
channels and display screens.
7. Select Button: Selects items on the display screen.
8. MENU Button: Used to access menu options to make
setup and feature changes.
9. DISP Button: Toggles display between the channel
number and name, channel number and category,
channel number and artist name, and channel number
and song title. Holding the DISP button down flips the
display screen 180 degrees to enable mounting the
Receiver upside down on a vehicle visor.
10. FM Preset Button: Selects between preset FM
frequencies used for the built-in wireless transmitter.
Installing Batteries in the Remote
1. Remove the battery cover.
2. Install CR2032 battery. (+ positive side is up)
3. Replace the battery cover.
1
4
7
2
5
8
BAND DISP
MUTE CH
SEL
CH
MENU
CAT CAT
0
3
6
9
1
3
2
6
4
5
10
9
7
8
5

SV1 Receiver User and Installation Guide 15
Pressing the category previous or next button will
cause the Receiver to display a listing of the
previous or next channel category.
Use the channel up/down buttons to display a
channel within a category and press the select
button to tune to the channel. When a new channel
is selected, the display will revert to the default
display screen for the new channel.
Display Button (DISP)
Momentarily pressing and releasing the DISP
(Display) button while the default screen is
displayed causes the Receiver to sequence the
display between the channel number and channel
name, channel number and category name, channel
number and artist name, and channel number and
song title.
After you have successfully activated your SIRIUS
subscription, and the Receiver has received the
subscription information from the SIRIUS signal, the
default display screen will be displayed.
rP4 v8 i1 e we
When the Receiver is powered On, the previously
selected channel will automatically begin playing,
and the channel name of the current channel will be
displayed.
Changing Channels
Pressing the channel up or down button will cause
the Receiver to immediately tune to the next or
previous channel.
Pressing the category previous or next button will
cause the receiver to display a list of the channels in
the current category. Use the channel up and down
buttons to navigate through the list.
51POP []

SV1 Receiver User and Installation Guide
16
lC4 V1 i l0 n ys
oR4 k10 c
lA4 c1 e o0 Ci
cS4 o1 o s0 l 'h
Note: If you are viewing a sports category channel
list (NFL®, NBA®, NHL®, or College), pressing and
releasing the DISP button will instead toggle
between the team names and the current score of
any live play-by-play game.
Use the category previous and next buttons to scroll
through the music and entertainment categories,
and the channel up and down buttons to scroll
through the available channels in each category to
find the channel to which you want to listen.
When you have found the channel you wish to listen
to, press the select button to tune to the channel.
The new channel will begin playing and the display
will revert to the default display screen for the new
channel.
Pressing and holding the DISP button for 1 second
will cause the Receiver to flip the display screen 180
degrees to enable mounting the Receiver upside
down on a vehicle visor.
Selecting Channels Directly
A channel may be directly selected by entering the
channel number using 0-9 buttons on the remote
control.
To enter a channel number, momentarily press and
release the select button. At the display prompt,
enter the three digit channel number.
:# _H _C _

SV1 Receiver User and Installation Guide 17
Advanced Features
Channel Presets (BAND)
You can store up to 30 of your favorite channels as
presets for quick recall access. The preset channels
are stored in 5 bands, A, B, C, D, E, and F each
containing 5 channel presets, and are numbered 1
to 5. The 5 channel presets in each band are
accessed by pressing the appropriate number (1 to
5) on the Receiver. A momentary press and release
of the BAND button cycles through the 5 preset
bands (A, B, C, D, E, and F).
Storing Channel Presets
To store a favorite channel as a preset, do the
following:
1. Momentarily press and release the BAND
button until the desired preset band, A, B, C, D,
E, or F, is displayed.
2. Tune the Receiver to the channel you wish to
store as a preset. (See the section, Basic
Operation for specific instructions for tuning to a
channel.)
3. Press and hold for 1 second the numbered
preset button in which you wish to store your
favorite channel. The band and preset number
will then be displayed to confirm that the
channel has been stored.
1A4 S1 a d0 v e
Note: If the preset button already has a channel
stored in it, the preset will be replaced by the newly
stored channel.
Using Channel Presets
Press and release the BAND button to cycle
between the preset bands until the preset band you
want is displayed.
The 5 preset channels in the active band can then
be selected by momentarily pressing and releasing
the 1 through 5 buttons.
When you have chosen a preset channel, the band
and preset number will be displayed.
A 1-

