SJÖBLOMS 016-5000 User manual

Ver 200320
USER MANUAL
GYNAECOLOGY EXAMINATION COLUMN TABLE
Model:
016-5000
NOTE!
The operator must read the user manual
carefully BEFORE the product is used,
to avoid unnecessary risks to the patient and operator.

Gyn column table Table of contents
SJÖBLOMS [phone] [email protected]m
TABLE OF CONTENTS
Foreword, warranty, important information
1. Function description
1.1 General description
2. Operation
2.1 Connection
2.2 Height adjustment
2.3 When the patient sits down
2.4 Backrest adjustment
2.5 Seat/Trendelenburg adjustment
2.6 Paper-roll holder
2.7 Castors
2.8 Battery backup
2.9 Leg plate
2.10 Patient handles
2.11 Legrests
2.12 Neck cushion
2.13 Knobs and handles
2.14 Seat pad and rinsing bowl
3. Maintenance and cleaning
3.1 Routine check-ups
3.2 Cleaning
3.3 Accessories
3.4 Spareparts
4. Technical specification
4.1 Dimensions
4.2 Motors and control boxes
4.3 Battery backup
4.4 Labels
5. EU-Declaration of Conformity
6. Contact details

Gyn column table Foreword, warranty, important info
SJÖBLOMS [phone] [email protected]m
FOREWORD
Welcome as the owner of a product manufactured by Sjöbloms Sjukvårdsutrustning
AB. We hope that you will be pleased and satisfied with our quality product.
If a problem should arise with this or any of our products, you are always welcome
to contact us, and our service department will assist you with the expertise needed
to solve the problem.
The user manual contains all the information needed to use, maintain and service
the product. The document is continuously updated as the products are modified.
Therefore we reserve against possible changes in the user manual.
WARRANTY
Sjöbloms provides a two-year warranty for material, design and manufacturing
defects, provided the products are not subjected to tampering or excessive wear.
For the guarantee to apply, the product must have been used in accordance with
the user manual, and the maintenance performed as specified.
IMPORTANT INFORMATION
This product is intended for professional medical use. The user manual should be
read carefully before using the product, to avoid unnecessary risks for the patient
and operator.
The user manual contains warnings where there is a risk of personal injury, which
should be noted. Improper handling can be fatal.
A warning triangle is shown where particularly important information can be found.
Warning triangle

Gyn column table Operation
SJÖBLOMS [phone] [email protected]m
1. FUNCTION DESCRIPTION
This gynaecology examination table is for professional use in health care only, for
examination of the patient.
It is designed to be a functional and user-friendly tool for the operator and patient.
Note that the product must only be used by competent health
professionals who read the user manual, for correct handling.
General description
Gynaecology table with electric adjustment of height, backrest and
seat/Trendelenburg. All-welded powder coated steel chassis. Pads covered in
artificial leather.
Legrests on a ball-joint and integral foam mounted onto rails placed alongside the
seat, onto which also accessories such as examination light may be attached.
100 mm central locking castors.

Gyn column table Operation
SJÖBLOMS [phone] [email protected]m
2. OPERATION
2.1 Connection
The plug should be connected to a grounded outlet. The product is now ready for
use.
2.2 Height adjustments
Hand control
Foot control
Ensure that no unauthorized persons are in the couch's working range.
Follow the symbols and arrows to regulate the chair. On the hand control, height
is adjusted via button line 2.

Gyn column table Operation
SJÖBLOMS [phone] [email protected]m
2.3 When the patient sits down
We recommend that the staff helps the patient down, especially elderly and
younger patients, so that they sit correctly.
1
2
Lock the castors before the patient is seated.
The patient is to be seated mid-seat leaning backwards against the backrest.
Max load 165 kg.

Gyn column table Operation
SJÖBLOMS [phone] [email protected]m
Leg plate
NOTE!
It is NOT allowed to sit on the pulled-out leg plate. The leg plate only
intended for temporary resting of the legs.

