Sistemalux LINEAR LASER BLADE 3652 User manual

LINEAR LASER BLADE
RECESSED SOLO UNIT MODEL: 3652
INSTRUCTIONS SHEET PAGE: 1 of 2
IMPORTANT - READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL CODES, BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT, AND THE HAZARDS INVOLVED. PROPER GROUNDING IS REQUIRED FOR SAFETY.
A- MAKE CEILING CUT-OUT (SEE TABLE ON PAGE 2).
B- OPEN CONNECTION BOX LOCATED ON THE TOP OF THE FIXTURE: UNSCREW CONNECTION BOX SCREW TO SLIDE OUT CAP. SEE DETAIL 1.
C- RAISE FIXTURE TO CEILING. INSERT AND LOCK BX CABLE INTO THE BX CONNECTOR (INCLUDED). MAKE NECESSARY WIRE CONNECTIONS.
*SEE WIRING DIAGRAM.
D- CLOSE CONNECTION BOX.
E- WITH MOUNTING BRACKETS IN A NARROW POSITION, GENTLY INSERT FIXTURE INTO THE CEILING CUT-OUT.
F- SCREW MOUNTING BRACKET SCREWS CLOCKWISE TO WIDEN AND LOWER THE MOUNTING BRACKETS OVER THE CEILING. SEE DETAIL 2.
G- CONNECT LIGHTING FIXTURE USING THE QUICK CONNECTORS (INCLUDED) AND SNAP LIGHTING FIXTURE AND/OR COVER PLATE BACK
INTO THE ALUMINUM EXTRUSION.
SOLO UNIT INSTALLATION
INTEGRAL DRIVER (120 / 277V)
DIMMING TRIAC/ELV (15%), 0-10V (1% / 15%), LUTRON HI-LUME®(1% EcoSystem™ / 1% 2-WIRE)
A
E
B
C
F
F
C
BX CABLE
FOR DIMMING
(BY OTHERS)
A/C AND 0-10V CONNECTION BOX
0-10V DIMMING
CONNECTION BOX
A/C CONNECTION
BOX
BX CABLE FOR
A/C CONNECTION
(BY OTHERS)
CONNECTION
BOX CAP
CONNECTION
BOX CAP SCREW
MARRETTES WIRE
CONNECTORS
(BY OTHERS)
DETAIL 1 DETAIL 2
WIDE POSITION
MOUNTING BRACKET
NARROW POSITION
MOUNTING BRACKET
MOUNTING
BRACKET SCREW
CEILING
MIN: 1/8"
MAX: 1"
*for reference only
WIRING DIAGRAM*
FIXTURE CABLES
LIVE
(black)
NEUTRAL
(white)
GROUND
(green)
DIMMING 120V ONLY
TRIAC/ELV (LTE) or TRIAC (D3)
FIXTURE CABLES
LIVE
(black)
NEUTRAL
(white)
DIM +
(purple)
DIM -
(purple/gray)
DIMMING 120-277V
0-10V (D10 / D01) or EcoSystem™ (D2B)
GROUND
(green)
DETAIL 2
DETAIL 1
0-10V DIMMING
CONNECTION BOX
BX CABLE (BY OTHERS)
BX CONNECTOR
(INCLUDED)
CEILING CUT-OUT
A/C CONNECTION BOX
ALUMINUM EXTRUSION
MOUNTING BRACKET
*IN NARROW POSITION
QUICK CONNECTORS
(INCLUDED)
LIGHTING FIXTURE
COVER PLATE
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
INS-618 JP - R0Last update: January 14, 2019
G

LINEAR LASER BLADE
RECESSED SOLO UNIT MODEL: 3652
INSTRUCTIONS SHEET PAGE: 2 of 2
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
INS-618 JP - R0Last update: January 14, 2019
46.83"
04'
1¾"
CUT-OUT FOR LINEAR RECESSED
ALL CONFIGURATIONS
Nominal length Actual length Cut-out
1¾" x 46¾" (44mm x 1.189m)3'-11" (1.194m)
04'
1¾" x 94¾" (44mm x 2.409m)7'-11" (2.413m)
08'
SOLO UNIT 4'
94.83"
08'
SOLO UNIT 8'
RECESSED CUT-OUT DISTANCE