SV1 Receiver User and Installation Guide
18
Empty presets are not displayed.
3. To exit the P.TUNE mode, press and hold the
BAND button for approximately 1 second, until
the default display screen is displayed.
FM Preset Button
The Receiver has a special button called the FM
Preset button, which is identified by the icon.
When the FM Preset button is pressed, the
Receiver turns on the built-in FM transmitter and
begins transmitting on the next frequency from the
FM frequency preset list. A screen will be displayed
for 3 seconds showing the currently selected FM
frequency. When the FM transmitter is turned on, an
FM radio tuned to the same FM frequency will
receive the currently tuned SIRIUS broadcast.
-M 8 1F 8 .1
Each subsequent press of the FM Preset button
advances to the next preset in the FM frequency
preset list. By using the FM Preset button, a quiet
FM frequency may be quickly tuned.
Searching for a Channel Preset (P.TUNE Mode)
To quickly search through all of your presets in the
P.TUNE mode, do the following:
1. Press and hold the BAND button for
approximately 1 second to enter the P.TUNE
mode. “Preset Tuning Mode” will momentarily be
displayed and the preset number will be
displayed to indicate the Receiver is in the
Preset Tune Mode.
enT M. oP d eu
lC1 V- i lA n ys
2. Use the channel up and down buttons to move
up or down through your channel presets and
immediately tune to each channel. Channel
presets are grouped and displayed by bank and
preset number, i.e., A-1, A-2...B-1, B-2, etc.

SV1 Receiver User and Installation Guide 19
If no FM frequencies have been preset when the FM
Preset button is pressed, the Receiver will default to
a frequency of 88.1 MHz.
Pressing and holding the FM Preset button will
display the list of FM presets. Use the channel up
and down buttons to browse through the list.
-M 8 1F 8 .1
-M 9 5F 1 .2
- 1M 0 9F 3 .5
If you want to change the FM frequency of a preset,
press the select button to choose the preset when it
is displayed. Use the channel up and down buttons
to select an FM frequency and press the select
button. The preset will now display the new FM
frequency. To select the preset, press the MENU
button.
You may also change the FM presets by using the
FM Presets menu option of the Receiver. (Refer to
the FM Transmitter section in the Menu Options
section of this manual for instructions on
programming the FM presets list.)
Menu Options
To enter the Menu Options page of the Receiver,
press and hold the select button, or press the
MENU button on the remote control. The menu
options will be then displayed.
AR SM M TF I TTN
To select a menu option, use the channel up and
down buttons to display the option you wish to
adjust, and press the select button. If a selection is
not made within 10 seconds, the Receiver will exit
the menu options mode, and revert to the last active
display mode.

SV1 Receiver User and Installation Guide
20
FM Presets
To create or add to a list of FM preset frequencies,
do the following:
1. Using the channel up and down buttons, display
the “FM PRESETS” menu item and press the
select button. You will then enter a list of FM
presets. (You may also enter this list by
pressing and holding the FM Preset button.)
-M 8 1F 8 .1
2. Using the channel up and down buttons, display
the FM preset you wish to set (or change) and
press the select button. You will then enter a list
of FM frequencies, beginning with the currently
selected FM frequency for the preset.
18 H8 z.M
3. Use your FM radio to locate quiet FM
frequencies where there is no interference from
To exit menu options, or any of the other menu
option screens, repeatedly press and release the
MENU key on the remote control until you are
returned to the default display screen.
The following sections explain each of the menu
options in the order in which they are displayed on
the Menu Options screen.
FM Transmitter
The FM Transmitter feature allows you to create a
preset list of 5 suitable FM frequencies which can
then be accessed by using the FM Preset button.
This option also allows you to turn the FM
transmitter On and Off.
ER EM TF SPS
/n fM fF OO