Gyn column table Operation
Backrest
SJÖBLOMS [phone] [email protected]m
2.4 Backrest adjustment
Hand control
Foot control
Ensure that no unauthorized persons are in the couch's working range.
Follow the symbols and arrows to regulate the chair. On the hand control, height is
adjusted via button line 2.

Gyn column table Operation
Trendelenburg
SJÖBLOMS [phone] [email protected]m
2.5 Adjusting Trendelenburg
Foot control
Ensure that no unauthorized persons are in the couch's working range.
Hand control
Follow the symbols and arrows to regulate the chair. On the hand control, height
is adjusted via button line 2.
Button line 4 on the hand control plus one of the foot controls activates ”Treatment
and Start position”. When the patient is seated and this function is activated, the
patient is gently transported backwards for 5 seconds, after which the
height/angle/backrest is adjuste simultaneously to the desired position.Button line 5
activates Trendelenburg. Left button lowers the chair, while simultaneously the seat
angle is raised and the backrest lowered.

Gyn column table Operation
Paper-roll holder
SJÖBLOMS [phone] [email protected]m
2.6 Paper-roll holder
1. Pull out the lock.
2. Turn the lock upwards
3. Remove the steel from the
hole on the oposite side and
place the roll onto it.
4. Place the steel in the left hole
and set the lock to its original.

Gyn column table Operation
Castors
SJÖBLOMS [phone] [email protected]m
2.7 Castors
Central locking castors are included
2.8 Battery backup
With the optional battery backup you can run the chair if the power is cut. Connects to
the back of the chair.
Unlocked
Locked

Gyn column table Operation
Leg plate
SJÖBLOMS [phone] [email protected]m
2.9 Leg plate
Dra i handtaget, den parallella kromade
stången undertill (BILD 1) tills det tar stopp
(BILD 2)
The leg plate is placed under the seat
Pull the leg plate towards you so that
the front is raised.
When pulled out completely, lift
carefully. The lock is then activated and
the leg plate is in its place.
DONE!
To push it into place again, pull the lock
and press the leg plate forward so that
it folds. Press the leg plate in under the
seat. DONE!
NOTE! The leg plate is only a support for
resting the legs temporarily, never to be
used for sitting. Damages due to mis-use
is not covered by warranty.

Gyn column table Operation
Patient handles and legrests
SJÖBLOMS [phone] [email protected]m
2.10 Patient handles
2.11 Leg rests
2.12 Neck cushion
The neck cushion may be adjusted up or down manually.
2.10 The patient handles can be adjusted along the accessory rail (arrow), and also be
completely removed from the rail when necessary.
2.11 The part onto which the leg rests is made of integral foam and may be adjusted
variously via a ball-joint. The leg rest may also be adjusted up and down and along the
rail forward/backwards. Note that the attachment that the legrest steel is placed into is
of left and right hand side design. If mounted on the wrong side, the backrest angle is
pointed backwards, not forward as on image.

Gyn column table Operation
Knobs and handles
SJÖBLOMS [phone] [email protected]m
2.13 Låsvredens funktion
A
B
The handles are tightened
clockwise and eased counter-
clockwise. If you have to turn more
than once, but you can not gain
access because of the frame being
in the way etc. as the picture two,
pull the handle down (applies to
handle A) or towards yourself
(applies to handle B), then the
tension mode is opened and you
can turn back the handle without
the achieved tension being
released. When you then release
the handle, it returns to the
operational mode, and you can
"repeat" your hold
2.14 Seat pad / rinsing bowl
The seat pad and bowl may be
removed for cleaning
Seat pad: Pull out the lock, lift the
seat plate, remove and clean.
When re-mounting the pad, lean it
as shown, så that the metal cut
glides under the steel pin. Press the
seat to activate the lock.
The rinsing bowl: Pull and lift.

Blood Sample chair Maintenance, cleaning
Routine controls, cleaning
SJÖBLOMS [phone] [email protected]m
3. MAINTENANCE AND CLEANING
3.1 Routine check-ups
Routine check-ups should be made to ensure proper functionality.
Important!
Failure to perform the following routine can cause the patient and/or operator to
be exposed to unnecessary risks and the couch may have a reduced life expectancy.
Please check all functions and parts on a regular basis.
Check the following:
Any unusual sounds.
Gas spring functions.
Castors and castor locking mechanism.
On electric tables:
Damages to electric cables.
The motor functions.
That joints and fittings are lubricated according to the lubrication chart.
3.2 Cleaning
Cleaning and disinfection of imitation leather
During normal cleaning, warm water and a mild soap solution should be used. For
full list/specification, ask us for the manufacturer’s pdf.
Chlorine
Chlorine-based solutions are not recommended as a general rule. It affects both
the environment and products negatively, even though both the concentration
level as well as post-treatment are factors. If chlorine-based solution are used
nonetheless, we recommend to wipe the artificial leather afterwards with a damp
cloth. In general, PVC handles chlorine acceptably, PU-materials doesn’t.

Gyn column table Maintenance and cleaning
Accessories, spareparts
SJÖBLOMS [phone] [email protected]m
3.3 Accessories
Art nr Item
010-5000-70 Battery backup
3.4 Spare parts
Art nr Item
BL141HA11324B-M Lifting column
CB6S654+X2009 Control box CB06
J01297 Hand control
2362102000100G4 Motor leg plate
J15591 Motor Trendelenburg
J09980 Motor backrest
00771985 Castor

Gyn column table Technical specifications
SJÖBLOMS [phone] [email protected]m
4. TECHNICAL SPECIFICATIONS
4.1 Dimensions
Length: 134 cm
Length including legplate: 174 cm
Width: 55 cm
Seat height: 55-95 cm
Max height at leg plate rim when extended and the seat angle is max out: 115 cm
Backrest length: 92 cm
Backrest angle: 10-60°
Seat plate length: 39 cm
Leg plate length x width: 31x44 cm
Trendelenburg angle: -22°
Weight: 97 kg
Lift capacity: 165 kg

Gyn column table Technical specifications
Control box
SJÖBLOMS [phone] [email protected]m
4.2 Motors and control units
The motors comply with EMC directives in accordance with standard EN 60601-1-2.
At full load, the motors can be used a maximum of 6 minutes/hour. The actuator
manufacturer guarantees at least 10 000 cycles performance.
Control units
Max. usage time 10% or 6 min/h at continuous operation. Complies with directives
in accordance with standard EN 60601-1.

Gyn column table Technical specifications
Battery backup
SJÖBLOMS [phone] [email protected]m
4.3 Battery backup
(optional)
Allmänt
General
The batteries used in the control unit are sealed lead batteries.
The included power cord should be plugged into an electrical outlet with 230 volts.
The charger will recharge the battery in less than 12 hours. The charger can safely
be connected for charging for extended periods.
If a battery is not used for a long time, it will gradually lose its stored energy. It is
therefore recommended that the batteries are recharged at least 8 hours before
usage.
Battery life
Battery life depends on several factors including the extent of discharging. If the
battery is discharged too extensively between charges the lifespan will be reduced.
Charging as often as possible is recommended.
The built-in buzzer "Charge the battery" that is built into the controller will sound
when a discharge of 50% has occurred.
The life expectancy of the batteries is about 500-1200 charge cycles.
NOTE!
When the battery is depleted, the battery should be brought to a battery
collection, if applied in your country, to conserve the environment.

Gyn column table Technical specifications
Labels
SJÖBLOMS [phone] [email protected]m
4.4 Labels
The CE label contains the date,
order number, serial number
and our contact information.
Max patient weight 165 kg.
Shows not to sit on the leg
plate
